Rubymount A4601-1 User manual

INSTRUCTION MANUAL
SPECIFICATIONS
BOX CONTENTS
Wall bracket (x1)
Mount arms (x 2)
Instruction Manual (x1)
Hardware Kit (x1)
TOOLS REQUIRED
HARDWARE KIT
WARNINGS
1.The wall or mounting surface must be capable of supporting the combined weight of the mount and the
display; if not, the structure must be reinforced.
2.Locate pipes, wires, or any other hazards in the wall where you wish to install the mount before drilling.
3.Safety gear and proper tools must be used. Failure to do so can result in injury or damage.
4.Two people are recommended for installation. Do not attempt to lift a heavy display without
assistance.
5.Follow all instructions and recommendations regarding adequate ventilation and suitable locations for
mounting your display. Consult the owner's manual for your particular display for more information.
CAUTION: This wall mount is intended for use only with the maximum weight of 35 kg . Use with
heavier than the maximum weights indicated may result in instability causing possible injury.
Screwdriver
Electric or Portable Drill
Drill Bit and Stud Finder for Drywall Installation
 Masonry Bit for Concrete Installation
Hammer
Tape Measure
(A)M6 x 50 Lag Bolt (x3)
(B) Lag Bolt Washer (x3)
(C)Concrete Anchor (x3)
(D)M4 x 20Screw (x4)
(E)M6x 20 Screw (x4)
(J)M6 Washer (x4)
(K)Spacer (x4)
Display Size: up to 46”
Maximum Load: 35 kg
Mounting Pattern: 400 mm x 400mm (max)
Profile:11.1cm-39cm
Tilt:15 down
Swivel: up to 180

Drywall Installation Concrete Installation
1. 1.
2. 2.
3. 3.
4. 4.
5. 5.
6. 6.
display is curved or recessed.
require washers.
do not require washers.
bolts
bolts
display is curved or recessed.
require washers.
do not require washers.
bolts
bolts
Carefully mount your display with the
mount arms onto the plate.
Insert the safety screws to the bottom of
the mount arms and tighten to prevent
the display from being lifted.
Carefully mount your display
with the mount arms onto the mount.
Insert the safety screws to the
bottom of the mount arms and
tighten to prevent the display
from being lifted.
Use a stud finder to locate a stud where you
wish to install your mount. Use the wall plate
as a template to mark three holes.
the mount arms to the back of your
Spacers and (E)/(G)/(H) should be used if the
back of your display is curved or recessed.
to fix display.
the mount arms to the back of your
Spacers and (E)/(G)/(H) should be used if the
back of your display is curved or recessed.
to fix display.
Choose (D)/(F) provided from the hardware kit
Choose (D)/(F) provided from the hardware kit
Drill a pilot hole at each marked location.
Fix the wall plate onto the wall using (A), (B) and (C)
provided from the hardware kit.
Fix the wall plate onto the wall using (A),
(B) and (C)provided from the hardware kit.
Drill a hole at each marked
location. Insert a concrete anchor
into each hole.
Use the wall plate as a template
to mark three holes.
