Ryobi RY36LT33A User manual

ORIGINAL INSTRUCTIONS
Cordless Line
Trimmer
RY36LT33A
PLACEHOLDER

Important!
It is essential that you read the instructions in this manual before assembling,
operating, and maintaining the product.
Subject to technical modification.

1
Safety, performance, and dependability have been given
top priority in the design of your cordless line trimmer.
INTENDED USE
The cordless line trimmer is intended to be used only by
adults who have read and understood the instructions and
warnings in this manual and can be considered responsible
for their actions.
The product is intended only for outdoor use in a well-
ventilated area. For safety reasons, the product must be
adequately controlled by a two-handed operation.
When tted with the line trimmer head (and appropriate
guard), the product is intended for cutting long grass, pulpy
weed, and similar vegetation at or about ground level.
The cutting plane should be approximately parallel to the
ground surface when trimming.
The product should not be used to cut or trim hedges,
bushes, or other vegetation where the cutting plane is not
parallel to the ground surface.
Do not use the product for any other purpose.
GENERAL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
WARNING
When using the product, the safety rules must be
followed. For your own safety and that of bystanders,
please read these instructions before operating the
product. Please keep the instruction safe for later use.
WARNING
This product is not intended to be used by children or
persons with reduced physical, mental, or sensory
capabilities. Children should be adequately supervised
to ensure they do not play with the product.
WARNING
Some regions have regulations that restrict the use of
the product. Check with your local authority for advice.
TRAINING
■Read the instructions carefully. Be familiar with all
controls and the proper use of the product.
■Never allow children or people unfamiliar with these
instructions to use the product. Local regulations may
restrict the age of the operator.
■Keep bystanders, children, and pets 15 m away from
the area of operation. Stop the product if anyone enters
the area.
■Do not use the product while tired, ill, or under the
influence of drugs, alcohol, or medication.
■Keep in mind that the operator or user is responsible
for accidents or hazards occurring to other people or
their property.
PREPARATION
■Wear full eye and hearing protection while operating the
product. If working in an area where there is a risk of
falling objects, head protection must be worn.
■Hearing protection may restrict the operator’s ability
to hear warning sounds. Pay particular attention to
potential hazards around and inside the working area.
■Wear heavy, long trousers, boots, and gloves. Do not
wear loose-fitting clothing, short trousers, or jewellery
of any kind, and do not use the product with bare feet.
■Secure long hair so that it is above shoulder level to
prevent entanglement in moving parts.
■Before use and after any impact, check that there are
no damaged parts on the product. A defective switch
or any part that is damaged or worn should be properly
repaired or replaced by an authorised service centre.
■Make sure that the cutting attachment is properly
installed and securely fastened.
■Never operate the product unless all guards, deflectors,
and handles are properly and securely attached.
■Consider the environment in which you are working.
Keep the working area free from wires, sticks, stones,
and debris, which if struck by the cutter can become
thrown objects.
BATTERY TOOL USE AND CARE
■Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
■Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
■When the battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
■Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may
cause irritation or burns.
CORDLESS LINE TRIMMER SAFETY WARNINGS
■Never allow children, persons with reduced physical,
sensory, or mental capabilities or lack of experience
and knowledge, or people unfamiliar with these
instructions to use the product.
■Use the product in daylight or with good artificial light.
■Avoid using the product on wet grass.
■Keep proper footing and balance at all times, and be
sure of proper footing on slopes.
■Do not walk backwards when using the product. Walk,
never run.

2
■Keep the head attachment below waist level.
■Never use the product with damaged guards or without
guards in place.
■Do not fit a metal replacement line.
■Keep hands and feet away from the cutting means at all
times, especially when turning on the motor.
■Beware, the cutting means continue to rotate after the
motor is turned off.
■Beware of objects thrown by the cutting means. Clear
debris like small stones, gravel, and other foreign
objects from the work area before starting operation.
Wires or string may become entangled with the cutting
means.
■To reduce the risk of injury associated with contacting
moving parts, always turn off the product, remove the
battery pack, and allow both to cool down. Make sure
that all moving parts have come to a complete stop:
●before servicing
●before clearing a blockage
●before checking, cleaning, and working on the
product
●before changing accessories
●after striking a foreign object
●whenever leaving the product unattended
●whenever performing maintenance
●whenever the product starts to vibrate abnormally
■Wear full eye and hearing protection while operating the
product. If working in an area where there is a risk of
falling objects, head protection must be worn.
■Hearing protection may restrict the operator’s ability
to hear warning sounds. Pay particular attention to
potential hazards around and inside the working area.
■Wear heavy, long trousers, boots, and gloves. Do not
wear loose-fitting clothing, short trousers, or jewellery
of any kind, and do not use the product with bare feet.
■Secure long hair so that it is above shoulder level to
prevent entanglement in moving parts.
■The small blade fitted to the safety guard is designed to
trim the new extended line to the correct length for safe
and optimum performance. The blade is very sharp.
Do not touch the blade, particularly when cleaning the
product.
■Always ensure that ventilation openings are kept clear
of debris.
■Before use and after any impact, check that there are
no damaged parts on the product. A defective switch
or any part that is damaged or worn should be properly
repaired or replaced by an authorised service centre.
■Make sure that the cutting head attachment is properly
installed and securely fastened.
■Make sure that all guards, deflectors, and handles are
properly and securely attached.
■Do not modify the product in any way. This may
increase the risk of injury to yourself or others.
■Use only the manufacturer’s replacement cutting line.
Do not use any other cutting attachment.
■Immediately turn off the product and remove the battery
pack in the event of accident or breakdown. Do not
operate the product again until it has been fully checked
by an authorised service centre.
WARNING
Ensure that the line cut-off blade in the guard is properly
positioned and secured before each use.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING
To reduce the risk of re, personal injury, and product
damage due to a short circuit, never immerse your
tool, battery pack, or charger in uid or allow a uid to
ow inside them. Corrosive or conductive uids, such
as seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a short
circuit.
TRANSPORTATION AND STORAGE
■Turn off the product, remove the battery pack, and allow
the product to cool down before storing or transporting.
■Clean all foreign material from the product.
■Do not store or transport the product with the battery
pack fitted. Remove the battery pack and secure it
separately. Store the product in a cool, dry, and well-
ventilated place that is inaccessible to children. Keep
the product away from corrosive agents, such as
garden chemicals and de-icing salts. Do not store the
product outdoors.
■For transportation in vehicles, secure the product
against movement or falling to prevent injury to persons
or damage to the product.
TRANSPORTING LITHIUM BATTERIES
Transport the battery pack in accordance with local and
national provisions and regulations. Follow all special
requirements on packaging and labelling when transporting
batteries by a third party.
Ensure that no batteries can come in contact with other
batteries or conductive materials while in transport by
protecting exposed connectors with insulating, non-
conductive caps or tape. Do not transport batteries that are
cracked or leaking. Check with the forwarding company for
further advice.
MAINTENANCE
WARNING
Use only original manufacturer’s replacement parts,
accessories, and attachments. Failure to do so can cause
possible injury, can contribute to poor performance, and
may void your warranty.

3
WARNING
Servicing requires extreme care and knowledge
and should be performed only by a qualied service
technician. Have the product serviced by an authorised
service centre only. When servicing, use only original
replacement parts.
■Turn off the product and remove the battery pack before
conducting any maintenance or cleaning work.
■You may make adjustments or repairs described in
this manual. For other repairs, contact an authorised
service centre.
■For the replacement line, use only a nylon filament line
of the diameter described in the specification table of
this manual.
■After extending the new cutter line, always return the
product to its normal operating position before starting.
■After each use, clean the product with a soft, dry cloth.
Any part that is damaged should be properly repaired or
replaced by an authorised service centre.
■Check all nuts, bolts, and screws before each use and
at frequent intervals for proper tightness to ensure the
product is in safe working condition. Any part that is
damaged should be properly repaired or replaced by an
authorised service centre.
■Bring the product to an authorised service centre to
replace damaged or unreadable labels.
RESIDUAL RISK
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise during use, and
the operator should pay special attention to avoid the
following:
■injury caused by vibration
–Hold the product by the designated handles, and
restrict working time and exposure.
■injury caused by exposure to noise
–Wear hearing protection, and limit exposure.
■injury caused by flying debris
–Wear eye protection at all times.
RISK REDUCTION
It has been reported that vibrations from handheld tools
may contribute to a condition called Raynaud’s Syndrome.
Symptoms may include tingling, numbness, and blanching
of the ngers, usually apparent upon exposure to cold.
Hereditary factors, exposure to cold and dampness, diet,
smoking, and work practices are all thought to contribute to
the development of these symptoms. There are measures
that can be taken by the operator to possibly reduce the
effects of vibration:
■Keep your body warm in cold weather. When operating
the product, wear gloves to keep the hands and wrists
warm. It is reported that cold weather is a major factor
contributing to Raynaud’s Syndrome.
■After each period of operation, exercise to increase
blood circulation.
■Take frequent work breaks. Limit the amount of
exposure per day.
If you experience any of the symptoms of this condition,
immediately discontinue use and see your physician.
WARNING
Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.
KNOW YOUR PRODUCT
See page 7.
1. Battery port
2. Rear handle
3. Lock-out trigger
4. Variable speed trigger
5. Charger
6. Charger cable
7. Battery pack
8. Battery latch button
9. Spool cover
10. Spool
11. Cutting line
12. Line cut-off blade
13. Grass deflector
14. Lower shaft
15. Front handle
SYMBOLS ON THE PRODUCT
Read and understand all the instructions
before operating the product. Follow all
the warnings and safety instructions.
Wear eye protection.
Wear ear protection.
Wear non-slip safety footwear when
using the product.
Do not use metal blade(s) on the
product.
Do not expose the product to rain or
damp condition.
PLACEHOLDER

4
Beware of thrown or ying objects.
Keep all bystanders, especially children
and pets, at least 15 m away from the
operating area.
Keep hands away from blades.
Please read the instructions carefully
before using the product.
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authority or retailer
for recycling advice.
The following signal words and meanings are intended to
explain the levels of risk associated with this product:
DANGER
Indicates an imminently hazardous situation, which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION
Without safety alert symbol
Indicates a situation that may result in property damage.
SYMBOLS IN THIS MANUAL
Parts or accessories sold separately
Note
Warning
PLACEHOLDER

5
x 1
x 1
x 1
x 1
x 1 x 1
x 4
x 1
RY36LT33A-120

6
x 1
x 1
x 1 x 1x 4
x 1
RY36LT33A

7
13
1112
86
14
9
10
15
1
2
5
7
3
4

8
2
3
1
1
2
3
1
6
2
5

9
1
2
1
2
2
8
3 4
7

10
33 cm
28 cm
p.11 p.14
p.15 p.16 p.17

11
1

12
1
2
2
12

13
1
2
3

14
2
1
1
2
1
2
28 cm
33 cm
28 cm
33 cm
33 cm
28 cm
1
2
3
4

15
2
1
2
1
3
2
1
1
2
3
2
1

16
2
1
1
2

17
20191021v1d3
2
1
1
2

PRODUCT SPECIFICATIONS
Cordless Line Trimmer
Model RY36LT33A / RY36LT33A-120
Voltage 36V d.c.
No-load speed 6,400 – 7,400 min-1
Cutting line diameter 2.0 mm
Cutting capacity 28-33 cm
Vibration level (in accordance with EN 50636-2-91:2014 Annex
CC)
Rear handle 1.9 m/s2
Front handle 5.2 m/s2
Uncertainty of measurement 1.5 m/s2
Noise emission level (in accordance with EN 50636-2-91:2014
Annex CC)
A-weighted sound pressure
level at operator’s position 84.3 dB(A)
Uncertainty of measurement 2.5 dB
A-weighted sound power level 93.6 dB(A)
Uncertainty 2.5 dB
Weight (with harness, without
battery and charger) 2.8 kg
Weight (with harness, with
heaviest battery pack) 5.6 kg
Maximum weight (with harness,
battery, and charger) 5.0 kg
BATTERY AND CHARGER
Model RY36LT33A RY36LT33A-120
Battery pack - BPL3626D2
Weight - 1.43 kg
Charger - RY36C17A
Compatible battery
packs
BPL3615, BPL3626, BPL3626D2,
BPL3640, BPL3626D, BPL3640D,
BPL3640D2, BPL3650D, BPL3650D2
Compatible charger BCL3620, BCL3620S, BCL30F,
RY36C17A, RY36C60A
REPLACEMENT PART
Complete spool RAC102, RAC103, RAC133, RAC142,
RAC143
VIBRATION LEVEL
The declared vibration value has been measured with a
standard test method and may be used to compare one
tool with another.
The declared vibration value may be used in a preliminary
assessment of exposure.
The vibration emission during actual use of power tool can
differ from the declared total value depending on the ways
in which the tool is used.
Identify safety measures to protect yourself based on an
estimation of exposure in the actual conditions of use,
taking account of all parts of the operating cycle such
as the times when the tool is switched off and when it is
running idle in addition to the trigger time.
