Operator Configuration
The Rubek Automatic Sliding Door operator is available in two forms:-
1. Standard operator
2. Standard operator with electric lock ( Motor Lock )
The Major components of the standard unit are:-
•The sliding door operator – self contained in aluminium beam housing with fitted
colour coded or anodised pelmet.
•Motion detector sensors – fitted centrally inside and outside the door entrance to
detect people entering or exiting and opening the door(s). Motion sensors can
vary depending on the location of your doors.
•A mode switch, which controls all the doors functions. This can be installed inside
the building at a position convenient to safe door operation. Some clients install
the mode switch next to the door entrance while some prefer it to be located
behind a reception counter.
•Infrared safety beams. These are installed in the door frame and detect if
someone is still standing in the doorway and if so hold the doors in the open
position. Safety beams can be substituted for a Crystal Presence radar motion
detector which will not only monitor the approaching traffic to the door but will also
look for people or obstacles in the door way.
Some installations include other control devices such as swipe card readers,
interfacing with building security systems, time locks to control door locking and
operation between certain times or remote controls. Manual and emergency
activation buttons, such as break glass switches, can also be installed where
required.
To secure a standard door operator without an electric lock fitted, a standard lock
must be fitted. Locks must be fitted in compliance with current building codes and fire
safety regulations.
