10 in. COMPOUND MITER SAW
MODEL NO. TS1342
REPAIR SHEET

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1342
2
1
2
4
3
4
6
7
9
10
11
12
122
16
13
30
18
19
20
21
21
85
84
22
50
8
52
39
55
56
57
58
59
60
61
62
63
64
65
67
66
95
86
87
88
98
105
109
111
110
106
107
108
99
100
101
89
90 91
92
89
93
94
68
71
121
72
73
74
75
23
24
25
112
112
120
114
16
16
14
14
14
14
116
113
69
53
81
117
119
118
54
26
27
29
70
97
28
31
32
33
96
34
102
103
104
35
36
38
37
17
115
15
14
8
5
40
41
42
44
45
46
47
48
49
51
43
76 77
79
83
80
82
78
97
123

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1342
3
* Standard Hardware Item – May Be Purchased Locally
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 089100210001 BASE .......................................................................................1
2 A31703010008 * LOCK NUT (M10) ....................................................................1
3 A36131020100 * SPRING WASHER (M10).........................................................1
4 A35031025153 * FLAT WASHER (M10) ..............................................................2
5 518106300 TABLE SPINDLE......................................................................1
6 089100210032 TABLE......................................................................................1
7 089100208010 MITER SCALE .........................................................................1
8 A49010020056 RIVET (Ø2.5 X 5 mm)...............................................................6
9 A07003060257 * CAP SCREW (M6 X 25 mm)....................................................2
10 A36030612157 * SPRING WASHER (M6) ..........................................................2
11 518104200 CONTROL ARM ......................................................................1
12 518103100 LOCK HANDLE .......................................................................1
13 503118000 GROMMET..............................................................................1
14 A35030410018 * FLAT WASHER (M4) ................................................................5
15 580114000 POINTER .................................................................................1
16 A10003040107 * SCREW (M4 X 10 mm PAN HD.) .............................................3
17 518105400 LOCK PLATE ...........................................................................1
18 089100207018 FENCE.....................................................................................1
19 A36030814204 * SPRING WASHER (M8)...........................................................4
20 A07103080457 * CAP SCREW (M8 X 45 mm)....................................................4
21 A36031018255 * SPRING WASHER (M10).........................................................3
22 A07003100256 * CAP SCREW (M10 X 25 mm)..................................................2
23 089100207023 SUPPORT BRACKET ASSEMBLY ..........................................1
24 089100207024 HANDLE ..................................................................................1
25 089100207025 TENSION SPRING...................................................................1
26 588058200 LOCK BOLT.............................................................................1
27 589015108 SHOULDER SCREW ...............................................................1
28 A31703006004 * LOCK NUT (M6) ......................................................................1
29 089100207029 RETAINING SPRING HOLDER................................................1
30 089100208007 TABLE HOLD DOWN...............................................................1
31 A35010616105 * FLAT WASHER (M6) ................................................................1
32 A10003050106 * SCREW (M5 X 10 mm PAN HD.) .............................................4
33 A19003040093 * SCREW (M4 X 9 mm PAN HD.) ...............................................2
34 089100207034 LOWER GUARD ......................................................................1
35 589021300 RETRACT SPRING..................................................................1
36 089100207036 TABLE INSERT ........................................................................1
37 A19001040091 * SCREW (M4 X 9 mm PAN HD.) ...............................................1
38 A16003040083 * SCREW (M4 X 8 mm FLAT HD.)..............................................4
39 581410003 * SCREW ...................................................................................1
40 580411000 WARNING LABEL (UPPER GUARD).......................................1
41 089100207710 UPPER SAFETY GUARD ASSEMBLY
(INC. KEY NOS. 40 AND 51) ...................................................1
42 503412000 ARBOR BOLT ..........................................................................1
43 588035105 FLANGE ..................................................................................2
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your MITER SAW or when ordering repair parts.

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1342
4
44 089100207044 LOGO LABEL (UPPER GUARD)..............................................1
45 089100207045 BLADE.....................................................................................1
46 A10003040152 * SCREW (M4 X 15 mm PAN HD.) .............................................1
47 589032207 STOPPER................................................................................1
48 A31703004006 LOCK NUT (M4) ......................................................................1
49 089100207900 DATA PLATE LABEL ................................................................1
50 089100207050 PIVOT SUPPORT ....................................................................1
51 089100207051 WARNING LABEL ...................................................................1
52 A35031030300 * FLAT WASHER (M10) ..............................................................1
53 A70003040200 * SCREW (M4 X 20 mm PAN HD.) .............................................4
54 A10003050083 * SCREW (M5 X 8 mm PAN HD.) ...............................................1
55 089100207055 DUST BAG ..............................................................................1
56 A63020000428 O-RING....................................................................................1
57 588031004 * SCREW (M5 X 10 mm) ............................................................2
58 A50060040052 BALL BEARING (6004Z/RS)....................................................1
59 588030200 GEAR SHAFT ..........................................................................1
60 A45204040180 PARALLEL KEY .......................................................................1
61 588029007 LOCK RING.............................................................................1
62 588028300 GEAR .....................................................................................1
63 A46000150008 C-RING....................................................................................1
64 A50060000027 BALL BEARING (6000ZZ)........................................................1
65 588027005 COMPRESSION SPRING........................................................1
66 A47000040006 E-RING ....................................................................................1
67 588026106 SPINDLE LOCK PIN................................................................1
68 089100207068 ARM ........................................................................................1
69 089100210700 BASE ASSEMBLY (INC. KEY NOS. 1, 5, 7, 8, 96, 97 & 123) ..1
70 089100207702 LOWER GUARD ASSEMBLY
(INC. KEY NOS. 34, 97, 102 AND 103) ...................................1
71 089100207071 * SCREW (M4 X 45 mm PAN HD.) .............................................2
72 A30003010007 * HEX NUT (M10) .......................................................................1
73 A18003100206 * FIXED SCREW (M10 X 20 mm) ...............................................1
74 A30003012194 * LOCK NUT (M12) ....................................................................2
75 A36031226023 * FLAT WASHER (M12) ..............................................................1
76 588021203 STOPPER................................................................................1
77 A90003040167 * SCREW (M4 X 16 mm PAN HD.) .............................................1
78 089100207706 STOP PIN ASSEMBLY ............................................................1
79 A50006080049 BALL BEARING (608) ..............................................................1
80 A50060020056 BALL BEARING (6002) ............................................................1
81 588505000 HANG TAG (FR).......................................................................1
82 A63020000320 O-RING....................................................................................1
83 9053D01000 ARMATURE ASSEMBLY .........................................................1
84 578206000 * HEX BOLT (M6 X 16 mm) ........................................................2
85 A30003006003 * HEX NUT (M6) .........................................................................2
86 A10003050300 SCREW (M5 X 30 mm PAN HD.) .............................................4
* Standard Hardware Item – May Be Purchased Locally
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your MITER SAW or when ordering repair parts.

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1342
5
87 A90101050603 SCREW (M5 X 60 L+S PAN HD.).............................................2
88 089100207088 FIELD ASSEMBLY ...................................................................1
89 089100207705 D-HANDLE ASSEMBLY (INC. KEY NO. 53) ............................1
90 089100207090 SWITCH ACTUATOR...............................................................1
91 511308000 COMPRESSION SPRING........................................................1
92 A18003050054 * FIXED SCREW (M5 X 5 mm) ...................................................2
93 089100207704 MOTOR HOUSING ASSEMBLY
(INC. KEY NOS. 86-88, 92, 98, 99, 105-109 AND 111) .........1
94 580302000 SWITCH .................................................................................1
95 089100207703 OUTPUT SPINDLE ASSEMBLY
(INC. KEY NOS. 56 AND 58-64) .............................................1
96 588071004 LINE WARNING LABEL...........................................................2
97 089100207097 WARNING LABEL (NO HAND) ................................................3
98 089100207098 MOTOR HOUSING..................................................................1
99 089100207099 END CAP.................................................................................1
100 588004100 BEND RELIEF..........................................................................1
101 089100207101 POWER CORD ........................................................................1
102 538417000 RETAINING RING ...................................................................1
103 089100207103 ROLLER...................................................................................1
104 089100207104 BEVEL SCALE.........................................................................1
105 089100207105 LOGO LABEL (HOUSING).......................................................1
106 588007305 BRUSH HOLDER ....................................................................2
107 089100207107 BRUSH ASSEMBLY ................................................................2
108 588005105 BRUSH CAP............................................................................2
109 089100207109 WARNING LABEL ...................................................................1
110 089100207110 BAFFLE ...................................................................................1
111 A10003050150 * SCREW (M5 X 15 mm PAN HD.) .............................................2
112 089100207112 POINTER .................................................................................2
113 089100207113 HEX KEY (M35 X 115 mm) ......................................................1
114 589010200 PIVOT SHAFT..........................................................................1
115 518A08130 WORK CLAMP ASSEMBLY ....................................................1
116 589011308 WASHER .................................................................................1
117 089100207117 HANG TAG LABEL (TIP OVER)................................................1
118 A46000150008 C-RING....................................................................................1
119 A10003050350 * SCREW (M5 X 35 mm PAN HD.) .............................................4
120 089100207708 PIVOT SUPPORT ASSEMBLY
(INC. KEY NOS. 8, 23, 50, 104, 114 AND 116) ......................1
121 089100207709 CARRY HANDLE ASSEMBLY .................................................1
122 A35030511158 FLAT WASHER (M5) ................................................................1
123 089100210009 WEAR PAD ..............................................................................5
* Standard Hardware Item – May Be Purchased Locally
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY.
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your MITER SAW or when ordering repair parts.
983000942 OPERATOR’S MANUAL
04-10-08
(REV:06)

RYOBI 10 in. COMPOUND MITER SAW – MODEL NUMBER TS1342
6
WIRING DIAGRAM
WHITE LEAD
WHITE LEAD
POWER CORD
BLACK LEAD
YELLOW LEAD
YELLOW LEAD
YELLOW
LEAD
BROWN
LEAD
MOTOR
BRUSHES
SWITCH
