RYOBI 10 in. DRILL PRESS – MODEL NUMBER DP102L
2
60
61
62
63
64
66
21
2368
69
106
105
SEE NOTE
77
78
70
65
67
59
98
43
42
41
39
40
39
38
37
36
8
9
10
11 12
19
22
23
24
21
28
27
26 20
106
25
92
89
88
87
86
85
84
83
82
80
79
76
72
21
71
21
91
75
74
73
81
35
45
34
2346 47
51
21
52 53 54
100
44
34 33
32
48
49
104
34
96
17
55
55
90
50
15
16
58
57
90
90
34
97
99
56
93
31
94
95
101
30
29
18
13
14
7
6
5
4
3
2
1
102
103
NOTE: The assembly shown represents an important part of the double insulated system. To avoid
the possibility of alteration or damage to the system, service should be performed by your nearest
Ryobi Authorized Service Center. For the service center nearest you call 1-800-525-2579.

RYOBI 10 in. DRILL PRESS – MODEL NUMBER DP102L
3
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your DRILL PRESS or when ordering repair parts.
PARTS LIST FOR FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 13103006M1 CHUCK KEY............................................................................ 1
2 13103006M CHUCK.................................................................................... 1
3 13203001A SPINDLE SHAFT ..................................................................... 1
4 089140200004 BALL BEARING (80201) .......................................................... 1
5 13203002D QUILL TUBE............................................................................ 1
6 13303006 QUILL GASKET ....................................................................... 1
7 TDP02001 BALL BEARING (60201) .......................................................... 1
8 TDP10001 RETAINING RING (11) ............................................................. 1
9 16101013A TABLE LOCK HANDLE............................................................ 1
10 13201014D TABLE...................................................................................... 1
11 TDP05001 * BOLTS (M12 X 25 mm HEX HD.)............................................. 1
12 TDP01001 * BOLTS (M8 X 20 mm HEX HD.)............................................... 4
13 13201002 BASE COLLAR ........................................................................ 1
14 089140200014 BASE ....................................................................................... 1
15 089140200015 CLIP......................................................................................... 1
16 089140200016 BALL........................................................................................ 1
17 089140200102 WASHER ................................................................................. 2
18 13201003 COLUMN TUBE ...................................................................... 1
19 13201010 RACK....................................................................................... 1
20 089140200097 COLUMN COLLAR.................................................................. 1
21 TDP03001 * SCREW (M8 X 10 mm SOC. HD.) ...........................................5
22 089140200022 KNOB ...................................................................................... 1
23 TDP06001 * HEX NUT (M8) ......................................................................... 3
24 089140200024 CRANK .................................................................................... 1
25 089140200025 TABLE SUPPORT.................................................................... 1
26 13201007 GEAR SHAFT .......................................................................... 1
27 13201006 GEAR....................................................................................... 1
28 13201008 WORM GEAR .......................................................................... 1
29 089140200029 ROLL PIN (D4 X 24 mm).......................................................... 1
30 089140200030 ROLL PIN (D2.5 X 16 mm)....................................................... 1
31 089140200031 RUBBER GROMMET .............................................................. 2
32 089140200032 LASER LIGHT.......................................................................... 2
33 TDP08001 TOOTHED LOCK WASHER (M5).............................................2
34 TDP07001 * SCREW (M5 X 6 mm PAN HD.) ............................................... 9
35 089140200035 * SCREW (M5 X 25 mm PAN HD.) ............................................. 1
36 089140200036 * SCREW (M3.5 X 9.5 mm PAN HD.) ......................................... 4
37 089140200037 SWITCH................................................................................... 1
38 TDP10002 RETAINING RING (17) ............................................................. 1
39 089140200039 BALL BEARING (60203) .......................................................... 2
40 13302023A SPACER .................................................................................. 1
41 089140200041 PULLEY INSERT ..................................................................... 1
42 089140200042 RETAINING RING (22) ............................................................. 1
43 089140200043 PULLEY SPINDLE ................................................................... 1
44 089140200044 LIGHT SWITCH ....................................................................... 2
45 089140200045 SWITCH BOX ......................................................................... 1
46 13202021 SPECIAL SET SCREW ............................................................ 1
47 089140200047 BAFFLE ................................................................................... 1
48 TDP03002 * SCREW (M8 X 8 mm HEX HD.) ............................................... 1
49 089140200049 HEAD STOCK.......................................................................... 1
50 089140200050 BATTERY BOX ........................................................................ 1
51 TDP06002 * HEX NUT (M10) ....................................................................... 2
52 13104008 SPRING CAP........................................................................... 1
53 13104009 TORSION SPRING .................................................................. 1
54 13104007 SPRING RETAINER ................................................................. 1
55 13202014 CORD CLAMP......................................................................... 4

RYOBI 10 in. DRILL PRESS – MODEL NUMBER DP102L
4
56 089140200056 BATTERY BOX CAP ................................................................ 1
57 089140200057 LOCK WASHER (16-1) ............................................................ 4
58 TDP11002 * WASHER (M8) ......................................................................... 2
59 089140200059 GUARD.................................................................................... 1
60 089140200035 * SCREW (M5 X 25 mm PAN HD.) ............................................. 1
61 089140200061 GEMEL .................................................................................... 1
62 089140200062 CLAMP GEMEL....................................................................... 2
63 089140200063 * SCREW (M4.2 X 9.5 mm PAN HD.) ......................................... 4
64 089140200064 SEAT GEMEL........................................................................... 2
65 089140200065 * HEX NUT (M8) ......................................................................... 4
66 089140200066 MOTOR PULLEY..................................................................... 1
67 089140200067 * SCREW (M4 X 8 mm PAN HD.) ............................................... 4
68 089140200068 BELT TENSION KNOB ............................................................ 1
69 089140200069 * SCREW (M8 X 60 mm HEX SOC. HD.) ................................... 1
70 089140200070 MOTOR ADJUST PLATE ......................................................... 1
71 089140200071 * SCREW (M6 X 5 mm HEX SOCKET)....................................... 1
72 089140200072 GEAR....................................................................................... 1
73 089140200073 SHAFT ..................................................................................... 1
74 089140200074 SHAFT SEAT ........................................................................... 1
75 089140200075 RETAINING RING (16) ............................................................. 1
76 089140200076 DEPTH STOP RING ................................................................1
77 089140200103 MOTOR (INC. KEY NO. 105) ................................................... 1
78 13202016 POWER CORD ........................................................................ 1
79 13205007 BELT (K31)............................................................................... 1
80 089140200080 * HEX KEY (3 mm) .....................................................................1
81 TDP04001 * HEX KEY (4 mm) .....................................................................1
82 089140200082 * HEX KEY (5 mm) .................................................................... 1
83 089140200083 KNOB ...................................................................................... 3
84 089140200084 ROD......................................................................................... 3
85 089140200085 HUB......................................................................................... 1
86 089140200086 KNOB DEPTH SCREW............................................................ 1
87 089140200087 * SCREW (M4.2 X 13 mm COUNTERSUNK HD.)...................... 2
88 089140200088 BULB SOCKET WITH NUT ..................................................... 1
89 089140200089 BULB SOCKET-BRACKET ...................................................... 1
90 089140200095 SCREW (M5 X 8 mm PAN HD.) ............................................... 3
91 089140200901 DEPTH SCALE ........................................................................ 1
92 089140200902 BRACKET-SCALE ................................................................... 1
93 089140200903 DEPTH (STROKE) INDICATOR................................................ 1
94 089140200904 WARNING LABEL ................................................................... 1
95 089140200905 LASER WARNING LABEL-1.................................................... 1
96 089140200906 DATA LABEL............................................................................ 1
97 089140200907 LABEL (SPEED CHART-1) ....................................................... 1
98 089140200908 LOGO LABEL .......................................................................... 1
99 089140200910 LABEL (SPEED CHART-2) ....................................................... 1
100 089140200911 LASER WARNING LABEL-2.................................................... 1
101 089140200909 LAMP WATT LABEL ............................................................... 1
102 984406003 SWITCH KEY........................................................................... 1
103 089140200092 VISE (2.5 in.) ............................................................................1
104 089140200912 LASER LABEL ......................................................................... 1
105 089140200094 CAPACITOR (DP102 MOTOR) ................................................1
106 089140200096 WASHER ................................................................................. 5
983000641 OPERATOR’S MANUAL
06-06-08
(REV:05)
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your DRILL PRESS or when ordering repair parts.
PARTS LIST FOR FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY.

RYOBI 10 in. DRILL PRESS – MODEL NUMBER DP102L
5
M
~
WHITE WHITE
WHITE
WHITE
RED LASER
LASER
RED
BLACK BLACK
BLACK (SMOOTH)
TO CENTER
BLACK (RIDGE) TO EDGE
GREEN
GREEN
WIRING DIAGRAM
