SAGITINE NEW YORK 20 BOX STAND User manual

1/1
NEW YORK 20 BOX STAND
ASSEMBLY INSTRUCTIONS
Parts:
Hardware:
Self-tapping screws
13mm long x12
Machine Screws
20 mm long x20
Screw-In Feet x4
ANo2PhillipsHeadScrewdriver
A No 4 Allen Key (Hex)
Vertical Frame
Side L x1
Vertical Frame
Side R x1
Rear Brace Short x4
Vertical Frame
Mid x 1
Base Plate x2
Timber Top x1
Rear Brace Long x2
To complete the assembly of your New York Stand
you will need the following tools:
Within your delivery you’ll nd the following parts and hardware.
1
2345
6
7
a
c
b

2/5
Place a clean towel or blanket on the ground rst to place the Timber Top on to
avoid scratching or marking the timber.
Place the Timber Top upside down on top of the towel or blanket on the ground
so that the holes are showing.
Step 1
x6
Place the Vertical Frame - Mid on top of
the Timber Top making sure the holes
in the timber and the brackets are
aligned.
Note: Ensure Threaded Insert
in the Frames is facing the rear.
Fasten the Frame to the
Timber Top with the 6x
Self Tapping screws.
Rear
Threaded Insert
a
1
1
2
2

3/5
Attach both Vertical Frames - Side L and R to the Timber Top as shown using 6x
Self Tapping screws.
Step 2
Note: Ensure all Frames are in line
with the rear edge of the Timber Top.
Fasten the Frame to the
Timber Top with the 6x
Self Tapping screws.
Rear
Threaded
Insert
Rear
Note: Ensure Threaded Insert in
the Frames is facing the rear.
3
4
x6
a

4/5
Place the Base Plates across the three Vertical Frames as shown, aligning the holes
with the Threaded Inserts.
Step 3
Fasten the Base Plates to the Vertical Frames
with 6x Machine Screws and 4x Screw-In Feet.
x6
x4
Larger hole
this side
52
4
3
5
c
b

5/5
Install the Rear Braces by aligning holes in the brace with the Threaded Inserts in
the Vertical Frames.
Step 4
Fasten with 14x Machine Screws.
Flip your New York Stand so that the Timber Top is upright,
insert your 20 Milan Boxes and enjoy your new Sagitine piece.
Sagitine – Storage you want to see
www.sagitine.com
