RugGear RG730 Instruction manual

Quick Start Manual
Rg730
TD-LTE Digital Mobile Phone

USB/Charging Port Headphone Jack
Distance and
light sensor Receiver Front Camera
PTT key
Touch Screen
Main Menu Back
Home Key
MIC Jack
Overview
-1-

Flsahight
Associate MIC
Volume Key
Power
Camera Key
Rear Camera
Speaker
Screw lock
NFC antenna sensing area
Wireless charging sensing area
Keys Introductions
Power key
Long press the button on/off;
Standby mode, long press to enterthe
phone mode menu;
Standby mode, short press this button
to turn off/wake the screen;
Customizable
key
Long press to select shortcutapp,short
press to enter the selected function.
USB Port Data cable jack, OTG cable jack
Associate
MIC Noise elimination
Tips: key
combination
Make Screenshot：Press and hold both
Volume Downand Power buttons
together for 1 second
-2-

SIM card/Micro SD card
installation and removale,
the back cover lock and
unlock
The device SIM card slot is only fit for the standard
Micro SIM.Single SIM card supports 4G separately.
As for dual SIM card,SIM1 supports 4G, SIM 2 only
supports GSM . SIM 2 supports 4G, SIM 1 only
supprots GSM.
Note: Use of other sized SIM cards will void
warranty.
Please follow the steps mentioned below to install
the memory card in the device:
1. Power off the phone
2. Open the screw lock according to the picture
direction.
-3-

3. Insert the SIM and SD card according to the
4. Put back the back cover and lock the screw
Operation please follow up the arrow direction.
Note:
To avoid damage to your phone or loss of data, make
sure that the phone has been turned off, and there is
no power or phone connectior before installing or
removing the SIM card or Micro SD card.
After installation is complete, be sure to tightly
cover the battery , Tighten the Battery cover screw
lock, to avoid water damage or dirt froming entering
the mobile phone.
Please try to use the phone's original data cable
and adapter, or RugGear’s approved data cable for
the phone to charge.
Gloves mode
-4-

Tips: Insert / Remove the memory card:
To store additional multimedia information, you must
insert a memory card, the device can only accept up
to 64GB Micro SD memory card.
Please make sure to remove the memory card in safe
circumstances.
1. In standby mode, open the application list, And
then select Settings →Storage →unmount SD → OK
2. Remove the memory card
The first time you use your phone, please run out of
power first, and then charge the battery until it is fully
charged.
Please try to use the phone's original data cable and
adapter, or RugGear approved data cable for the
phone to charge. Unqualified charger or USB cable
may lead to the device explosion.
When the battery is low, the device will emit a
warning tone and a low battery message prompts.
The battery icon will appear blank. If the battery is
too low, the phone will automatically shut down.
Need to charge the battery in order to continue to
use the phone.
If the battery is completely discharged, even if the
connection on the travel charger, cannot turn on the
device. Before attempting to turn on the device,
Charging the battery
-5-

1. Please open waterproof rubber plug according
to the following right direction, before inserting the
headset or data cable.
The travel charger not connected properly may
result in serious damage to mobile phones. For any
damage caused due to misuse, is not in the warranty
scope.
2. The Voltage instability will lead to the touch
screen not in good working condition.
The phone becomes warm while charging. It is
normal, does not affect the service life or
performance of the phone.
To save power, unplug the device when not in use
travel charger.
Charging Travel Charger
-6-

The device wireless charger function uses energy-
saving control technology, and comprehensive
identification of emission control technology, all
functions by emitting part is completed. Before using
the wireless charger function,read all safety
precautions and this manual carefully to ensure
safety and proper use.
1. This mobile phone built-in QI standard wireless
charging receiver. This phone only supports QI
Standard wireless charger.
2. Do not expose the wireless charger to rain or
water.
3. Do not disassemble, modify or repair phone by
yourself.
4. Do not store the device in water heaters,
microwave ovens, hot cooking equipment or near the
high pressure vessel.
Wireless charging photo:
Wireless charging devices
-7-

To save power, you can:
1. When not using Bluetooth, Wi-Fi or GPS, please
close these wireless communication function;
2. Lowering the phone screen brightness and
setting a shorter sleep time can save power. You can
press the power button to turn off the screen when
not using the device;
3. Closing Email, calendar and contacts, and other
applications of automatic synchronisation; Long
pressing the HOME main menu button, selecting the
icon and dragging left or right to slide to disappear;
4. Your installstion and use of some of the
applications may shorten battery life, please exit
used applications or long press the menu button to
view the used application list and slide left/right to
exit.
Extend battery life
Because this phone has built-in battery, if the phone
cannot be turned off owing to crash fault, you can
long press the reset button for 14 seconds to reset,
so as to restart the phone on normal standby.
Abnormal operating this button may result in loss of
some unsaved data, please use the reset key with
great caution.
Using reset key
-8-

Your device has been tested waterproof and
dustproof:
Please note that compliance with waterproof and
dustproof requirements, does not mean that your
device will not be damaged by water under any
conditions.
Cautions:Please make sure the battery cover of
mobile phones, battery cover screw lock ,
headphones and USB plug all rubber cover are
tightly closed, in order to have perfect dustproof and
waterproof effect. Be sure to close the back cover
(specific reference in front of the battery back cover
installation method).
This mobile phone drop test conditions as follows:
1.2 metres.
Waterproof and dustproof
Gloves mode
Please check “Settings → Display → gloves mode
selected” You can also use the touch screen while
wearing gloves. Please make the fingers of gloves
touch the phone's screen. The touch screen support
wet hand operation, too.
-9-

1. Please make sure the back cover screw lock,
headphones and USB plug and all rubber cover are
tightly closed, in order to have perfect dustproof and
waterproof effect. Be sure to close a battery cover
(specific reference in front of the battery back cover
installation method) .
2. Do not immerse the phone in water. There is no
harmful effect if the device is water sprayed strongly
in all directions.
3. Do not expose your phone in the water
dynamics such as waves or waterfalls.
4. Do not expose the equipment to salt water,
ionized water or soapy water.
5. Do not use the phone in the spa or hot water
because waterproof rubber is easily affected by high
temperature.
6. Please do not use wet hands to open the
battery cover. When open it, you must put the cover
down in case water goes into the cover slot.
7. Do not immerse the phone in water or in
extremely wet conditions when opening the back
cover. (such as swimming or shower)
8. Do not open the battery cover while the body is
not completely dry.
To be waterproof and
dustproof, please follow
below step
-10-

9. Do not use detergent cleaning products and
other chemicals.
10. Rubber seal stoppers in the battery cover are
an important part of the device, Please be careful to
avoid damaging it when you open or close the
battery cover. Also, make sure there is no debris,
such as sand or dust on the rubber seal.
11. If the device is dropped or subjected to impact,
the battery cover and multifunction jack cover may
be loose. Ensure that all covers are properly aligned
and tightly closed.
12. Under certain conditions, such as high volume
levels, it may be slightly vibrated. It is normal due to
waterproof design and does not affect the
performance.
13. If you accidentally drop your phone in
the quagmire, do not worry, just flush it with clean
water and dry it.
14 .If you accidentally drop your phone on the
beach, do not worry, just flush it with clean water and
dry it.
15. If the device is immersed in water or wet
microphone or speaker, during a call, the other party
may not be able to hear your voice, so wipe with a dry
cloth to make sure the microphone or speakers are
clean and dry. Hair dryer is not permitted.
16. If water droplets are found on the screen, it
may affect the perception of the touch screen
resulting in errors. Recommend to continue to use
the phone after drying the water droplets.
-11-

Safety Information
To protect yourself and others from harm, please
read all of the following information before using
your mobile phone.
Please use RugGear original profession adapters,
chargers, accessories and supplies.
Do not put the device in hot or cold places.
Do not put the phone inside the heater,
microwave, cooking equipment or high pressure
vessel.
Do not touch the phone or charger when the phone
is charging with wet hands.
Do not use the phone in outdoor thunderstorm
weather.
In a potentially explosive environment, gas
station, etc., please turn off the phone.
When using the phone at a restricted area ,
please observe all safety warnings and regulations.
Please abide by all the relevant safety warnings
and regulations of using mobile phones while
driving.
Please turn off the phone while flying.
Do not use the phone in the occasion where is
easily affected by radio frequency interference like
hospitals and so on.
If possible, avoid the use of mobile phones within
15cm range from the pacemaker. The reason is the
phone may interfere with pacemakers.
-12-

If you must use the phone, please keep a distance
of at least 15cm with pacemaker Please use the
phone at the other side of the body or opposite the
pacemaker in order to reduce the interference with
the pacemaker.
If you use a hearing aid, please contact with the
manufacturer about radio interference information.
If you use other medical devices, please contact
with the device manufacturer before using this
medical device to determine whether the equipment
will be affected by this phone emitted radio
frequencies.
Do not allow children or animals to bite, chew, or
suck the phone or battery.
Do not touch the multifunction jack and battery
electrode with conductive elements of metal or
liquids.
Do not use the flash or lights when approaching
human or animals eyes.
Do not use high-volume to listen to long
conversation or music, so as not to damage your
hearing.
Do not disassemble, modify or repair the phone.
Do not approach other handset manufa- cturers
for any changes or modifications or this will void the
warranty. For service,please contact with after-sales
service department of RugGear or your local dealer.
Only qualified service personnel can repair
phones
-13-

Operating temperature: -20℃~50℃.
The product contains a re-changer battery, the
charging voltage 4.3V. The device contain a power
adapter, charging temperature is 0℃〜+40℃.
Caution risk of explosion if battery is replaced by
an incorrect type. Dispose used batteries according
to the instructions.
Excessive sound pressure from earphones and
headphones can cause hearing loss.
All content and services available through this
device belong to third parties and is protected by
copyright, patent, trademark and other intellectual
property laws, such content and services for
personal, non-commercial use only. In the absence
of obtaining license from content owner or service
provider, you may not use any content or services.
In addition to the above limitations, unless expressly
permitted by the application content or service
Disclaimer
-14-

providers, otherwise, any content or service this
equipment displays, you may not modify, copy,
republish, upload,post, transmit, translate, sell ,
create derivative works, exploit, or distribute in any
way
Third-party content and services as is available.
Regardless, for any purpose, RugGear does not
provide any express or implied warranties for the
provided content or service. RugGear explicitly
stated, does not undertake any implied warranty and
terms or conditions accepted by laws and
regulations Common law or in any other way
including but not limited to the applicability of the
merchantability or for a specific purpose.
The third-party service may at any time to stop or
interrupt, RugGear is not responsible for any period
of time when the content or services is available.
Content and services are transmitted by third parties
through the network and transmission equipment
outside the control of RugGear In addition to the
generality of this exceptions clause, RugGear makes
it clear that our company is not responsible for any
interrupt and delay of any
content or service applicable for this device.
RugGear involving content and services are
neither responsible nor liable. Any content or
services related services should be made
directly by the content and service providers.
-15-

Specific Absorption Rate
(SAR)
Your equipment radiation standard unit of
measurement is known as specific absorption rate
(SAR).The SAR limit of Europe is 2.0 W/kg. Device
types RG730 has also been tested against this SAR
limit. The highest SAR value reported under this
standard during product certification for use at the
ear is 0.190W/kg and when properly worn on the
body is 0.444 W/kg. This device was tested for
typical body-worn operations with the back of the
handset kept 1.0cm from the body. To maintain
compliance with RF exposure requirements,use
accessories hat maintain a 2.5cm separation
distance
between the user's body and the back of the
handset.The use of belt clips, holsters and similar
accessories should not contain metallic components
in its assembly.The use of accessories that do not
satisfy these requirements may not comply with RF
exposure requirements, and should be avoided.
During use, the actual SAR values for this device are
usually well below the values stated above. This is
because, for purposes of system efficiency and to
minimize interference on the network, Organizations
such as the World Health Organization and the US
Food and Drug Administration have suggested that if
people are concerned and want to reduce their
exposure, they could use a hands-free accessory to
-16-

NOTICE:
-17-

NOTICE:
Changes or modifications made to this equipment
not expressly approved by (manufacturer name) may
void the FCC authorization to operate this
equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV
technician for help.
-18-

FCC/ISED RF Exposure
Information and Statement:
The SAR limit of FCC (ISED) is 1.6 W/kg averaged
over one gram of tissue. Device types: TD-LTE
digital mobile phone (FCC ID:ZLE-RG730) has
also been tested against this SAR limit. The
highest SAR value reported under this
standard during product certification for use at
the ear is 0.910W/kg and when properly worn on
the body is 1.530W/kg. This device was tested
for typical body-worn operations with the back
of the handset kept 10mm from the body. To
maintain compliance with FCC RF exposure
requirements, use accessories that maintain a
10mm separation distance between the user's
body and the back of the handset. The use of belt
clips, holsters and similar accessories should not
contain metallic components in its assembly. The
use of accessories that do not satisfy these
requirements may not comply with FCC RF
exposure requirements, and should be avoided.
-19-
