Ryobi RJ160V User manual

OPERATOR'S MANUAL
VARIABLE SPEED
RECIPROCATING SAW
RJ160V - DOUBLE INSULATED
SPECIFICATIONS:
Length of stroke 1 3/16 in. (30 mm)
Variable Strokes per Minute 2400 max
Rating 120 volts, 60Hz, AC
Input 6.0 amps
Net weight 7.3 lbs. (3.32 kg.)
THANK YOU FOR BUYING A RYOBI RECIPROCATING SAW.
Your new saw has been engineered and manufactured to Ryobi's high standard for dependability, ease of operation, and
operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
CAUTION: Carefully read through this entire operator's manual before using your new saw.
Pay close attention to the Rules for Safe Operation, Warnings, and Cautions. If you use your saw properly and only for what
it is intended, you will enjoy years of safe, reliable service.
Please fill out and return the Warranty Registration Card so we can be of future service to you.
Thank you again for buying Ryobi tools.
SAVE THIS MANUAL FOR FUTURE REFERENCE
6

Page 2
■Product Specifications.....................................................................................................................1
■Table of Contents and Introduction .................................................................................................2
■Rules for Safe Operation.................................................................................................................3
■General Safety Rules ...................................................................................................................4-5
■Symbols and Electrical....................................................................................................................6
■Unpacking and Features .................................................................................................................7
■Operation....................................................................................................................................8-10
■Maintenance..................................................................................................................................11
■Parts Ordering / Service ................................................................................................................12
TABLE OF CONTENTS
The operation of any power tool can result in foreign objects being thrown into your eyes, which
can result in severe eye damage. Before beginning tool operation, always wear safety goggles or
safety glasses with side shields and a full face shield when needed. We recommend Wide Vision
Safety Mask for use over eyeglasses or standard safety glasses with side shields. Always wear
eye protection which is marked to comply with ANSI Z87.1.
WARNING:
Your reciprocating saw has many features for making
cutting operations more pleasant and enjoyable. Safety,
performance, and dependability have been given top priority
in the design of this tool making it easy to maintain and
operate.
INTRODUCTION
CAUTION:
Carefully read through this entire operator's manual
before using your new saw. Pay close attention to the
Rules for Safe Operation and all Safety Alert Symbols
including Danger, Warning, and Caution. If you use your
saw properly and only for what it is intended, you will
enjoy years of safe, reliable service.
Lookforthissymboltopointoutimportantsafetyprecautions.
It means attention!!! Your safety is involved.

Page 3
DOUBLE INSULATION
Your Ryobi power tool is double insulated. This means you
areseparatedfromthetool'selectricalsystembytwocomplete
sets of electrical insulation. This extra layer of insulation is
intended to protect the user from electrical shock due to a
break in the wiring insulation. All exposed metal parts are
isolated from the internal metal motor components with
protecting insulation. Double insulated tools do not need to
be grounded.
IMPORTANT
Servicing of a tool with double insulation requires extreme
careand knowledgeof thesystem andshould beperformed
onlybyaqualifiedservicetechnician.Forservicewesuggest
you return the tool to your nearest RYOBI AUTHORIZED
SERVICE CENTER for repair. When servicing use only
identical Ryobi replacement parts.
WARNING:
The double insulated system is intended to protect the
user from shock resulting from a break in the tool's
internal wiring. Observe all normal safety precautions
related to avoiding electrical shock. Failure to do so
could result in possible serious injury.
WARNING:
Do not attempt to operate this tool until you have read
thoroughly and understand completely all instructions,
safety rules, etc. contained in this manual. Failure to
comply can result in accidents involving fire, electric
shock, or serious personal injury. Save operator's manual
and review frequently for continuing safe operation, and
instructing others who may use this tool.
RULES FOR SAFE OPERATION
The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols, and the
explanations with them, deserve your careful attention and understanding. The safety warnings do not by
themselves eliminate any danger. The instructions or warnings they give are not substitutes for proper
accident prevention measures.
SYMBOL MEANING
SAFETY ALERT SYMBOL:
Indicatesdanger,warning,orcaution.Maybeusedinconjunctionwithothersymbolsorpictographs.
DANGER:Failuretoobeyasafetywarningwillresult inseriousinjurytoyourself ortoothers.Always
follow the safety precautions to reduce the risk of fire, electric shock and personal injury.
WARNING:Failuretoobeyasafetywarningcanresultinseriousinjurytoyourselfortoothers.Always
follow the safety precautions to reduce the risk of fire, electric shock and personal injury.
CAUTION: Failure to obey a safety warning may result in property damage or personal injury to
yourselfortoothers.Alwaysfollowthesafetyprecautionstoreducetheriskoffire,electricshockand
personal injury.
NOTE: Advises you of information or instructions vital to the operation or maintenance of the equipment.

Page 4
GENERAL SAFETY RULES
inattention while operating power tools may result in
serious personal injury.
■Dress properly. Do not wear loose clothing or
jewelry. Contain long hair. Keep your hair, cloth-
ing, and gloves away from moving parts. Loose
clothes, jewelry, or long hair can be caught in moving
parts.
■Avoid accidental starting. Be sure switch is off
before plugging in. Carryingtoolswithyourfinger on
the switch or plugging in tools that have the switch on
invites accidents.
■Remove adjusting keys or wrenches before turn-
ing the tool on. A wrench or a key that is left
attached to a rotating part of the tool may result in
personal injury.
■Do not overreach. Keep proper footing and
balance at all times. Proper footing and balance
enables better control of the tool in unexpected situ-
ations.
■Use safety equipment. Always wear eye protec-
tion. Dust mask, non-skid safety shoes, hard hat, or
hearingprotectionmustbeusedforappropriatecon-
ditions.
Tool Use and Care
■Use clamps or other practical way to secure and
support the workpiece to a stable platform. Hold-
ing the work by hand or against your body is
unstable and may lead to loss of control.
■Do not force tool. Use the correct tool for your
application. The correct tool will do the job better
and safer at the rate for which it is designed.
■Do not use tool if switch does not turn it on or
off.Any toolthatcannotbecontrolledwiththeswitch
is dangerous and must be repaired.
■Disconnect the plug from the power source
beforemakinganyadjustments, changing acces-
sories, or storing the tool. Such preventive safety
measures reduce risk of starting the tool acciden-
tally.
■Store idle tools out of reach of children and other
untrained persons. Tools are dangerous in the
hands of untrained users.
■Maintaintoolswithcare. Keep cutting tools sharp
and clean. Properly maintained tools with sharp
cutting edges are less likely to bind and are easier
to control.
■Check for misalignment or binding of moving
parts, breakage of parts, and any other condi-
tion that may affect the tool's operation. If dam-
aged, have the tool serviced before using. Many
accidents are caused by poorly maintained tools.
WARNING:
Read and understand all instructions. Failure to
followallinstructionslisted below,mayresult in elec-
tric shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
Work Area
■Keep your work area clean and well lit. Cluttered
benches and dark areas invite accidents.
■Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
■Keep bystanders, children, and visitors away
while operating a power tool. Distractions can
cause you to lose control.
Electrical Safety
■Double insulated tools are equipped with a
polarizedplug(onebladeis wider than the other).
This plug will fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a
qualified electrician to install a polarized outlet.
Do not change the plug in any way. Double insu-
lation eliminates the need for the three wire
grounded power cord and grounded power supply
system.
■Avoid body contact withgroundedsurfacessuch
as pipes, radiators, ranges and refrigerators.
Thereisanincreasedriskofelectricshockifyourbody
is grounded.
■Don't expose power tools to rain or wet condi-
tions. Water entering a power tool will increase the
risk of electric shock.
■Do not abuse the cord. Never use the cord to
carry the tools or pull the plug from an outlet.
Keep cord away from heat, oil, sharp edges or
moving parts. Replace damaged cords immedi-
ately. Damaged cords increase the risk of electric
shock.
■When operating a power tool outside, use an out-
door extension cord marked “W-A” or “W”.These
cords are rated for outdoor use and reduce the risk of
electric shock.
Personal Safety
■Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use tool while tired or under the influence of
drugs, alcohol, or medication. A moment of

Page 5
SAVE THESE INSTRUCTIONS
■Donotabusecord.Nevercarrytoolbycordoryank
it to disconnect from receptacle. Keep cord from
heat, oil and sharp edges. Following this rule will
reduce the risk of electric shock or fire.
■Inspect for and remove all foreign objects from
workpiece before cutting. Following this rule will
reduce the risk of serious personal injury.
■Make sure your extension cord is in good condi-
tion.Whenusinganextensioncord,besuretouseone
heavy enough to carry the current your product will
draw. A wire gage size (A.W.G.) of at least 12 is
recommended for an extension cord 100 feet or less in
length. A cord exceeding 100 feet is not recommended.
If in doubt, use the next heavier gage. The smaller the
gage number, the heavier the cord. An undersized cord
will cause a drop in line voltage resulting in loss of power
and overheating.
■Drugs, Alcohol, Medication. Do not operate tool
while under the influence of drugs, alcohol, or any
medication. Following this rule will reduce the risk of
electric shock, fire, or serious injury.
■Keep hands away from cutting area. Following this
rule will reduce the risk of serious personal injury.
■Save these instructions. Refer to them frequently
and use them to instruct others who may use this tool.
If you loan someone this tool, loan them these instruc-
tions also.
WARNING:
Somedustcreatedbypowersanding,sawing,grinding,
drilling, and other construction activities contains
chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these
chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other
masonry products, and
• arsenic and chromium from chemically-treated
lumber.
Your risk from these exposures varies, depending on
how often you do this type of work. To reduce your
exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such
asthosedustmasksthatarespeciallydesignedtofilter
out microscopic particles.
GENERAL SAFETY RULES
■Use only accessories that are recommended by the
manufacturer for your model.Accessories that may
besuitableforonetool,maybecomehazardouswhen
used on another tool.
Service
■Tool service must be performed only by qualified
repair personnel. Service or maintenance performed
by unqualified personnel could result in a risk of injury.
■When servicing a tool, use only identical replace-
ment parts. Follow instructions in the Maintenance
section of this manual. Use of unauthorized parts or
failure to follow Maintenance Instructions may create
a risk of electric shock or injury.
Specific Safety Rules for Reciprocating Saws
■Hold tool by insulated gripping surfaces when
performinganoperation wherethe cutting toolmay
contact hidden wiring or its own cord. Contact with
a “live” wire will make exposed metal parts of the tool
“live” and shock the operator.
Additional Rules for Safe Operation
■Know your power tool. Read operator's manual
carefully. Learn its applications and limitations as well
as the specific potential hazards related to this tool.
Followingthisrulewillreducetheriskofelectricshock,
fire, or serious injury.
■Always wear safety glasses with side shields.
Everydayeyeglasseshaveonlyimpactresistantlenses;
they are NOT safety glasses.
■Protect your lungs. Wear a face or dust mask if the
operation is dusty.
■Protectyourhearing.Wearhearingprotectionduring
extended periods of operation.
■Inspect tool cords periodically and if damaged, have
repaired at your nearest authorized service center. Stay
constantly aware of cord location.
■Check damaged parts. Beforefurther use ofthetool,
a guard or other part that is damaged should be
carefully checked to determine that it will operate
properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts,
breakageofparts,mounting,andanyotherconditions
thatmayaffectits operation. A guard orotherpartthat
isdamagedshouldbeproperlyrepairedorreplacedby
an authorized service center. Following this rule will
reduce the risk of electric shock, fire, or serious injury.
■Keep the tool and its handle dry, clean, and free
from oil and grease. Always use a clean cloth when
cleaning. Never use brake fluids, gasoline, petroleum-
based products, or any strong solvents to clean your
tool.

Page 6
ELECTRICAL
SYMBOLS
SYMBOL NAME DESIGNATION/EXPLANATION
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
min Minutes Time
Alternating Current Type or a characteristic of current
n0No Load Speed Strokes, at no load
Designates Double Insulated
Construction tools
Revolutions, strokes, surface speed,
orbits etc. per minute
Indicates danger, warning or caution.
It means attention!!! Your safety is
involved.
Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to operate the tool better and safer.
Safety Alert Symbol
Revolutions or Reciprocation Per Minute
Class II Construction
.../min
ELECTRICAL CONNECTION
Your saw has a precision built electric motor. It should be
connected to a power supply that is 120 volts, 60Hz, AC
only (normal household current). Do not operate this tool
on direct current (DC). A substantial voltage drop will cause
aloss of powerand themotorwill overheat. Ifyourtool does
not operate when plugged into an outlet, double-check the
power supply.
EXTENSION CORDS
Whenusingapowertoolataconsiderabledistancefromthe
powersource, use anextension cordheavyenough tocarry
the current that the tool will draw. An undersized extension
cord will cause a drop in line voltage, resulting in a loss of
power and causing the motor to overheat. Use the chart
providedbelowtodeterminetheminimumwiresizerequired
in an extension cord. Only round jacketed cords listed by
Underwriter's Laboratories (UL) should be used.
Length of Extension Cord Wire Size (A.W.G.)
Up to 25 16
26 to 50 14
51 to 100 12
When working with the tool outdoors, use an extension cord
that is designed for outside use. This is indicated by the
letters WA on the cord's jacket.
Before using an extension cord, inspect it for loose or
exposed wires and cut or worn insulation.
CAUTION:
Keep the cord away from the work area and position the
cord so that it may not get caught on materials or other
objects during cutting.

Page 7
KNOW YOUR RECIPROCATING SAW
Before attempting to use your saw, familiarize yourself with
alloperatingfeaturesandsafetyrequirements. SeeFigure1.
Hex Key Holder
A convenient feature on your saw is a hex key holder. It is
located on the bottom portion of your saw's handle. It is
convenient for storing the hex key when not in use. See
Figure 1.
Variable Speed Dial
Your reciprocating saw has a variable speed dial designed
to allow operator control of speed and power limits. See
Figure 1.
UNPACKING
FEATURES
UNPACKING
Your saw has been shipped completely assembled, except
fortheblade,andisreadyforuse.Inspectitcarefullytomake
sure no breakage or damage has occurred during shipping.
If any parts are damaged or missing, call 1-800-525-2579 to
obtain replacement parts before attempting to operate saw.
An operator's manual and warranty registration are also
included.
6
6
Fig. 1
TRIGGER
BASE
ASSEMBLY
HEX KEY HEX KEY
HOLDER
BLADE
VARIABLE
SPEED DIAL
WINDOW
INSULATED
GRIPPING
SURFACE
INSULATED
GRIPPING
SURFACE

Page 8
WARNING:
Always wear safety goggles or safety glasses with side
shieldswhenoperatingyourreciprocatingsaw.Failureto
dosocouldresultinforeignobjectsbeingthrownintoyour
eyes resulting in possible serious injury.
SWITCH
See Figure 2.
Toturn your reciprocatingsaw ON,depresstrigger. Release
trigger to turn your saw OFF.
VARIABLE SPEED DIAL
See Figure 2.
Yourreciprocatingsawhasavariablespeeddialdesignedto
allow operator control of speed and power limits. The speed
and power of your saw can be increased or decreased
depending on the position of the variable speed dial.
Avoid running your saw at low speeds for extended periods
of time. Running at low speeds under constant usage may
cause the motor of your saw to become overheated. If this
occurs, cool your saw by running it without a load and at full
speed.
WARNING:
Your saw should never be connected to power supply
when you are assembling parts, making adjustments,
installingorremovingblades,whencleaning,orwhennot
in use. Disconnecting your saw will prevent accidental
starting that could cause serious injury.
BLADE SELECTION
To obtain the best performance from your saw it is important
to select a specific blade for the particular application and
type of material you wish to cut. By doing this you will get a
smoother, faster cut and prolong blade life. Replacement
blades for this saw are available from your nearest Ryobi
dealer.
TO INSTALL BLADES
See Figure 3.
■UNPLUG YOUR SAW.
WARNING:
Failure to unplug your saw could result in accidental
starting causing serious injury.
■Removethe3mmhexkeyprovidedwiththissawfromhex
key holder.
Note: Hex key holder is located in the side of the saw
handle. See Figure 1.
■Loosen the blade clamp screw enough to permit the saw
blade to be inserted between blade clamp and pin.
Note: It is never necessary to remove the blade clamp
from the tool or the blade clamp screw from the blade
clamp to change the blade.
OPERATION
6
Fig. 2
VARIABLE
SPEED DIAL
Fig. 3
1
HEX KEY
PIN
BLADE
CLAMP SCREW
SAW BAR
BLADE
CLAMP
TO
INCREASE
TO
DECREASE
WINDOW

Page 9
■Align the hole in the shank of the blade and blade clamp
withthe pinin thesawbar,thenseat bothon thepin inthe
saw bar.
■Tighten blade clamp screw securely. Do not overtighten
screw or use an aid with hex key.
■Remove hex key and store it in the hex key holder.
Note:Theremaybetimeswhenthebladeclampstickstothe
saw bar and will not loosen enough to allow blades to be
installedorremoved.If thishappens,loosenthebladeclamp
screw with the hex key, then tap lightly on the end of the hex
key with a mallet. See Figure 4.
BASE ASSEMBLY
See Figure 5.
The base assembly of your reciprocating saw pivots up and
down in both directions. The base is adjustable, allowing the
use of the blade teeth at different positions on the blade.
TO CHANGE POSITIONS OF THE BASE ASSEMBLY:
See Figure 6.
■UNPLUG YOUR SAW.
WARNING:
Failure to unplug your saw could result in accidental
starting causing serious injury.
■Loosenthebutton headscrews in thegear frame withthe
3 mm hex key mentioned above.
■Reposition base assembly.
■Retightenbuttonheadscrewssecurely.Donotovertighten
screws or use an aid with hex key.
■Remove hex key and store it in hex key holder.
BLADE
CLAMP
OPERATION
HEX KEY
Fig. 5
MALLET
BASE
ASSEMBLY
HEX KEY
BLADE
CLAMP SCREW
Fig. 4
BASE
ASSEMBLY
PIVOT
BUTTON
HEAD SCREWS
Fig. 6
SAW BAR
Cuttingintoelectricalwiringinwallscancause blade,blade
clamp, and saw bar assembly to become electrically live.
Do not touch metal parts when cutting into a wall; grasp
only the insulated gripping surface provided on the tool.
Make sure hidden electrical wiring, water pipes, and
mechanical hazards are not in the blade path when cut-
ting into a wall.
WARNING:

Page 10
GENERAL CUTTING
See Figure 7.
Hold your saw firmly in front of and clearly away from you.
Makesure sawblade isclear ofany foreignmaterial andthat
power cord and extension cord are out of the blade path. Be
surematerialtobecutisheldfirmly.Smallworkpiecesshould
be securely clamped in a vise or with clamps to the work
benchortable.Markthelineofcutclearly.Depressthetrigger
switch starting the cutting action, set the base assembly
againstthework,thenmovethebladeintothework.DONOT
FORCE. Use only enough pressure to keep the saw cutting.
Let the blade and saw do the work.
PLUNGE CUTTING
See Figure 8.
Mark the line of cut clearly. Choose a convenient starting
pointinsidetheareatobecutoutandplacethetipoftheblade
overthatpoint.Restfrontedgeofbaseassemblyonworkand
hold firmly in position.
WARNING:
Makesure blade doesnot touchworkuntil motorreaches
full speed, since this can cause loss of control resulting in
serious injury.
Withsawbladeatfullcuttingspeed,slowlytiltsawdownward
until tip of blade starts cutting work. After blade penetrates
work, tilt saw until blade is perpendicular to the work.
OPERATION
METAL CUTTING
See Figure 9.
Metalssuchassheetsteel,pipe,steelrods,aluminum,brass,
and copper may be cut with your saw. Be careful not to twist
or bend the saw blade. DO NOT FORCE. We recommend
cuttingoilwhencuttingmostsoftmetalsandsteel.Cuttingoil
will also keep blades cool, increase cutting action, and
prolong blade life.
Never use gasoline since normal sparking of motor could
ignite fumes. Clamp the work firmly and cut close to the
clamping point to eliminate any vibration of the work being
cut. When cutting conduit pipe or angle iron, clamp work in a
vise if possible and cut close to the vise. To cut thin sheet
material, "sandwich" the material between hardboard or
plywood and clamp the layers to eliminate vibration and
material tearing.
6
6
6
Fig. 9
Fig. 7
Fig. 8
Hold tool by insulated gripping surfaces when performing
an operation where the cutting tool may contact hidden
wiring or its own cord. Contact with a “live” wire will make
exposed metal parts of the tool “live” and shock the
operator.
WARNING:

Page 11
Standarduniversal1/2 inchshankreciprocating sawblades
available at your local supplier may be used with your Ryobi
reciprocating saw.
GENERAL
Avoidusingsolventswhencleaningplasticparts.Mostplastics
are susceptible to various types of commercial solvents and
may be damaged by their use. Use clean cloths to remove
dirt, carbon dust, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleum-
based products, penetrating oils, etc. come in contact
with plastic parts. They contain chemicals that can
damage, weaken, or destroy plastic.
LUBRICATION
All of the bearings in this tool are lubricated with a sufficient
amount of high grade lubricant for the life of the unit under
normaloperatingconditions.Therefore,nofurtherlubrication
is required.
Ithasbeenfoundthatelectrictoolsaresubjecttoaccelerated
wear and possible premature failure when they are used on
fiberglassboats,sportscars,wallboard,spacklingcompounds,
or plaster. The chips and grindings from these materials are
highlyabrasivetoelectrictoolpartssuchasbearings,brushes,
commutators,etc.Consequently, itisnotrecommendedthat
thistoolbeusedforextendedworkonanyfiberglassmaterial,
wallboard, spackling compounds, or plaster. During any use
on these materials, it is extremely important that the tool is
cleaned frequently by blowing with an air jet.
WARNING:
Always wear safety goggles or safety glasses with side
shieldsduringpowertooloperationorwhenblowingdust.
If operation is dusty, also wear a dust mask.
WARNING: When servicing use only identical Ryobi replacement parts. Use of any other parts can create a
hazard or cause product damage.
ACCESSORIES
MAINTENANCE

OPERATOR'S MANUAL
RECIPROCATING SAW
RJ160V
DOUBLE INSULATED
RYOBI TECHNOLOGIES INC.
1428 Pearman Dairy Road Anderson, SC 29625
Post Office Box 1207 Anderson, SC 29622
www.ryobitools.com
Phone [phone]
972000-945 Printed in U.S.A.
• SERVICE
Now that you have purchased your tool, should a need ever exist for repair parts or
service, simply contact your nearest Ryobi Authorized Service Center. Be sure to
provide all pertinent facts when you call or visit. Please call 1-800-525-2579 for your
nearest Ryobi Authorized Service Center. You can also check our web site at
www.ryobitools.com for a complete list of Authorized Service Centers.
• MODEL NO. AND SERIAL NO.
The model number of this tool will be found on a plate attached to the motor housing.
Please record the model number and serial number in the space provided below.
• HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS,
ALWAYS GIVE THE FOLLOWING INFORMATION:
• MODEL NUMBER
• SERIAL NUMBER
RJ160V
EXTENSION CORD CAUTION
When using a power tool at a considerable distance from a power
source, be sure to use an extension cord that has the capacity to
handlethecurrentthetoolwilldraw.Anundersizedcordwillcause
a drop in line voltage, resulting in overheating and loss of power.
Use the chart to determine the minimum wire size required in an
extension cord. Only round jacketed cords should be used.
When working with a tool outdoors, use an extension cord that is
designed for outside use. This is indicated by the letters "WA" on
the cord's jacket.
Before using any extension cord, inspect it for loose or exposed
wires and cut or worn insulation.
**Ampere rating
(on tool faceplate) 0-2.0 2.1-3.4 3.5-5.0 5.1-7.0 7.1-12.0 12.1-16.0
Cord Length Wire Size (A.W.G.)
25' 16 16 16 16 14 14
50' 16 16 16 14 14 12
100' 16 16 14 12 10 —
CAUTION: Keep the extension cord clear of the working
area. Position the cord so that it will not get caught on lumber,
tools or other obstructions while you are working with a power
tool.
**Used on 12 gauge - 20 amp circuit.
