RTA TECHNI MOBILI RTA-913D User manual

REV.NTL-6-7438-0823
HOME OFFICE WORKSTATION WITH STORAGE
MODEL RTA-913D
ASSEMBLY INSTRUCTIONS
Thank you for purchasing our product
Scan QR to view full
assembly video
VIDEO

1
x1 2
x1 3
x1
4
x1
Tabletop (main panel) Left side panel Back-left panel
(Front)
(Bottom)
(Back)
Middle panel 5
x1 6
x1
7
x1 8
x2
Right-lower panel Right side panel
Top front panel Drawer front panel 9
x2
10
x2 11
x2 12
x2
Drawer right panel
Drawer left panel Drawer back panel Drawer bottom
board 13
x1
Back-right board
P.1 P.1
RTA-913D
MAIN PARTS LIST
Replacement Parts for International
Customers & AK-HI-PR orders:
RTA Products will replace the part free of
charge, while the customer is responsible
for shipping costs plus any International
local taxes or duties.
Do a quick inventory
of all the parts and
hardware listed below.
For Support, assembly questions
& Replacement Parts within the
48 Contiguous United States:
Please email us at:
[email protected]
(Front)
(Back)
(Bottom)
(Left)
(Right)
(Right Side)
(Back)
(Left Side)
(Back)
(Right Side)

RTA-913D
P.2 P.2
MAIN PARTS LAYOUT (For reference)
HARDWARE LIST
TOOLS REQUIRED BUT NOT INCLUDED
PART QTY SIZE ITEM
C
D
E
F
M6x30
Wooden dowel
(x2)
(Front)
(Back)
(Right)
(Left)
B
A
25
16
16
8
8
4
4
M5x31
Bolt
M12x9
Cam lock
M6x10
Euro screw
M3.5x40
M3.5x25
PART QTY SIZE ITEM
I
J
Hammer
Phillips Screwdriver or power
drill with Phillips drill bit
K
L
M4x12
M3x12
G
16
12
40
6
2
15mm plastic
adhesive cover
M4x23
Nails
12x12x6mm
Glide stud
128mm Handle
M
1Touch-up
H
N
415x15x40mm
Angle bracket
O
2
Sets 13.75" Drawer
metal sliders,
Set of 4 pcs
RIGHT
LEFT
RIGHT
LEFT
"FLAT": 2 pcs per set,
go inside the cabinet
"L shape": 2 pcs per
set, go on the drawers
Or Pencil
(Front)
(Back)
(Left)
(Right)

P.3 P.3
RTA-913D
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
M6
30mm
M6x30
• Make sure you understand which
hardware will be used on each step. Using
the wrong size of screw, bolt or pin might
strip the threads or cause damage to the
part in which it is being used.
• To avoid misalignments, always leave the screws
loosely and do not tighten them until all the pieces
are positioned correctly.
• Do not overtighten or force the screws as they might
break, strip, damage the threads of the holes, or get
stuck inside the parts.
• If the hole seems to small for the screw, make sure
you are using the correct size of screw and/or that
you are installing it in the correct hole.
• Sometimes on the wood panels the laminate or
material might be covering the hole partially or
entirely, if there is no visible hole or if it looks too
small, pass and press the tip of your finger over the
area to feel its indentation, and carefully pierce the
laminate to uncover the hole underneath.
• Do not discard this manual or any of the packaging
material until the unit is completely assembled.
• Please read the assembly instructions throughly and
follow step by step.
• The product assembles ONLY as shown in the
front page, with the drawers on the RIGHT side.
The drawers cannot install on the LEFT side.
Thank you!
12
Leave loose,
tighten all together
√
√
X
• The assembly might require of 2 persons for certain
steps. Before you start the instalation, make sure there
is someone else nearby to help you.
Do not
overtighten
• Please be kind to our planet, when done with the
assembly, recycle any of the packaging materials
that is accepted by your city or recycling service.

RTA-913D
P.4 P.4
1. Screw the bolt into the indicated hole on the
panel indicated in the assembly step.
CAM BOLT AND CAM LOCK TUTORIAL
THE INSTRUCTIONS BELOW
ARE NOT ACTUAL ASSEMBLY STEPS
This unit uses cam bolts and locks (also known as mini fixes).
If you are not familiar with this kind of hardware, the below is a tutorial
that explains how to use them on the steps where they are required.
2. Join the other panel (with the big hole) to the
panel with the bolt. If it comes with the cam
locks already pre-installed, make sure to align
them to receive the bolt's head (refer to point
3). There might be a very small gap between
the panels which is normal.
3. Insert the cam lock on the panel with the big
hole making sure it goes aligned to receive the
bolt's head.
4. Use a Phillips screwdriver to turn the cam
lock clockwise. This will lock the panels
togheter and also will close any gaps.
Cam lock
alignment
If the cam locks come
pre-in stalled, make sure they
are aligned (see point 3).
THE ASSEMBLY STEPS START ON NEXT PAGE
THIS IS ONLY
A TUTORIAL
THIS IS ONLY
A TUTORIAL
THIS IS ONLY
A TUTORIAL
THIS IS ONLY
A TUTORIAL

WE RECOMMEND TO PLACE THE PIECES OVER BLANKETS TO PROTECT THEIR
FINISH DURING ASSEMBLY.
RTA-913D
Attach the dowels Ainto the indicated holes on the panels 2, 3, 4, 5, 6, 7, 9, 10
and 11.
STEP 1
Hardware
AM6x30 25
Pcs
Tools (NOT included)
P.5 P.5
ASSEMBLY STEPS

RTA-913D
STEP 2
Hardware
BBolt 16
Pcs
Tools (NOT included)
Or
• Attach the bolts Binto the indicated holes on panels 1, 2, 6and 8.
• On panel 4, attach the bolts Binto the indicated holes on both surfaces of the panel, but
please pay attention where each bolt goes.
(Bottom)
(Bottom)
(Bottom)
(Top)
(Top)
(Bottom)
(Bottom)
P.6 P.6
Flip the panel,
the bolts attach
on both sides

RTA-913D
P.7 P.7
The "flat" ones are
used in this setp.
STEP 3 • Grab both sets of sliders O(total 8 pieces) and separate them into 2 groups
according to their shape:
• The "flat" ones are the ones used on this step.
• The "L" shaped won't be used until step 9, so set them aside.
(Front)
(Front)
(Front)
O"L" Shaped
O"Flat"
RIGHT
LEFT
O
4 "flat" pieces:
• Use screws Dto assemble the "Flat" sliders Oto the panels 4and 6in their respective sides
(Left sliders to 4, right sliders to 6).
NOTES:
• The wheels go towards the front of the panels.
• Attach first on the front, through the 4th hole on the slider.
• The sliders will show 2 free holes above the wheels.
Hardware
D8
Pcs
Tools (NOT included)
Or
(Front)
RIGHT
LEFT
The "L" shaped
won't be used until
step 9, set them
aside.
M6x10
"Flat", LEFT "Flat", RIGHT

RTA-913D
P.8 P.8
THE CAM LOCKS CARE INSERTED AFTER PANEL 3IS INSTALLED.
ISticker
(Front)
(Front) (Back)
6
Pcs
• With the help of another person, join the left side panel 2and the middle panel
4to the tabletop 1 and keep holding them upright.
•The other person will join the back panel 3in between the 2 panels as shown,
and will insert the cam locks Cinto the holes of panel 2, 3 and 4 and turn them
to lock the pieces together as explained in the Cam Lock-Bolt Tutorial page.
• Cover the cam locks with stickers I.
STEP 4
Hardware
CCam lock 6
Pcs
This step
requires of
2 persons
Tools (NOT included)
Or

RTA-913D
P.9 P.9
THE CAM LOCKS CARE INSERTED AFTER PANEL 5IS INSTALLED.
ISticker 2
Pcs
• With the help of another person, join the right side panel 6to the tabletop 1
and keep holding it upright.
•The other person will join the lower panel 5in between the 2 panels as shown,
and will insert the cam locks Cinto the holes of panel 5 and turn them to lock
the pieces together as explained in the Cam Lock-Bolt Tutorial page.
• Cover the cam locks with stickers I but only for panel 6.
STEP 5
Hardware
CCam lock 6
Pcs
This step
requires of
2 persons
Tools (NOT included)
Or
I ONLY FOR
PANEL 6
