RTA Techni Mobili RTA-8407 User manual

Thank you for purchasing our product.
MODEL RTA-8407
ASSEMBLY INSTRUCTIONS
REV.FP-6606-0322-2

•Please read carefully the assembly instructions
before the installation.
•Do not discard this manual or any of the packaging
material until the unit has been completely
assembled.
•Might require two people.
P. 1 RTA-8407 P. 1
SAMPLE –DO NOT SCAN
•We have added QR Codes to some steps for your
assistance. If a QR code is provided on a step, scan
it to view the assembly video online.

P. 2 RTA-8407 P. 2
A
x1
B
x1
C
x1
E
x1
Tabletop Left back panel Left panel
Middle panel
MAIN PARTS LIST
F
x1
G
x1
H
x3
I
x3
Shelf panel Bottom panel Drawer front
panel
Drawer left
panel
D
x1
Right panel
J
x3
Drawer right
panel
K
x3
L
x3
M
x1
N
x1
Drawer back
panel
Drawer bottom
panel
Right-upper
back panel
Right-lower
back panel
MAIN PARTS LAYOUT (FOR REFERENCE):
A
C
D
E
F
G
H
J
K
LB
M
N
LIST OF HARDWARE, SCREWS AND FITTINGS
PART
QTY ITEM
124 Wooden
dowels
224
sets
Cam lock and
bolt set
312 M3.5x15
44M3x16
512 M4x38
612 Cam lock
covers
712 M5x8 (Euro)
83
sets
Drawer
sliders
93
sets
Handle with
screw
10 2Corner
bracket
11 6Glide studs
NOTE: You will need for the assembly a
screwdriver (or power drill) and mallet/hammer
(not included).
15.5"x12.8" 14.8"x13.1" 14.8"x13.5"
I

P. 3 RTA-8407 P. 3
☛This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the
assembly using this kind of hardware.
Cam Bolt
Cam Lock
1. Screw the bolt into the corresponding hole
on panel “A”.
3. Insert the cam lock on panel “B” making
sure it goes aligned to receive the bolt’s head.
4. Turn the cam lock clockwise. This will lock the
parts together and will close any gaps.
Alignment: The cross points
towards the panel “A” with the bolt.
2. Join panel “B” to panel “A”. If panel “B” comes
with the cam lock pre-installed, make sure it is
aligned to receive the bolt’s head (refer to point
3). There might be a very small gap between the
panels which is normal.
Panel “B”
Panel “B”
Panel “B”
Panel “B”

BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
❶Do aquick inventory
to make sure the package
contains all the parts and
hardware listed in the
assembly instructions.
❷Missing, damaged
and defective parts can
be replaced at no cost
to you. Please refer to
the last pages on this
manual.
❹If during assembly
you find an issue or
need clarification, please
contact our Customer
Service for assistance.
Please refer to the last
pages on this manual.
❺On each step read the
instructions and analyze
the illustrations thoroughly
before proceeding to do the
assembly.
❽Do not overtighten
or force the screws as
they might break, strip,
damage the threads of
the holes or get stuck
inside the part.
❻Make sure you
understand which
hardware will be used on
each step.Using the
wrong size of screw, bolt
or pin might strip the
threads or cause damage
to the part in which it is
being used.
❼To avoid
misalignments, always
leave the screws loose
and tighten them until
all pieces are
positioned correctly.
❾Sometimes the laminate might cover
partially or entirely the hole on apanel.If there
is no visible hole for the screw, pass and press
the tip of your finger over the area where the
hole should be located to feel the indentation,
and once found, carefully pierce the laminate to
reveal the hole underneath.
❿If the hole seems too small for the screw,
first make sure you are using the correct size of
screw and that it’s been installed in the correct
hole.If the hole still appears to be too small,
carefully pierce the laminate to reveal the
hole’s actual size.
P. 4 RTA-8407 P. 4
❸The replacement parts
service is limited to the
48 contiguous United States.
If you reside in Alaska,
Hawaii, Puerto Rico,
U.S. territories or other
countries, please contact the
supplier from where the unit
was purchased.

ASSEMBLY STEPS
Use a wooden mallet (or hammer) to install the wooden dowels 1into
the indicated holes on panels B, C, D, E, F, G, Iand J.
STEP 1
Hardware:
1
Dowels
24
Pcs
(NOT INCLUDED)
P. 5 RTA-8407 P. 5
•Use a screwdriver to install the bolts 2into the indicated holes on
panels A, C, D, Eand H. Note that on Ethe bolts are installed on both
sides.
•Use a hammer to install the glide studs 11 to the bottom of panels C,
Dand E.
C
B
(Top)
(Front)
(Front)
(Back)
STEP 2
Hardware:
2
Bolts
24
Pcs
11
Glides
6
Pcs
(NOT INCLUDED)
11
2
E
D
G
F
J
I
C
A
E
D
E
H
J
I
J
I
H
H
Bolts 2 are installed
on both sides of E
(Back)
(Front)
(Back)
(Back)
(Back)
(Front)

P. 6 RTA-8407 P. 6
(Front)
(Front)
(Back)
Grab all the sets of sliders 8 (total 12 pcs) and separate them into 2
groups according to their shape:
-The “Flat” ones will be used on the next step.
-The “L Shaped” will be used until step 15, set them aside.
STEP 3
(“Flat” Right, x3)
(Front)
(Front)
(Front)
(Front)
The “Flat” ones will
be used on step 4.
The “L-Shaped” will
be used on step 15,
set them aside.
8
8
8
8
(“Flat” Left, x3)
(“L” Right, x3)
(“L” Left, x3)
Use a screwdriver to assemble the “Flat” sliders 8 to the side panels D
and E with euro screws 7. Please note:
•The sliders attach at the front on the 4th hole
•The wheel is at the front, and faces down with 2 empty holes above it.
•The front of the sliders will be receded about 0.75” from the front
edge on the panels.
STEP 4
Hardware:
7M5x8
(Euro)
12
Pcs
8
“Flat”
sliders
3
Left
3
Right
(NOT INCLUDED)
D
4th hole from front
(Front)
2 empty holes
above the wheel
E
The front of the
sliders are receded
about 0.75” from
the front.
Scan QR Code
to view this step
8 Left 8 Right
(Back)
8
3th hole from end

P. 7 RTA-8407 P. 7
•With the help of another person, Join the side panels Cand Eto back
panel B. Make sure the surface with the cam locks face towards the
exterior.
•Insert the cam locks 2and use a screwdriver to turn them to lock the
pieces as explained in page 3.
•Position the parts built in step 5laying down as shown.
•Join panels Fand Gto the middle panel Ein their respective places.
Make sure the holes for cam locks face towards the bottom and the
grooves are located at the back.
•Insert the cam locks 2on panels Fand G, and use a screwdriver to
turn them to lock the pieces as explained in page 3.
(Top)
(Bottom)
(Front)
(Top)
(Front)
(Back)
STEP 5
Hardware:
2
Cam lock
4
Pcs
(NOT INCLUDED)
STEP 6
Hardware:
2
Cam lock
4
Pcs
(NOT INCLUDED)
E
C
G
F
Cam locks
alignment
on F, G
E
BCam locks
alignment on B
(The sliders on E
are located on the
other side)
(Top)
(Bottom)
(Front)
(Front)

P. 8 RTA-8407 P. 8
Slide the right-lower-back panel Nthrough the grooves of panels Fand
Gand into the groove of E.
•With the help of another person, bring the unit built in step 8upright.
•Slide the right-upper-back panel Mthought the grooves of panels D
and Eand into the groove of panel F.
STEP 7
STEP 9
F
N
D
M
G
E
STEP 8
Hardware:
2
Cam lock
4
Pcs
(NOT INCLUDED)
Join the right panel Dto panels Fand G, insert the cam locks 2and use
a screwdriver to lock them as explained in page 3.
E
F
G
D
F
Cam locks
alignment
on F, G
(Front)

P. 9 RTA-8407 P. 9
(Front)
(Back)
A
C
•With the help of another person, place the tabletop Aover the unit.
•Insert the cam locks 2in panels C, Dand Eand use a screwdriver to
turn them to lock the pieces as explained in page 3.
STEP 10
Hardware:
2
Cam lock
6
Pcs
(NOT INCLUDED)
Cam locks
alignment
on C, D, E
E
D
For each of the 3 drawers,
use a screwdriver to
assemble the side panels
I and Jto the front panel
H with cam locks 2as
explained in page 3.
For each of the 3 drawers, slide the bottom
panel L through the grooves of the side
panels and into the front panel as shown.
STEP 11
Hardware:
2
Cam lock
6
Pcs
(NOT INCLUDED)
J
I
H
STEP 12
Cam locks
alignment
on I and J
J
I
H
L

P. 1 0 RTA-8407 P. 1 0
I
For each of the 3 drawers,
use a screwdriver to
assemble the back panel
K to the side panels I and
J with screws 5.
STEP 13
Hardware:
5
M4x38
12
Pcs
(NOT INCLUDED)
J
I
•For each of the 3
drawers, use a
screwdriver to
assemble the handle 9
to front panel H with its
own screw.
•Cover the cam locks
with 6.
H
9
For each of the 3 drawers, flip upside-down and use a screwdriver to
assemble the “L” shaped sliders 8 with screws 3, making sure the wheel
goes towards the back, and that they don’t protrude, otherwise, the
drawer raises 1” and won’t fit in the cabinet.
STEP 15
Hardware:
3
M3.5x15
12
Pcs
8
“L shape”
Sliders
3
left
3
right
(NOT INCLUDED)
(Front)
(Back)
When finished, the sliders
should look like this from the
back of the drawer:
The assembly below is
incorrect, it raises 1” and the
drawer won’t fit:
STEP 14
Hardware:
6Cam lock
cover
6
Pcs
9Handle
with
screw
3
sets
(NOT INCLUDED)
Scan QR Code
to view this step
6
8 Left
8 Right
K
(Top)J

P. 11 RTA-8407 P. 11
Use a screwdriver to attach the corner brackets 10 to the back of the unit
on its right side with screws 4as shown.
(Front)
(Back)
STEP 16
Hardware:
4
M3x16
4
Pcs
10 Corner
bracket
2
Pcs
(NOT INCLUDED)
STEP 17
Hardware:
6Cam lock
cover
6
Pcs
10
M
C
6
4
•Cover the cam locks with 6on panels C, Dand E.
•Insert the drawers into the cabinet, first the bottom one, then the
middle, then the top one. Insert at an angle with their fronts facing
down, making sure the wheels from the drawer slide in the middle of
the sliders inside the cabinet.
•If the top drawer doesn’t fit, and/or there is a gap at the bottom, and/or
the top drawer hits the top panel, make sure the drawers are sliding
through the cabinet sliders, not on top of them. Also review the
assembly done in steps 4and 15 for the correct assembly of the
sliders.
D
E

ALL DONE!
Give yourself a nice pat on the back. You did a
great job!
P. 1 2 RTA-8407 P. 1 2

WEIGHT LIMITS
P. 1 3 RTA-8407 P. 1 3
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and
water, then dry with a clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as
underneath the tabletop.
•Do not sit on the unit or lean against it.
•Do not allow small children to play under or over the unit.
•Do not allow small children to reach inside the drawers or compartment without your
supervision.
•Do not pull, push or drag the unit to move it for more than 1 feet. The unit must be lifted by
at least 2 persons when moving in the same or adjacent rooms.
•Before moving the unit, make sure to secure or remove any object that is heavy or might
fall off. Please note that lifting from the tabletop with too much weight on the product might
lead to part damage/separation.
•When lifting the unit, use both hands and bend your knees, not your backs.
•When transporting the unit to places far away, protect and secure the unit to avoid damage
in transit.
•Shall any part of the unit become defective during the warranty period, replacement parts
might be available to you at no charge. Please refer to the last pages on this manual.
•The warranty does not extend to regular wear and tear, nor the manufacturer assumes
liability for damages or consequences due to accidents, incorrect assembly, negligence,
improper use, modifications, or not heeding the above warnings.
CARE, MAINTENANCE AND SAFETY WARNINGS:
11 Lbs.
(5 Kg)
88 Lbs.
(40 Kg)
20 Lbs.
(9 Kg)

RTA Products, LLC warrants to the Original Purchaser who acquired a new product from RTA
Products or its authorized resellers that this product will be free from defects in its
workmanship and materials, under normal use and service conditions, as described herein.
"Defects" as used in this warranty, is defined as any imperfections that impair the use of the
furniture or product. RTA Products LLC will replace any defective part, at its discretion, and
without charge to the original purchaser other than the freight from the end consumer to RTA
Products.
Replacement parts can only be supplied if parts are available. Items out of production may be
unavailable. This warranty will be effective for the applicable time period beginning the date
of purchase on your original sales receipt. RTA product’s obligation under this warranty is
limited to repairing or replacing products or parts as provided herein. This product has been
designed for and is intended for office and home-office use only. This warranty is Original
Purchaser’s sole remedy for product defects, and this warranty does not extend to any
product, or damage to any product, caused by or attributed to abuse or misuse, products
used for commercial or rental purposes, use modifications of, or attachments to the product,
and products or parts not used, maintained, or extended hereunder is in lieu of any and all
other warranties, express or implied, including without limitations any implied warranty or
merchantability or of fitness for a particular purpose. Please note, all desks made with PVC
Laminate surface should not be exposed to direct sunlight, as it may damage the material.
Damage of this nature is not covered under this warranty.
RTA Products will not be responsible for indirect, special, incidental or consequential
damages. This warranty is limited to merchandise purchased in the Continental United
States, excludes AK, HI and PR. Some States do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitations or exclusions may not apply to
you. This warranty gives you specific legal rights. You may also have other rights that may
vary from state to state.
RTA Products will advise you of the procedure to follow in making warranty claims. The
following are the procedures for warranty claims:
a. Call us Monday –Friday, from 9am-5pm (Eastern Time) at [phone] to explain the
defect and give your name, address and phone number. Please have ready the model
number of our product, date and place of purchase. You can also write to us by e-mail
to [e-mail] and include the same information.
b. If we determine that replacement will remedy the situation, and in order to determine the
extent or the cause of the defect, purchaser will need to send the part in question at
purchaser’s expense. Once we receive the part, we will examine it and determine
whether the claim is valid (or not), and then proceed to send the replacement. We will
ship the replacement at our expense.
P. 1 4 RTA-8407 P. 1 4
TECHNI MOBILI DESK WARRANTY
DESKS/LAPTOP CARTS/FILE CABINETS: LIMITED 5-YEAR WARRANTY

FOR SEVERAL HELP OPTIONS
INCLUDING REPLACEMENT PARTS ORDERS
_________________________________________________________________
VISIT: WWW.TECHNIMOBILI.COM
CLICK ON SUPPORT TAB
Scan QR Code to order replacement parts
OR EMAIL US: [e-mail]
