10 in. TABLE SAW
MODEL NO. BTS211
REPAIR SHEET

1
2
2
3
37
8
9
10
18
19
142
41
22
23
24
27
148
38
155
46
48
45
36
154
44
45
46
34
137
55
131
131
156
10
113
112
111
110
108
145
107
105 104
103
102
101
114
115
116
118
117
139
140
106
4760
14661
63
65
154
100
37
9998
97 96
95
9094
143
92
91
89
85
83
82
81
80
79
78
77
75
74
73
72
71
76
69
68
67
66
84
8887
70
109
126
144
120
132
133
136
134
135
132
120
5
21
20
49
148
39
40
41
42
43 50
58
93
57
53
62
119
124
125
151
130
129
128
127
10
96
122
123
55
86
51
52
53 54
26
35
27
33
32
31
64
121
59
30
29 27
26 25
28
17
16
14
13
15
150
141 56
147
12
SEE
FIGURE B
SEE
FIGURE E
SEE
FIGURE D
SEE
FIGURE A
SEE
FIGURE C
11
4
6138
152
149
153
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
2

3
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TABLE SAW or when ordering repair parts.
PARTS LIST
1 0134011803 REAR RAIL ................................ 1
2 0134010211 END CAP (REAR RAIL).............. 2
3 0134010308 RAIL HOLDER NUT................... 4
4 089110110002 EXTENDED TABLE.................... 1
5 0134010322-58 OUTFEED SUPPORT ................ 1
6 410341004 SCREW w/WASHER
(M6 x 15 mm HEX SOC HD.)..... 4
7 0134010212 END CAP
(RIGHT FRONT RAIL) ................ 1
8 410561014 SCREW (M4 x 5 mm) ................ 1
9 089110110023 FRONT RAIL.............................. 1
10 410561004 SCREW
(M4 x 12 mm PAN HD.) ............. 8
11 0134010242 FRONT RAIL STOPPER ............ 1
12 0134010219 EXTENDED TABLE
INDICATOR ............................... 1
13 089110110003 THROAT PLATE ........................ 1
14 410101005 SCREW
(M5 x 15 mm FLAT HD.)............ 2
15 0121011301 THROAT PLATE PAD ................ 2
16 089110110004 SAW TABLE .............................. 1
17 0134010213 SLIDER...................................... 5
18 089110110031 TABLE TILT HANDLE ................ 1
19 0131010814 SCREW (#10-32 x 25 mm) ........ 4
20 410551701 SCREW w/WASHER
(1/4-20 x 1/2 in.) ........................ 2
21 0134010916 GUIDE ROD............................... 2
22 0134010911 MITER TABLE LATCH ............... 1
23 089110110005 GUIDE ....................................... 1
24 410171721 SCREW (8-32 x 3/8 in.) ............. 2
25 410011013 SCREW
(M6 x 40 mm HEX HD.) ............. 1
26 0134010206 LOCKING BLOCK ..................... 2
27 411071001 LOCK NUT ................................ 4
28 0134010332 ADJUSING PLATE..................... 1
29 0134010902 SHORT LINKAGE ...................... 1
30 0134010229 TABLE EXTENSION LEVER ...... 1
31 410031002 CARRIAGE BOLT
(M6 x 40 mm) ............................ 1
32 0134010306 BRACKET.................................. 1
33 410251017 SCREW w/WASHER
(M6 x 12 mm) ............................ 2
34 089110110021 SLIDING MITER TABLE ............ 1
35 0134010903 LONG LINKAGE ........................ 1
36 0134010309 SUPPORTING PLATE ............... 1
37 089110110017 BEVEL LOCK LEVER LABEL..... 1
38 0134010223 REAR RAIL HOLDER................. 3
39 410351003 SCREW w/WASHER
(M6 x 25 mm HEX HD.) ............. 6
40 0121010214 EXTENSION BRACKET ............. 2
41 089110110032 SCREW (#10-24 x 1/2 in.) ......... 6
42 089110110006 CORD WRAP............................. 1
43 089110110024 SCREW w/WASHER ................. 4
44 0134010216 HOOK........................................ 4
45 410201005 SCREW
(M4 x 12 mm FLAT HD.)............ 4
46 0134010314 SLIDING MITER TABLE BAR .... 2
47 411071707 LOCK NUT (1/4-20)................... 1
48 0134011804 SLIDING BAR ............................ 2
49 410192001 SCREW
(D4 x 10 mm TRUSS HD.) ......... 4
50 410109008 SCREW
(M5 x 12 mm PAN HD.) ............. 4
51 0134010220 SLIDER...................................... 2
52 089110110033 BRACKET.................................. 2
53 410371003 SCREW w/WASHER
(M6 x 12 mm) ............................ 6
54 089110110034 SLIDER...................................... 2
55 410031014 CARRIAGE BOLT
(M8 x 15 mm) ............................ 5
56 089110110018 SCALE LABEL........................... 1
57 0134010319 RIVING KNIFE BRACKET.......... 1
58 411171003 WING NUT (M8)......................... 1
59 0134010321 PIVOT BRACKET ...................... 1
60 411011707 HEX NUT (1/4 x 20) ................... 1
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.

4
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
61 410291006 SCREW w/WASHER
(M8 x 10 mm) ............................ 1
62 410161010 HEX SCREW (M6 x 25 mm) ...... 5
63 0134010317 INDICATOR BRACKET.............. 1
64 0121010901 ECCENTRIC SHAFT.................. 1
65 0134010503 PLATE ....................................... 1
66 410109019 SCREW
(M6 x 20 mm FLAT HD.)............ 1
67 412011701 WASHER (1/4 x 16 x 1t) ............ 2
68 089110110035 HEX NUT (3/8 in.) ...................... 1
69 0134010305 SUPPORT BRACKET ................ 1
70 410291004 SCREW w/WASHER
(M6 x 10 mm) ............................ 2
71 0134010236 LOCKING RING......................... 1
72 412011117 WASHER (M10 x 23 x 2t) .......... 1
73 0134010339 CAM .......................................... 2
74 410134005 SCREW
(M4 x5 mm PAN HD.) ............... 2
75 412042002 LOCK WASHER
(D4, EXTERNAL TOOTH) .......... 2
76 411071004 LOCK NUT (M10) ...................... 1
77 0134010320 FRONT CABINET
SUPPORT PLATE...................... 1
78 410499007 SCREW
(M5 x 8 mm TRUSS HD.) .......... 2
79 412011074 WASHER
(D10 X D26 X 2T) ....................... 1
80 0134011301 RUBBER PAD............................ 1
81 0134010230 BEVEL LOCKING LEVER .......... 1
82 0134010912 SCREW ..................................... 1
83 0134010316 SHIM ......................................... 1
84 410138743 SCREW
(8-32 x 1 in. PAN HD.) ............... 1
85 0134010224 BEVEL LOCKING LEVER
CAM .......................................... 1
86 412011037 WASHER
(D8.5 x D16 x 1.5T).................... 1
87 0101140203 SCREW (SPECIAL).................... 1
88 0131020212 HAND WHEEL GRIP.................. 1
89 412012041 WASHER
(6.5 x 13 x 1.5T)......................... 1
90 089110110007 HEIGHT/BEVEL
ADJUSTINGHANDWHEEL ........ 1
91 411072702 LOCK NUT (1/4-20)................... 1
92 089110110008 HANDWHEEL END CAP ........... 1
93 412041005 EXTERNAL STAR
WASHER (D8)............................ 1
94 0134010905 HANDWHEEL ROD ................... 1
95 0101010907 COMPRESSION SPRING.......... 1
96 0000120817 SCREW
(8-16 x 19.05 mm PAN HD.)...... 5
97 0134010228 GEAR RACK.............................. 1
98 410331010 SCREW w/WASHER
(M5 x 8 mm PAN HD.) ............... 2
99 0134010233 BEVEL SCALE INDICATOR....... 1
100 089110110009 BEVEL SCALE LABEL............... 1
101 410011027 SCREW
(M6 x 70 mm HEX HD.) ............. 1
102 0134010318 MOTOR BRACKET.................... 1
103 0134010907 SPACER .................................... 1
104 410161001 SCREW (M6 x 15 mm
HEX - TOOTH HD.).................... 3
105 411061001 HEX NUT (M6 TOOTH HD.)....... 3
106 414011002 PIN (D8 x 90 mm) ...................... 1
107 0121010902 GLIDER ..................................... 1
108 089110110001 BLADE (36T).............................. 1
109 089110110036 OUTER BLADE WASHER.......... 1
110 0181010804 BLADE NUT (5/8-18) ................. 1
111 0134010225 INNER DUST COVER................ 1
112 410331003 SCREW w/WASHER
(M6 x 10 mm PAN HD.) ............. 4
113 0134010226 OUTER DUST COVER............... 1
114 410031710 CARRIAGE BOLT
(5/16-18 x 1/2 in.) ...................... 1
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TABLE SAW or when ordering repair parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.

5
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TABLE SAW or when ordering repair parts.
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.
115 089110110010 CABINET ................................... 1
116 984406001 SWITCH .................................... 1
117 410601004 SCREW (M4 x 18 mm) .............. 4
118 984406003 SWITCH KEY............................. 1
119 0121010242 WIRE CLAMP ............................ 3
120 412011744 WASHER (D6.5 x D20 x 1.6t) .... 2
121 410011024 HEX SCREW
(M6 x 110 mm) .......................... 2
122 0131010210 CLAMPING PAD........................ 1
123 0131010209 SWITCH BOX ............................ 1
124 451010003 STRAIN RELIEF......................... 1
125 0134010701 POWER CORD .......................... 1
126 410499006 SCREW
(M8 x 40 mm BUTTON HD.)...... 4
127 089110110037 SMALL BLADE WRENCH
(OPEN END = 19 mm;
CLOSED END = 19 mm) ........... 1
128 0134010331 LARGE BLADE WRENCH
(OPEN END = 21 mm;
CLOSED END = 10 mm) ........... 1
129 0134010238 KNOB RING
(FLANGE WASHER) .................. 1
130 0131020211 WING NUT................................. 1
131 410611001 SCREW w/WASHER
(M6 x 15 mm) ............................ 2
132 089110110012 WHEEL ...................................... 1
133 0134010301 LEFT BRACKET......................... 1
134 411061003 NUT (M8) ................................... 4
135 0134010909 AXLE.......................................... 1
136 0134010302 RIGHT BRACKET ...................... 1
137 A134013901 OUTFEED SUPPORT
ASSEMBLY ............................... 1
138 089110110013 SCALE LABEL........................... 1
139 089110110014 NAME PLATE ............................ 1
140 089110110015 WARNING LABEL ..................... 1
141 9134015330201 PINCH POINT LABEL................ 1
142 0134010304 SHIM ......................................... 1
143 414011003 PIN (4 x 20 mm)......................... 1
144 0181010247 DUST BAG ELBOW................... 1
145 089110110019 LABEL ....................................... 1
146 0134010906 SPACER .................................... 2
147 0134010216 HOOK........................................ 3
148 410561013 SCREW
(M5 x 16 mm PAN HD.) ............. 7
149 0134010214 ADJUSTING HOOK................... 1
150 089110110041 ECCENTRIC SCREW ................ 1
151 089110110025 HEX KEY (M5 x 100 mm) .......... 1
152 089110110016 SET UP LABEL.......................... 1
153 411071003 LOCK NUT (M5) ........................ 1
154 410181001 SCREW
(M4 x 7 mm FLAT HD.).............. 6
155 089110110704 MITER TABLE ASSEMBLY ....... 1
156 089110110702 DUST BAG ASSEMBLY ............ 1
987000586 OPERATOR’S MANUAL
(089110114903)
2-06-09
(REV:01)

6
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
9
5
4
3
2
1
8
7
6
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TABLE SAW or when ordering repair parts.
PARTS LIST FOR FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY.
A134010801 MITER FENCE ASSEMBLY (INC. KEY NOS. 1-9) .......................1
1 0134010227 END CAP ....................................................................................2
2 0181010208-58 MITER INDICATOR......................................................................1
3 0134011801 MITER FENCE .............................................................................1
4 0134010244 LOCATOR PIN .............................................................................1
5 410451702 SCREW (3/16 in. PAN HD.)..........................................................2
6 0181010209 ADJUSTING KNOB .....................................................................1
7 412011051 WASHER (D8 x D16 x 1.5t)..........................................................1
8 0181010210 MITER FENCE HOLDER..............................................................1
9 410011717 SCREW (5/16-18 x 3-1/4 in. HEX HD.)........................................1
FIGURE A

7
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TABLE SAW or when ordering repair parts.
PARTS LIST FOR FIGURE B
KEY PART
NO. NUMBER DESCRIPTION QTY.
089110110701 RIP FENCE ASSEMBLY (INC. KEY NOS. 1-17) ..........................1
1 411071001 LOCK NUT (M6)...........................................................................1
2 412011030 WASHER (D6.5 x D16 x 1.5t).......................................................4
3 0121010310 REAR CLAMPING PLATE............................................................1
4 0121010915 COMPRESSION SPRING ............................................................1
5 0134010904 ROD .............................................................................................1
6 412011115 WASHER (D16 xD25 x1.5t)........................................................2
7 0134010232 INDICATOR..................................................................................1
8 410331008 SCREW w/WASHER (M4 x 10 mm).............................................1
9 0121010209 RIP FENCE SLIDER.....................................................................1
10 0134011805 RIP FENCE (506.2 mm) ...............................................................1
11 410051001 SCREW (M6 x 15 mm TRUSS) ....................................................2
12 089110110030 FRONT BLOCK............................................................................1
13 0134010218 FENCE SLIDER............................................................................2
14 089110110040 SCREW (8-32 x 1/2 in. FLAT HD.) ...............................................4
15 0121010210 ROUND PAD................................................................................2
16 0134010231 LOCKING LEVER ........................................................................1
17 0134010241 AXLE ............................................................................................1
12342
5
6
17 16
15
14
13
12
7
9
10
11
2
8
FIGURE B

8
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
1
2
1
2
3
4
5
6
7
32
31
9
10
11
17
25
26
27
28
29
16
14
15
18
20
19
21
22
23 24
12
13
30
33
8
FIGURE C

9
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TABLE SAW or when ordering repair parts.
PARTS LIST FOR FIGURE C
KEY PART
NO. NUMBER DESCRIPTION QTY.
089110110703 LEG STAND ASSEMBLY (INC. KEY NOS. 1-33).........................1
1 089110110901 TEAR DOWN LABEL ...................................................................1
2 089110114001 LATCH BAR w/GROMMET .........................................................1
3 0131010810 SCREW........................................................................................1
4 0131010323-82 BRACKET ....................................................................................1
5 411011707 HEX NUT (1/4 x 20)......................................................................2
6 412041702 WASHER (1/4 in.).........................................................................2
7 0131010915 SPRING .......................................................................................1
8 411071702 LOCK NUT (1/4 x 20)...................................................................1
9 A134017001 LEG BRACKET ASSEMBLY ........................................................1
10 0131010923 PIN...............................................................................................2
11 410011722 HEX SCREW (1/4-20 x 50.8 mm) ................................................2
12 0131011302 PAD..............................................................................................4
13 410451017 SCREW (M6 x 18 mm).................................................................4
14 0512010812 LOCK NUT (M10).........................................................................4
15 412011111 WASHER (D10.3 x D27 x 2T).....................................................12
16 089110110022 REAR LEG SUPPORT .................................................................1
17 0134010235 LEG UPPER END CAP ................................................................2
18 0134010240 SPACER TUBE ............................................................................2
19 410011028 SCREW (M10 x 105 mm HEX HD.)..............................................2
20 0134010243 LEG END CAP .............................................................................3
21 089110110705 FRONT LEG SUPPORT ...............................................................1
22 0131010918 SPRING .......................................................................................1
23 0131010232 FOOT LEVEL ADJUSTMENT.......................................................1
24 410031714 BOLT (5/8-11 x 88.9 mm) ............................................................1
25 0131010230 LEG REAR SLIDER......................................................................1
26 089110110706 TUBE ...........................................................................................1
27 0131010231 LEG FRONT SLIDER ...................................................................1
28 0134010239 LEG SPACER TUBE ...................................................................2
29 410011029 SCREW (M10 x 115 mm HEX HD.)..............................................2
30 412011025 WASHER (6.5 x 10 x .8T).............................................................4
31 9134015335703 LEG LOCK LABEL .......................................................................1
32 9134015335704 LEG UNLOCK LABEL..................................................................1
33 9134015330202 PINCH POINT LABEL ..................................................................2

10
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
1
2
3
3
14
15
7
4
5
6
3
3
8
8
9
9
10
11
12 13
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TABLE SAW or when ordering repair parts.
PARTS LIST FOR FIGURE D
KEY PART
NO. NUMBER DESCRIPTION QTY.
089110110700 BLADE GUARD ASSEMBLY (INC. KEY NOS 1-15) ....................1
1 089110110020 BLADE GUARD............................................................................1
2 414050004 DOWEL PIN (5/16 in. x 45.5 mm) ................................................1
3 411101702 LOCKING NUT (5/16 in.)..............................................................4
4 0134010310 ARM.............................................................................................1
5 0134010913 RIVET...........................................................................................1
6 0134010207 ARM SHIM...................................................................................2
7 9181015330203 LABEL..........................................................................................1
8 0181010303 ANTI-KICKBACK PAWLS ............................................................2
9 0134010208 SHIM (ANTI-KICKBACK PAWLS) ................................................2
10 0121010914 TORSION SPRING ......................................................................1
11 0134010311 SPREADER..................................................................................1
12 414051701 PIN (5/16 x 34.5 mm)...................................................................1
13 414011035 PIN (D5 x 32)................................................................................1
14 9181015330202 WARNING LABEL........................................................................1
15 089110110900 BLADE ROTATION LABEL ..........................................................1
FIGURE D

11
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
1
2
4
3
7
17
14
15
21
16 18
8
19
9
10
11
12
13
20
5
6
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TABLE SAW or when ordering repair parts.
PARTS LIST FOR SECTION “A”
SECTION “A”
SECTION “A” REPRESENTS AN IMPORTANT PART OF THE DOUBLE INSULATED SYSTEM OF THIS
TOOL. ANY REPAIR TO THIS TOOL REQUIRES DIELECTRIC TESTING TO INSURE CUSTOMER
SAFETY AND TO COMPLY WITH COMPANY REQUIREMENTS.
A134010104 MOTOR ASSEMBLY
(INC. KEY NOS. 1-21).............. 1
1 410071005 SOCKET SCREW (M5 x 8) ......2
2 0134010201 MOTOR HOUSING.................. 1
3 410271701 SCREW w/WASHER
(3/16-32 x 1-3/8 in. PAN HD.) . 4
4 0121010231 BRUSH TUBE.......................... 2
5 0502025007 BRUSH (7 x 17 x 19/17) .......... 2
6 0121010238 BRUSH CAP............................2
7 A134010401 FIELD ASSEMBLY...................1
8 410581001 SCREW w/WASHER
(M5 x 60 mm PAN HD.) ...........2
9 451010003 STRAIN RELIEF ....................... 1
10 0134010202 BAFFLE ...................................1
11 089110110026 BALL BEARING
(6200ZZ C3, HVQ) ...................1
12 089110110707 ARMATURE ASSEMBLY
(INC. KEY NOS. 11 AND 13)....1
13 089110110027 BALL BEARING (6201ZW)....... 1
14 089110110708 GEAR BOX .............................. 1
15 420110004 NEEDLE BEARING ................. 1
16 089110110039 SCREW w/WASHER
(M5 x 12 mm PAN HD.) ...........2
17 410174721 SCREW
(8-32 x 3/8 in. TRUSS HD.)......1
18 412042002 LOCK WASHER....................... 1
19 0121010242 WIRE CLAMP ..........................1
20 441010012 “O” RING (D29.6 x 1.2T).......... 1
21 A134010503 ARBOR ASSEMBLY ................ 1
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.

12
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS211
WIRING DIAGRAM
MOTOR
WHITE LEAD
WHITE LEAD
BLACK LEAD
WHITE
LEAD
GREEN
LEAD
GREEN
LEAD
GREEN
LEAD
BLACK LEAD
BLACK LEAD
POWER
CORD
MOTOR
CORD
GROUNDING
GROUNDING
GROUNDING
BRUSH
ASSEMBLY
