Safavieh Luigi BST7000A User manual

CARE AND MAINTENANCE
Spot clean using a mild water-free solvent. Only a professional cleaner shuould
undertake a complete overall cleaning.
The use of steam or water-based cleaners may cause excessive shrinking or staining.
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this
item
* This item should be assembled on a soft surface to prevent scratching the finish
during assembly
* This item may require periodic tightening
Model# BST7000A
Product Dimensions: 22.05"Wx20.08"Dx36.55"H
Part Lise and Hardware List
A
C
B
D
E
1
2
3
4
5
6
Backrest
Chair Leg
Footrest
Apron with swivel plate
Cushion seat
JDBC Scew M6×30mm
JDBC Scew M6× 45mm
Spring Washer M6×10mm
Flat Washer M6×16mm
Allen Key Small M4
1X
4X
1X
1X
1X
4X
6X
18X
22X
1X
12X
JDBC Scew M6× 35mm
Weight Capacity:275 lbs
Warming:Do not stand on chair
Warming:Do not over torque bolts
PIECE DESCRIPTION PICTURE QUANTITY
WARNING

6
34
5
4x
8x
3
4
5
6
PREPARATION
Before beginning assembly of product make sure all parts are present.Compare parts with package contents list
and hardware contents list.
If any part is missing or damaged,do not attempt to assemble the product.
Estimated Assembly Time:10 minutes.
Tools Required for Assembly(included):Allen Key
Step 1
Attach 4 chair legs (B) to swivel plate(D) with 35mm
screw (3)& 10&16mm washer(4)(5).
Attach 4 chair legs(B) to footrest (C) with 35mm
screw(3) & 10&16mm washer (4)(5).
Tighten with Allen key(6).
Step 2
Attach cushion seat (E) to backrest (A) with 45mm
screw(2) & 10&16mm washer(4)(5).
Tighten with Allen key(6).
Step 3
Attach the bottom from Step1 to the cushion seat from Step 2
with 30mm screw(1) & 16mm washer(5) through 4 holes in the swivel plate .
Tighten with Allen key(6).
Stand chair upright. Assembly is complete.
B
D
c
5
4
2
6
6X
6
1
5
4x
E
A
1 2 3
