RTS SCC Line User manual

Retrofit instructions
SCC Line
Number: 16/2005
Date: 21.09.2005
Topic: Thermocover of transport trolley Combi-Duo
Units
concerned: SelfCooking Center®/Combi Master 61 – 102
Required tools: Spanner 10 mm, scissor
Labour time approx. 60 minutes
- 1 -
1. Adjust the transport trolley to the
required height of the corresponding type
of the Combi-Duo. pic. 1
- First set the lower transport frame to the
necessary position (Combi-Duo on rolls,
on wheels, on legs or 61/61 on stand.
- Second set the height of the upper trans-
port frame to the corresponding height of
the upper unit if the Combi Duo.
2. Remove upper transport frame:
- Hang out spring of lever mechanism
- Loosen combi-nuts pic. 2
- Remove upper transport frame
3. Put thermocover over the transport trolley
pic. 3
1
2
3
RTS

- 2 -
4. Guide the upper lever mechanism through
the opening of the thermocover. pic. 4
5. Put the upper transport frame to the trolley
and fasten it with the combi-nut.
6. Remount the spring of the lever mechanism.
pic. 4
7. Guide the lever through the opening of the
thermocover. pic. 5
8. Shorten thermocover to required length
(depends on the configuration of the Combi
Duo) at the corresponding seam.
Make sure the cut is in the center of the
selected seam, to avoid that the seam frays
pic. 6/7
4
5
7
6
