INSTRUCTIONS AND WARRANTY
MODEL NO. RHI102
RUSSELL HOBBS STEAM, SPRAY AND SURGE IRON

2
Congratulations on purchasing our RUSSELL HOBBS Steam, Spray and Surge Iron.
Each unit is manufactured to ensure safety and reliability. Before using this appliance for
the first time, please read the instruction manual carefully and keep it for future
reference.
IMPORTANT SAFEGUARDS
When using any electrical appliance, basic safety precautions should always be followed
including the following:
1. Please read the instructions carefully before using any appliance.
2. Always ensure that the voltage on the rating label corresponds to the mains
voltage in your home.
3. Incorrect operation and improper use can damage the appliance and cause injury
to the user.
4. The appliance is intended for household use only. Commercial use invalids the
warranty and the supplier can not be held responsible for injury or damage
caused when using the appliance for any other purpose than that intended.
5. Avoid any contact with moving parts.
6. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
7. Children should be supervised to ensure that they do not play with the appliance.
8. Check the power cord and plug regularly for any damage. If the cord or the plug
is damaged, it must be replaced by the manufacturer or a qualified person in
order to avoid an electrical hazard.
9. Do not use the appliance if it has been dropped or damaged in any way. In case
of damage, take the unit in for examination and/or repair by an authorised service
agent
10. To reduce the risk of electric shock, do not immerse or expose the motor
assembly, plug or the power cord to water or any other liquid.
11. Never immerse the unit in water or any other liquid for cleaning purposes.
12. Remove the plug from the socket by gripping the plug. Do not pull on the cord to
disconnect the appliance from the mains. Always unplug the unit when not in
use, before cleaning or when adding or removing parts.

3
13. The use of accessory attachments that are not recommended or supplied by the
manufacturer may result in injuries, fire or electric shock.
14. A short cord is provided to reduce the hazards resulting from becoming
entangled in or tripping over a longer cord.
15. Do not let the cord hang over the edge of a table or counter. Ensure that the cord
is not in a position where it can be pulled on inadvertently.
16. Do not allow the cord to touch hot surfaces and do not place on or near a hot gas
or electric burner or in a heated oven.
17. Do not use the appliance on a gas or electric cooking top or over or near an open
flame.
18. Use of an extension cord with this appliance is not recommended. However, if it
is necessary to use an extension lead, ensure that the lead is suited to the power
consumption of the appliance to avoid overheating of the extension cord,
appliance or plug point. Do not place the extension cord in a position where it can
be pulled on by children or animals or tripped over.
19. This appliance is not suitable for outdoor use. Do not use this appliance for
anything other than its intended use.
20. DO NOT carry the appliance by the power cord.
21. Do not leave this appliance unattended during use. Always unplug the unit when
not in use or before cleaning.
22. Always operate the appliance on a smooth, even, stable surface. Do not place
the unit on a hot surface.
23. Ensure that the switch is in the “Off” position after each use.
24. The manufacturer does not accept responsibility for any damage or injury caused
by improper or incorrect use, or for repairs carried out by unauthorised
personnel.
25. In case of technical problems, switch off the machine and do not attempt to repair
it yourself. Return the appliance to an authorised service facility for examination,
adjustment or repair. Always insist on the use of original spare parts. Failure to
comply with the above mentioned pre-cautions and instructions, could affect the
safe operation of this machine.

4
ADDITIONAL SAFEGUARDS
Always unwind and straighten the power cord before use.
Disconnect the iron from the mains supply outlet when filling with water.
Remove the water remaining in the water tank when finished using the iron. Be
careful, this water may be hot.
Do not leave the iron unattended when it is connected to the mains supply outlet.
Do not add perfumed, vinegar or other chemical liquids into the water tank, they
can damage the iron.
Do not roll the power cord around the iron for storage until it has cooled down
completely.
PARTS DIAGRAM
1. Soleplate
2. Temperature Dial
3. Temperature Dial Pointer
4. Pilot Light
5. Water Inlet Hole
6. Spray Nozzle
7. Steam Control/Self-Cleaning
Knob
8. Spray Button
9. Burst of Steam Button

5
OPERATING INSTRUCTIONS
HINTS FOR IRONING:
Sort out the articles to be ironed into groups according to the type of fabric. This
will minimise the frequency of temperature adjustment for different garments.
Test the iron on a small area or on the back or inside of the garment if you are
unsure about the type of fabric. Start with a low temperature and gradually
increase the temperature.
Wait for about three minutes after adjusting the temperature before ironing heat
sensitive fabrics. Temperature adjustments need a certain time to reach the
required level, no matter if it is lower or higher.
Delicate fabrics such as silk, wool, velour, etc are best ironed with an ironing
cloth cover to prevent shine marks.
You may need to press the spray button a few times in order to activate the spray,
burst and vertical burst functions.
Heating up is quicker than cooling down, so being ironing the clothes which
require a lower ironing temperature first (Synthetic fibre fabric and silk) and then
iron other clothes of different material that require a higher temperature in the
correct order (Wool, cotton and linen).
READ THE GARMENT LABELS AND FOLLOW THE MANUFACTURER’S IRONING
INSTRUCTIONS THAT ARE OFTEN SHOWN BY SYMBOLS SIMILAR TO THE
FOLLOWING:
TEMPERATURE CONTROL SETTING
Acetate
Elastene
Polyamide
Polypropylene
Cupro
Polyester
Protein
Silk
Triacetate
Viscose
Wool
Cotton
Linen

6
HOW TO FILL WITH WATER:
Note: It is recommended to use purified or mineral water.
Disconnect the iron from the mains supply outlet.
Turn the Steam Control / Self-Cleaning Knob to the
position.
Fill water through the Water Inlet Hole.
Fill up to the Max level of the water tank.
BEFORE USING YOUR IRON FOR THE FIRST TIME:
Clean the water tank and the steam vents on the soleplate to remove dust which
may have accumulated during the manufacturing process.
Some vapour may be given off when the iron is first used. This is safe and will
stop after a short time.
Remove protective wrappings and labels from the soleplate and clean it with a
soft, damp cloth.
Fill the iron as described in the HOW TO FILL WITH WATER section.
Place the iron on its heel and connect the iron to a suitable mains supply outlet.
Turn the Temperature Dial to the ‘●●●’ position – the pilot light will start to glow.
The pilot light goes off when the required temperature is reached.
Turn the Steam Control / Self-Cleaning Knob to the position. Steam will start
to come out of the holes in the soleplate.
Begin first time ironing with an old towel or old cotton garment.
When the water tank is empty and there is no more steam being produced then
the preparation work is complete and the iron is ready for proper use.
DRY IRONING:
Connect the iron to a suitable mains supply outlet.
Turn the Temperature Dial in a clockwise direction to select ‘●’, ‘●●’ or ‘●●●’
according to the recommendation of the garment label.
Move the Temperature Dial in an anti-clockwise direction to ‘Min’ when ironing is
complete to switch the iron off.
Disconnect the iron from the mains supply outlet.

7
SPRAY FUNCTION:
This function can be used at any time and it does not affect the ironing
temperature.
Fill the iron as described in the HOW TO FILL
WITH WATER section.
Aim the nozzle at the garment.
Press the Spray Button.
Please Note: It may be necessary to press the spray button a few times to start this
function.
STEAM FUNCTION:
Fill the iron as described in the HOW TO FILL WITH WATER section.
Turn the Temperature Dial in a clockwise direction to the ‘●●●’ setting.
Please Note: Do not use the ‘●’ or ‘●●’ setting for steam ironing.
When the pilot light turns off the required temperature has been reached and the
iron is ready for use.
Rotate the Steam Control / Self-Cleaning Knob backwards for more steam or
rotate it forwards for less steam. Alternatively, rotate the knob to the position
for no steam.
BURST OF STEAM FUNCTION:
This function provides extra steam to remove stubborn
wrinkles.
Fill the iron as described in the HOW TO FILL WITH
WATER section.
Turn the Temperature Dial in a clockwise direction to
the ‘●●●’ setting.
Press the Burst of Steam Button once.
Steam will penetrate into the garment to remove the wrinkles.
Wait a few seconds before pressing the Burst of Steam Button again.
Usually all wrinkles can be removed within three presses.
Please Note: It may be necessary to press the Burst of Steam Button a few times to
start this function.

8
Please Note: for optimum steam quality, do not operate the Burst of Steam Button
more than three times after the pilot light goes off.
VERTICAL BURST OF STEAM FUNCTION:
Warning: Do not apply steam to any clothes or fabrics while they are being worn by
humans or pets. The temperature of the steam is very high and may cause burns.
This function provides extra steam to remove wrinkles from delicate garments in
a hanging position, hanging curtains or other hanging
fabrics.
Fill the iron as described in the HOW TO FILL WITH
WATER section.
Turn the Temperature Dial in a clockwise direction to the
‘●●●’ setting.
Hold the iron between 15 and 30 centimetres away from
the hanging garment or fabric.
Press the Burst of Steam Button once.
Steam will penetrate into the garment removing the wrinkles.
For stubborn wrinkles wait a few seconds before pressing the Burst of Steam
button again.
Usually all wrinkles can be removed within three presses.
Please Note: It may be necessary to press the Burst of Steam Button a few times to
start this function.
Please Note: for optimum steam quality, do not operate the Burst of Steam Button
more than three times after the pilot light goes off.
SELF CLEANING FUNCTION:
This function removes the scales and mineral build-up in the Steam Chamber.
The iron will remain in the best condition if this function is performed at least
once a month or more regularly, depending on the hardness of the water being
used.
Fill the iron as described in the HOW TO FILL WITH WATER section. Fill the
tank to halfway full.
Place the iron on a stable surface in an upright standing position.
Connect the iron to the mains supply outlet.

9
Turn the Temperature Dial in a clockwise direction to the ‘●●●’ setting.
The pilot light will turn on to indicate that the iron is switched on. When the
required temperature is reached, the pilot light will turn off.
Wait for the pilot light to turn on and off once more.
Turn the Temperature Dial in an anti-clockwise direction to the Min mark.
Disconnect the iron from the mains supply outlet.
Hold the iron horizontally over a sink.
Rotate and hold the Steam Control / Self Cleaning Knob to the descaling
position.
Please Note: Steam and boiling hot water will emit from the holes in the soleplate
washing away the scales and minerals deposited in the Steam Chamber. Keep
skin/body away from the steam and hot water.
Gently move the iron back and forth until the water tank is empty.
When the Self-Cleaning is complete, release the Steam Control / Self-Cleaning
Knob and return it to the no steam position.
Place the iron on a stable surface in an upright standing position and allow the
iron to cool down completely.
Wipe the soleplate with a cool, damp cloth.
DRAINING THE WATER TANK:
Draining the water tank after ironing can prolong the life of your iron as it reduces
the build-up of calcification and lime in the steam chamber.
Disconnect the iron from the mains supply outlet.
Turn the Steam Control / Self-Cleaning Knob to the
position.
Press the Burst of Steam and Spray buttons to release
any reserve water.
Hold the iron upside down and gently shake it to
remove the water remaining in the water tank.
Please Note: Set the Steam Control Knob to the position before storing the iron.

10
CLEANING AND MAINTENANCE
Disconnect the iron from the mains supply outlet.
Use a damp cloth or non-scratching cleaner to remove any deposits on the
soleplate or the cabinets
Never use sharp or rough objects to remove the deposits on the soleplate.
Never use any abrasive, vinegar or descaling agents to clean the iron.
It is recommended to store the iron in an upright position.
Use the Self-Cleaning function at least once a month.
Clean the Steam Valve regularly.
This appliance is for household use only and is not user-serviceable.
Do not open or change any parts by yourself. Please refer to a qualified electrical
service department or return to the supplier if servicing is necessary.
Always remember to unplug the unit from the electrical outlet when not in use
and before cleaning. Ensure that the speed control is set to “0”.
It is much easier to clean the accessories directly after they have been used.
Wash them in warm, soapy water, rinse and dry well.
The body of the appliance and the stand should be cleaned with a damp cloth.
Do not let water enter the appliance or the stand.
Do not use bleach or other abrasive substance or solvents to clean your
appliance as it can be damaging to the finish.
Do not immerse the appliance in water or any other liquid, or hold it under a
running tap to clean.
To remove stubborn spots/marks, wipe the surfaces with a cloth slightly
dampened in soapy water or mild non-abrasive cleaner. Rinse and dry a clean,
dry, soft cloth.
STORING THE APPLIANCE
Unplug the unit from the wall outlet and clean all the parts as instructed above.
Ensure that all parts are dry before storing.
Store the appliance in its box or in a clean, dry place.
Never store the appliance while it is still wet or dirty.
Never wrap the power cord around the appliance.
