RTA NAPOLES MLV 4449 User manual

NAPOLES
WALL CABINET
Mueble superior kit
lavaplatos Napoles
Alto: 49 cm
Ancho: 100 cm
Fondo: 32.05 cm
Height: 19,3 in
Width: 39,3 in
Depth: 12,6 in
LOT N°
ASSEMBLY INSTRUCTIONS
INSTRUCCIONES DE ENSAMBLE
IF ANY PARTS ARE BROKEN OR
MISSING PLEASE CONTACT US
AT: 1-888-391-01-66 /
[e-mail]
OUR CUSTOMER SERVICE TEAM WILL PROVIDE
YOU HELP TO RESOLVE ANY ISSUES IMMEDIATELY

!
WARNING
!
Page 2
IMPORTANT
RECOMMENDATIONS RECOMENDACIONES IMPORTANTES
No pintar el mueble.
Limpiar los herrajes metálicos con un paño seco.
NO sobrecargar el mueble (ver las cargas sugeridas).
No golpear ni martillar el mueble (solo cuando se
indique).
Limpiar con un paño ligeramente húmedo,
usar jabones suaves.
No arrastre el mueble, levántelo entre dos personas.
Evite el contacto directo con el agua, el fuego o la
exposición a fuentes de calor.
Do not paint the cabinet.
The cabinet MUST be used exclusively indoors,
do not expose to direct sun.
Clean metallic hardware with a dry cloth.
Do NOT overload the cabinet (see suggested loads).
Do not hit or hammer the cabinet (just when
indicated).
Clean with a slightly damp cloth, use gentle soaps.
Do not drag, lift and move between two people.
Avoid direct contact with water, fire or exposure
to heat sources.
Never allow children to climb or manipulate
the cabinet, furniture tip over can cause
serious injuries or death.
ADVERTENCIA
!
Nunca permita que los niños escalen o
manipulen el mueble, la caída de este
puede provocar lesiones graves o la muerte.

REQUIRED TOOLS* HERRAMIENTAS NECESARIAS*
Page 3
*Not included, and not shown actual size. *No incluidas y no se muestran en tamaño real.
INDEX ÍNDICE
Assembly Hardware
Assembly Parts
Suggested Loads
Assembly Recommendations
Assembly Steps
Warranty
4
5
6
6
7-12
13
Herrajes para Armado
Piezas de Armado
Cargas Sugeridas
Recomendaciones de Ensamble
Pasos de Armado
Garantía
4
5
6
6
7-12
13

x4
Minifix Cams
Minifix
ASSEMBLY HARDWARE HERRAJES PARA ARMADO
Page 4
Please check that the hardware content is correct.
If any item is missing, please call to our customer
service line.
Hardware items are NOT shown actual size. Los herrajes no se muestran en el tamaño real.
Compruebe que el contenido de los herrajes sea
el correcto. En caso de que falte alguna pieza, por
favor llame a nuestra línea de atención al cliente.
Spreading Bolt
Perno Minifix
x4 x15
Wood Dowel
Tarugo
Cover Caps
Tapa Adhesiva
Minifix
x10
Full Overlay Hinge
Bisagra Parche
x4
Drywall Screw +
Wall Anchor
Chazo Mariposa
+ Tornillo Ensamble
x3
x2
Handle
(Screws Included)
Manija
(Incluye tornillos)
x2
2" Drywall
Screw
Tornillo de
Ensamble 2"

ASSEMBLY PARTS PIEZAS DE ARMADO
Page 5
A
B
C
F
E
GHD
A - x1
B - x1
C - x1
D - x1
E - x1
F - x1
G - x1
H - x1

MAX SUGGESTED LOADS CARGAS MÁXIMAS SUGERIDAS
ASSEMBLY
RECOMMENDATIONS RECOMENDACIONES DE ENSAMBLE
Page 6
Two people are recommended to assemble
the product.
Assemble the cabinet on a flat, smooth
surface, preferably on a carpeted floor
or the carton box of the product.
Carefully read the assembly instructions
and identify every wood and hardware
part before start assemblying the cabinet.
Ensamble el mueble entre dos personas.
Ensamble el mueble sobre una superficie
plana y lisa, preferiblemente sobre un
tapete o el cartón de la caja
Lea cuidadosamente las instrucciones e
identifique todas las piezas y herrajes
antes de empezar a armar el mueble.
10kg
22lb

1
Page 7
2
A
B
x2
Arrow
!
Do NOT tighten the
cams in this step.
NO apriete las cajas
minifix en este paso.
x2

Page 8
3
4
D
x2
C
x2

Page 9
5
6
A
E
E
Drywall
screw 2"

Page 10
7
8
A
B
C
D
E
Turn minifix cams to
the right to tighten.
Gire las cajas minifix
hacia la derecha para
apretar las piezas.
x4
G
H

Page 11
9
C
D
A
G
BH
Door Installation
Instalación de las Puertas
Side adjustment
Ajuste lateral
Height adjustment
Ajuste de altura
Depht adjustment
Ajuste de profundidad
Hinge adjustment
Ajuste de las bisagras
45 3
2
1
2"

Page 12
10
After you finish the adjustment
of the cams, cover them with
the cover caps.
Después de ajustar todas las
cajas minifix, cúbralas con las
tapas adhesivas.
After you finish assembling the
cabinet, take off the adhesive
letters.
Al terminar de armar, desprenda
las letras adhesivas.
A
180 cm
suggested height
F
-Drill / Taladro
Broca de -Wall Drill /
muro de 5/16"
32 cm 32 cm
E
F
Herramienta No incluida
Tool Not included
Wall Installation
Instalación a pared
70,86"
Finished wall / Pared terminada
Floor / Piso
12,6" 12,6"
2"1/2

Page 13
IF ANY PARTS ARE BROKEN OR
MISSING PLEASE CONTACT US
AT: 1-888-391-01-66 /
[e-mail]
OUR CUSTOMER SERVICE TEAM WILL PROVIDE
YOU HELP TO RESOLVE ANY ISSUES IMMEDIATELY
Furniture has a 3 year warranty coverage in wooden parts and 1 year warranty coverage
in hardware pieces since its manufacturing date, which you can see in the lot number
printed on the product box and the assembly instructions leaflet.
Warranty covers materials and workmanship imperfections which impair the assembly
or correct functioning of the cabinet.
This warranty is not valid if the defects or imperfections are caused by the incorrect
following of the assembly instructions, warnings and recommendations, misuse,
intentional damage, fire or flood, or after modifications or any kind of alteration, or
repaired by someone not authorized, when it´s been assembled 3 months after the date
of purchase. These defects MUST be reported before the warranty coverage period ends.
Once the product has been assembled, the company will not be responsible for
defective and/or damaged parts.
This warranty is ONLY valid for the ORIGINAL PURCHASER, it doesn’t apply if the
product has been resold, rented, etc.
Furniture will take no liability for incidental or consequential damages caused to or by
the product (This may not apply in your state).
To make this warranty valid you must write to our customer service email describing the
product defect, lot number and submitting your sales reciept or proof of purchase, or
contact us at our customer service line. Replaced parts will be under the product´s
original warranty coverage period. Damaged parts will become property of the
company.
There are no other warranties applicable to this product.
