RTS LCP-102 User manual

USER MANUAL
Model LCP-102
Level Control Panel
ADAM™, ADAM™ CS, and ZEUS™ Intercom Systems
™
9350-7623-000 Rev B 04/2006
ADDRESS
KEY
INPUT
LEVEL
OUTPUT
LEVEL
LCP-102
TM
TRIMS
PAP
CDP

PROPRIETARY NOTICE
The product information and design disclosed herein were
originated by and are the property of Telex Communications,
Inc. Telex reserves all patent, proprietary design, manufactur-
ing, reproduction, use and sales rights thereto, and to any arti-
cle dislcosed therein, except to the extent rights are expressly
granted to others.
COPYRIGHT NOTICE
Copyright 2006by Telex Communications, Inc. All rights
reserved. Reproduction, in whole or in part, without prior writ-
ten permission from Telex is prohibited.
WARRANTY NOTICE
See the enclosed warranty card for further details.
CUSTOMER SUPPORT
Technical questions should be directed to:
Customer Service Department
RTS/Telex Communications, Inc.
12000 Portland Avenue South
Burnsville, MN 55337 USA
Telephone: [phone]
Fax: [phone]
Factory Service: 800-553-5992
RETURN SHIPPING INSTRUCTIONS
Customer Service Department
Telex Communications, Inc (Lincoln, NE)
Telephone: [phone]
Fax: [phone]
Factory Service: 800-553-5992
Please include a note in the box which supplies the company
name, address, phone number, a person to contact regarding
the repair, the type and quantity of equipment, a description of
the problem and the serial number(s).
SHIPPING TO THE MANUFACTURER
All shipments of product should be made via UPS Ground,
prepaid (you may request from Factory Service a different
shipment method). Any shipment upgrades will be paid by the
customer. The equipment should be shipped in the original
packing carton. If the original carton is not available, use any
suitable container that is rigid and of adequate size. If a substi-
tute container is used, the queipment should be wrapped in
paper and surrounded with at least four (4) inches of excelsior
or similar shock-absorbing material. All shipments must be
sent to the following address and must include the Proof of
Purchase for warranty repair. Upon completion of any repair
the equipment will be returned via United Parcel Service or
specified shipper, collect.
Factory Service Department
Telex Communications, Inc.
8601 Cornhusker Hwy.
Lincoln, NE 68507 U.S.A.
Attn: Service
This package should include the following:

User Manual, LCP-102 Level Control Panel 3
TABLE OF CONTENTS
INTRODUCTION ...........................................................4
LCP-102 DESCRIPTION........................................................4
PACKAGE CONTENTS ........................................................5
INSTALLATION ............................................................5
Location and Mounting .......................................................5
Connections .............................................................5
POWER-UP AND INITIAL SETTINGS................................................5
Applying Power ...........................................................5
Programming Menus ........................................................5
Setting the Panel Address ......................................................5
Adjusting the Dimmer........................................................6
OPERATION ..............................................................6
Panel Mode Selection ........................................................6
Page Select .............................................................6
TRIMS Mode Assignments and Operation .............................................6
PAP Mode Asignments and Operation ...............................................6
CDP Mode Assignments and Operation ..............................................7
Saving Configuration Changes ...................................................8
LIST OF FIGURES
Figure 1. LCP-102 Reference View...................................................4
Figure 2. Typical connection methods for the LCP-102 ........................................9
Figure 3. Interconnect cable from a Zeus or ADAM Intercom System to the LCP-102 .......................10
Figure 4. "Y" cable for connection of an LCP-102 and a UIO-256 to a Zeus or ADAM Intercom System .............10
Figure 5. Cable to interconnect two LCP-102's (All intercom systems) ...............................10
Figure 6. Interconnect cable from an ADAM CS Intercom System to the LCP-102 .........................10
Figure 7."Y" cable for connection of an LCP-102 and a UIO-256 to an ADAM CS Intercom System ...............10
Figure 8. Cable to connect a UIO-256 to the LCP-102 (All intercom systems)............................10
LIST OF TABLES
Table 1. The LCP-102 Programming Menus ..............................................5

1. INTRODUCTION
These instructions describe the installation and operation
of the LCP-102 Level Control Panel, Version 1.0, in an
ADAM™, ADAM™ CS, or Zeus™ Intercom System.
Note that the LCP-102 is not compatible with the
CS9000 Series Intercom Systems. To complete the
configuration of some features, you may need to run your
CSedit, ADAMedit, or Zeus-edit Intercom System
Configuration Software, and you may need to refer to the
documentation for that software.
2. LCP-102 DESCRIPTION
The LCP-102 combines the features of an Analog Trim
Panel, a Camera Delegate Panel, and a Program Assign
Panel in a single frame that is only 2 rack units high. You
can easily switch between its three panel modes and
make rapid configuration changes using the menu
selector on the front panel. In each mode, you can make
up to 64 assignments and then adjust the levels for those
assignments. For example, in TRIMS mode, you can
assign and adjust the analog input and output trims for up
to 64 intercom ports. In PAP mode, you can select the
program input source and set its level for each of 64
IFB's. In CDP mode, you can assign up to 64 intercom
ports to any combination of party lines and then adjust
the listen level for each participant on that party line.
The LCP-102 connects to the auxiliary data port of any
ADAM™, ADAM™ CS, or Zeus™ Intercom System,
and it also has a loop connector for connection to another
auxiliary device, such as another LCP-102, or a UIO-256
Universal Input/Output frame. Since a single LCP-102
provides trim adjustments for 64 ports, only one unit is
required to completely configure an ADAM CS or Zeus
system. For larger ADAM Intercom Systems, up to 15
additional LCP-102 frames can be connected via the loop
connectors.
4User Manual, LCP-102 Level Control Panel
110
220
TELEX COMMUNICATIONS, INC.
MADE IN USA
SERIAL NO.
INPUT
LEVEL
OUTPUT
LEVEL
ADDRESS
KEY
PAP
CDP
TRIMS
LCP-102
LOOP
DATA
TM
Figure 1. LCP-102 Reference View
Menu Selector
Menu Display
Mode Indicators
DATA Connector for Connection
to Intercom System
LOOP Connector for
Connection to Additional
LCP-102's and/or a UIO-256
Fused Power Entry Module
with On/Off Switch
(100-240VAC, 50/60 Hz)
Displays and
Controls for
each of 16
Assignments

3. PACKAGE CONTENTS
1 LCP-102 Level Control Panel
1 Power cord
1 User Manual
4. INSTALLATION
4.1. Location and Mounting
The LCP-102 occupies 2 rack spaces in a standard
19-inch equipment rack or bay, and it is 7.25 inches
(184.2 mm) deep behind the front panel (including the
rear panel connectors). There are no special ventilation
requirements. The LCP-102 should be mounted at or near
operator eye-level when standing or sitting to permit easy
access to the front panel controls and displays.
4.2. Connections
System connections are summarized in Figure 2. Cable
diagrams are shown in Figures 3to 8. Note that when
connecting a UIO-256 Frame along with the LCP-102,
you have a choice of two methods: either using the
LOOP connector of the LCP-102, or using a "Y" cable. If
you have several LCP-102's connected in a chain, you
can connect the UIO-256 to the LOOP connector of the
last LCP-102 in the chain, or you can insert it anywhere
in the chain with a "Y" cable. Whichever configuration
you use, you can also connect three additional UIO-256
Frames to the first UIO-256 in a ring configuration as
illustrated in the UIO-256 Manual.
5. POWER-UP AND INITIAL SETTINGS
5.1. Applying Power
Turn on the power switch on the back of each connected
LCP-102. During a normal power-up the alphanumeric
displays will first show asterisks ( **** ). After a few
moments, some assignments may appear in the displays
above selected keys (depending on whether or not
anything was previously assigned using the intercom
system configuration software). If there are currently no
assignments, the displays will show dashes. If the
LCP-102 that is connected to the intercom system cannot
establish communication with the intercom system, all
LCP-102 displays will continue to show asterisks. In this
case, check the cable from the first LCP-102 to the
intercom system and verify that the intercom system is
operational. If more than one LCP-102 is used, you will
have to set the addresses using the programming menus
as described below.
5.2. Programming Menus
The LCP-102 programming menus are accessed using the
ADDRESS KEY. The menus are summarized in Table 1
The following paragraphs describe the use of the menus.
5.3. Setting the Panel Address
Before programming any assignments, each LCP-102
should be set to a unique panel address as follows:
☞Each programming step should be performed within
about 10 seconds. Otherwise, the LCP-102 will
automatically cancel the procedure.
1. Rotate the ADDRESS KEY to display SERVICE,
then click the key once. DIMMER will appear in the
menu display.
2. Rotate the ADDRESS KEY to display SET ADDR,
then click the control. ADDR 1 will display.
3. For the first LCP-102, select ADDR 1, then click the
ADDRESS KEY. This will store the setting, and all
displays will show asterisks for a few moments.
Then, all displays will show dashes.
4. Double-click the ADDRESS KEY control to exit
programming mode when finished. Otherwise, the
LCP-102 will automatically exit after about 10
seconds.
☞The address setting is retained in the LCP-102
memory when power is removed.
5. Repeat the above steps for any additional LCP-102's,
selecting ADDR 2 for the second LCP-102 and so
forth.
User Manual, LCP-102 Level Control Panel 5
PAGE SEL MENU ITEMS SERVICE MENU ITEMS
PAGE 1 DIMMER
PAGE 2 SET ADDR
PAGE 3 SET MODE
PAGE 4 VER
Table 1. The LCP-102 Programming Menus

5.4. Adjusting the Dimmer
Rotate the ADDRESS KEY until SERVICE appears in
the menu display, then click the ADDRESS KEY once.
DIMMER will appear in the display. Click the
ADDRESS KEY again. One or more right-pointing
arrowheads will appear. Rotate the ADDRESS KEY to
increase or decrease the brightness of the arrowheads.
Click the ADDRESS KEY to save your change. All
displays will flash asterisks at the new brightness level
and then return to displaying their normal assignments.
6. OPERATION
6.1. Panel Mode Selection
The LCP-102 has three panel modes: TRIMS, PAP and
CDP. Select the panel mode as follows:
1. Rotate the ADDRESS KEY to display SERVICE
then click.
2. Rotate the ADDRESS KEY to display SET MODE
then click.
3. Rotate the ADDRESS KEY to display the desired
panel mode then click. Once you have selected a
panel mode, you are ready to select a setup page.
6.2. Page Select
Within each panel mode, there are four setup pages of
assignments available. Each page lets you setup 16
assignments. You can then switch between pages to view
settings or make changes. Select pages as follows:
1. Rotate the ADDRESS KEY to display PAGE SEL,
then click.
2. Rotate the ADDRESS KEY to select PAGE 1, or
PAGE 2 etc., then click. Any assignments that have
already been configured for that page will now
appear in the displays. Otherwise, the displays will
show dashes. You are now ready to setup
assignments on the newly selected page. Refer to the
following paragraphs that apply to the currently
selected panel mode.
6.3. TRIMS Mode Assignments and
Operation
6.3.1 General
In TRIMS mode, you assign individual ports of the
intercom system to displays and then adjust the input and
output trims. This is the same as adjusting the Analog
Input/Output Gains in ADAMedit or Zeus-edit.
6.3.2 Trims Mode Assignments
1. Place the LCP-102 in TRIMS mode as previously
described under "Panel Mode Selection".
2. Select one of the four setup pages as previously
described under "Page Select".
3. Select one of the 16 assignable displays that is
currently unused by clicking either of the controls
under that display. Then, rotate the control to scroll
through the list of intercom ports. When you locate
the intercom port that you want to assign, click the
control again. The selected intercom port is now
assigned to that display.
4. Repeat these steps to make further assigments.
5. To cancel or clear an assignment, click either of the
assigment's controls. The display will go blank.
Click the control once more and the display will
return to showing dashes, indicating no assignment.
6.3.3 Trims Mode Operation
For each assigned display, rotate the upper control under
that display to change the input level. Rotate the lower
control to change the output level. Rotating a control one
notch in either direction will display the current level.
Further rotation will change the level.
6.4. PAP Mode Asignments and
Operation
6.4.1 General
In PAP mode, you setup IFB's and then adjust the level
from the defined program input to the defined IFB
output.
6User Manual, LCP-102 Level Control Panel

6.4.2 PAP Mode Assignments
1. Run ADAMedit or Zeus-edit and define the output
port for each IFB that you want to setup, then send
your changes to the intercom system. (To get help on
this topic, click the IFB button on the ADAMedit or
Zeus-edit toolbar, then press the F1 key on the
computer keyboard.)
☞For each IFB, you can define or change the input
port either from the intercom system configuration
software or from the LCP-102, but you must always
define the output port first using the intercom system
configuration software.
2. Place the LCP-102 in PAP mode as previously
described. See "Panel Mode Selection".
3. Select one of the four setup pages as previously
described. See "Page Select".
4. Select one of the 16 assignable displays that is
currently unused. Double-click either control below
that display to enter IFB assign mode, then rotate the
control to scroll through the list of IFB's. When you
locate the desired IFB, click the control once to
assign it to the display.
☞If you already assigned the input port for the IFB
using the intercom system configuration software
you can skip steps 5 and 6.
5. With the display showing the name of the IFB, click
either control to enter input port assignment mode.
The scroll list of intercom ports should appear in the
display.
6. Rotate the upper control to select the intercom port
where the program source for the IFB is connected.
Click the control to assign the selected port. The
display will again show the IFB name, and the IFB
should now be completely setup.
7. Repeat these steps to make further assignments.
8. To cancel an assignment, click either of the
assignment's controls. The display will go blank.
Click the control once more, and the display will
return to showing dashes, indicating no assignment.
6.4.3 PAP Mode Operation
To change the program level, simply rotate either control.
Rotating the control one notch in either direction will
display the current level. Further rotation will change the
level.
6.5. CDP Mode Assignments and
Operation
6.5.1 General
In CDP mode, you use each display and its controls to
assign one intercom port to any party line. Then during
operation you can adjust the level at which that port hears
the party line audio.
6.5.2 CDP Mode Assignments
1. Select CDP mode as previously described. See
"Panel Mode Selection"
2. Select a setup page as previously described. See
"Page Select".
3. Select one of the 16 assignable displays that is
currently unused. Double-click either control below
that display to access the scroll list of intercom ports.
4. Rotate the control to locate the intercom port that
you want to assign to a party line, then click the
control once to select the port.
5. Click the control again to access the party line scroll
list.
6. Rotate the control to locate the party line to which
you want to assign the intercom port, then click the
control. This will assign the port to the party line as a
talker and listener, and the name of the port will
reappear in the display.
7. Repeat these steps to make further assignments.
8. To cancel an assignment, click either of the
assignment's controls. The display will go blank.
Click the control once more, and the display will
return to showing dashes, indicating no assignment.
6.5.3 CDP Mode Operation
To change the listen level for a port, rotate either control.
Rotating the control one notch in either direction will
User Manual, LCP-102 Level Control Panel 7

display the current level. Further rotation will change the
level.
To display the party line to which a port is assigned, click
either control once. The party line name will display for
about 4 seconds, then the port name will reappear.
6.6. Saving Configuration Changes
The settings for address, current panel mode and current
setup page are saved in the LCP-102 and will be retained
if the power is turned off.
All display assignments and level settings are uploaded
to the intercom system and become part of the on-line
configuration. This configuration will be retained if there
is a loss of power to the intercom system. However, if
you wish to have a backup copy of your settings, save the
settings to disk using your intercom system configuration
software.
8User Manual, LCP-102 Level Control Panel

User Manual, LCP-102 Level Control Panel 9
LCP-102
ZEUS J26
ADAM CS J902
XCP-ADAM-MC J3 (ADAM)
LOOP
DATA
LCP-102 UIO-256
LOOP
DATA
J2
LCP-102
ADDR 1
LCP-102
ADDR 2
LOOP
LOOP
TO ADDITIONAL
LCP-102’S
(UP TO 16 TOTAL)
DATA
DATA
LCP-102 UIO-256
LOOP
DATA J2
CONNECTIONS FOR A SINGLE LCP-102 OR MULTIPLE LCP-102’S
TWO METHODS FOR CONNECTING A UIO-256WITHTHE LCP-102
UPTOTHREE MORE UIO-256 FRAMES MAY BE CONNECTEDTO
THE FIRST UIO-256 IN A RING CONFIGURATION AS ILLUSTRATED
INTHE UIO-256 MANUAL
ZEUS J26
ADAM CS J902
XCP-ADAM-MC J3 (ADAM)
ZEUS J26
ADAM CS J902
XCP-ADAM-MC J3 (ADAM)
ZEUS J26
ADAM CS J902
XCP-ADAM-MC J3 (ADAM)
Figure 2. Typical connection methods for the LCP-102

10 User Manual, LCP-102 Level Control Panel
DE-9P
(Male)
6
1
2
ZEUS J26
XPC-ADAM-MC J3 (ADAM)
7
2
1
TO LCP-102
DATA
DE-9S
(Female)
Figure 3. Interconnect cable from a Zeus or ADAM
Intercom System to the LCP-102
DE-9P
(Male) DE-9P (Male)
6
1
2
1
2
ZEUS J26
XPC-ADAM-MC J3
(ADAM)
TO UIO-256
J2
7
2
1
TO LCP-102
DATA
DE-9S
(Female)
Figure 4. "Y" cable for connection of an LCP-102
and a UIO-256 to a Zeus or ADAM Intercom System
DE-9P
(Male)
7
2
1
TO FIRST LCP-102
LOOP
7
2
1
TO SECOND LCP-102
DATA
DE-9S
(Female)
Figure 5. Cable to interconnect two LCP-102's (All
intercom systems)
DE-9S
(Female)
6
1
2
TO ADAM CS
J902
7
2
1
TO LCP-102
DATA
DE-9S
(Female)
Figure 6. Interconnect cable from an ADAM CS
Intercom System to the LCP-102
DE-9S
(Female) DE-9P (Male)
6
1
2
1
2
TO ADAM CS
J902 TO UIO-256
J2
7
2
1
TO LCP-102
DATA
DE-9S
(Female)
Figure 7."Y" cable for connection of an LCP-102
and a UIO-256 to an ADAM CS Intercom System
DE-9P
(Male)
7
2
1
TO LCP-102
LOOP
1
2
TO UIO-256
J2
DE-9P
(Male)
Figure 8. Cable to connect a UIO-256 to the
LCP-102 (All intercom systems)
