Safe-T-element PTI STEZA Guide

Care and Use Manual
Limited Warranty
For Optimum Cooking Results, Safety and Energy Efficiency
Models PTI STEZA, PTI STEZB, PTI STEZC & PTI STEZD
NEVER LEAVE COOKING UNATTENDED
!
Version: B Jun 20 11
Pioneering Technology Corp.
220 Britannia Rd E. - Mississauga, ON - L4Z1S6 - tel [phone]

Important Safety Instructions………………………………….Page 2
Introduction……………………………………………………...Page 3
Getting Started………………………………………………….Page 4
Care & Maintenance……………………………………………Page 6
Troubleshooting…………………………………………………Page 9
Warranty………………………………………………………….Page 10
IMPORTANT SAFETY INSTRUCTIONS
Read all instruction before use.
Never leave food cooking on the stovetop unattended.
Keep cooking area clean and clear of combustibles (e.g. potholders,
towels, rags, drapes and food packing).
Keep children and pets away from cooking areas by creating a
three-foot (one-meter) ʻkid-free zoneʼaround the stove.
Wear short, close fitting or tightly rolled sleeves when cooking.
Loose clothing can dangle onto stove burners and catch fire.
Turn pot handles inward so they canʼt be bumped and children canʼt
grab them.
Never use a wet oven mitt, as it presents a scald danger if the
moisture in the mitt is heated.
The Safe-T-element® plate will not glow red at any temperature.
Therefore, the stove panel element indicator light will be your best
way to determine if an element is on.
The Safe-T-element® may take 30 minutes to cool after use due to
the elements large thermal mass.
Note: Please read all the above instructions and follow basic precautions suggested
by the National Fire Protection Associations (NFPA)
!2
Contents

INTRODUCTION
Congratulations on your purchase of the Safe-T-element® cooking
system. The Safe-T-element® cooking system is a patented product
upgrade for electric coiled stovetops, engineered to help prevent
cooking fires before they start while reducing the amount of electricity
required to cook. A regular stove element on high without Safe-T-
element can reach a dangerously high temperature of 700C/1291F. No
one needs 700C/1291F when oil ignites at as low as 370C/698F.
The Safe-T-element® “Control Unit” inside the stove controls the
temperature of the plate cover allowing it to only reach a maximum of
350C/662F. When the plate reaches a temperature of 350C/662F, it
automatically shuts the stove off and conversely as it cools to just
below 350C/662F the stovetop is turned on again. At this temperature,
it is more than enough for efficient and effective cooking, while not
allowing most household materials to ignite.
The Safe-T-element® helps to prevent kitchen stove fires but is only
one of the four key benefits you will appreciate. In addition, you will
have greater control over your elementʼs temperature for improved
cooking results, ease in keeping your stove-top and element cavity
clean, reduced energy consumption and therefore lower electric bills. It
is important to note that a little experimentation may be required to
familiarize yourself with the various temperature levels while using the
technology.
!3

GETTING STARTED
1. ARE YOU USING THE RIGHT COOKWARE
How economically you cook depends on the quality of the cookware
you use, especially the flatness of the bottom of the pot.
Basically, the pot should be slightly larger than the hotplate and have a
level, thick and sturdy bottom. Attempt to match large pots with large
burners, small pots with small burners for optimal cooking results.
Poor Characteristics:
!4
Check for flatness by
rotating a ruler across
the bottom of the pot.
Recommended Characteristics:
Flat bottom and straight sides
Tight fitting lids
Pan/pot is well balanced
Pan/pot is made of material that is
a good conductor of heat
Curved and warped pan/pot bottoms
Heavy handle tilts pan/pot
Pan/pot overhangs Safe-T-element® plate
by more than 2.5 cm (1”)
Pan/pot is smaller than the Safe-T-element®
plate

2.!COOKING WITH THE SAFE-T-ELEMENT®
It is important to note that no behavioral change is required when
cooking with the Safe-T-element®. However, a little experimentation
may be required to familiarize yourself with the various temperature
temperatures. Therefore, the stove panel element indicator light will be
the best way to determine if an element is on.
How would like your food done?
Control Setting
TYPES OF COOKING
Max
Start most foods; bring water to a boil;
pan-broiling; frying.
Medium
Maintain a slow boil; thicken sauces and
gravies; steam vegetables.
Medium Low
Keep foods cooking; poaching; stewing.
Low
Keep foods warm; melt; simmer.
COOKING PERFORMANCE WITH SAFE-T-ELEMENT®
The Safe-T-element® plate is slightly larger in diameter than the burner
element so the heat is dispersed evenly across the plate rather than
being focused on just three or four rings. This factor along with the type
of utensil material and quality can result in a longer initial heat up time.
However, once the plate is fully heated up, there should be no obvious
point 1 “Are you using the right cookware”.
!5
levels while using the device. DO NOT cook food directly on the
Since the Safe-T-element® cycles on and off at 350C (662F), the plate
will never have a red glow like the unprotected element does at higher
Safe-T-element® plate without using cookware.
NOTE: To improve cooking performance please use the right cookware. Refer to
cooking.
difference in cooking time. The plate retains heat and energy savings can
be achieved by turning the controls off and using the retained heat to finish

CARE & MAINTENANCE
1.!BEFORE COOKING WITH THE SAFE-T-ELEMENT®
up on maximum setting for approximately 4 minutes without any utensil.
During this ʻcuringʼprocess, the protective coating is hardened and obtains
its maximum strength.
NOTE: There may be a slight odor the first time you use your stove-top elements with the
Safe-T-element® plate installed. This should dissipate after the first use. For daily cooking
use dry pots only. Keep wet utensils or objects with condensation, such as pot lids, away
from Safe-T-element®.
2. CLEANING YOUR SAFE-T-ELEMENT®
1. Ensure burner is cool before attempting to clean.
2. Use damp cloth or sponge with mild detergent to clean surface of burner
and surrounding plate. Never use harsh abrasives or steel wool pad on
any part of the Safe-T-element® .
3. Thoroughly wipe soap from heating element and towel dry.
4. For best results clean your elements and drip pans regularly.
!6
For hard-to-remove stains, please try one of the following options:
Option #1 - Vegetable Oil:
!1. Apply vegetable oil sparingly on each safe-T-element® cast iron plate and spread it
around the entire surface of the plate.
!2. Turn the hood vent ON to allow for the minimal amount of smoke created to escape.
!3. Turn the power of burners ON Med-HI.
!4. Allow the burners to be ON for roughly 5 minutes. This will help break up the grease/
rust on the burner.
!5. Turn the burners OFF after roughly 5 minutes.
!6. Once the burners are cool, clean the cast iron plates with mild soap and towel dry.
Option #2: - Electrol Range Solid Element Cleaner:
In those instances where spotting or rusting has occurred there is a product that can be
applied that can help to maintain the original matte black appearance.
Directions for use:
!1. Turn on the hood vent first as some smoke and a strong smell will occur. This is
normal and is non-toxic and will eventually disappear.
!2. Prior to applying Electrol clean the plates with a soapy, non-abrasive scouring pad.
!3. Dry the plates thoroughly.
!4. Apply Electrol sparingly to a lukewarm element. !
!5. Spread polish evenly with a paper towel or dry cloth.
!6. Turn the element ON a Med-Hi setting for 3-5 minutes to bake the polish in.
!7. When the element is completely cool, rub lightly with a paper towel to remove any
excess polish.
Note: If you are interested in Option #2, please contact us for more information.
Before being used for the first time, the Safe-T-element® should be heated

3. CLEANING THE DRIP PAN BELOW THE SAFE-T-ELEMENT®:
1. Gently remove plate and element from element socket by lifting edge of
plate up and removing from socket hole.
Note: on some models it may be easier to lift and remove both the plate and the drip pan together.
2. Disconnect thermocouple wire attached to plate.
3. Place Safe-T-element® plate with coiled element attached to one side
while cleaning the drip pan and other areas below the stove top.
Note: Clean one plate at a time and then reconnect. To replace plate and element, reconnect
particular burner. (Refer to Figure 2)
!7
Plate
Plate Drip pan
Drip pan
Plate
Thermocouple
Plate
Drip pan
Plate
Drip pan
White Connector
Figure 1 Figure 1A
Figure 2
Figure 3 Figure 3A
Important:
Remove one plate at a time,
clean drip pan and reconnect
before removing next element.
thermocouple wire to white connector. Connectors positive (+) and negative (-) teeth must line up.
important that each thermocouple is connected to the right white connector assigned for that
Simply slide the heating element back into socket and press down firmly on the plate. It is very
The two connectors must be completely plugged in.

4. CLEANING UNDER THE COOKTOP: (available on select models)
Note: Be sure all surface units are turned off before raising the cooktop
!8
Lift-Up Cooktop
The entire cooktop may be lifted up and
supported in the up position for easier
cleaning
The Surface units do not need to be
removed; however, you may remove one
to make raising the cooktop easier. There
are two side supports that lock into
After cleaning under the cooktop with warm, mild soap with water and a
clean cloth, lower the cooktop. Be careful not to pinch your fingers.
To lower the cooktop, push the rods back and gently lower the cooktop until
it rests in place.

TROUBLESHOOTING
Read this BEFORE you call for service.
The Safe-T-element® device is a carefully engineered product. Many times
what may appear to be a reason to call for service is, under certain
conditions, a normal operating characteristic of the device.
TROUBLE
PROBABLE CAUSE
REMEDY
Entire stove does
not operate
Blown fuse/tripped
circuit breaker.
Replace fuse/reset circuit
breaker.
Entire stove does
not operate
Loose/corroded circuit
connection.
Clean and tighten
connections.
Entire stove does
not operate
Cord/plug not attached
to wall outlet.
Make sure cord/plug is
plugged tightly into outlet.
Entire stove does
not operate
Power Outage.
Check house lights to be
sure.
Safe-T-element®
plates do not heat
Control knob set too
low.
Turn knob slightly higher
until it starts heating.
Safe-T-element®
plates do not heat
Safe-T-element®
thermocouple
disconnected.
Remove plate and ensure
thermocouple (white
connector) is connected to
the brown wire. **
Safe-T-element®
plates do not heat
Incorrect element knob
is turned on.
Ensure the correct
element knob is turned on.
Safe-T-element®
plates do not heat
Safe-T-element® plate
not seated properly.
Straighten terminals on
end of coil element. **
Safe-T-element®
plate too hot
Incorrect temperature
setting on the control
knob.
Lower temperature setting
until proper amount of
heat is obtained.
Safe-T-element®
plate too hot
Safe-T-element®
thermocouple wire is
connected to the wrong
white connector.
Ensure thermocouple wire
is connected to the right
white connector. (Refer to
Figure 2)
** Ensure knob is set to OFF and the Safe-T-element® plates are completely
cool.
!9

WARRANTY
Pioneering Technology Corp. warrants that the product is free from defects in
materials and workmanship when operated and maintained according to the
instructions provided for a period of:
One (1) year from date of purchase for residential use
Ninety (90) days from date of purchase for commercial use
This warranty does not cover physical damage caused by improper installation,
misuse, neglect or accident.
This warranty is VOID if this product has been altered or modified in any way. The
Safe-T-element® must be installed by a qualified service technician.
For service under this warranty contact your Safe-T-element® distributor or
Pioneering Technology Corp. at:
Pioneering Technology Corp. - Service Dept.
220 Britannia Rd. E
Mississauga, Ontario
Canada L4Z 1S6
Tel: [phone] or [phone] ext. 228
Email: [email protected]
www.safetelement.com
THERE ARE NO OTHER WARRANTIES. PIONEERING TECHNOLOGY CORP.
DISCLAIMS ALL OTHER WARRANTIES, EITHER EXPRESSED OR IMPLIED. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHERS WHICH
VARY FROM STATE TO STATE.
EXCEPT AS STATED HEREIN, IN NO EVENT SHALL PIONEERING TECHNOLOGY
CORP. BE LIABLE FOR ANY DAMAGES WHATSOEVER WHETHER BASED ON
CONTRACT, TORT, WARRANTY OR OTHER EQUITABLE GROUNDS, INCLUDING,
WITHOUT LIMITATION, OR OTHER PECUNIARY LOSS, ARISING OUT OF THE USE OR
INABILITY TO USE THIS PRODUCT, EVEN IF PIONEERING TECHNOLOGY HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGE, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
Pioneering Technologyʼs entire liability and your exclusive remedy shall be at
Pioneering Technologyʼs option, either (a) return of the price paid for the product or
(b) repair or replacement of the product that does not meet Pioneering Technologyʼs
Limited Warranty and which is returned to Pioneering Technology. In no event shall
Pioneering Technologyʼs liability exceed the purchase price of the product.
!10
