Saeco PHEDRA User manual

Automatic drink vending machine
Model
PHEDRA
Type: D.A. 5P07
WARNING: This instruction manual is intended exclusively for specialized personnel.
USE AND MAINTENANCE
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
2
CONTENTS
CONTENTS ............................................. 2
MAIN PARTS - ESPRESSO VERSION.......... 3
MAIN PARTS - INSTANT VERSION............ 5
MAIN PARTS - T.T.T. VERSION .................. 7
MAIN PARTS - CAPPUCCINO VERSION .... 9
1 - INTRODUCTION TO THE MANUAL... 11
1.1 Introduction...................................................11
1.2 Symbols used................................................11
2 - INFORMATION ON THE VENDING MACHINE ... 11
2.1 Information for the Maintenance Technician.....11
2.2 Description and intended use..........................12
2.3 Vending Machine Identification ......................12
2.4. Technical specifications .................................13
3 SAFETY ............................................ 13
3.1 Introduction...................................................13
3.2 General safety regulations..............................13
3.3 Operators’ requirements ................................14
3.4 Safety devices ...............................................14
3.5 Residual risks ................................................15
4 - HANDLING AND STORAGE............. 15
4.1 Unloading and handling ................................15
4.2 Storage ........................................................15
5 - INSTALLATION ............................... 15
5.1 Important......................................................15
5.2 Unpacking and positioning ............................16
5.3 Label application...........................................16
5.4 Fitting the payment systems ............................17
5.5 Connection to water mains.............................18
5.6 Connection to the electric network...................18
5.7 Coffee Grounds Discharge Setting ..................19
5.8 Liquid Drain Setting .......................................19
5.9 Drip Tray Locking ..........................................20
5.10 Front Door Intermediate Locking .....................20
6 - CONTROLS DESCRIPTION ............... 21
6.1 Display.........................................................21
6.2 Keypad.........................................................21
6.3 Key description in standard operation mode....21
6.4 CPU card keys...............................................21
7 - SUPPLY AND STARTING UP ............ 22
7.1 Container supply (Espresso)............................22
7.2 Container supply (Instant)...............................22
7.3 Container supply (T.T.T.) ................................23
7.4 Container supply
(Cappuccino) ......................... 23
7.4.1 Coffee bean supply ............................................24
7.4.2 Instant product supply..........................................24
7.5 Coffee grinding calibration ............................25
7.6 Dose calibration ............................................25
7.7 First start-up of the vending machine...............26
7.8 Filling the boiler manually ..............................26
7.9 Use of the vending machine ...........................26
8 - PROGRAMMING AND MAINTENANCE
MENU ........................................... 27
8.1 Key description of programming and
maintenance phases ......................................27
8.2 Programming menu .......................................27
8.2.1 Entering the programming menu............................ 27
8.2.2 Structure of the programming menu........................28
8.2.3 Description of messages in the programming menu ...29
8.3 Maintenance menu........................................41
8.3.1 Entering the maintenance menu.............................41
8.3.2 Structure of the maintenance menu.........................41
8.3.3 Description of messages in the maintenance menu....41
8.4 Machine Ready/Free Button................................. 43
8.5 Reset ............................................................43
9 - OPERATION AND USE .................... 44
9.1 Beverage selection ........................................44
9.2 Cappuccino with cold milk function
(only for Cappuccino version).........................44
10 - CLEANING AND MAINTENANCE ..... 44
10.1 General notes for correct operation.................45
10.2 Cleaning and scheduled maintenance .............45
10.2.1 Maintenance schedule ........................................45
10.2.2 Cleaning the Drip Tray and the Coffee Grounds
Drawer.............................................................45
10.2.3
Cleaning the tray and drawer - Version with extension ...45
10.2.4 Cleaning of the coffee brew group ........................46
10.2.5 Cleaning the dispensing arm ................................ 46
10.2.6
Cleaning the instant product dispenser and the mixer ...47
10.2.7 Cleaning the containers.......................................48
10.2.8 Cleaning the coffee grinder..................................48
10.2.9
Semi-automatic cleaning of the Cappuccinatore
(only for Cappuccino version) ................................49
10.2.10 Manual cleaning of the Cappuccinatore
(only for Cappuccino version) ...............................50
10.3 Software Update ...........................................51
11 - DISPLAY MESSAGES ....................... 52
11.1 Messages during operation ............................52
11.2 Error messages..............................................52
12 - STORAGE - DISPOSAL .................... 54
12.1 Change of location ........................................54
12.2 Inactivity and storage periods.........................54
13 - INSTRUCTIONS FOR END-OF-LIFE DI-
SPOSAL TREATMENT ...................... 54
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
3
MAIN PARTS - ESPRESSO VERSION
1
2
3
4
5
6
7
Fig. 2
1 Top door
2 Display
3 Front door
4 Buttons
5 Dispensing outlet (beverage dispensing)
6 Coupling for connection to water network
7 Power cord outlet
Fig. 1
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
4
8 Door lock
9 Front door fastener knob
10 CPU electronic board
11 Coffee bean hopper
12 Container 2/3 (instant products)
13 Container 1 (instant products)
14 Adjustable powder dispensing channel
15 Instant product dispenser
16 Mixer
17 Spiral mixer
18 Safety switch
19 Brewing arm
20 Coffee grounds drawer
21 Grill
22 Coffee grinder
23 Brew group
22
23
8
9
10
11
12
13
14
15
16
17
18
19
21
Fig. 3
20
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
5
MAIN PARTS - INSTANT VERSION
6
7
Fig. 1
1 Top door
2 Display
3 Front door
4 Buttons
5
Dispensing outlet (beverage dispensing)
6 Coupling for connection to water network
7 Power cord outlet
24 Extension (option)
1
2
3
4
5
Fig. 2
24
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
6
8 Door lock
9 Front door fastener knob
10 CPU electronic board
12 Container 2/3 (instant products)
13 Container 1 (instant products)
14 Adjustable powder dispensing channel
15 Instant product dispenser
16 Mixer
18 Safety switch
19 Brewing arm
20 Coffee grounds drawer
21 Grill
25 Container 5 (instant products)
26 Container 4 (instant products)
27 Grill for extension (option)
28 Powder diverter for small-type containers
29 Coffee grounds drawer (option)
30 Drip conveyor (option)
31 Drip tray (option)
28
8
9
10
25
26
12
13
14
15
16
18
19
21
27
20
29
30
31
Fig. 3
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
7
MAIN PARTS - T.T.T. VERSION
6
7
Fig. 1
Fig. 2
1 Top door
2 Display
3 Front door
4 Buttons
5
Dispensing outlet (beverage dispensing)
6 Coupling for connection to water network
7 Power cord outlet
1
2
3
4
5
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
8
8 Door lock
9 Front door fastener knob
10 CPU electronic board
11 Coffee bean hopper
12 Container 1/2 (instant products)
14 Adjustable powder dispensing channel
15 Instant product dispenser
16 Mixer
18 Safety switch
19 Brewing arm
20 Coffee grounds drawer
21 Grill
22 Coffee grinder
32 Container 3 (“fresh brew” pre-ground coffee)
33 T.T.T. Brew group
22
33
8
9
10
11
32
12
14
15
16
18
19
21
Fig. 3
20
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
9
MAIN PARTS - CAPPUCCINO VERSION
6
7
Fig. 1
1 Top door
2 Display
3 Front door
4 Buttons
5
Dispensing outlet (beverage dispensing)
6 Coupling for connection to water network
7 Power cord outlet
24 Extension (option)
1
2
3
4
5
Fig. 2
24
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
10
8 Door lock
9 Front door fastener knob
10 CPU electronic board
11 Coffee bean hopper
12 Container 2/3 (instant products)
13 Container 1 (instant products)
14 Adjustable powder dispensing channel
15 Instant product dispenser
16 Mixer
18 Safety switch
19 Brewing arm
20 Coffee grounds drawer
21 Grill
22 Coffee grinder
23 Brew group
27 Grill for extension (option)
29 Coffee grounds drawer (option)
30 Drip conveyor (option)
31 Drip tray (option)
34 Cappuccinatore
35 Hose for Cappuccinatore
8
9
10
11
12
13
14
15
16
18
34
19
21
27
20
29
30
31
Fig. 3
22
23
35
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
11
User
Indicates the user of the vending machine. This person is
not authorized to carry out any cleaning or maintenance
operation.
Supply operator
Indicates operations to be carried out only by personnel in
charge of supplying and cleaning the vending machine.
Maintenance operations requiring a Maintenance Technician
are not to be performed by the supply operator.
Maintenance Technician
Indicates operations to be carried out by qualified personnel
in charge of maintenance.
The Maintenance Technician is the only person authorized
to keep the MICROSWITCH ENABLING KEY, by which the
security systems can be disabled.
2 - INFORMATION ON THE
VENDING MACHINE
2.1 Information for the
Maintenance Technician
The vending machine must be installed in a well-lit, dry and
not dusty area, protected from exposure.
To guarantee the correct operation and reliability over time,
the following is recommended:
- ambient temperature: from +1°C to +32°C;
- maximum humidity: 90% (not condensed).
For special installations not covered in this publication,
please contact the dealer or the local importer. If this is not
possible, please contact the Manufacturer directly.
AUTHORIZED CUSTOMER SERVICE CENTRES are available
for information and explanations about the vending machine,
and to provide technical assistance or spare parts.
The Maintenance Technician must carefully read and respect
the safety warnings contained in this manual so that every
intervention concerning installation, starting up, use and
maintenance will be safely carried out.
It is the Maintenance Technician’s absolute responsibility to
give the keys to access the inside of the vending machine
to another operator (Supply Operator), provided that the
Maintenance Technician bears full responsibility for all work
carried out.
This manual is an integral part of the machine and must be
always read carefully before performing any operation.
1 - INTRODUCTION TO THE
MANUAL
1.1 Introduction
Important
This publication is an integral part of the vending machine and
must be read carefully to ensure the machine is used correctly
and in compliance with essential safety requirements.
This manual contains the technical information required for
the correct use, installation, cleaning, and maintenance of
the vending machine model PHEDRA. Always refer to this
publication before carrying out any operation.
Manufacturer: SAECO Vending S.p.A.
Località Casona, 1066 - 40041 Gaggio Montano
Bologna, Italy
This publication should be kept carefully, together with the
vending machine throughout its operational life, even in case
of changes of ownership.
Should this manual be lost or worn out, a copy can be
requested from the Manufacturer or an Authorized Customer
Service Centre by indicating all data on the identification
plate on the back of the vending machine.
1.2 Symbols used
This publication contains various warnings which indicate
different degrees of danger or skills required.
The symbol is integrated with a message suggesting use
procedures or actions and providing useful information for
the correct operation of the machine.
Warning
Indicates dangerous situations for the users, supply operators
and maintenance technicians dealing either with the vending
machine or the product to be dispensed.
Important
Indicates the operations for keeping the vending machine in
good working order.
Recommended solutions
Indicates alternative procedures that make the programming
and/or maintenance operations quicker.
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
12
2.2 Description and intended
use
The vending machine is intended for automatic distribution of
coffee and hot beverages (decaffeinated coffee, cappuccino,
chocolate, etc.) and is programmable for every single type of
dispensing dosage. The instant products must be consumed
immediately, and cannot be preserved for a long time.
Any other use is to be considered improper and therefore
dangerous.
Do not place any product inside the distributor which may
be dangerous as a result of unsuitable temperatures.
With reference to the definition of “professional appliance” given by the
standard EN60335-2-75 for vending machines, this appliance can not be
classed as professional.
Important
Improper use of the vending machine invalidates all warranties.
The Manufacturer declines any liability for damage to property
or injury to persons.
Improper use also includes:
- any use of the vending machine other than the intended use
and/or according to procedures which are not described
in this publication;
- any intervention on the vending machine which differs from
the instructions given in this publication;
- any alteration of components and/or safety devices
without prior consent of the Manufacturer or carried out
by personnel not authorized for such operations;
- any location of the appliance which is not recommended
in this manual.
Fig. 4
Data plate
2.3 Vending Machine
Identification
The vending machine is identified by the name, model and
serial number which can be found on the relevant data
plate (Fig. 4).
The following data can be found on the plate:
- name of Manufacturer;
- marks of compliance;
- model;
- serial number;
- year and month of manufacture;
- supply voltage (V);
- supply frequency (Hz);
- electrical power consumption (W).
Warning
It is strictly forbidden to tamper with or modify the data
plate.
Important
When contacting the AUTHORIZED CUSTOMER SERVICE
CENTRES always refer to this plate and its relevant data.
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
13
Fig. 6
2.4. Technical specifications
Data plate
showing minimum
and maximum
water supply
pressure
Container capacity
Coffee beans: 1,00 kg
Chocolate: 1,75 kg
Milk: 0,65 kg
Lemon tea: 1,50 kg
Ginseng:
double: 1,85 kg, standard: 1,15 kg
Ground coffee: 0,62 kg
Freeze-dried coffee:
standard: 0,41 kg, small: 0,23 kg
Barley:
standard: 0,36 kg, small: 0,20 kg
Height:
594 mm standard
714 mm with extension
Width: 394 mm
Depth: 430 mm
Weight:
31 kg Espresso
35 kg Instant with extension
31 kg T.T.T.
38 kg Cappuccino with extension
Power consumption: see data plate
Supply voltage: see data plate
Electric voltage frequency: see data plate
Power cord length: 1,600 mm
Water mains connection: 3/4” Gas type
Water mains pressure: see figure 6
3 SAFETY
3.1 Introduction
In compliance with the Low Tension Directive 2006/95/
EC (which replaces the directive 73/23/EEC and following
amendments) and CE Marking Directive 93/68/EEC,
SAECO VENDING has drawn up a technical file of the
PHEDRA vending machine held at its plants. The following
regulations were taken into account during the design
phase:
- EN 55014 - EN 6100-3-2
- EN 61000-3-3 - EN 61000-4-2
- EN 61000-4-3 - EN 61000-4-4
- EN 61000-4-5 - EN 61000-4-11
- EN 60335-2-75 - EN 60335-1
3.2 General safety regulations
It is forbidden to:
- tamper with or disable the safety systems installed on the
vending machine;
- carry out maintenance on the vending machine without
unplugging it first;
- install the vending machine outdoors. It should be placed in
dry areas where the temperature never falls below 1°C;
- use the vending machine for purposes other than those
indicated in the sale contract and in this publication;
- connect the appliance to the mains using multi-sockets or
adapters;
- use water jets to clean the vending machine (Fig. 6).
It is compulsory to:
- check the electrical power line for conformity;
- use original spare parts;
- read the instructions contained in this publication and in
the enclosed documents carefully;
- use personal protection devices during installation, testing
and maintenance operations.
Fig. 7
Fig. 5
594
430
394
714
Standard version
Extension version
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
14
Precautions for preventing human errors:
- make the operators aware of safety issues;
- handle the vending machine, either packaged or
unpackaged, in safe conditions;
- have a thorough knowledge of the installation procedures,
its operation and limits;
- dismantle the vending machine in safe conditions, in
accordance with the environmental protection and health
and safety laws in force.
Warning
In case of failure or malfunctioning contact only qualified
CUSTOMER SERVICE personnel.
Important
The Manufacturer declines any liability for any damage
caused to property or injury caused to persons as a result of
failure to observe the safety regulations described here.
Important
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
3.3 Operators’ requirements
Three operators with different skills are required in order to
guarantee the safety of the vending machine:
User
Access to the internal part of the vending machine is forbidden
to the user.
Supply operator
The Maintenance Technician assigns the safekeeping of the
access key to the Supply operator who is in charge of product
supply, external cleaning, and starting up / stopping of the
vending machine.
Warning
The Supply Operator is not authorized to carry out operations
which are indicated as being the duties of the Maintenance
Technician in this publication.
Maintenance Technician
The Maintenance Technician is the only person authorized
to intervene and start programming procedures, and perform
adjusting, setting up and maintenance operations on the
vending machine.
Fig. 8
3.4 Safety devices
The vending machine is equipped with:
- A microswitch (Ref. 18, Fig. 8) automatically cuts out the
power supply when the front panel is opened.
The microswitch can be disabled by inserting the key (Ref.
24, Fig. 8).
- A microswitch (Ref. 25, Fig. 8) blocks vending machine
operation when the drip tray and/or coffee grounds
drawer are not correctly positioned. A message indicating
the incorrectly positioned part appears on the display.
Maintenance Technician
In case of programming or setting up operations only the
Maintenance Technician can intervene by inserting the
relevant key into the safety switch (rif. 24, fig. 8) and resetting
the voltage even if the door is open.
Warning
This operation, necessary for starting up the vending machine,
disables the safety system.
It must therefore be carried out by qualified personnel
(Maintenance Technician) aware of the risks resulting from
the presence of live or moving components.
25
18
24
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
15
3.5 Residual risks
Warning
Risk of scalding if hands are placed inside the outlet during
brewing.
Do not remove the cup or put your hands inside the
compartment during beverage brewing before the brewing
cycle has finished.
Before removing the cup from the outlet, please wait for the
message “REMOVE CUP” on display.
Important
Before brewing another beverage, check that the previous
one has been taken out and that the cup support is empty.
4 - HANDLING AND
STORAGE
4.1 Unloading and handling
Unloading and handling operations after transportation
must be carried out only by qualified personnel and using
suitable equipment.
Warning
The vending machine must always be kept in the upright
position. Avoid:
- dragging the vending machine;
- overturning or laying the vending machine flat during
transport and handling;
- shaking the vending machine;
- leaving the vending machine exposed to the elements, in
humid areas or close to heat sources.
4.2 Storage
If the vending machine is not installed immediately, it should
be stored in a sheltered area, conforming to the following
instructions:
- the packaged vending machine must be stored in a closed,
dry area at a temperature between 1°C and 40°C;
- do not put other appliances or boxes on the vending
machine;
- it is always good practice to protect the vending machine
from any deposits of dust or other material.
Fig. 9
5 - INSTALLATION
5.1 Important
Warning
The vending machine cannot be installed outdoors; avoid
placing it in areas where the temperature is less than 1°C or
more than 32°C and in particularly dump or dusty areas.
Before unpacking, check that the installation area complies
with the following specifications:
- the power socket must be located in an easily accessible
area, not more than 1.5 meters away;
- the socket voltage must comply with that on the identification
plate;
- the surface or floor must NOT have a gradient of more
than 2°.
If the vending machine needs to be positioned close to a wall,
it is necessary to leave a space of at least 15 cm between
the back and the wall in order to keep the air outlet grille
free (Fig. 9).
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
16
Fig. 10
- Instruction booklet
- Power cord
- Product labels and prices
The vending machine is protected by an expanded
polyethylene foam sheet and a plastic bag inside a box
(Fig. 11).
5.2 Unpacking and
positioning
On receipt of the vending machine make sure that it has
not been damaged during transportation and that package
has not been tampered with or that internal parts have not
been removed.
An envelope, called “CUSTOMER KIT” is supplied with the
vending machine; it contains the objects shown in Fig. 10.
Fig. 11
If damage of any kind is found, the courier must be informed
and notice must be given to the importer or the seller
immediately. If these are not in the purchaser’s country,
please contact the manufacturing company directly.
The accessory bag contains:
- 1 key for the brew group;
5.3 Label application
Product labels
Open the vending machine. Insert the product labels (Fig.
12).
Check the exact position of the labels against the selection
key (Fig. 13a,13b, 13c, 13d).
Fig. 12
Fig. 13a
Espresso version
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
17
5.4 Fitting the payment
systems
Important
The vending machine is not supplied with any payment
system, which must be installed by the person in charge of
its fitting.
The vending machine is designed for the installation of
various payment systems, such as:
- Parallel coin validator, 24 V DC
- Cashless reader (EXECUTIVE, PRICE HOLDING, MDB, and
BDV systems)
Coin
validator
Cashless
reader
Fig. 13b
Fig. 13c
Instant version
T.T.T. version
Fig. 13d
Cappuccino version
Fig. 14
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
18
Fig. 15
5.5 Connection to water
mains
Important
The pressure reducer is calibrated during assembly. Should
problems occur with the calibration of the pressure reducer,
the outlet pressure value must absolutely be reset to 0.8 – 1
bar max. Different or approximate calibration may cause
product quality and quantity variations when brewed.
Important
It is recommended to use a descaling device for the water
network supplying the vending machine, especially for water
with a high calcium and magnesium content (hard water).
Connect the vending machine to a drinking water supply
pipe with a pressure ranging between 1.5 and 8 bars (see
data plate).
Important
Before connecting the appliance to water network, please
read and follow the applicable regulations in force in your
country.
Remove the cap from the coupling placed on the vending
machine back panel (Fig. 15). Connect the water supply
pipe to the 3/4” Gas coupling of the vending machine
(Fig. 15).
5.6 Connection to the
electric network
Warning
The Maintenance Technician, who is responsible for the
installation of the vending machine, must ensure that:
- the electric system complies with current safety
regulations;
- the supply voltage corresponds to that indicated on the
data plate.
If in doubt, do not proceed with the installation and ask
qualified and authorized personnel to check the system
accurately.
The vending machine is equipped with a power cord which
must be plugged into the appropriate socket on the vending
machine back panel (Fig. 16).
Important
After the chosen payment system has been installed,
the corresponding parameters can be set through the
programming menu (see 8.2).
Warning
The Manufacturer declines any liability for any damage to the
vending machine, to property and/or injury to persons, caused
by the installation of the payment system. The responsibility
falls to the person who carried out the installation.
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
19
5.7 Coffee Grounds Discharge
Setting
The appliance is setup for direct discharge of the coffee
grounds into the bag in the dedicated cabinet or into another
container located below the appliance (ex. bar counter).
For this setting, the plate (Ref. A, Fig. 18) and coffee grounds
drawer (Ref. A, Fig. 19) must be cut along the indicated
marks.
Remove the tab the coffee grounds drawer hooks to (Ref. B,
Fig. 19) using a cutter or a jigsaw.
Fig. 18
Fig. 19
Fig. 20
A
A
B
A
Important
The appliance has an alarm signal to indicate when to empty
the coffee grounds in the standard version. For this setting it
is necessary to exclude this counter using the menu.
5.8 Liquid Drain Setting
The appliance is setup for direct drainage of the drip tray into
container in the dedicated cabinet or into another container
located below the appliance.
To use this setting, cut (or drill a hole in) the panel in the
indicated area (Ref. A, Fig. 20).
Do not use adapters or multi-sockets (Fig. 17).
Fig. 17
Fig. 16
For more information visit www.Gumball.com | 800-260-0010 | [phone]

English
20
5.9 Drip Tray Locking
Important
This option can be used to guarantee the appliance additional
safety.
It is possible to block the removal of the drip tray without
opening the door.
To use this option, remove the two locking pins integrated
on the drip tray (Ref. A, Fig. 21).
Divide them and, after trimming them with a cutter, glue them
on the two studs (Ref. A, Fig. 22) located on the lower front
part of the drip tray (thus lengthening the centring pieces).
In this manner, it will no longer be possible to remove the
drip tray without first opening the door.
Fig. 21
Fig. 22
A
A
5.10 Front Door Intermediate
Locking
In order to perform an unscheduled maintenance lock the
front door as shown in Fig. 23.
Fig. 23
Fig. 24
This is possible after opening the vending machine, by
turning the key clockwise and fitting the slots (Ref. A, Fig.
24) on the pins (Ref. B, Fig. 24).
B
A
For more information visit www.Gumball.com | 800-260-0010 | [phone]
