Safavieh PAT7003 User manual

6X70mm
6x55mm
6x50mm
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* This item may require periodic tightening
Part List and Hardware List
A
B
C
D
E
H1
H2
H3
H4
H5
H6
H7
Seat Frame
Leg Frame
Cross bar of leg
Cross bar of leg
Back frame
Screw -1
Allen key
Allen bolt L
Allen bolt L
Allen tandu L
Wood dow
Horizontal spread
1X
2X
1X
2X
1X
4X
4X
7X
6X
4X
2X
2X
PIECE DESCRIPTION PICTURE QUANTITY
Model# PAT7003
Product Dimensions:22.83" W x 39.37" D x 40.55" H
CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use.
Remove wooden furniture from standing water. Dust regularly with small brush or vacuum
Spills should be taken care of immediately before they harden or
stain with a slightly dampened sponge.

Attach seat frame (A) to crossbars of leg (D),
use screws-1 (H1) and tighten with allen key(H7)
Insert wood dows (H6) into the holes on (C),
attach (B) to (A) by using (H3),then use (H2)
to conect (B) and (E).
Use allen bolts (H3) and allen tandus(H5) to
connect (C) and (B)
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list.
If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 10 minutes.
Tools Required for Assembly (included): Allen Key
