RYOBI
SPEED SAW
MODEL NO. P530
REPAIR SHEET

WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
RYOBI SPEED SAW – MODEL NUMBER P530
2
1
6
2
9
7
3
30
14
4
11
25
22
15
31
16
19
26
23
21
12
13
33
29
32
28
8
10
5
18
17
20
24
26
27
36
38
37
39
35
34
41
40

* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
RYOBI SPEED SAW – MODEL NUMBER P530
3
1 270011090 SWITCH ASSEMBLY .......................................... 1
2 3900201 SWITCH KNOB ................................................... 1
3 5991501 MOTOR RING (BACK) ........................................ 1
4 7439401 MOTOR ............................................................... 1
5 690026002 RETAINING RING ............................................... 1
6 513071001 FAN ..................................................................... 1
7 640911001 BEARING HOLDER ............................................ 1
8 6904201 BALL BEARING (NSK) ........................................ 1
691067001 BALL BEARING (CW) ........................................ 1
9 6904401 COLLET (1/8 in.) ................................................ 1
10 6904301 COLLET NUT ...................................................... 1
11 6960101 SLEEVE SPRING ................................................ 1
12 6960201 BASE SLEEVE .................................................... 1
13 6725201 LOCK WASHER .................................................. 1
14 3031704 KNOB ASSEMBLY .............................................. 1
15 6960301 BASE PLATE ..................................................... 1
16 670233003 1/8 in. PLLOTED DRYWALL CUT BIT ................ 1
670233005 1/8 in. NON-PLLOTED DRYWALL CUT BIT ....... 1
17 1263301 CIRCLE CUTTER ASSEMBLY (INC. 18-24) ....... 1
18 5924301 ROUND ADAPTOR ............................................. 1
19 6946901 CIRCLE CUTTER ARM ...................................... 1
20 5924401 THREADED KNOB ............................................. 1
21 3031703 KNOB ASSEMBLY ................................................ 1
22 3068801 PIVOT POINT ASSEMBLY .................................. 1
23 6633701 * SCREW (1/4 in. X 12) .......................................... 1
24 6633801 NUT ..................................................................... 1
25 6620805 * SCREW (M4 X 16 mm) ....................................... 6
26 200006012 HOUSING ASSEMBLY (INC. 36-39) ................... 1
27 640912001 MOTOR MOUNTING BRACKET ......................... 1
28 6725101 E-RING ................................................................ 1
29 6723101 SPRING ............................................................... 1
30 6722901 LOCK PIN ............................................................ 1
31 6960401 WRENCH ............................................................ 1
32 6904501 COLLET (1/4 in.) ................................................. 1
33 200292003 PLUG-IN LANYARD ............................................ 1
34 300597002 DEPTH GUIDE ASSEMBLY (INC. 11-15) ........... 1
35 300707004 MOTOR & SHAFT ASSEMBLY
(INC. 4-10, 27, 40-41) .......................................... 1
36 940303195 DATA LABEL ....................................................... 1
37 940263138 LOGO LABEL ...................................................... 1
38 940230094 WARNING LABEL ............................................... 1
39 940230093 WARNING LABEL ............................................... 1
40 620215002 OUTPUT SHAFT ................................................. 1
41 660441001 SCREW (M5 X 7 mm) ......................................... 2
983000512 OPERATOR’S MANUAL (960223358)
983000512R REPAIR SHEET (REV:02)
07-14-05
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
SPEED SAW or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY

RYOBI SPEED SAW – MODEL NUMBER P530
4
WIRING DIAGRAM
RED LEAD
RED LEAD
BLACK LEAD
MOTOR
SWITCH
