SAFETY INSTRUCTIONS
1_Introduction 5
2_Faults and damages 6
3_Further safety advises 7
QUICK START
4_Keys 9
5_First steps 10
5.1_Battery 10
5.1.1_Installing and extracting the battery 10
5.1.2_Charging the battery 11
5.1.3_Battery use 11
5.2_Installation of the SIM card 12
5.3_Installation of the microSD card 12
6_Status icons 13
MENU NAVIGATION
7_Menu navigation 14
7.1_Call center 14
7.2_Multimedia 14
7.3_Phonebook 15

3
TITEL DES KAPITELS
EN
En
7.4_Messages 16
7.5_Tools 17
7.6_Charger PAL 17
7.7_USB mode 17
7.8_Bluetooth® 18
7.9_Settings 18
INFORMATION
8_Specications 19
9_Troubleshooting 20
10_Maintenance 22
11_ SAR 23
Service Center 25

rESErvation
Technical Data is subject to change without notice.
Changes, errors and misprints may not be used as a
basis for any claim for damages.
All rights reserved.
RugGear Europe GmbH cannot be held responsible
for any data or other loss and direct or indirect
damages caused by any improper use of this phone.
This document contains a quick start guide and the
safety instructions necessary for the safe use of the
mobile phone RG100.
More detailed instructions on the use of the phone
can be found at www.ruggear-europe.com or directly
at our Service Centre.
C 2014 RUGGEAR EUROPE GMBH
DW3140819

5
EN
SafEty inStructionS
1_introDuction
This document contains information and safety regulations
which are to be observed without fail for safe operation of the
mobile phone RG100 under the described conditions.
The current EC declaration of conformity, EC certicate of
conformity, safety instructions and manual can be found
at www.ruggear-europe.com, or requested from
RugGear Europe GmbH.
NOTE
This document contains only the instructions necessary for setting
up and safe use of your phone. A complete Quick Start Manual can
be found at www.ruggear-europe.com.
To ensure the IP protection of the phone please make sure that the
seals of the battery, the USB port cover and all the screw covers are
in their correct place.

6SafEty inStructionS
2_faultS anD DaMaGES
If there is any reason to suspect that the safety of the phone has
been compromised, it must be withdrawn from use immediately.
Measures must be taken to prevent any accidental restarting
of the phone.
The safety of the phone may be compromised if, for example:
malfunctions occur.
the housing of the phone or the battery shows damage.
the phone has been subjected to excessive loads.
the phone has been stored improperly.

7
EN
SafEty inStructionS
3_furtHEr SafEty aDviSES
Do not touch the screen of the phone with sharp objects.
Dust particles and dirt may scratch the screen. Please maintain
the screen clean. Remove dust on the screen with a soft cloth
gently and do not scratch the screen.
Charge the phone under indoor conditions only.
Please do not put the phone in environments with excessive
temperatures as this could lead to heating of the battery,
resulting in re or explosion.
Do not charge the phone near any ammable or explosive
substances.
Do not charge the phone in environments with much
dust, humidity, or excessively high or low temperatures
(the permitted charging temperature range is 0 °C – 45 °C).
Do not use the phone in areas where regulations or legislatives
prohibit the use of a mobile phone.
Do not expose the phone, the battery or the charger to strong
magnetic elds, such as are emitted from induction ovens or
micro-waves.
Do not attempt to open or repair the phone. Improper repair
or opening can lead to the destruction of the phone, re or
explosion. Only authorized personnel are allowed to repair
the phone.
Only use accessories approved by RugGear Europe GmbH.
Please do not connect the poles of the battery directly, to avoid
short-circuiting the battery.
Power o the phone in hospitals or other places where the use
of mobile phones is prohibited. This phone may aect proper
work of medical equipment, like pacemakers, so always keep a
distance of at least 15 cm between the phone and these devices.

8SafEty inStructionS
Observe all corresponding laws that are in force in the
respective countries regarding the use of mobile phones
while operating a vehicle.
Please power o the phone and disconnect the charging cable
before cleaning the phone.
Do not use any chemical cleaning agents to clean the phone or
the charger. Use a damp and anti-static soft cloth for cleaning.
Do not discard old and abandoned lithium batteries into
the trash, send them to designated waste disposal locations
or return them to RugGear Europe GmbH.
The user alone is responsible for any and all damages and
liabilities caused by malware downloaded when using the
network or other data-exchange functions of the phone.
RugGear Europe GmbH cannot be held responsible for any
of these claims.
WARNING
RugGear Europe GmbH will not assume any liability for damages
caused by disregarding any of these advices or by any inapprop-
riate use of the phone.

9
EN
4_kEyS
1_Power
Lock the phone. Long
press to power on and
o the phone.
2_Send
Bring up the call log
or answer a call when
the phone is ringing.
3_Contacts
4_Menu
While on the homescreen:
enter settings.
5_Navigation
4-way navigation
through menus.
6_OK
Conrm the selected
item or function.
7_Keypad
Use for text or number entry.
8_Volume
Adjust the volume.
9_Torch on/o
Quick Start
1
8
7
2
5
9
4 3
6

10 Quick Start
5_firSt StEpS
5.1_BATTERY
The battery is inserted into the back of the mobile phone. The
battery is not fully charged when the mobile phone is purchased,
but it contains enough energy to power on the phone.
To obtain best battery performance and battery life, let the battery
discharge completely before charging it completely for the rst
three charging cycles.
5.1.1_INSTALLING AND EXTRACTING THE BATTERY
When installing the battery, insert the teeth at the top of the battery
into the corresponding notches of the mobile phone, then press
the battery down and secure it by turning the two screws with the
delivered screw driver. Ensure that the battery is safely in place
before powering on the phone.

11
EN
Quick Start
5.1.2_CHARGING THE BATTERY
Connect the USB-cable with the phone as
indicated in the picture.
Connect the plug with the socket of the
power supply.
After charging, remove the USB-cable from
the charger.
5.1.3_BATTERY USE
In actual use, the standby time and talk time of the phone varies
with the network status, working environment and usage.
When the power of the battery is lower than normal, the phone
will prompt you to charge it. Please charge the battery; otherwise
you may lose any les which have not been saved.
If you do not charge for a long time, the phone will be powered o
automatically.
WARNING
The phone may only be charged at ambient temperatures in
a range from 0 °C – 45 °C. Please do not use charging equipment
if the temperature exceeds this range. Only use the RugGear
approved USB-cable and charger. Using any other cable may
cause danger and will void the warranty.

12 Quick Start
5.2_INSTALLATION OF
THE SIM CARDS
The phone features two SIM card
slots (1, 2). They are placed in the
battery compartment. Please
remove the battery to gain access
to the holders.
Unlock a SIM card holder by sliding
it forward as indicated on the holder.
Open the holder and insert the SIM
card. Close the holder and lock it
again to safely retain the SIM card.
5.3_INSTALLATION OF THE MICROSD CARD
The SD card holder (3) is placed in the battery compartment.
Please remove the battery to gain access to the holder.
Unlock the SD card holder by sliding it forward as indicated on
the holder. Open the holder and insert the SD card. Close the
holder and lock it again to safely retain the SD card.
WARNING
Do not try to insert or remove the SIM card when any external
power supply is connected, otherwise the SIM card or the mobile
phone may be damaged.
2
31

13
EN
Quick Start
Current Signal Strength
Battery power level
indicator
GPRS Connectiont
EDGE Connection
Bluetooth® active
Call in progress
Missed calls
Airplane mode
Vibration only
Vibration and ringtone
Mute
New SMS
New MMS
Alarm clock active
MP3 playing
FM radio active
Ringtone only
6_StatuS iconS

14 MEnu naviGation
7_MEnu naviGation
Image viewer options view Browse style
Send
Use as (wallpaper,…)
Rename
Delete
Sort by
Delete all
Storage
Image information
Camera take picture OK button
(SD card is needed) camera key switch to record video
photos (view images)
camera settings
image settings
white balance
screen mode
restore default
Audio player local music Press UP key: repeat play state
Press DOWN key: open or close function
Left key: change the song to previous one
Right key: change song to later one
Press OK key: play or stop
BT (Bluetooth®) make sure that the device is connected
7.2_MULTIMEDIA
7.1_CALL CENTER
Call history missed calls
(SIM1/SIM2) dialed calls
received calls
delete call logs
call times
Call settings advanced blacklist
(SIM1/SIM2) settings auto redial
call time reminder
connect notice
reject by SMS
answer mode
auto recorder

15
EN
MEnu naviGation
Video recorder OK key start recording
(navigation)
right/left key adjust brightness of recording
up/down key focal distance
options switch to camera
camcorder settings
video settings
white balance
eect settings
restore default
Video player options play
send (send current document via BT)
rename
delete
sort by
FM radio left/right key automatical channel selection
(earphone pluged in) (navi)
up/down key manual channel selection by 0.1 Hz steps
options channel list
manual input
auto search
settings
record
le list
Sound recorder options new record
list play
append
settings rename
delete
use as
send
Contacts options select SIM1, SIM2 or phone
mark several
(send SMS, delete contacts)
phone book settings view
send SMS
call
edit
delete
copy
add to blacklist
mark several
settings
7.3_PHONEBOOK

16 MEnu naviGation
7.4_MESSAGES
Write messages SMS, options send to
insert symbol
Input method
Input method options
Insert template
Advanced
Save
MMS, options send to
insert symbol
Input method
Input method options
Add picture
Add sound
Add video
Preview MMS
Slide options
Advanced
Save
Inbox local, options reply by SMS
reply by MMS
call sender
forward
delete
advanced
BT (Bluetooth®) make sure that the device is connected
Drafts local view
send
edit
delete
delete all
BT (Bluetooth®) make sure that the device is connected
Outbox local send
edit
delete
delete all
BT (Bluetooth®) make sure that the device is connected
Sent messages local, options view
forward
delete
delete same contact
delete all
BT (Bluetooth®) make sure that the device is connected

17
EN
MEnu naviGation
Broadcast messages receiver mode
channel settings
languages
read messages
Templates choose existing templates
use existing templates
edit
remove
Settings SMS preferred connection
Reply path
Prole settings
Voicemail server
Delivery report
MMS set up slide time
creation mode
picture resizing
request delivery report
request read report
priority
service messages path and service loading
can be set up
7.7_USB MODE
When connected by USB the phone can be used as a mass storage or a modem.
7.6_CHARGER PAL
If this function is switched on, the phone can be used as a PAL charger to charge another phone.
7.5_TOOLS
File manager
Games
Ebook reader txt format, stored on SD card
options add folder
sort
World clock fold
Alarm delete
Calculator share
Calendar move
copy

18 MEnu naviGation
Proles General
Silent
Meeting
Outdoor
Earphone
Power savings
options activate
customize (self dene)
Dual SIM settings dual SIM open
only SIM1 open
only SIM2 open (micro SIM)
Phone settings time and date
schedule power o/on
language selection
prefered input mode
shortcuts
dedicated keys
charger PAL
ight mode
display wallpaper
screen saver
show date and time
screen auto lock
Network settings SIM1/SIM2 network selection
GPRS transfer pref.
Security settings SIM1 security / SIM2 security
PIN lock
PIN code
phone security
privacy protection
Restore settings passwort for restoring factory settings 1122
Notication settings set the applications of messaging and download
Services internet service
STK
data accounts (APN settings)
7.8_BLUETOOTH®
Settings turn on/o
visibility
paired devices
Anti lost
7.9_SETTINGS

19
EN
inforMation
8_SpEcificationS
Frequencies
Quad band
GSM 850/900/1800/1900 MHz
Dimension
weight: 165 g,
size: 126 x 58 x 23 mm
Screen
2.0" (5.08 cm) RugDisplay-
Glass with a resolution of
176 x 220 pixel
Camera
1.3 MP rear camera
Wireless technologies
Bluetooth® 3.0,
Battery
2400 mAh battery, standby
600 hrs., talktime 2G/3G:
560 min./440 min.
Memory
internal memory 64 MB
ROM, 64 MB RAM, external
memory microSD up to
32 GB
Processor
MT6260A
Temperature
operation range from
-20 °C to 60 °C
IP68
waterproof: 30 min. up
to 2 m, impervious to dust
and microparticles
MIL-STD-810G
2 m drop-protection,
impervious to dust and
microparticles

20 inforMation
9_troublESHootinG
If problems occur when using the mobile, please try the
following tips. If the problem is not solved, please contact
your vendor or RugGear Europe GmbH directly.
THE PHONE CANNOT BE POWERED ON
The battery voltage is too low.
Please recharge the battery.
The power on key is not pressed long enough.
Please press power on key for more than three seconds.
The connection to the battery is bad.
Please assemble the battery again or clean the contact
points of the battery carefully.
The SIM card has a failure.
Please check or replace the SIM card.
THE PHONE HAS INSUFFICIENT STANDBY TIME
The battery performance is reduced because of the age
of the battery.
Please contact your vendor or RugGear Europe GmbH
for a replacement battery.
Too many programs running.
Please reduce the number of running programme.
