RTA Techni Mobili RTA-325 User manual

B06 190924
Thanks for purchasing one of our products.
Please read carefully the assembly instructions before the installation.
Do not discard this manual or any of the packaging material until the unit
has been completely assembled.

P.2P.2
RTA-325

P.3P.3
RTA-325

P.4P.4
RTA-325

P.5P.5
RTA-325
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
•Do a quick inventory to make sure the product contains all the parts and hardware.
•Missing, damaged and defective parts can be replaced at no cost to you. Please refer to the CONTACT card
included with the product.
•The replacement parts service is limited to the continental United States. If you reside in Hawaii, Puerto
Rico, U.S. Dependencies or other countries, please contact the supplier from where the unit was purchased.
•If during assembly you find an issue or need clarification, please contact our Customer Service for
assistance. Please refer to the CONTACT card included with the product.
•On each step read the instructions and analyze the illustrations thoroughly before proceeding to do the
assembly.
•Make sure you understand which hardware will be used on each step. Using the wrong size of screw, bolt or
pin might strip the threads or cause damage to the part in which it is being used.
•To avoid misalignments, always leave the screws loose and tighten them until all pieces are positioned
correctly.
•Do not overtighten or force the screws as they might break, strip, damage the threads of the holes or get
stuck inside the part.
•Sometimes the laminate might cover partially or entirely the hole on a panel, but the hole should still be
located under the laminate.
•If there is no visible hole for the screw, pass and press the tip of your finger over the area where the hole
should be located to feel the indentation, and once found, carefully pierce the laminate to reveal the hole
underneath.
•If the hole seems too small for the screw, first make sure you are using the correct size of screw and that it’s
been installed in the correct hole. If the hole still appears to be too small, carefully pierce the laminate to
reveal the hole’s actual size.

P.6P.6
RTA-325
FRONT
FRONT
FRONT
FRONT
BOTTOM
TOP
TOP
BOTTOM
PLEASE REFER TO PAGE 4
PLEASE REFER TO PAGE 4
Screw the Bolts (B) to the corresponding holes on the inside face of
the Cabinet Top Panel (11), then assemble it to the panels (7 & 8)
by turning all the corresponding cam locks as shown.
(Panels from step 2 shown
here with front facing UP)

P.7P.7
RTA-325
FRONT
FRONT
TOP
TOP
FRONT
PLEASE REFER TO PAGE 4
(Parts from step 5 shown
here upside-down)

P.8P.8
RTA-325
FRONT
TOP
LEFT

P.9P.9
RTA-325
FRONT
LEFT
PLEASE REFER TO PAGE 4
(View from behind the unit)

P.10P.10
RTA-325
(Normal view)

P.11P.11
RTA-325
FRONT
PLEASE REFER TO PAGE 4

Left
Right
4X35 MM
P.12P.12
RTA-325
FRONT
FRONT
PLEASE REFER TO PAGE 4
INCORRECT! Will raise 1"
more and drawer won't fit
CORRECT

4X35 MM
P.13P.13
RTA-325
INCORRECT! Will raise 1"
more and drawer won't fit
CORRECT

P.14P.14
RTA-325
DONE! Before you start using the unit, make sure that all the screws, bolts, cam locks, etc.
are properly tightened, and read all the warnings in the next page.
ENJOY YOUR NEW UNIT!

P.15P.15
RTA-325
AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE FOLLOWING
CARE AND MAINTENANCE WARNINGS:
WEIGHT LIMITS
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and water, then dry with a
clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as underneath the tabletop.
•Do not seat on the unit or lean against it.
•Do not allow small children to play under or over the unit, or inside the CPU cabinet.
•Do not allow small children to reach inside the drawers or CPU cabinet without your supervision.
•The unit must be handled by at least 2 persons when moving in the same or adjacent rooms.
•Before moving the unit, make sure to remove any object that is heavy or might fall off. Please note that lifting
from the tabletop with too much weight on the product might lead to part damage/separation.
•When lifting the unit, use both hands and bend your knees, not your backs.
•When transporting the unit to places far away, protect and secure the unit to avoid damage in transit.
•The glass is made of safety tempered glass. The safety feature is that when breakage occurs, the glass
shatters into many tiny pieces minimizing the risk of serious injuries. If the glass breaks, do not handle the
pieces with your bare hands, take some pictures and contact Customer Service immediately. Please refer to
the Contact Us card.
•Shall any part of the unit become defective during the warranty period, replacement parts might be available
to you at no charge. Please refer to the WARRANTY card included with the product.
•The warranty does not extend to regular wear and tear, nor the manufacturer assumes liability for damages
or consequences due to accidents, incorrect assembly, negligence, improper use, modifications, or not
heeding the above warnings.
•The warranty is limited to the continental United States. If you reside in Hawaii, Puerto Rico, U.S.
Dependencies or other countries, please contact the supplier from where the unit was purchased.
