Saab 2005 9-7X User manual

Seats and Restraint Systems ........................... 1-1
Front Seats ............................................... 1-2
Rear Seats ............................................... 1-5
Safety Belts .............................................. 1-7
Child Restraints ....................................... 1-25
Airbag System ......................................... 1-45
Restraint System Check ............................ 1-59
Features and Controls ..................................... 2-1
Keys ........................................................ 2-3
Doors and Locks ....................................... 2-8
Windows ................................................. 2-14
Theft-Deterrent Systems ............................ 2-16
Starting and Operating Your Vehicle ........... 2-19
Mirrors .................................................... 2-31
OnStar
®
System ...................................... 2-34
HomeLink
®
Wireless Control System ........... 2-36
Storage Areas ......................................... 2-41
Sunroof .................................................. 2-45
Vehicle Personalization ............................. 2-45
Instrument Panel ............................................. 3-1
Instrument Panel Overview .......................... 3-4
Climate Controls ...................................... 3-20
Warning Lights, Gages, and Indicators ........ 3-25
Driver Information Center (DIC) .................. 3-43
Audio System(s) ....................................... 3-56
Driving Your Vehicle ....................................... 4-1
Your Driving, the Road, and Your Vehicle ..... 4-2
Towing ................................................... 4-34
Service and Appearance Care .......................... 5-1
Service ..................................................... 5-3
Fuel ......................................................... 5-4
Checking Things Under the Hood ................. 5-8
All-Wheel Drive ........................................ 5-44
Rear Axle ............................................... 5-45
Front Axle ............................................... 5-46
Headlamp Aiming ..................................... 5-47
Bulb Replacement .................................... 5-47
Windshield Replacement ........................... 5-51
Windshield Wiper Blade Replacement ......... 5-51
Tires ...................................................... 5-54
Appearance Care ..................................... 5-85
Vehicle Identification ................................. 5-94
Electrical System ...................................... 5-94
Capacities and Specifications ................... 5-106
Maintenance Schedule ..................................... 6-1
Maintenance Schedule ................................ 6-2
Customer Assistance and Information .............. 7-1
Customer Assistance and Information ........... 7-2
Reporting Safety Defects ............................ 7-6
Index ................................................................ 1
2005 Saab 9-7X Owner Manual M
2005 - Saab 9-7X Owner Manual

Saab Automobile, Saab Cars USA, SAAB, Saab 9-7X,
9-7X and the Saab Emblem are registered trademarks
of Saab Automobile, AB.
This manual includes the latest information at the time it
was printed. We reserve the right to make changes
after that time without further notice. For vehicles first
sold in Canada, substitute the name “General Motors of
Canada Limited” for Saab Automobile, AB whenever
it appears in this manual.
Keep this manual in the vehicle, so it will be there if it is
needed while you are on the road. If the vehicle is
sold, leave this manual in the vehicle.
Canadian Owners
A French language copy of this manual can be obtained
from your dealer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
How to Use This Manual
Many people read the owner manual from beginning to
end when they first receive their new vehicle. If this
is done, it can help you learn about the features
and controls for the vehicle. Pictures and words work
together in the owner manual to explain things.
Index
A good place to quickly locate information about the
vehicle is the Index in the back of the manual. It is an
alphabetical list of what is in the manual and the
page number where it can be found.
Litho in U.S.A.
Part No. 0597X A First Edition
©
2005 General Motors Corporation. All Rights Reserved.
ii
2005 - Saab 97X Owner Manual

Safety Warnings and Symbols
There are a number of safety cautions in this book. We
use a box and the word CAUTION to tell about things
that could hurt you if you were to ignore the warning.
{CAUTION:
These mean there is something that could hurt
you or other people.
In the caution area, we tell you what the hazard is.
Then we tell you what to do to help avoid or reduce the
hazard. Please read these cautions. If you do not,
you or others could be hurt.
You will also find a circle
with a slash through it in
this book. This safety
symbol means “Do Not,”
“Do Not do this” or “Do Not
let this happen.”
iii
2005 - Saab 97X Owner Manual

Vehicle Damage Warnings
Also, in this manual you will find these notices:
Notice: These mean there is something that could
damage your vehicle.
A notice tells about something that can damage the
vehicle. Many times, this damage would not be covered
by your vehicle’s warranty, and it could be costly. But
the notice will tell what to do to help avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors or in
different words.
There are also warning labels on the vehicle. They use
the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along with
the text describing the operation or information
relating to a specific component, control, message,
gage, or indicator.
If you need help figuring out a specific name of a
component, gage, or indicator, reference the following
topics:
•Seats and Restraint Systems in Section 1
•Features and Controls in Section 2
•Instrument Panel Overview in Section 3
•Climate Controls in Section 3
•Warning Lights, Gages, and Indicators in Section 3
•Audio System(s) in Section 3
•Engine Compartment Overview in Section 5
iv
2005 - Saab 97X Owner Manual

These are some examples of symbols that may be found on the vehicle:
v
2005 - Saab 97X Owner Manual

✍NOTES
vi
2005 - Saab 97X Owner Manual

Front Seats ......................................................1-2
Power Seats ..................................................1-2
Power Lumbar ...............................................1-2
Heated Seats .................................................1-3
Power Reclining Seatbacks ..............................1-4
Head Restraints .............................................1-5
Rear Seats .......................................................1-5
Rear Seat Operation .......................................1-5
Safety Belts .....................................................1-7
Safety Belts: They Are for Everyone .................1-7
Questions and Answers About Safety Belts ......1-11
How to Wear Safety Belts Properly .................1-12
Driver Position ..............................................1-12
Safety Belt Use During Pregnancy ..................1-18
Right Front Passenger Position .......................1-19
Rear Seat Passengers ..................................1-19
Rear Safety Belt Comfort Guides ....................1-22
Safety Belt Pretensioners ...............................1-24
Safety Belt Extender .....................................1-24
Child Restraints .............................................1-25
Older Children ..............................................1-25
Infants and Young Children ............................1-27
Child Restraint Systems .................................1-31
Where to Put the Restraint .............................1-34
Top Strap ....................................................1-35
Top Strap Anchor Location .............................1-37
Lower Anchors and Tethers for
Children (LATCH) ......................................1-37
Securing a Child Restraint Designed for
the LATCH System ....................................1-39
Securing a Child Restraint in a
Rear Outside Seat Position .........................1-39
Securing a Child Restraint in the
Center Rear Seat Position ..........................1-41
Securing a Child Restraint in the
Right Front Seat Position ............................1-42
Airbag System ...............................................1-45
Where Are the Airbags? ................................1-47
When Should an Airbag Inflate? .....................1-50
What Makes an Airbag Inflate? .......................1-51
How Does an Airbag Restrain? .......................1-52
What Will You See After an Airbag Inflates? ........1-52
Passenger Sensing System ............................1-54
Servicing Your Airbag-Equipped Vehicle ...........1-58
Adding Equipment to Your Airbag-Equipped
Vehicle ....................................................1-58
Restraint System Check ..................................1-59
Checking the Restraint Systems ......................1-59
Replacing Restraint System Parts
After a Crash ............................................1-60
Section 1 Seats and Restraint Systems
1-1
2005 - Saab 97X Owner Manual

Front Seats
Power Seats
The power seat controls
are located on the
outboard side of the front
seat cushions. The
horizontal control adjusts
the seat cushion and
the vertical control adjusts
the seatback.
•Move the front of the horizontal seat control up or
down to adjust the front portion of the cushion.
•Move the rear of the horizontal seat control up or
down to adjust the rear portion of the cushion.
•Lift up or push down on the center of the horizontal
seat control to move the entire seat up or down.
•To move the seat forward or rearward, slide the
horizontal seat control forward or rearward.
•To recline the seatback, press the vertical control
rearward. To raise the seatback, press the vertical
control forward. See Power Reclining Seatbacks
on page 1-4 for more information.
Power Lumbar
The seatback lumbar
support can be adjusted
by moving the control
located on the outboard
side of the seat cushions.
To increase or decrease support, hold the control
forward or rearward. Keep in mind that as your
seating position changes, as it may during long trips,
so should the position of your lumbar support. Adjust
the seat as needed.
1-2
2005 - Saab 97X Owner Manual

Heated Seats
Your vehicle may have
heated front seats.
The buttons used to control
this feature are located
on the front door armrests.
The engine must be
running for the heated seat
feature to work.
To heat the entire seat, press the horizontal button with
the heated seat symbol. Press the button repeatedly
to cycle through the temperature settings of high,
medium, low and off. The indicator lights above the
button will glow to designate the level of heat
selected: three for high, two for medium, and one for
low. The low setting warms the seatback and seat
cushion until the seat temperature is near body
temperature. The medium and high settings heat the
seatback and seat cushion to a slightly higher
temperature. You will be able to feel heat in about
two minutes.
To heat only the seatback, press the button with the
words BACK ONLY. An indicator light on the switch will
glow to designate that only the seatback is being
heated. Additional presses will cycle through the heat
levels for the seatback only.
The feature will shut off automatically when the ignition
is turned off.
1-3
2005 - Saab 97X Owner Manual

Power Reclining Seatbacks
The vertical power seat control described earlier allows
the seatback to recline. See Power Seats on page 1-2
for more information.
But do not have a seatback reclined if your vehicle
is moving.
{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts cannot do their
job when you are reclined like this.
The shoulder belt cannot do its job. In a crash,
you could go into it, receiving neck or other
injuries.
The lap belt cannot do its job either. In a crash
the belt could go up over your abdomen. The
belt forces would be there, not at your pelvic
bones. This could cause serious internal
injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety belt
properly.
1-4
2005 - Saab 97X Owner Manual

Head Restraints
Adjust your head restraint so that the top of the restraint
is closest to the top of your head. This position
reduces the chance of a neck injury in a crash.
The head restraints lock into place when raised.
To release the head restraint and lower it, press
the tab located on the top of the seatback.
Rear Seats
Rear Seat Operation
Your vehicle has a 60/40 folding rear seat which lets
you fold the seatbacks down for more cargo space.
Pull up on the loop located where the seat cushion
meets the seatback to fold the seat cushion up and out
of the way. This will allow the seatbacks to fold flat
and increase the cargo area.
1-5
2005 - Saab 97X Owner Manual

The rear seatback levers
are located on the
outboard side of each
rear seatback.
Pull the seatback toward you as you lift up on the lever.
The head restraint will automatically fold out of the
way when the seatback is folded down.
To raise the seatback, lift up the seatback and push
until it locks into the upright position. Push and pull on
each seatback to make sure they are latched securely.
Then fold the bottom seat cushion back into place.
To return the head restraint to the upright position,
reach behind the seat and pull the restraint up until it
locks into place. Push and pull on the head restraint to
make sure that it is latched securely.
1-6
2005 - Saab 97X Owner Manual

Safety Belts
Safety Belts: They Are for Everyone
This part of the manual tells you how to use safety
belts properly. It also tells you some things you should
not do with safety belts.
{CAUTION:
Do not let anyone ride where he or she cannot
wear a safety belt properly. If you are in a
crash and you are not wearing a safety belt,
your injuries can be much worse. You can hit
things inside the vehicle or be ejected from it.
You can be seriously injured or killed. In the
same crash, you might not be, if you are
buckled up. Always fasten your safety belt,
and check that your passengers’ belts are
fastened properly too.
{CAUTION:
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a
collision, people riding in these areas are more
likely to be seriously injured or killed. Do not
allow people to ride in any area of your vehicle
that is not equipped with seats and safety
belts. Be sure everyone in your vehicle is in a
seat and using a safety belt properly.
Your vehicle has a light
that comes on as a
reminder to buckle up.
See Safety Belt Reminder
Light on page 3-28.
In most states and in all Canadian provinces, the law
says to wear safety belts. Here is why: They work.
1-7
2005 - Saab 97X Owner Manual

You never know if you will be in a crash. If you do have
a crash, you do not know if it will be a bad one.
A few crashes are mild, and some crashes can be so
serious that even buckled up, a person would not
survive. But most crashes are in between. In many of
them, people who buckle up can survive and sometimes
walk away. Without belts they could have been badly
hurt or killed.
After more than 30 years of safety belts in vehicles,
the facts are clear. In most crashes buckling up
does matter...a lot!
Why Safety Belts Work
When you ride in or on anything, you go as fast as
it goes.
Take the simplest vehicle. Suppose it is just a seat
on wheels.
1-8
2005 - Saab 97X Owner Manual

Put someone on it. Get it up to speed. Then stop the vehicle.
The rider does not stop.
1-9
2005 - Saab 97X Owner Manual

The person keeps going until stopped by something.
In a real vehicle, it could be the windshield... or the instrument panel...
1-10
2005 - Saab 97X Owner Manual

or the safety belts!
With safety belts, you slow down as the vehicle does.
You get more time to stop. You stop over more distance,
and your strongest bones take the forces. That is why
safety belts make such good sense.
Questions and Answers About
Safety Belts
Q: Will I be trapped in the vehicle after an accident
if I am wearing a safety belt?
A: You could be — whether you are wearing a safety
belt or not. But you can unbuckle a safety belt, even
if you are upside down. And your chance of being
conscious during and after an accident, so you can
unbuckle and get out, is much greater if you
are belted.
Q: If my vehicle has airbags, why should I have to
wear safety belts?
A: Airbags are in many vehicles today and will be in
most of them in the future. But they are supplemental
systems only; so they work with safety belts — not
instead of them. Every airbag system ever offered for
sale has required the use of safety belts. Even if you
are in a vehicle that has airbags, you still have to
buckle up to get the most protection. That is true not
only in frontal collisions, but especially in side and
other collisions.
1-11
2005 - Saab 97X Owner Manual

Q: If I am a good driver, and I never drive far from
home, why should I wear safety belts?
A: You may be an excellent driver, but if you are in an
accident — even one that is not your fault — you
and your passengers can be hurt. Being a good
driver does not protect you from things beyond your
control, such as bad drivers.
Most accidents occur within 25 miles (40 km) of
home. And the greatest number of serious injuries
and deaths occur at speeds of less than
40 mph (65 km/h).
Safety belts are for everyone.
How to Wear Safety Belts Properly
This part is only for people of adult size.
Be aware that there are special things to know about
safety belts and children. And there are different
rules for smaller children and babies. If a child will be
riding in your vehicle, see Older Children on page 1-25
or Infants and Young Children on page 1-27. Follow
those rules for everyone’s protection.
First, you will want to know which restraint systems your
vehicle has.
We will start with the driver position.
Driver Position
Lap-Shoulder Belt
The driver has a lap-shoulder belt. Here is how to wear
it properly.
1. Close and lock the door.
2. Adjust the seat so you can sit up straight.
To see how, see “Seats” in the Index.
3. Pick up the latch plate and pull the belt across you.
Do not let it get twisted.
1-12
2005 - Saab 97X Owner Manual

The shoulder belt may lock if you pull the belt
across you very quickly. If this happens, let the belt
go back slightly to unlock it. Then pull the belt
across you more slowly.
4. Push the latch plate into the buckle until it clicks.
Pull up on the latch plate to make sure it is secure.
If the belt is not long enough, see Safety Belt
Extender on page 1-24.
Make sure the release button on the buckle is
positioned so you would be able to unbuckle the
safety belt quickly if you ever had to.
5. To make the lap part tight, pull up on the
shoulder belt.
The lap part of the belt should be worn low and snug on
the hips, just touching the thighs. In a crash, this applies
force to the strong pelvic bones. And you would be less
likely to slide under the lap belt. If you slid under it, the
belt would apply force at your abdomen. This could cause
serious or even fatal injuries. The shoulder belt should go
over the shoulder and across the chest. These parts of
the body are best able to take belt restraining forces.
The safety belt locks if there is a sudden stop or crash,
or if you pull the belt very quickly out of the retractor.
1-13
2005 - Saab 97X Owner Manual

Q: What is wrong with this?
A: The shoulder belt is too loose. It will not give nearly
as much protection this way.
{CAUTION:
You can be seriously hurt if your shoulder belt
is too loose. In a crash, you would move
forward too much, which could increase injury.
The shoulder belt should fit against your body.
1-14
2005 - Saab 97X Owner Manual
