INSTRUCTIONS AND WARRANTY
MODEL NO. RHCT01-W
RUSSELL HOBBS COOL TOUCH KETTLE

2
Congratulations on purchasing our RUSSELL HOBBS COOL TOUCH KETTLE. Each
unit is manufactured to ensure safety and reliability. Before using this appliance for the
first time, please read the instruction manual carefully and keep it for future reference.
PARTS DESCRIPTION
1. Kettle lid
2. Spout
3. Kettle body
4. Power base
5. Lid release button
6. Handle
7. Switch
8. Power cord

3
IMPORTANT SAFEGUARDS
When using any electrical appliance, basic safety precautions should always be followed
including the following:
1. Please read the instructions carefully before using any appliance.
2. Always ensure that the voltage on the rating label corresponds to the mains
voltage in your home.
3. Incorrect operation and improper use can damage the appliance and cause injury
to the user.
4. The appliance is intended for household use only. Commercial use invalidates
the warranty and the supplier cannot be held responsible for injury or damage
caused when using the appliance for any other purpose than that intended.
5. Avoid any contact with moving parts.
6. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
7. Children should be supervised to ensure that they do not play with the appliance.
8. Check the power cord and plug regularly for any damage. If the cord or the plug
is damaged, it must be replaced by the manufacturer or a qualified person in
order to avoid an electrical hazard.
9. Do not use the appliance if it has been dropped or damaged in any way. In case
of damage, take the unit in for examination and/or repair by an authorised service
agent.
10. Do not open the lid while the kettle is in use.
11. Only fill the kettle with cold water. Do not fill the kettle above the MAX level (1.7L)
otherwise boiling water may splash out if overfilled.
12. Unplug from outlet when not in use and before cleaning. Allow it to cool down
completely before cleaning the appliance.
13. Do not insert any objects into holes or slots in this appliance.
14. To reduce the risk of electric shock, do not immerse or expose the motor
assembly, plug or the power cord to water or any other liquid.
15. Never immerse the unit in water or any other liquid for cleaning purposes. Do not
allow liquid to penetrate into the electrical parts of this kettle.

4
16. Remove the plug from the socket by gripping the plug. Do not pull on the cord to
disconnect the appliance from the mains. Always unplug the unit when not in
use, before cleaning or when adding or removing parts.
17. The use of accessory attachments that are not recommended or supplied by the
manufacturer may result in injuries, fire or electric shock. The kettle is only to be
used with the base provided.
18. A short cord is provided to reduce the hazards resulting from becoming
entangled in or tripping over a longer cord.
19. Do not let the cord hang over the edge of a table or counter. Ensure that the cord
is not in a position where it can be pulled on inadvertently.
20. Do not allow the cord to touch hot surfaces and do not place on or near a hot gas
or electric burner or in a heated oven.
21. Cleaning and user maintenance shall not be made by children unless they are
older than 8 years and supervised. Keep the appliance and its cord away from
reach of children aged less than 8 years old.
22. Keep the device and the cable away from heat, direct sunlight, moisture, sharp
edges and the like.
23. Do not use the appliance on a gas or electric cooking top or over or near an open
flame.
24. Use of an extension cord with this appliance is not recommended. However, if it
is necessary to use an extension lead, ensure that the lead is suited to the power
consumption of the appliance to avoid overheating of the extension cord,
appliance or plug point. Remember to not place the extension cord in a position
where it can be pulled on by children or animals or tripped over.
25. This appliance is not suitable for outdoor use. Do not use this appliance for
anything other than its intended use.
26. DO NOT carry the appliance by the power cord.
27. Do not leave this appliance unattended during use. Always unplug the unit when
not in use or before cleaning.
28. Always operate the appliance on a smooth, even, stable surface. Do not place
the unit on a hot surface.
29. Ensure that the switch is in the “Off” position after each use.

5
30. The manufacturer does not accept responsibility for any damage or injury caused
by improper or incorrect use, or for repairs carried out by unauthorised
personnel.
31. In case of technical problems, switch off the machine and do not attempt to repair
it yourself. Return the appliance to an authorised service facility for examination,
adjustment or repair. Always insist on the use of original spare parts. Failure to
comply with the above mentioned pre-cautions and instructions, could affect the
safe operation of this machine.
32. Do not touch hot surfaces. Use the handle and lid knob.
33. Take care when pouring –pour slowly, and don’t over-tilt the kettle.
34. Wind excess cable beneath the base.
35. Check that the lid is fully closed before switching the kettle on - otherwise it may
not switch off.
36. Check the kettle is properly located on the base before switching on.
37. Do not switch on unless the kettle contains at least 2 cups of water.
38. Do not fill past the MAX level, or it may eject boiling water.
39. Remove the kettle from its stand before filling or pouring.
40. This appliance must not be operated by an external timer or remote control
system.

6
OPERATING INSTRUCTIONS
PREPARATION FOR USE
Carefully remove your kettle from the box. You may wish to retain the packaging for
further use.
BEFORE USING THE KETTLE FOR THE FIRST TIME
Before first use, fill the kettle with cold water to the MAX water level mark, bring
to boil and discard the boiling water –do this twice. This will ensure that any
residues left over from the manufacturing process are completely removed.
POSITIONING THE KETTLE
Position the power base on a dry flat surface away from any potential heat
source.
The underside of the power base is fitted with a cable storage feature. Unwind
the length of the mains cable required to reach the mains socket.
Ensure the mains cable does not hang over the work surface edge.
FILLING THE KETTLE
Remove the kettle from the power base.
Open the lid by pressing the lid release button.
Fill the kettle between the MIN and MAX markings on the water level indicator
with cold water.
Close the lid and place the kettle back on the power base. Make sure the lid is
securely closed before boiling.
Always remove the kettle from the power base before filling. Do not fill the kettle
above the MAX mark or below the MIN mark on the water gauge.
SWITCHING ON
Position the kettle on the power base.
Plug the kettle into a mains supply socket.
To start boiling the water, press the on/off switch down to “1” (on) position.
The power indicator light will illuminate and the kettle will start to boil.
Never open the lid during boiling.

7
Do not operate this kettle without the filter fitted.
Please beware of escaping steam from the lid of the kettle when in use.
USAGE STEPS
Put the power base on a flat table.
Push the button lightly to open the lid and fill in a proper amount of water. Close
the lid and put the kettle on the power base.
Connect the power cord into a 220-240V power outlet.
Move the switch to the “ON” position. The indicating light will go on indicating that
the heating and boiling process has begun.
Once the water has boiled, the switch will move to the “OFF” position. Disconnect
the kettle from the power supply and the indicating light will go off.
To keep water inside the kettle warm - push the button for keeping warm. The
kettle comes into heat insulation and the corresponding light goes on. The
temperature for the boiled water with maximum capacity is no less than 65° after
two hours of heat insulation.
During boiling, you can move the switch to the “OFF” mark with your hand to cut
the power supply.
Pour out the water only after you have lifted the kettle from the base.
The kettle can be put on the power base but with power supply disconnected
after using.
DOUBLE DRY HEATING PROTECTION
If you have forgotten to add water or the water inside is below the minimum
accepted level, the metal sheet for dry heating protection of the temperature
controller will disconnect automatically when the kettle is switched on in order to
protect the kettle from being damaged by dry heating.
If the above situation happens, please turn off the power supply, unplug the kettle
and wait 10 minutes for it to cool down. Once this is done, the temperature
controller connects and the kettle will operate normally again.
Note: Do not add cold water in the kettle in an attempt to cool it down quicker –this will
decrease the life span of the kettle’s heating plate.

8
SWITCHING OFF
When the water has boiled, the kettle will switch off automatically. You can stop
the boiling process at any time by lifting the on/off switch to the “0” (off) position
or lifting the kettle off the base.
GENERAL
Always remove the kettle from the base before pouring.
To avoid the risk of splashing, pour slowly and do not over-tilt the kettle.
Do not tilt the kettle backwards - water might get on to the control area. If this
happens, let the kettle dry thoroughly before use –place it somewhere warm for
12 hours.
When you lift the kettle, you may see moisture on the base. Do not worry –it’s
the steam used to switch the kettle off automatically, which then condenses and
escapes via vents under the kettle.
You may see some discolouration on the floor of the kettle. Again, do not worry –
it is due to the bonding of the element to the kettle floor.
CLEANING AND MAINTENANCE
This appliance is for household use only and is not user-serviceable.
Do not open or change any parts by yourself. Please refer to a qualified electrical
service department or return to the supplier if servicing is necessary.
Always remember to unplug the unit from the electrical outlet when not in use
and before cleaning.
Do not immerse the appliance in water or any other liquid, or hold it under a
running tap to clean.
To remove stubborn spots/marks, wipe the surfaces with a cloth slightly
dampened in soapy water or mild non-abrasive cleaner. Rinse and dry with a
clean, dry, soft cloth.
Unplug the base from the wall socket, and let the kettle cool down before
cleaning.
Wipe the kettle, inside and out, with a damp cloth. You may use a little household
detergent, but if you do, rinse well to avoid tainting the water.
Wipe the stand with a damp cloth.

9
Keep all connectors and sockets dry.
Do not immerse the kettle or kettle base in liquid.
Do not use harsh or abrasive cleaning agents or solvents.
We recommend that you descale your kettle regularly, even in soft water areas. Lime
scale may be white, coloured, or even rusty-looking, but it is normally visible. Phosphate
scale is not generally visible, but there is always a build-up, even in soft water areas.
Any build-up of scale causes overheating, which reduces the life of the element, and
may trigger the boil-dry cut-out to engage. So, even in a soft water area, descale at least
monthly, to help keep your kettle in working order.
To descale your kettle:
Use a descaler suitable for plastic products (all kettles have plastic parts). Follow
the instructions on the descaler, then rinse several times, fill, boil and discard the
water, to remove all chemical residues.
Products returned under guarantee with faults related to scale will be subject to a
repair charge.
If you notice your kettle getting noisier –descale it.
Do not rely on visible scale, as phosphate scale is not visible. Rather descale the
kettle for preventative purposes.
Do not try to move or remove the diffuser –you will break it.
Water filter:
Scale particles suspended in the water may give it a cloudy or greasy
appearance.
The filter will prevent these particles going into your drink. If you see deposits on
the filter, clean it, otherwise the performance of your kettle will drop, your drinks
may contain scale, and the water inside the kettle may look cloudy.
Cleaning the filter:
The filter is located inside the kettle behind the spout.
With the lid open, gently pull the filter out of its retaining slot.
Lift the filter out of the kettle.

10
Rinse the filter in warm water and gently remove any scale with a soft brush.
To replace the filter, slide it down into its slot until it clicks into place.
Removing mineral deposits
Decalcification refers to removing the calcium deposits which may form on the
interior metal parts of the kettle.
To get the best performance from your kettle, descale your kettle from time to
time. Frequency depends on the hardness of your tap water and how often you
use the kettle.
We suggest use of a kettle descaler in order to dissolve chalky deposits or scale.
Follow the directions on the descaler package. If a commercial descaler is not
available, fill the kettle with enough white vinegar to cover the bottom by about
1.5cm. Bring the vinegar to a boil. You may need to repeat this several times with
cooled vinegar to remove the calcium build-up completely. When the descaling
process is complete, empty the kettle and rinse out several times with clean
water.
STORING THE APPLIANCE
Unplug the unit from the wall outlet and clean all the parts as instructed above.
Ensure that all parts are dry before storing.
Store the appliance in its box or in a clean, dry place.
Never store the appliance while it is still wet or dirty.
Never wrap the power cord around the appliance.
SERVICING THE APPLIANCE
There are no user serviceable parts in this appliance. If the unit is not operating
correctly, please check the following:
You have followed the instructions correctly
That the unit has been wired correctly and that the wall socket is switched on.
That the mains power supply is ON.
That the plug is firmly in the mains socket.
If the appliance still does not work after checking the above:
