SAGEMCOM RM50 User manual

Internet Radio RM50
User Guide
English

2
Introduction
Dear customer:
Thank you for purchasing a SAGEMCOM WiFi IP Radio; we appreciate your trust in us.
This product was manufactured with the upmost care, should you encounter any
difficulties during its use, we recommend that you refer to this user guide. You can also
find information on the following site:
http://www.sagemcom.com/faq
The new material is guaranteed (parts and labour) by SAGEMCOM under the conditions
and according to procedures defined on the site www.sagemcom.com heading support.
In the event of a technical problem, please refer to the table at the end of this user guide
for a list of incidents and the way to solve them.
The SAGEMCOM site (www.sagemcom.com assistance section) also provides information
on how your IP Radio works and how to solve any problems you may encounter. You can
also contact our assistance service by E-mail. If the problem persists, you should contact
our call centre (see the table below). They will offer an expert appraisal of your material
remotely to determine the cause as well as the type of repair required.
For your comfort and safety, please read carefully the paragraphs below on safety
recommendations and instructions.
WELCOME

3
Introduction
Do not install your IP Radio in a humid room (bathroom, laundry, kitchen, etc.), or within 1.50mof a tap
or water source, or outside. Your IP Radio should be used at an ambient temperature of between 15 °C
and 35 °C for optimum sound results.
Do not set up your IP Radio in a dusty environment as dust deposits might adversely affect the sound
quality.
Avoid objects or liquids getting into the unit.
Unplug the power lead if the unit will not be used for a long period.
Do not handle your AC cord with wet hands. If liquid spills on your product, unplug immediately and
contact your dealer for cleaning instructions.
Only the power supply provided with the IP Radio should be used. Connect this to the mains in
accordance with the installation instructions in this user guide and the information on the
identification label affixed to the power supply (voltage, current, mains frequency). As a precaution, in
case of danger, the main adapters act as a disconnecting mechanism for the 230 V power supply. They
should be placed near the device and should be easily accessible.
Do not attempt to use force to plug a connector into the audio jack. If the connector cannot be plugged
into the jack easily, the connector is incompatible.
Do not attempt to remove any screws or open the unit. No user serviceable parts are inside.
The length of the USB cables used on this product shall not exceed 3m.
This terminal was designed for private use inside a building (CPE customer premises equipment) in the
European Free Trade association (EFTA). It has been tested in accordance with the technical provisions
for radio equipment (EN 300328).
The radio frequency bands authorized for Wireless transmission depend on national
regulations.The installation of this terminal operating in the 2.4 GHz band is covered by the European
recommendation ERC 70-03.
Before use, make sure that the gateway with which you establish a wireless connection from your
terminal is set up in accordance with this regulation and with the national regulations where it is used.
SAGEMCOM accepts no liability if the regulations in force on the installation site are notcomplied with.
Some sensitive medical equipment and safety equipment may be affected by the radio-frequency
transmissions of your radio. In all cases, we ask that you respect the safety recommendations.
The device shall not permanently be installed or used closer than 20cm from the human body.
The CE marking certifies that the product meets the essential requirements of Directive 1999/5/CE of
the European Parliament and of the Council pertaining to microwave radio equipment and
telecommunication terminal equipment, for the safety and health of users, for electromagnetic
interference. Furthermore, it efficiently uses the frequency spectrum attributed to ground and spatial
communication to prevent damaging
interference.
The declaration of compliance may be looked up on the www.sagemcom.com site or can
be obtained from the following address:
SAGEMCOM
Malmasion - FRANCE
Recommendations and safety instructions
!
250, route de l'Empereur, 92500 Rueil
Customer relations department

4
Table of Contents
1. Your IP Radio 6
Main Features 6
Unpacking 6
Front Panel 7
Rear Panel 8
Remote Control 8
Menu Structure 10
2. Getting Started 11
Turning On The Device for The First Time 11
Adjusting The Volume 16
Text Entry 16
Standby Mode 17
3. Listening To Music 18
Listening To Internet Radio 18
Listening To FM Radio 21
Listening To The Music In Your Computer (UPnP) 23
Listening To Podcast 25
Favorite List 26
4. Setup 27
Audio Profile 27
Time Setup 28
Sleep Timer 28
Snooze Timer 28
Alarm 1&2 29
Advanced Setup 30
Language 30
Time Zone 30
Clock 31
Radio Scan 31
Reset To Default 31
F/W Version 32
Demo Mode 32

5
Table of Contents
ECO 33
Backlight 33
Brightness 33
Volume limitation 34
Network Config 34
Scan For Networks 34
View Config 34
Edit Config 35
5. Appendix 37
Care And Maintenance 37
Problems 37
6. Specifications 40
7. Environment 41
Packaging 41
Batteries 41
The Product 41

6
Your IP Radio
1.1 Main Features
1.2 Unpacking
This product is an IP Radio that, once connected to an Internet gateway, will allow
you to access worldwide Internet radio stations and to listen to your digital music files
stored on your PC, or on a multimedia UPnP server. It can also be used as an alarm
clock for wake-up and important appointments.
1. Your IP Radio
WiFi 802.11 b/g1.
Software update through USB2.
Internet Radio3.
FM RDS4.
Audio Codec : MP3 / WMA / WAV5.
Output Connector : Line-out6.
• 1 x IP Radio Device
• 1 x Power Adapter (DC 5V / 2A)
• 1 x Remote Control
• 1 x CD / User Manual
• 1 x Quick Guide
• 1 x Quick Warranty Guide

7
Your IP Radio
1.3 Front Panel
1
23456
7
8
9
10
1 1
12 12
11
1. Display Screen Displays contents on the screen.
2. PRESETS [1] Press and hold to display a list of available FM stations.
[2] Press to activate auto/manual scan.
3. MODE Displays the Mode menu.
4. VOL. Enables volume control on the Wheel.
5. MENU Displays the submenu.
6. STATIONS [1]Press to displays the Favorite List
[2] Press and hold to add/remove stations to/from the
Favorite List.
7. Navigation Wheel [1] In playback screen, rotate to increase/decrease the
volume. Press to mute the audio volume.
[2] Navigate in the menu list. Press to enter or confirm the
highlighted item in the menu list.
8. C Act as the BACK/CANCEL button in all display screen.
9. INFO [1] While listening to an IP Radio music source, press to
switch the display the music information.
[2] While listening to the IP Radio, press and hold to set
“auto tune”, which allows you to set a tuned station to
play again at a certain time.
10. SMART RANDOM
SWITCH Switch randomly to a new station.
11. SMART RANDOM
THEME
Displays a list of all existing themes defined by Internet
Radio.
12. Speakers Provides music sound output.

8
Your IP Radio
1.4 Rear Panel
5V DC
RAUDIO L
1
234 5
1. POWER [1] Press to shut off the music source currently playing and
put the device into the Standby mode.
[2] Press and hold to put the device in the Power off mode.
2. USB Port Connection to USB devices.
3. 5V DC Power Jack Plug in the power adaptor.
4. Audio Line Out Jack
Left/Right Plug in external speakers.
5. Headset Jack Plug in an external headset. Speakers do not function while
headset is plugged in.
1.5 Remote Control
1
2
3
4
5
9
10
6
7
8
11
12
13
15
16
14
13

9
Your IP Radio
1. Mode Displays the Mode menu.
2. Snooze/Sleep Timer [1] Snooze - When the alarm is on, press to shut the alarm
off and reactivate again later.
[2] Sleep Timer - Set a screen off period of time and stop
the current music source then enter the Standby mode.
3. Back Act as the BACK/CANCEL button.
4. VOL +/VOL - Enables volume control.
5. Mute Mute all the sound.
6. Presets [1] Press and hold to display a list of available FM
stations.
[2] Press to activate auto/manual scan.
7. Stations [1]Press to displays the Favorite List
[2] Press and hold to add/remove stations to/from the
Favorite List.
8. Menu Displays the submenu.
9. On/Off [1] Press to shut off the music source currently playing
and put the device in standby mode.
[2] When the alarm goes off, presses this button to turn it
off and go to the Standby mode.
10. Info [1] While listening to an IP radio music source, press to
switch the display music information.
[2] While listening to the IP Radio, press and hold to set
“auto tune”, which allows you to set a tuned station to
play again at a certain time.
11. Smart Random
SWITCH Switch randomly to a new station.
12. Smart Random
THEME
Displays a list of all existing themes defined by Internet
Radio.
13. UP and DOWN Move to the previous/next item.
14. Previous Menu list: go to the top of list.
15. Next Menu List: go to next list.
16. Play/Pause/Select [1] Menu List: confirm or enter the highlighted item.
[2] FM Radio: stop music and go back to Mode menu.
[3] IP radio/UPnP/Podcast: Play/ Pause

10
Your IP Radio
1.6 Menu Structure
Press MODE to enter the menu:
(1) Internet radio, (2) FM radio, (3) UPnP, (4) Podcast.
Mode
Internet Radio
> Search by theme
> Search by name
> Search by region
> FM Internet radio
FM Radio UPnP Podcast
> Search by theme
> Search by region
Press MENU to enter the submenu:
(1) Audio profile, (2) Time setup, (3) Advanced setup, (4) ECO, (5) Network config.
Menu
Audio Prole
> Off
> Classical
> Rock
> Pop
> Jazz
> Customized
ECO
> Backlight
> Brightness
> Volume Limitation
Time Setup
> Sleep Timer
> Snooze Timer
> Alarm 1
> Alarm 2
Advanced Setup
> Language
> Time Zone
> Clock
> Radio Scan
> Reset to Default
> F/W Version
> Demo Mode
Network Cong.
> Scan for Networks
> View Cong.
> Edit Cong.

11
Getting Started
2. Getting Started
2.1 Turning On The Device for The First Time
Please confirm that your wireless router or Access Point (AP) is connected to
the broadband network. The diagram below describes the network
environment that should be established to use your IP Radio.
Internet
DSL/ Cable Modem
Wireless
Router
5V DC
RAUDI O L
5V DC
(1) Plug the included power adapter into a wall outlet.
(2) Connect the power adapter to the power jack on the rear panel of the
device.
(3) Press and hold the Power button on the rear panel to turn on the device.
2.1.2 Setting Up The device
2.1.1 Network Environment

12
Getting Started
After scanning and a network connection is found, a Scan for networks menu
displays:
Rotate the Wheel to select the desired network connection method.
The device will scan for network connection automatically.
After the device is turned on, a welcome screen appears.
Note: Turning on the device for the first time will require you to set up the
Network, Language and Time Zone for your device. Please follow the setup guide
for proper setup.
2.1.3 After A Network Is Found

13
Getting Started
WPS PBC (Push Button Configuration):
(1) Press the WPS button on your AP.
(2) Select WPS PBC on the menu within the time limit (AP dependent) to
establish a connection.
(1) Press the Wheel to select the AP list menu.
(2) Select a desired network from the list.
Note: If you have selected a network with a lock icon at the front, you must
enter the password for the selected network.
On the text entering screen, rotate the Wheel to choose the characters or
numbers from the list at the bottom of the screen. Press the Wheel to select
the character.
Rotate the Wheel to select End to quit the edit screen and start connecting to
the network.
AP List
WPS
The IP Radio supports WPS (WiFi Protected Setup). If your AP supports WPS
as well, you can choose this network connecting method.

14
Getting Started
WPS PIN (Personal Identification Number): Use the PIN code to connect to the
AP.
(1) Select WPS PIN on the menu.
(2) The PIN code is generated automatically or you can choose Refresh if you
need to change the PIN code.
(3) Open the WPS configuration page of your AP on your computer, and then
enter the PIN code to establish a connection.
The device will automatically set up the local language. If you need to set up
your own preferred display language on the device see step (1).
Choose YES to confirm the language selection.
(1) Choose NO to continue the Language setting.
(2) Rotate the Wheel to choose the desired Language.
(3) Press the Wheel to activate the setting.
2.1.4 Connection Established
If the network connection is established, continue adjusting the following
settings:
Language

15
Getting Started
After the Network, Language and Time Zone settings are set, the menu screen
will be displayed.
After scanning, if no network connection is found, a network error message
appears for a few seconds and then the Network Config. menu will be
displayed.
Please refer to Setup →Network Config. section in the
manual for more details.
Select your time zone in the device to synchronize the date and time with the
Internet. The device will automatically set up the local Time one.
Choose YES to confirm the Time zone selection.
(1) Choose NO to continue the Time zone setting.
(2) Rotate the Wheel to choose your time zone.
(3) Press the Wheel to activate the setting.
Time Zone
2.1.5 If The Network Is Not Found

16
Getting Started
2.2 Adjusting the Volume
2.3 Text Entry
If no action has been taken from the Network Configuration menu for 5 minutes,
the device will display the Demo Mode with music. Press any button on the
device, except the Wheel for volume adjustment, to quit the demo mode.
While the device is playing music from any source, press the VOL. button and
rotate the Wheel to the right will increase the volume and rotate it to the left will
decrease the volume.
Warning: Always start playing music with volume setting farthest to the left to
protect hearing. Or you can set up a limitation for volume, refer to Volume
Limitation chapter for details.
For certain settings you will need to enter text. Follow the procedures below:
(1) Rotate the Wheel to select the desired letters, numbers or symbols.
(2) Press the Wheel to choose the highlighted item.
(3) Rotating to select End to quit the edit screen.
Or, pressing the Back button on the remote control to delete the input. Press and
hold the Back button to quit the edit screen.
2.1.6 Demo Mode

17
Getting Started
2.4 Standby Mode
While the device is playing from any music source, press Power on the device
or On/Off on the remote control to stop playing from the music source and
enter the Standby mode.
In the Standby mode, rotate the Wheel or press SELECT on the remote
control will have no effects on the status of the device.
If the alarm has been set, the standby screen will display an alarm icon.
When the alarm is ringing, press POWER on the device or On/Off on remote
control to turn alarm off.
If Snooze has been set, press SNOOZE on the remote control to shut the
alarm off temporarily and it will automatically reactivate after few minutes
(according to your settings in the Setup →Time Setup → Snooze Timer
section.)

18
Listening to Music
3.1 Listening To Internet Radio
3. Listening To Music
This IP Radio device is a high-performance audio player that can play music from
various types of sources. You can use it to listen to Internet radio from all over the
world, local FM broadcasting services, and music files in your computer.
The following explains how to listen to music using this IP Radio device.
With the Internet radio function, you can listen to music or programs from
Internet radio stations.
Rotate the Wheel to select and press the Wheel to activate the Internet Radio
function in the main menu.
When using this function for the first time, you will be asked to set your preferred
display method by theme, name, region or FM Internet radio station. If you want
to adjust the settings, press PRESETS on the device.
1. Search by theme:
(1) Rotate the Wheel to choose a theme from the available theme list.
(2) Press the Wheel to start loading the related stations.
(3) Rotate the Wheel to choose from the station list.
(4) Press the Wheel to start playing the selected station.
3.1.1 Search For A Station

19
Listening to Music
2. Search by name:
When you choose to search by name, a text edit screen will appear.
(1) Rotate the Wheel to choose characters or numbers from the list at the
bottom of the screen. Press the Wheel to select the character.
(2) Choose End to quit the edit screen.
(3) Press the Wheel to start loading the available stations.
(3) Rotate the Wheel to select from the station list.
(4) Press the Wheel to start playing the selected station.
3. Search by region:
(1) Rotate the Wheel to choose a region and press the Wheel to select Region
→Country →City lists.
(2) Press the Wheel to start loading the available stations.
(3) Rotate the Wheel to select from the station list.
(4) Press the Wheel to start playing the selected station.
4. FM Internet radio:
If you do not want to search the stations, choose FM Internet radio to listen
to FM radio stations that are broadcast via the Internet.
(1) Press the Wheel to start loading the available stations.
(2) Rotate the Wheel to select from the station list.
(3) Press the Wheel to start playing the selected station.

20
Listening to Music
Please refer to the Favorite List chapter to add a station to the Favorite List.
The playback screen of the Internet Radio (see diagram below).
Press the INFO button to display the program information you are listening to,
the start time, the ending time and the program content.
Press and hold to set auto tune, which allows you to set a tuned station to play
again at a certain time.
3.1.2 The Playback Screen
3.1.4 Adding A Station To The Favorite List
Power ( ) 1. Press to stop the music source currently playing and
enter the Standby Mode.
2. Press and hold to connect to the AP automatically
and then start to play the last tuned station.
PRESETS Press to see the Internet Radio list or search engines.
C ( ) Return to the Mode Menu.
Wheel 1. Rotate to adjust the volume.
2. Press to mute the audio volume.
SMART RANDOM
SWITCH
Press to switch randomly to a new station base on your
theme settings.
STATIONS 1. Press to view your Favorites List.
2. Press and hold to add/remove current station in the
Favorites List.
SMART RANDOM
THEME
Press to view the list of all existing themes defined by
the Internet radio station.
INFO 1. Press to switch the playback screen display.
2. Press and hold to set auto tune.
3.1.3 Key (and remote control) command on the playback screen
