RTA Techni Mobili RTA-3992D User manual

By
MODEL RTA-3992D
ASSEMBLY INSTRUCTIONS
Thank you for purchasing one of our products.
Please read carefully the assembly instructions before the installation.
Do not discard this manual or any of the packaging material until the unit
has been completely assembled.

P. 2 RTA-3992D P. 2
❶
x1
❷
x1
❸
x1
❹
x1
Left leg structure Left ornament panel Right ornament panel
MAIN PARTS LIST
Right leg structure
❺
x1
❻
x1
Main panel Back panel
❼
x1
❽
x2
Middle shelf Support panels
❾
x1
⓭
x1
Small accessory
holder
Large cup
holder
⓬
x1 Control holder
⓫
x1
Large cup
holder
❿
x1
Small cup
holder

MAIN PARTS LAYOUT (FOR REFERENCE):
PARTQTY SIZE / DESCRIPTION FIGURE
10
12
12
14
1
P. 3 RTA-3992D P. 3
SCREWS LIST:


4X14 MM
B
�ID
6X55 MM


6X30 MM

6X40 MM

☛This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the assembly using this
kind of hardware.
1. Screw the bolt into the
corresponding panel.
2. In the other panel, insert the
cam lock and align it so it can
properly receive the bolt, then join
both panels (the cam locks might
come pre-installed in this unit).
3. The panels might have a very
small gap which is normal; turn
the cam lock clockwise to lock the
parts together and the gap will
also close.
Cam Bolt Cam Lock
ALIGNMENT
DIRECTION

BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
P.4RTA-3992D P.4
❶Do a quick inventory to
make sure the package
contains all the parts and
hardware listed in the
assembly instructions.
❷Missing, damaged and
defective parts can be
replaced at no cost to you.
Please refer to the CONTACT
card included with the
product.
❸The replacement parts service
is limited to the continental United
States. If you reside in Hawaii,
Puerto Rico, U.S. Dependencies
or other countries, please contact
the supplier from where the unit
was purchased.
❹If during assembly you
find an issue or need
clarification, please contact
our Customer Service for
assistance. Please refer to the
CONTACT card included with
the product.
❺On each step read the
instructions and analyze the
illustrations thoroughly
before proceeding to do the
assembly.
❽Do not overtighten
or force the screws as
they might break, strip,
damage the threads of
the holes or get stuck
inside the part.
❻Make sure you understand
which hardware will be used
on each step. Using the wrong
size of screw, bolt or pin might
strip the threads or cause
damage to the part in which it
is being used.
❼To avoid misalignments,
always leave the screws
loose and tighten them until
all pieces are positioned
correctly.
❾Sometimes the laminate might cover partially or entirely
the hole on a panel. If there is no visible hole for the screw,
pass and press the tip of your finger over the area where
the hole should be located to feel the indentation, and once
found, carefully pierce the laminate to reveal the hole
underneath.
❿If the hole seems too small for the screw, first make
sure you are using the correct size of screw and that it’s
been installed in the correct hole. If the hole still appears to
be too small, carefully pierce the laminate to reveal the
hole’s actual size.

ASSEMBLY STEPS
First screw the bolts Ⓐ into the underside holes of the shelf ⑦, then align the cam
locks on one of the support panels ⑧ and assemble both panels as shown and as
explained in page 3.
STEP 1
Hardware/Tools:
🅐6x40mm
2
Pcs
P.5RTA-3992D P.5
STEP 2
Hardware/Tools:
🅒6x55mm
12
Pcs
Refer to page 3.
Use screws Ⓒ to assemble in between the left and right leg structures ① and ②:
-The shelf ⑦ and support panel ⑧ in the middle.
-The other support panel ⑧ at the front/top.
-The back panel ⑥ at the back/top.
IMPORTANT: Screw loosely, and tighten only after all the panels are in place.
YES √NO X
All the panels come with pre-
aligned insert nuts that look like
screws. Please check them first
and re-align them with screwdriver
if necessary so they can properly
receive the screws.
Pay attention to the
orientation of the holes
on panel ⑧.

P. 6 RTA-3992D P. 6
Assemble the left and right ornament panels ③ and ④ to the legs ① and ②
using screws Ⓑ from the inside as shown.
STEP 3
Hardware/Tools:
󰐗6x30mm
12
Pcs
First screw the bolts Ⓐ into the underside holes of the main panel ⑤, then align
the cam locks on the leg structures ① and ②, and assemble the main panel as
shown and as explained in page 3.
STEP 4
Hardware/Tools:
🅐6x40mm
8
Pcs
Refer to page 3.
Pay attention to the orientation of the
main panel ⑤.
(Front)

P.7RTA-3992D P.7
Use screws Ⓓ to assemble to the main panel ⑤ and from underneath, all the
holders and accessories ⑨, ⑩, ⑪, ⑫ and ⑬ on the sides of your choice and
in the configuration of your preference.
STEP 5
Hardware/Tools:
🅓4x14mm
14
Pcs
ALL DONE! Give yourself a nice pat on the back. You did a great job!
Before you start using the unit, make sure that all the screws, bolts, cam
locks, etc. are properly tightened, and read all the warnings in the next page.

AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE FOLLOWING
CARE AND MAINTENANCE WARNINGS:
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and water, then dry
with a clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as underneath the
tabletop.
•Do not seat on the unit or lean against it.
•Do not allow small children to play under or over the unit.
•The unit must be handled by at least 2 persons when moving in the same or adjacent rooms.
•Before moving the unit, make sure to secure or remove any object that is heavy or might fall off.
•When lifting the unit, use both hands and bend your knees, not your backs.
•When transporting the unit to places far away, protect and secure the unit to avoid damage in transit.
•Shall any part of the unit become defective during the warranty period, replacement parts might be
available to you at no charge. Please refer to the WARRANTY card included with the product.
•The warranty does not extend to regular wear and tear, nor the manufacturer assumes liability for
damages or consequences due to accidents, incorrect assembly, negligence, improper use, modifications,
or not heeding the above warnings.
•The warranty is limited to the continental United States. If you reside in Hawaii, Puerto Rico, U.S.
Dependencies or other countries, please contact the supplier from where the unit was purchased.
P.8RTA-3992D P.8
3.3 Lbs. (1.5 Kg)
3.3 Lbs. (1.5 Kg)
WEIGHT LIMITS
110 Lbs. (50 Kg)
3.3 Lbs. (1.5 Kg)
3.3 Lbs. (1.5 Kg)
3.3 Lbs. (1.5 Kg)
44 Lbs. (20 Kg)
