Ryobi RBL3600 User manual

RBL3600
ORIGINAL INSTRUCTIONS
36V Cordless
Blower

Important!
It is essential that you read the instructions in this manual before assembling,
operating and maintaining the product.
Subject to technical modification.

1
Safety, performance, and dependability have
been given top priority in the design of your
cordless blower.
INTENDED USE
The cordless blower is intended only for
outdoor use, in dry, and well-illuminated
conditions.
The product is not intended to be used by
children or persons with reduced physical,
mental, or sensory capabilities.
The product is designed for blowing light
debris, such as leaves, grass, and other
garden refuse.
Do not use the product for any other purpose.
GENERAL SAFETY WARNINGS
WARNING
When using the product, the safety rules
must be followed. For your own safety
and that of bystanders, you must read
and fully understand these instructions
before operating the product. Keep these
instructions safe for later use.
WARNING
This product is not intended to be used by
children or persons with reduced physical,
mental, or sensory capabilities. Children
should be adequately supervised to ensure
that they do not play with the product.
TRAINING
■Read the instructions carefully. Be familiar
with the controls and the correct use of the
product.
■Never allow children, persons with reduced
physical, sensory or mental capabilities
or lack of experience and knowledge,
or people who are unfamiliar with these
instructions to use the product. Local
regulations may restrict the age of the
operator.
■Keep in mind that the operator or user
is responsible for accidents or hazards
occurring to other people or their property.
■Keep bystanders, children and pets 15 m
away from the area of operation. Stop the
product if anyone enters the area.
■Never use the product while tired, ill or
under the influence of alcohol, drugs or
medication.
PREPARATION
■Some regions have regulations that restrict
the use of the product to some operations.
Check with your local authority for advice.
■While operating the product, always wear
substantial footwear and long trousers.
Do not operate the product when barefoot
or wearing open sandals. Avoid wearing
clothing that is loose-fitting or that has
hanging cords or ties; they can be caught
in moving parts.
■Do not wear loose clothing or jewellery that
can be drawn into the air inlet.
■Secure long hair so that it is above shoulder
level to prevent entanglement in moving
parts.
■Wear hearing protection at all times while
operating the product. The product is noisy,
and may cause permanent hearing injury if
precautions to limit your exposure and to
reduce noise are not strictly adhered to.
■Wear full eye protection at all times while
operating this product. Wear a full face
mask or fully enclosed goggles. Normal
spectacles or sun glasses are not adequate
protection. Objects can be thrown at high
speed by the powerful air jet at any time
and may rebound from hard surfaces
toward the operator.
■Ensure before each use that all controls
and safety devices function correctly. Do
not use the product if the OFF switch does
not stop the product.
■Before each use, always inspect the
housing for damage. Ensure that guards
and handles are in place and properly
secured.
■Return the product to an authorised service
centre to replace damaged or unreadable
labels.
■Never operate the product with defective
guards or shields, or without safety devices
in place.
■Keep all cooling air inlets clear of debris.
■Use rakes and brooms to loosen debris
before blowing.

2
■Clear the work area before each use.
Remove all objects, such as rocks, broken
glass, nails, wires, or string which can be
blown a considerable distance by high
velocity air.
■Operate the product on a firm, level surface
only.
BATTERY TOOL USE AND CARE
■Recharge only with the charger specified
by the manufacturer. A charger that is
suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.
■Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury
and fire
■When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together
may cause burns or a fire.
■Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
OPERATION
■Operate the product only at reasonable
hours – not early in the morning or late at
night when people might be disturbed.
■Never operate the product in an explosive
atmosphere.
■Avoid using the product in bad weather
conditions especially when there is a risk
of lightning.
■Do not operate the product in poor lighting.
The operator requires a clear view of the
work area to identify potential hazards.
■The use of hearing protection reduces the
ability to hear warnings (shouts or alarms).
The operator must pay extra attention to
what is going on in the working area.
■Do not get distracted and always
concentrate on the task.
■Operating similar tools nearby increases
both the risk of hearing injury and the
potential for other persons to enter the
working area.
■Keep firm footing and balance. Do not
overreach. Overreaching can result in loss
of balance.
■Always be sure of the footing on slopes.
Walk, never run.
■Keep all parts of the body away from any
moving part. Rotating impeller blades can
cause severe injury.
■Never run the product without the proper
equipment attached.
■Do not modify the product in any way or
use parts and accessories which are not
recommended by the manufacturer.
WARNING
If the product is dropped, su󰀨ers heavy
impact, or begins to vibrate abnormally,
immediately stop the product and inspect
for damage or identify the cause of the
vibration. Any damage should be properly
repaired or replaced by an authorised
service centre.
WARNING
The product may be supplied with a harness.
Carefully adjust the harness to comfortably
help you in supporting the weight of the
product.
Identify the quick-release mechanism and
practice using it before you start using the
product. Its correct use may prevent serious
injury in the case of an emergency. Never
wear additional clothing over the harness or
otherwise restrict access to the quick-release
mechanism.
■To reduce the risk of injury associated
with contacting rotating parts, always stop
the product, remove the battery pack, and
make sure all moving parts have come to
a stop:
●before cleaning or clearing a blockage
●when leaving the product unattended
●before installing or removing
attachments
●before checking, maintaining, or working
on the product
●to inspect the product for damage after
striking a foreign object

3
●if the product starts to vibrate abnormally
(inspect immediately)
■Immediately turn off the product and
remove the battery pack in the event of
accident or breakdown. Do not operate
the product again until it has been fully
checked by an authorised service centre.
BLOWER SAFETY WARNINGS
■Wear a face filter mask in dusty conditions
to reduce the risk of injury associated with
the inhalation of dust.
■Slightly dampen surfaces in dusty
conditions.
■Do not point the blower nozzle in the
direction of people or pets.
■Never place objects inside the blower
tubes.
■Do not operate the product near open
windows.
■Use the full blower nozzle extension so that
the air stream can work close to the ground
and perform effectively.
■Do not place the product on top of or near
loose debris. Debris can be sucked into the
intake vent, resulting in possible damage
to the product.
ADDITIONAL BATTERY SAFETY
WARNINGS
WARNING
To reduce the risk of re, personal injury,
and product damage due to a short circuit,
never immerse the product, battery pack or
charger in uid or allow uid to ow inside
them. Corrosive or conductive uids, such
as seawater, certain industrial chemicals,
and bleach or bleach-containing products,
etc., can cause a short circuit.
TRANSPORTATION AND STORAGE
■Stop the product, remove the battery pack,
and allow it to cool down before storing or
transporting.
■Clean all foreign materials from the product.
Store the product in a cool, dry, and well-
ventilated place that is inaccessible
to children. Keep the product away
from corrosive agents, such as garden
chemicals and de-icing salts. Do not store
the product outdoors.
■For transportation in vehicles, secure the
product against movement or falling to
prevent injury to persons or damage to the
product.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local
and national provisions and regulations.
Follow all special requirements on packaging
and labelling when transporting batteries by a
third party. Ensure that no batteries can come
in contact with other batteries or conductive
materials while in transport by protecting
exposed connectors with insulating, non-
conductive caps or tape. Do not transport
batteries that are cracked or leaking. Check
with the forwarding company for further
advice.
MAINTENANCE
WARNING
Use only original manufacturer’s
replacement parts, accessories, and
attachments. Failure to do so can cause
possible injury, can contribute to poor
performance, and may void the warranty.
WARNING
Servicing requires extreme care and
knowledge and should be performed only
by a qualied service technician. Have the
product serviced by an authorised service
centre. When servicing, use only original
replacement parts.
■Do not make adjustments and repairs not
described in this manual. For other repairs,
contact an authorised service agent.
■After each use, clean the product with a
soft, dry cloth.
■Check all nuts, bolts, and screws at
frequent intervals for proper tightness to
ensure that the product is in safe working
condition. Any part that is damaged should
be properly repaired or replaced by an
authorised service centre.
■Bring the product to an authorised service
centre to replace damaged or unreadable
labels.

4
CLEARING A BLOCKAGE
■To reduce the risk of injury associated with
contacting moving parts, always turn off
the product, remove the battery pack, and
make sure that all moving parts have come
to a complete stop.
■Remove the blower tubes to inspect for
blockage. Clear the tubes if required.
■Reinstall the blower tubes before starting
the product.
WHAT’S IN THE BOX
■1 x Blower assembly
■1 x Blow tube
■1 x High speed nozzle
■1 x Manual
SYMBOLS ON THE PRODUCT
Read and understand all
instructions before operating
the product. Follow all warnings
and safety instructions.
Do not expose to rain or damp
conditions.
Wear ear protection.
Wear eye protection.
Beware of thrown or ying
objects. Keep all bystanders at
least 15 m away.
Rotating Fans. Keep hands and
feet out of the openings while
the product is running.
Remove the battery before
starting any work on the
product.
97
Guaranteed sound power level
Regulatory Compliance
Mark (RCM). This product
meets applicable regulatory
requirements.
Waste electrical products
should not be disposed of
with household waste. Please
recycle where facilities exist.
Check with your Local Authority
or retailer for recycling advice.
SYMBOLS IN THIS MANUAL
Note
Warning
Parts or accessories sold
separately
The following signal words and meanings
are intended to explain the levels of risk
associated with this product.
DANGER
Indicates an imminently hazardous
situation, which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a potentially hazardous situation,
which, if not avoided, could result in death
or serious injury.
CAUTION
Indicates a potentially hazardous situation,
which, if not avoided, may result in minor or
moderate injury.
CAUTION
Without safety alert symbol
Indicates a situation that may result in
property damage.

5

6
WHAT’S IN THE BOX
x 1
x 1
x 1
RBL3600
x 1

7
Know your product
KNOW YOUR PRODUCT
67 5 4
1
2
11
10
3
8
9
1. Handle
2. Variable speed trigger
3. Blow tube
4. Charger (sold separately)
5. Battery pack (sold separately)
6. Battery latch button
7. High speed nozzle
8. Blow tube outlet
9. Nozzle tab
10. Blower housing outlet
11. Tube latch

8
GETTING STARTED
1
2
1
3
2
Wear full eye and ear protection, substantial footwear, and
long trousers at all times while operating the product. Do
not operate the product when barefoot or wearing open
sandals.
Insert the high-speed nozzle into the blow tube outlet until it
clicks into place. Insert the blow tube into the product until
it clicks into place.
Insert the battery pack until it clicks into place. Press the
variable speed trigger to operate the product.
Hold the handle with your right hand and point to the
intended area of operation.

9
OVERVIEW
p.10 p.11
p.12
Using the blower Cleaning the blower
Storing the blower

10
OPERATION
2
1
USING THE BLOWER
1. Insert the battery pack until it clicks into
place.
2. Press the trigger to turn on the product.
Let the air stream work close to the
ground.
WARNING! Do not use the product without
the blower tube securely attached.

11
MAINTENANCE
2
1
1
2
CLEANING THE BLOWER
1. Press the battery latch button, and
remove the battery pack.
2. Clean the blower using a brush.
WARNING! Avoid using solvents when
cleaning plastic parts. Most plastics are
susceptible to damage from various types of
commercial solvents and may be damaged
by their use. Use a clean brush to remove
dirt, dust, lubricant, grease, etc.

12
STORAGE
2
1
2
1
2
1
3
20201026v3d5
STORING THE BLOWER
1. Press the battery latch button, and
remove the battery pack.
2. Press the blow tube latch and remove
the blow tube.
3. Store the product in a cool, dry, and
well-ventilated place that is inaccessible
to children.

PRODUCT SPECIFICATIONS
36V Cordless blower
Model RBL3600
Rated voltage 36 V
Maximum air velocity 264 km/h
Weight ( without battery)
1.90 kg
Weight ( with heaviest battery) 4.7 kg
Vibration level (in accoordance with Annex BB of
EN 50636-2-100:2014)
Vibration total value ah= 0.3 m/s2
Uncertainty of measurement K= 1.5 m/s2
Noise emission level (in accordance with Annex CC of
EN 50636-2-100:2014)
A-weighted sound pressure
level at operator’s position
LPA = 80.8 dB(A)
Uncertainty of measurement K= 2.5 dB
A-weighted sound power level LWA = 94.0 dB(A)
Uncertainty of measurement K= 2.5 dB
BATTERY AND CHARGER
Model RBL3600
Battery pack not included
Weight -
Charger not included
Weight -
Compatible battery pack
BPL3620D, BPL3640D2,
BPL3650D2, BPL3660D.
BPL3690D, BPL3612D
Compatible charger BCL3660F, BCL3617U, BCL3617S
VIBRATION LEVEL
The declared vibration total values and the
declared noise emission values given in this
instruction manual have been measured
in accordance with a standardised test
and may be used to compare one tool with
another. They may be used for a preliminary
assessment of exposure.
The declared vibration and noise emission
values represent the main applications of the
tool. However, if the tool is used for di󰀨erent
applications, used with di󰀨erent accessories,
or poorly maintained, the vibration and noise
emission may di󰀨er. These conditions may
signicantly increase the exposure levels over
the total working period.
An estimation of the level of exposure to
vibration and noise should take into account
the times when the tool is turned o󰀨 or when
it is running idle. These conditions may
signicantly reduce the exposure level over
the total working period.
Identify additional safety measures to protect
the operator from the e󰀨ects of vibration and
noise, such as maintaining the tool and the
accessories, keeping the hands warm (in case
of vibration), and organising work patterns.

RYOBI is a trade mark of Ryobi Limited,
and is used under license.
© 2017-20 Techtronic Cordless GP.
Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley, VIC 3149,
Melbourne, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
Imported by:
960746013-01
