Ryobi RY18LTX33A-150 User manual

RY18LTX33A

2
Original Instructions
IMPORTANT!
It is essential that you read the instructions in this manual
before assembling, operating, and maintaining the
product.
Subject to technical modication.
Safety, performance, and dependability have been given top
priority in the design of your cordless line trimmer or edge
trimmer.
INTENDED USE
The cordless line trimmer is intended to be used only by
adults who have read and understood the instructions and
warnings in this manual and can be considered responsible
for their actions.
The product is intended only for outdoor use in a well-
ventilated area. For safety reasons, the product must be
adequately controlled by a two-handed operation.
When tted with the line trimmer head (and appropriate
guard), the product is intended for cutting long grass, pulpy
weed, and similar vegetation at or about ground level. The
cutting plane should be approximately parallel to the ground
surface when trimming and approximately vertical when
edging.
The product should not be used to cut or trim hedges,
bushes, or other vegetation where the cutting plane is not
parallel to the ground surface.
Do not use the product for any other purpose.
GENERAL SAFETY WARNINGS
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and instructions
may result in electric shock, re, and /or serious injury.
■When using the product, the safety rules must be
followed. For your own safety and that of bystanders,
please read these instructions before operating the
product. Please keep the instructions safe for later use.
■The product is not intended to be used by children or
persons with reduced physical, mental, or sensory
capabilities. Children should be adequately supervised
to ensure that they do not play with the product.
■Some regions have regulations that restrict the use of
the product. Check with your local authority for advice.
TRAINING
■Read the instructions carefully. Be familiar with all
controls and the proper use of the product.
■Never allow children or people who are unfamiliar with
these instructions to use the product. Local regulations
may restrict the age of the operator.
■Keep bystanders, children, and pets 15 m away from the
area of operation. Turn off the product if anyone enters
the area.
■Never use the product while tired, ill, or under the
influence of alcohol, drugs, or medication.
■Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their
property.
PREPARATION
■Wear full eye and hearing protection while operating the
product. If working in an area where there is a risk of
falling objects, head protection must be worn.
■Hearing protection may restrict the operator’s ability
to hear warning sounds. Pay particular attention to
potential hazards around and inside the working area.
■Wear heavy, long trousers, boots, and gloves. Do not
wear loose-fitting clothing, short trousers, or jewellery of
any kind. Do not use the product with bare feet.
■Secure long hair so that it is above shoulder level to
prevent entanglement in moving parts.
■Before use and after any impact, check that there are no
damaged parts on the product. A defective switch or any
part that is damaged or worn should be properly repaired
or replaced by an authorised service centre.
■Make sure that the cutting attachment is properly
installed and securely fastened.
■Never operate the product unless all guards, deflectors,
and handles are properly and securely attached.
■Consider the environment in which you are working.
Keep the working area free from wires, sticks, stones,
and debris, which if struck by the cutter, can become
thrown objects.
BATTERY TOOL USE AND CARE
■Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
■Use power tools only with specifically designated battery
packs. Use of any other battery packs may create a risk
of injury and fire.
■When the battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
■Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
LINE TRIMMER SAFETY WARNINGS
■Never allow children, persons with reduced physical,
sensory, or mental capabilities or lack of experience
and knowledge, or people who are unfamiliar with the
instructions to use the product.
■Use the product in daylight or with good artificial light.
■Avoid using the product on wet grass.
■Keep firm footing and balance at all times, and be sure
of proper footing on slopes.
■Do not walk backwards when using the product. Walk,
never run.
■Keep the head attachment below waist level.
■Never use the product with damaged guards or without
guards in place.
■Never fit a metal replacement line.
■Keep hands and feet away from the cutting means at all
times, especially when turning on the motor.

3
Original Instructions
■Beware, the cutting elements continue to rotate after the
motor is turned off.
■Beware of objects thrown by the cutting means. Clear
debris like small stones, gravel, and other foreign objects
from the work area before starting the operation. Wires
or string may become entangled with the cutting means.
■To reduce the risk of injury associated with contacting
moving parts, always turn off the product, remove the
battery pack, and allow both to cool down. Make sure
that all moving parts have come to a complete stop:
●before servicing
●before clearing a blockage
●before checking, cleaning, and working on the
product
●before changing accessories
●after striking a foreign object
●whenever leaving the product unattended
●whenever performing maintenance
●whenever the product starts to vibrate abnormally
■Wear full eye and hearing protection while operating the
product. If working in an area where there is a risk of
falling objects, head protection must be worn.
■Hearing protection may restrict the operator’s ability
to hear warning sounds. Pay particular attention to
potential hazards around and inside the working area.
■Wear heavy, long trousers, boots, and gloves. Do not
wear loose-fitting clothing, short trousers, or jewellery of
any kind. Do not use the product with bare feet.
■Secure long hair so that it is above shoulder level to
prevent entanglement in moving parts.
■The small blade fitted to the lawn guard is designed to
trim the newly extended line to the correct length for safe
and optimum performance. The blade is very sharp.
Do not touch the blade, particularly when cleaning the
product.
■Always ensure that ventilation openings are kept clear
of debris.
■Before use and after any impact, check that there are no
damaged parts on the product. A defective switch or any
part that is damaged or worn should be properly repaired
or replaced by an authorised service centre.
■Make sure that the cutting head attachment is properly
installed and securely fastened.
■Make sure that all guards, deflectors, and handles are
properly and securely attached.
■Do not modify the product in any way. This may increase
the risk of injury to yourself or others.
■Use only the manufacturer’s replacement cutting line.
Do not use any other cutting attachment.
■Immediately turn off the product and remove the battery
pack in the event of an accident or breakdown. Do not
operate the product again until it has been fully checked
by an authorised service centre.
■Ensure that the line cut-off blade in the guard is properly
positioned and secured before each use.
ADDITIONAL BATTERY SAFETY WARNINGS
To reduce the risk of re, personal injury, and product
damage due to a short circuit, never immerse the tool,
battery pack, or charger in uid or allow uid to ow inside
them. Corrosive or conductive uids, such as seawater,
certain industrial chemicals, and bleach or bleach-containing
products, etc., can cause a short circuit.
TRANSPORTATION AND STORAGE
■Turn off the product, remove the battery pack, and allow
both to cool down before storing or transporting.
■Remove all foreign materials from the product.
■Do not store or transport the product with the battery
pack fitted. Remove the battery pack, and secure it
separately. Store the product in a cool, dry, and well-
ventilated place that is inaccessible to children. Keep
the product away from corrosive agents, such as garden
chemicals and de-icing salts. Do not store the product
outdoors.
■For transportation in vehicles, secure the product
against movement or falling to prevent injury to persons
or damage to the product.
TRANSPORTING LITHIUM BATTERIES
■Transport the battery pack in accordance with local and
national provisions and regulations.
■Follow all special requirements on packaging and
labelling when transporting batteries by a third party.
Ensure that no batteries can come in contact with other
batteries or conductive materials while in transport
by protecting exposed connectors with insulating,
nonconductive caps or tape. Do not transport batteries
that are cracked or leaking. Check with the forwarding
company for further advice.
MAINTENANCE
■Use only original manufacturer’s replacement parts,
accessories, and attachments. Failure to do so can cause
possible injury, can contribute to poor performance, and
may void your warranty.
■Servicing requires extreme care and knowledge
and should be performed only by a qualified service
technician. Have the product serviced by an authorised
service centre only.
■Turn off the product and remove the battery back before
conducting any maintenance or cleaning work.
■You may make adjustments or repairs described in this
manual. For other repairs, contact an authorised service
centre.
■For the replacement line, use only a nylon filament line
of the diameter described in the specifications table of
this manual.
■After each use, clean the product with a soft, dry cloth.
Any part that is damaged should be properly repaired or
replaced by an authorised service centre.
■Check all nuts, bolts, and screws before each use and
at frequent intervals for proper tightness to ensure that
the product is in safe working condition. Any part that is
damaged should be properly repaired or replaced by an
authorised service centre.
■Bring the product to an authorised service centre to
replace damaged or unreadable labels.
■Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged periods,
ensure that you take regular breaks.

4
Original Instructions
KNOW YOUR PRODUCT
See page 5.
1. Rear handle
2. Lock-out trigger
3. Speed selector
4. Variable speed trigger
5. Lower shaft
6. Front handle
7. Spool cover
8. Spool
9. Eyelet
10. Line release button
11. Cutting line
12. Grass deflector
13. Screws
14. Battery pack
15. Charger
16. Operator's manual
SYMBOLS ON THE PRODUCT
Read and understand all the instructions
before operating the product. Follow all
the warnings and safety instructions.
Wear eye protection.
Wear ear protection.
Wear non-slip safety footwear when
using the product.
Wear non-slip, heavy-duty protective
gloves.
Do not use metal blades on the product.
Do not expose the product to rain or
damp condition.
Beware of thrown or ying objects.
Keep all bystanders, especially children
and pets, at least 15 m away from the
operating area.
Keep hands away from the cut-o󰀨 blade.
96
Guaranteed sound power level
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authority or retailer
for recycling advice.
European Conformity Mark
EurAsian Conformity Mark
Ukraine Conformity Mark
SYMBOLS IN THIS MANUAL
Parts or accessories sold separately
Note
Warning

5
12
1
2
3
4
5
6
7
8
9
10
11
13
14
15
16
RY18LTX33A-0
x 4
RY18LTX33A-125

6
x 4
3
12
2
1
3
1
2
1
3
2
2
1
1
4
7
2
5
8
6
4
7
3

7
4
7
p.13
p.8 p.10
p.12p.11

8
1

9
12
3
1
2
3
1
2
2

10
1
2
1
2
1
2
1
180°
2
3
4
5

11
1
2
1
1
2
2
3
1
23
4
4
5

12
2
1
2
1

13
2
1
2
1

PRODUCT SPECIFICATIONS
Cordless line trimmer
Model RY18LTX33A-0 /
RY18LTX33A-125
Weight 2.5 kg
Voltage 18 V d.c.
No-load speed 6,000 – 6,800/min
Cutting line diameter 1.65 mm
Cutting capacity 28 – 33 cm
Vibration total values determined according to EN 50636-
2-91 Annex BB
Vibration emission value
Front handle ah = 0.2/ 0.2 m/s²
Rear handle ah = 0.1/ 0.2 m/s²
Uncertainty K = 1.5 m/s²
Noise emission values determined according to EN
50636-2-91 Annex CC
A-weighted sound pressure
level at operator’s position LpA = 77.3 dB(A)
Uncertainty K = 3.0 dB
A-weighted sound power level LWA = 92.5 dB(A)
Uncertainty K = 3.7 dB
LWA + K = 97 dB(A)
BATTERY AND CHARGER
Model RY18LTX33A-125 RY18LTX33A-0
Battery pack RB18L25 -
Weight 0.46 kg -
Charger RC18120 -
Compatible
battery packs RB18..
Compatible
charger BCL14.., RC18..,
REPLACEMENT PART
Complete spool RAC124, RAC125
WARNING! The declared vibration total values and the
declared noise emission values given in this instruction
manual have been measured in accordance with a
standardised test and may be used to compare one tool with
another. They may be used for a preliminary assessment
of exposure.
The declared vibration and noise emission values represent
the main applications of the tool. However, if the tool is used
for di󰀨erent applications, used with di󰀨erent accessories,
or poorly maintained, the vibration and noise emission
may di󰀨er. These conditions may signicantly increase the
exposure levels over the total working period. An estimation
of the level of exposure to vibration and noise should take
into account the times when the tool is turned o󰀨 or when
it is running idle. These conditions may signicantly reduce
the exposure level over the total working period.
Identify additional safety measures to protect the operator
from the e󰀨ects of vibration and noise, such as maintaining
the tool and the accessories, keeping the hands warm (in
case of vibration), and organising work patterns.

RYOBI® WARRANTY APPLICATION CONDITIONS
In addition to any statutory rights resulting from the purchase, this product is covered
by a warranty as stated below.
1. The warranty period is 24 months for consumers and commences on the date
when the product was purchased. This date has to be documented by an invoice
or other proof of purchase. The product is designed and dedicated to consumer
and private use only. So there is no warranty provided in case of professional or
commercial use. This warranty applies only on new products.
2. There is a possibility to extend for a part of the range of power tools (AC/DC)
the warranty period over the period described above using the registration on
the www.ryobitools.eu website. The eligibility of products for extended warranty
is clearly displayed in stores and / or on packaging and is contained within the
product documentation. The end user is required to register his/her newly-
acquired products online within 30 days from the date of purchase. The end user
may register for the extended warranty in his/her country of residence if listed on
the online registration form where this option is valid. Furthermore, end users
must give their consent to the storage of their personal data that is required to be
entered online. They must also accept the terms and conditions. The registration
confirmation receipt, which is sent out by e-mail, and the original invoice showing
the date of purchase will serve as proof of the extended warranty.
3. The warranty covers all defects of the product during the warranty period due to
faults in workmanship or material at the purchase date. The warranty is limited to
repair and/or replacement and does not include any other obligations including
but not limited to incidental or consequential damages. The warranty is not valid
if the product has been misused, used contrary to the instruction manual, or has
been incorrectly connected to a power supply. This warranty does not apply to:
– any damage to the product that is the result of improper or lack of maintenance
– any product that has been altered or modified
– any product where original identification (trade mark, serial number) markings
have been defaced, altered or removed
– any damage caused by non-observance of the instruction manual
– any product not displaying the CE approval mark on the rating plate
– any product that has been attempted to be repaired by a non-authorised
warranty service centre or without prior authorisation by Techtronic Industries
– any product connected to improper power supply (amps, voltage, frequency)
– any product used with inappropriate fuel mixture (fuel, oil, ratio of oil/ fuel
mixture)
– any damage caused by external influences (water, chemical, physical,
shocks) or foreign substances
– normal wear and tear spare parts
– inappropriate use, overloading of the tool
– use of non-approved accessories or parts
– Accessories provided with the tool or purchased separately including but not
limited to blades, saw chains, cutting lines, etc.
– Any periodic adjustments to or maintenance cleaning of carburettors
– Components (parts and accessories) subject to natural wear and tear,
including but not limited to bump knobs, drive belts, clutch, blades of hedge
trimmers or lawn mowers, harness, cable throttle, carbon brushes, power
cord, tines, felt washers, hitch pins, blower fans, blower and vacuum tubes,
vacuum bag and straps, guide bars, saw chains, hoses, connector fittings,
spray nozzles, wheels, spray wands, inner reels, outer spools, cutting lines,
spark plugs, air filters, gas filters, mulching blades, etc.
4. For servicing, the product must be sent or presented to a RYOBI authorised
service station listed for each country in the following list of service station
addresses. In some countries your local RYOBI dealer undertakes to send the
product to the RYOBI service organisation. When sending a product to a RYOBI
service station, the product should be safely packed without any dangerous
contents such as petrol, marked with sender’s address and accompanied by a
short description of the fault.
5. A repair / replacement under this warranty is free of charge. It does not constitute
an extension or a new start of the warranty period. Exchanged parts or products
become our property. In some countries delivery charges or postage will have
to be paid by the sender. Your statutory rights arising from the purchase of the
product remain unaffected.
6. This warranty is valid in the European Community, Switzerland, Iceland, Norway,
Liechtenstein, Turkey, and Russia. Outside these areas, please contact your
authorised RYOBI dealer to determine if another warranty applies.
AUTHORISED SERVICE CENTRE
Any request or issue with the product can be addressed to your local authorised
service centres (visit www.ryobitools.eu) or directly to: Techtronic Industries GmbH,
Max Eyth Straße 10, 71364 Winnenden, Germany. Please state the serial number and
product type printed on the label.
DECLARATION OF CONFORMITY
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany
We declare under our sole responsibility that the product mentioned below
Cordless line trimmer
Brand: RYOBI
Model number: RY18LTX33A
Serial number range: 47567901000001 - 47567901999999
fulfills all the relevant provisions of the following European Directives, European
Regulations and harmonised standards:
2006/42/EC, 2014/30/EU, 2000/14/EC, 2005/88/EC, 2011/65/EU,
EN 60335-1:2012+A11:2014+A13:2017+A1:2019+A14:2019+A2:2019, EN
50636-2-91:2014, EN 62233:2008, EN 55014-1:2017+A11:2020,
EN 55014-2:2015
Measured sound power level: 92.5 dB(A)
Guaranteed sound power level: 96 dB(A)
Conformity assessment method to Annex V Directive 2000/14/EC amended by
2005/88/EC.
The notified body involved:
TÜV Rheinland LGA Products GmbH (NB 0197)
Tillystraße 2 90431 Nüremberg Germany
Todd Chipner
Vice President, Quality – Ryobi Asia
Winnenden, June 1, 2021
Authorised to compile the technical file:
Alexander Krug, Managing Director
Techtronic Industries GmbH
Max-Eyth-Straße 10, 71364 Winnenden, Germany
RYOBI is a trade mark of Ryobi Limited,
and is used under license.
© 2019–21 Techtronic Cordless GP.

961068239-01
Techtronic Industries GmbH
Max-Eyth-Straße 10,
71364 Winnenden, Germany
Techtronic Industries (UK) Ltd
Fieldhouse Lane
Marlow Bucks SL7 1HZ
UK
