OWNER’S OPERATING MANUAL
1350 WATT CIRCULAR SAW
MODEL ECS1350
CAUTION: Carefully read through this entire owner's manual before using your
circular saw
SAVE THIS MANUAL FOR FUTURE REFERENCE.
THANK YOU FOR BUYING A RYOBI CIRCULAR SAW
Your new saw has been engineered and manufactured to Ryobi's high standard for dependability,
ease of operation, and operator safety. Properly cared for, it will give you years of rugged,
trouble free performance.
DOUBLEDOUBLE
DOUBLEDOUBLE
DOUBLE
INSULATEDINSULATED
INSULATEDINSULATED
INSULATED
SPECIFICATIONS :
Power Input.................... 1350 watt
No Load Speed.............. 4800 rpm
Blade Diameter.............. 190 mm
Blade Bore Size............. 24 mm
Depth of Cut @0˚........... 60 mm
@45˚......... 38 mm
Weight............................ 5.04 kg
Pay close attention to the Rules for Safe Operation, Warnings, and Cautions.
If you use your saw properly and only for what it is intended, you will enjoy years of safe, reliable
service.
Thank You again for buying Ryobi tools.

The purpose of safety rules is to attract your attention to possible
dangers. The safety symbols and the explanations with them,
require your careful attention and understanding. The safety
warnings do not by themselves eliminate any danger. The
instruction or warnings they give are not substitutes for proper
accident prevention measures.
SAFETY ALERT SYMBOL. Indicates caution or
warning. May be used in conjunction with other
symbols or pictures.
WARNING: Failure to obey a safety warning can
result in serious injury to yourself or to others.
Always follow the safety precautions to reduce the
risk of fire, electric shock and personal injury.
WARNING: Do not attempt to operate this tool until
you have read thoroughly and understood
completely, safety rules, etc. contained in this
manual. Failure to comply can result in accidents
involving fire, electric shock or serious personal
injury. Save owners manual and review frequently
for continuing safe operation and instructing others
who may use this tool.
1. KNOW YOUR POWER TOOL. Read owners manual carefully.
Learn its applications and limitations as well as the specific
potential hazards related to this tool.
2. GUARD AGAINST ELECTRICAL SHOCK BY PREVENTING
BODY CONTACT WITH GROUNDED SURFACES. For
example, pipes, radiators, ranges, refrigerator enclosures.
3. KEEP WORK AREA CLEAN. Cluttered areas and benches
invite accidents.
4. AVOID DANGEROUS ENVIRONMENT. Don't use power tools
in damp or wet locations or expose to rain. Keep work area
well lit.
5. KEEP CHILDREN AND VISITORS AWAY. Visitors should
wear safety glasses and be kept a safe distance from work
area. Do not let visitors contact tool or extension cord.
6. STORE IDLE TOOLS. When not in use, tools should be stored
in a dry and high or locked-up place, out of reach of children.
7. DON'T FORCE TOOL. It will do the job better and safer at
the rate at which it was designed.
8. USE RIGHT TOOL. Don't force small tool or attachment to
do the job of a heavy duty tool. Don't use tool for purpose not
intended.
9. DRESS PROPERLY. Do not wear loose clothing or jewellery.
They can be caught in moving parts. Rubber gloves and non-
skid footwear are recommended when working outdoors. Also
wear protective hair covering to contain long hair.
10.ALWAYS WEAR SAFETY GLASSES. Everyday eyeglasses
have only impact resistant lenses, they are not safety glasses.
11. PROTECT YOUR LUNGS. Wear a dust mask if operation is
dusty.
12.PROTECT YOUR HEARING. Wear hearing protection during
extended periods of operation.
13.DON'T OVERREACH. Keep proper footing and balance at
all times. Do not use tool on a ladder or unstable support.
Secure tools when working at elevated levels.
14.MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean
for better and safer performance. Follow instructions for
lubricating and changing accessories.
15.REMOVE ADJUSTING KEYS AND WRENCHES. Form a
habit of checking to see that keys and adjusting wrenches
are removed from tool before turning it on.
16.NEVER USE IN AN EXPLOSIVE ATMOSPHERE. Normal
sparking of the motor could ignite fumes.
17.KEEP HANDLES DRY, CLEAN AND FREE FROM OIL AND
GREASE. Always use a clean cloth when cleaning. Never
use brake fluids, gasoline, petroleum based products, or any
strong solvents to clean your tool.
18.STAY ALERT AND EXERCISE CONTROL. Watch what you
are doing and use common sense. Do not operate tool when
you are tired. Do not rush operation of tool.
19.CHECK DAMAGED PARTS. Before further use of the tool,
a guard or any other part that is damaged should be carefully
checked to determine that it will operate properly and perform
its intended function. Check for alignment of moving parts,
binding of moving parts, breakage of parts, mounting and
any other conditions that may affect its operation. Aguard or
any other part that is damaged should be properly repaired
or replaced by an authorised service centre.
20.DO NOT USE TOOL IF SWITCH DOES NOT TURN IT ON
AND OFF. Have defective switches replaced by authorised
service centre.
21.DO NOT OPERATE THIS TOOL WHILE UNDER THE
INFLUENCE OF DRUGS, ALCOHOL OR ANY
MEDICATION.
22.THE APPLIANCE IS NOT INTENDED FOR USE BY YOUNG
OR INFIRM PERSONS WITHOUT SUPERVISION. YOUNG
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT
THEY DO NOT PLAY WITH THE APPLIANCE.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
RULES FOR SAFE OPERATION
The operation of any tool can result in
foreign objects being thrown into your
eyes, which can result in severe eye
damage. Before beginning power tool
operation, always wear safety goggles
or safety glasses with side shields and
a full face shield when needed. We recommend Wide Vision
Safety Mask for use over eyeglasses or standard safety
glasses with side shields.
Due to continued product
refinement policy, product features
and specifications can and will
change without notice. Check
current features and specifications
with your retailer.

1. KEEP GUARDS IN PLACE AND IN WORKING ORDER.
Never wedge or tie lower blade guard open. Check operation
of lower blade guard before each use. Do not operate if lower
blade guard does not close briskly over saw blade.
WARNING: If saw is dropped, lower blade guard may be bent,
restricting full return. If lower blade guard becomes bent or
damaged, replace it before use.
2. DON’T ABUSE CORD. Never carry the tool by the cord or
yank it to disconnect from receptacle. Keep cord away from
heat, oil and sharp edges.
3. SECURE WORK. Use clamp or a vise to hold work piece.
Use both hands when operating the tool.
4. AVOID ACCIDENTAL STARTING. Don’t carry plugged-in tool
with finger on switch. Be sure switch is off when plugging in.
5. OUTDOOR USE EXTENSION CORDS. When tool is used
outdoors, use only extension cords intended for use outdoors
and so marked.
6. KEEP BLADES CLEAN AND SHARP. Sharp blades
minimise stalling and kickback.
7. KEEP HANDS AWAY FROM CUTTING AREA. Keep hands
away from blades. Do not reach underneath work while blade
is rotating. Do not attempt to remove cut material when blade
is moving. WARNING: Blades coast after turning off.
8. INSPECT TOOL CORDS PERIODICALLY. If damaged, have
repaired by authorised service centre. Stay constantly aware
of cord location and keep it well away from rotating blade.
9. USE RIP FENCE. Always use a fence or straight edge guide
when ripping.
10.BEFORE MAKING A CUT. Be sure the depth and bevel
adjustments are tight.
11. USE CORRECT BLADES. Do not use blades with incorrect
size holes. Never use blade washers or bolts that are
defective or incorrect. The maximum blade capacity of your
saw is 190mm.
12.AVOID CUTTING NAILS. Inspect and remove all nails from
timber before cutting.
13.NEVER. Touch the blade or moving parts during use.
14.NEVER. Start the saw when the blade is in contact with the
workpiece.
FEATURES
Features include easily operated bevel cut and depth of cut
adjustment mechanism, directed air flow for keeping line of cut
clear; blade wrench and storage; and lock-off switch.
Before attempting to use your saw, familiarise yourself with
all operating features and safety requirements.
OTHER SAFETY PRECAUTIONS
FOR USING CIRCULAR SAW
1. TRIGGER SWITCH
2. LOCK - OFF BUTTON
3. HOUSING COVER
4. FRONT HANDLE
5. ANGLE LOCKING LEVER
6. LOWER BLADE GUARD
7. DEPHT LOCKING LEVER
8. DUST EXTRACTION PORT
9 . QUADRANT SCALE
10.PARALLEL FENCE LOCKING KNOB
11. BASE PLATE
12 .BLADE GUARD LEVER
13. UPPER BLADE GUARD
14. MAIN HANDLE
15. SPINDLE LOCK BUTTON
16. RIVING KNIFE
WARNING:If any parts are missing, do not
operate your tool until the missing parts are
replaced. Failure to do so could result in serious
personal injury.
SAFETY LOCK-OFF SWITCH
Your Ryobi saw is fitted with a safety Lock-Off switch to help
prevent accidental saw start ups. To operate saw press the Safety
Lock-Off switch while pressing the trigger switch. Always let the
blade reach full speed, then guide the saw into the work.
APPLICATIONS
(use only for the following purposes)
Cutting all types of timber product (wood, plywood, paneling)
Ask your local dealer for more detail if required
ELECTRICAL CONNECTION
Your circular saw has a precision built electric motor. It should
be connected to a power supply that is 240volts, 50-60Hz only.
Do not operate this tool on direct current (DC). A substantial
voltage drop will cause a loss of power and overheating. If your
saw does not operate when plugged into an outlet, have a
qualified electrician double check the power supply.
Trigger switch
3
6
1
2
4
5
7
8
9
10
12
13
14
15
16
11
Lock-off switch

OPERATION
1. REMOVAL AND REFITTING THE SAW BLADE (Fig 1.)
Unplug the saw.
Press in the blade lock button and rotate blade until the blade
locking pin activates and the blade will no longer rotate.While
still pressing the blade lock button, remove the blade bolt using
the allen key, rotating anti-clockwise. Remove the blade bolt
and outer washer. The blade can now be removed.
2. LOCK-OFF BUTTON
The lock-off button provides a safety measure to prevent the
saw from being accidentally switched on.The trigger switch
can only be depressed. When the switch is released, the lock-
off button is automatically re-engaged, preventing inadvertent
operation of the saw.
3. MOTOR HOUSING
Regularly check to see if any dust or foreign matter has
entered the grills at the rear of the motor housing. Use a soft
brush to remove any accumulated dust. Wear safety glasses
to protect your eyes whilst cleaning.
4. BEVEL ANGLE LOCKING LEVER (Fig 2.)
CAUTION. Always ensure that the saw is switched off and
unplugged from the power supply before making any
adjustments.
To adjust the cutting angle loosen the angle locking lever
located at the front of the base plate. Tilt the body of the saw
until the required angle is reached using the quadrant scale
as a guide.
For accurate work, it is necessary to make a trial cut, measure
the work and reset the angle until the correct setting is
achieved. Tighten the locking lever to secure the base plate.
5. LOWER BLADE GUARD
As the saw advances through the work piece, the pivoting
lower blade guard is pushed back by the edge of the work to
expose only that part of the blade which is needed. When
the blade clears the work, the spring-loaded lower blade
guard snaps back to completely enclose the blade.
6. DEPTH LOCKING LEVER (Fig 3.)
CAUTION. Always ensure that the saw is switched off and
unplugged from the power supply before making any
adjustments.
To adjust the cutting depth of the saw, first turn the saw so
that it is facing away from you. Next loosen the depth locking
lever. Now, hold the base plate flat against the edge of the
work piece and lift the body of the saw until the blade is at
the right depth. Finally, tighten the depth locking lever.
WARNING: Your saw should never be connected
to the power supply when you are assembling
parts, making adjustments, assembling or
removing blades, cleaning, or when not in use.
Disconnecting your saw will prevent accidental
starting that could result in serious personal injury.
WARNING: 190mm blade is the maximum blade
capacity of your saw. Never use a blade that is
too thick to allow outer blade washer to engage
with the flat on the spindle. Larger blades will
come in contact with the blades guards, while
thicker blades will prevent blade bolt from
securing blade on spindle correctly. Either of
these situations could result in serious personal
injury.
WARNING: Failure to unplug your saw could
result in accidental starting causing possible
serious personal injury
Fig 2.
Fig 1. Fig 3.

OPERATION
7. DUST EXTRACTION PORT
The dust extraction port allows a dust extraction system or
standard vacuum cleaner nozzle to be fitted to the saw
permitting the efficient removal of dust whilst the tool is in
use.
8. QUADRANT SCALE
The quadrant scale shows the angle to which the base plate
is tilted.
9. PARALLEL FENCE GUIDE (Fig 4.)
The parallel fence guide allows you to make parallel cuts in
a length of wood. CAUTION. Always ensure that the saw is
switched off and unplugged from the power supply before
making any adjustments. Slide the fence guide into the slot
in the base plate.
Adjust the guide to the required width and secure it in position
with the locking knob. Ensure that the guide rests against
the wood along its entire length to give a consistent parallel
cut.
10.PARALLEL FENCE LOCKING KNOB
The locking knob is used to secure the parallel fence guide
to the base plate.
11. BASE PLATE
The base plate should be kept flat against the work piece
when making a cut. It can be tilted to change the angle of
cut.
12.BLADE GUARD LEVER
The blade guard lever can be used to lift the blade guard
clear of the work when plunge cutting.
13.UPPER BLADE GUARD
The fixed guard encloses the upper part of the blade.
14.RIVING KNIFE (Fig 5.)
The riving knife is positioned behind the saw blade. It prevents
freshly cut timber from closing up onto the blade. The riving
knife should always be positioned central to and in line with
the blade and adjusted so that the distance between the riving
knife and the toothed rim of the saw blade is even along the
curve of the blade and not more than 5mm wide.
To adjust the position of the riving knife first lower the base
plate and lift the lower blade guard using the blade guard
Fig 4.
lever. This allows access to the two screws that secure the
knife. Loosen the screws, adjust the knife as required and
retighten the screws.
Fig 5.

GENERAL
MAINTENANCE
•Do not use saw blades that are deformed or cracked.
•Do not use saw blades made of high speed steel.
•Do not use saw blades that do not comply with the
characteristics specified in this instruction sheet.
•Do not stop the saw blade by lateral pressure on the disc.
•Do not lock the movable guard in the open position.
•Ensure that the movable guard operates freely without
jamming.
•Ensure that any retraction mechanism of the guard system
operates correctly.
•Remove plug from the main supply before replacement of the
saw blade or making adjustments or other maintenance work.
•Do not use any abrasive wheel unless the machine is designed
for that purpose.
Cord extension
set rating
10
10
15
15
20
20
Conductor area
sq. mm
1.0
1.5
1.5
2.5
2.5
4.0
Maximun length
of flexible cord m
25
32
25
40
32
40
Avoid using solvents when cleaning plastic parts. Most plastics
are susceptible to damage from various types of commercial
solvents and may be damaged by their use. Use clean cloths to
remove dirt, carbon dust, etc.
EXTENSION CORDS
The use of any extension cord will cause some loss of power.
To keep the loss to a minimum and to prevent tool from over-
heating, follow the recommended cord sizes on the table. Every
240 volt flexible extension cord shall be of heavy duty sheathed
type to comply with AS3199, Approval and Test Specification,
Cord Extension Sets.
SERVICE
Now that you have purchased your tool, should a need ever
exist for repair parts or service, simply contact your nearest
Ryobi Authorised Service Centre or qualified service
organisation. Be sure to provide all pertinent facts when you
call or visit.
LUBRICATION
All the bearings in this tool are lubricated with a sufficient amount
of high grade lubricant for the life of the unit under normal
operating conditions, therefore no further lubrication is required.
WARNING
Do not at any time let brake fluid, gasoline
petroleum based products or penetrating oils
come into contact with plastic parts. They
contain chemicals that can damage, weaken
or even destroy plastic.
ADDITIONAL SAFETY INSTRUCTIONS
FOR CIRCULAR SAWS

RYOBI TECHNOLOGIESAUSTRALIAPTY. LTD.
GUARANTEE
RYOBI TECHNOLOGIES AUSTRALIA PTY. LTD.
A.B.N. 98 002 277 509
SYDNEY: 359-361 Horsley Road, Milperra, N.S.W. 2214.
Contact during normal business hours.
Tel: [phone] - Fax: [phone] - Email: [email protected]
Purchased From
Address Of Dealer
Date Model No Serial No
RYOBI NEW ZEALAND PTY. LTD.
AUCKLAND: 503 Mt Wellington Highway, Mt Wellington, N.Z.
Tel: [phone] - Free Call: 0800 279 624 - Fax: [phone] - Email: [email protected]
Contact during normal business hours.
Subject to the guarantee condition below, this Ryobi tool
(hereinafter called “the product”) is guaranteed by Ryobi
(hereinafter called “the Company”) to be free from
defects in material or workmanship for a period of 24
months from the date of original purchase covering
both parts and labour. Under the terms of this
guarantee, the repair or replacement of any part shall
be the opinion of the Company or its authorised agent.
Should service become necessary during the warranty
period, the owner should contact the Authorised Ryobi
Retailer from whom the Product was purchased, or the
nearest Company Branch Office. In order to obtain
guarantee service, the owner must present the sales
docket and Guarantee Certificate to confirm date of
purchase. This product is sold by the dealer or agent as
principal and the dealer has no authority from the
Company to give any additional guarantee on the
Company’s behalf except as herein contained or herein
referred to.
Guarantee Conditions
This guarantee only applies provided that the Product
has been used in accordance with the manufacturer’s
recommendations under normal use and reasonable
care (in the opinion of the Company) and such
guarantee does not cover damage, malfunction or
failure resulting from misuse, neglect, abuse, or used
for a purpose for which it was not designed or is not
suited and no repairs, alterations or modifications
have been attempted by other than an Authorised
ServiceAgent. This guarantee will not apply if the tool is
damaged by accident or if repairs arise from normal
wear and tear.
The Company accepts no additional liability pursuant to
this guarantee for the costs of travelling or
transportation of the Product or parts to and from the
service dealer or agent - such costs are not included in
this guarantee.
Certain legislation, including the Trade Practices Act,
1974 (as amended) and other state and territorial laws
give rights to the buyer and impose liability on the seller in
certaincircumstances. Nothinghereinshallhavetheeffect
of excluding, restricting or modifying any condition,
guarantee, right or liability imposed, to the extent only
that such exclusion, restriction or modification
would render any term herein void.
This Guarantee Form Should Be Retained By The Customer At All Times
For your record and to assist in establishing date of purchase (necessary for in-guarantee service)
please keep your purchase docket and this form completed with the following particulars.
Present This Form With Your Purchase Docket When Guarantee Service Is Required.
BRISBANE: All enquiries Tel : [phone]
TOWNSVILLE: All enquiries Tel : [phone]
MELBOURNE: 960 Stud Road, Rowville,Vic. 3178
Tel : [phone]
HOBART: All enquiries Tel : [phone]
ADELAIDE: All enquiries Tel : [phone]
PERTH:
33-35 Sorbonne Cres., Canning Vale,W.A. 6155.
Tel : [phone]
