Sailsky BL260Q User manual

Shenzhen Shuotian Information Technology Co.,LTD
1
User Manual
This is the user manual of 300Mbps Ceiling AP, which will approximate guide you how to set and apply the Ceiling AP,
it provide a convenient graphical interface for network construction and maintenance person, as well as a user through
a simple and accurate operation, and configuration management of the ceiling wireless access point.
Attention:
1. Check box contents:
Ceiling Wireless AP
Power adapter
LAN cable
User Manual
Setting Screws
2. Warning:

Shenzhen Shuotian Information Technology Co.,LTD
2
Contents
1st: Hardware and Operation mode Instruction……………........…………………….......……….4
LED indicator:………………………………………….......…………………………………….4
AP Interface:……………………………………………………….......…………………………4
Power Supply:…………………………………………………………….......………………….4
1. PoE Adapter Power Supply:…………………………………….......…………………...…..4
2. PoE Switch Power Supply…………………………...................................………............4
AP installation:....................................................................................................................5
2nd: Connect Wireless AP with PC:………………………………………………….......…..………5
3rd：Login………………………………………………………………………........……………..….6
4th : WEB GUI interface Setting:……………………........……………………………………….…9
1) Status……………………………………………….......…………………………………....9
2) Wizard Configuration:………………………………………………….......……………...11
1. Gateway Mode:………………………………………………………….....…………..12
2. WiFi Repeater mode…………………………………………………………….....….14
3. WISP Operation mode:…………………………………………………….....……....15
4. AP Operation mode:……………………………………………………………....…...17
3) Advanced Setting:…………………………………………………….…………...……….19
Device Status:……………………………………………………………………...……..19
Wireless Setting…………………………………………………………....……….........20
Virtual AP…………………………………………………………………………….........22
Access Control……………………………………………………………..……......…...23
Advanced Settings………………………………………………………………………..23
Network setting……………………………………………………………………………23
Management……………………………………………………………………………....24
5th Share Internet and Obtain IP address automatically…………………………….….…….....26
Trouble Shooting………………………………………………………………………………….…..27

Shenzhen Shuotian Information Technology Co.,LTD
3
1st Hardware and Operation mode Instruction
L ED i nd i ca t o r:
Gr e en : P ow er I nd i ca t or
Bl u e: W iF i In di c at o r
AP In t er f a ce :
RST: Reset Button, it make AP revert to default data after press it 15 seconds.
WAN: WAN Port, connect with ADSL modem or Internet mainly. It will be LAN port under Wireless AP and WiFi
Repeater operation mode
LAN: LAN Port to end users
LED: LED Indicator of WAN port and LAN port
DC: DC power connector
Power Supply:
1. PoE Adapter Power Supply:
The connection diagram showed as P1, internet cable connect to PoE adapter’s LAN Port, Ceiling AP’s WAN port
connect to PoE adapter’s PoE Port, then PC will access into ceiling AP through cable or wireless
The PD wireless AP support 48V IEEE 802.3af standard PoE, so PoE adapter should be 48V PoE standard.
P1

Shenzhen Shuotian Information Technology Co.,LTD
4
2. PoE Switch Power Supply
The connection diagram shows as P2, Internet cable from PoE Switch to Ceiling AP’s WAN Port, then PC access into
ceiling AP wired/wireless.
Pls note the PD wireless AP support 48V IEEE 802.3af standard PoE, the PoE switch should comply with 802.3af 48V
PoE standard.
P2
AP In s ta l l at i o n:
For the Ceiling Wireless AP, will be installed under ceiling based on following steps:

Shenzhen Shuotian Information Technology Co.,LTD
5
2nd : Connect Wireless AP with PC:
Use can co nn ec t the PC wi th wi rel es s AP by W ire le ss SSI D an d LAN ca ble:
T he d ia g r a m of wi r el e s s co n ne c t i o n sh o w e d as f o l l o w:
Pl s no te : the d efaul t SS ID is Wi r e l e s s 2. 4 G , S S I D ’s p a ss w o r d i s 66666666
T he d ia g r a m of L A N ca b l e c o nn e c t io n sh o w e d a s fo l l o w :
P3 Co nne ct io n wa y
3rd ：Login
1）Connect the Ceiling AP with computer by wired or wireless
2）The default IP address of this wireless AP is 192.168.188.253, Configure the PC’s local connection IP address as
192.168.188.X (X is number from 2 to 254), subnet mask is 255.255.255.0, follow P4 and P5 to finish.
P4 Setting of computer’s IP address

Shenzhen Shuotian Information Technology Co.,LTD
6
P 5 Setting of computer’s IP address
3) Input 192.168.0.254 into IE browser, then pop up the login page, the default login password: admin, then login,
pls do following P6
P6 Login

Shenzhen Shuotian Information Technology Co.,LTD
7
4) After login, then P7 Device Status will be showed;
This page will show the Wireless AP’s default operation mode, channel, connection status, CPU usage, Wireless
settings, LAN Setting, Wireless AP’s Location, hardware/firmware version.
P7: Device Status
4th : WEB GUI interface Setting:
1) Status
After login, then P8 Device Status and home page will be showed:
P8: Device Status

Shenzhen Shuotian Information Technology Co.,LTD
8
In this page, show the AP’s default operation mode, channel, end user QTY, connection status, CPU usage status,
Wireless, LAN and AP location info.
Then in Wireless Setting, GUI configuration page showed as below:
User can configure the SSID, password, band width, channel here, then Apply to finish.
P9. Wireless setting
LAN Setting to configure the DHCP or Fix IP
P10 LAN Setting

Shenzhen Shuotian Information Technology Co.,LTD
9
AP location setting: can mark where the AP set up, and AP name as P11:
P11 AP Postion setting
2) Wizard Configuration:
Wizard: It instruct users to configure wireless AP’s operation mode based on needs: there are four operation mode
including gateway, repeater, WISP, Wireless AP. Please confirm the operation mode first before configuration starting.
Click Wizard in Status page, will pop up following page to configure the operation mode and there are explanation for
each operation mode for better application.
P12 Operation mode
1. Gateway Mode:

Shenzhen Shuotian Information Technology Co.,LTD
10
Before Click Gateway mode, confirm your internet will be static IP, PPPoE, or DHCP:
Then will pop up following picture after click it, Please choose the right WAN setting mode, then click next to continue.
P13. WAN setting in Gateway Mode
P14 Wireless Setting in Gateway Mode
Please not: to make the AP in some clear channel, user can click wireless analyzer at first. Less AP in the channel,
then Wireless performance will be more stable. Picture showed as below:

Shenzhen Shuotian Information Technology Co.,LTD
11
P15 Channel Analysis
When click Next, then will complete the Gateway mode setting and show following picture:
P16 Complete the setting in Gateway Mode

Shenzhen Shuotian Information Technology Co.,LTD
12
When return to Status, will show wireless router’s SSID, internet connection, LAN connection status showed as follow:
P17 Status in Gateway Mode
2. WiFi Repeater mode
A. Login the Web management page, click “Wizard”, then “WiFi Repeater”
B. Select the AP’s SSID want to bridge, take “wireless 2.4G” for example, then input the AP’s key, click next to
complete
P18 Repeater Mode

Shenzhen Shuotian Information Technology Co.,LTD
13
Click Return button, will back to Status, show Repeater mode data, show fail or success, and user can configure this
data in this page if required.
P19 Status in Repeater Mode
In wifi repeater operation mode, the default is SSID disable. If want to enable SSID, then click Wireless Setting.
Pls note, when click wireless relay setting, following page will pop up, you can make change from here easy:
P20 Wireless Relay Setting

Shenzhen Shuotian Information Technology Co.,LTD
14
3. WISP Operation mode:
Click WISP operation mode in Wizard, then will pop up the configure page, pls set the WISP operation mode based on
the steps showed in picture:
P21 WISP Mode
Configure the right WAN setting in WISP operation mode, then next to complete
P22 WAN setting in WISP mode

Shenzhen Shuotian Information Technology Co.,LTD
15
Then complete and back to status, will show the connection fail or success, then can configure the data based on
request:
P23 Status in WISP mode
Remark: When click WAN Setting, will pop up following picture to ask you choose PPPoE, DHCP or Static IP
P24 WAN setting in WISP mode
4. AP Operation mode:
Set the wireless data, AP Location info as required, then click next to continue and enter into LAN setting.
After LAN setting, complete the AP mode configuration and back to Status:
P25 Wireless setting in AP Mode

Shenzhen Shuotian Information Technology Co.,LTD
16
P26 LAN Setting in AP Mode
P27 Status in AP Mode
3) Advanced Setting:
In advanced setting, mainly for wireless AP’s device status, wireless setting, Networking setting and AP management
configure.
Let’s Click Advanced Setting in status page, will show return home, Setup Wizard which we showed before.
Let’s shown more in Device Status, Wireless, Network and Management in following pages:

Shenzhen Shuotian Information Technology Co.,LTD
17
Device Status: to show the Wireless AP’s status, Wireless Status and LAN status.
In status, mainly to check the ceiling wireless AP’s firmware version, hardware version, uptime info.:
P28 Device Status
In wireless status, to show wireless AP’s SSID, MAC address for WiFi, Channel, Encryption, Client List info.
P29 Wireless Status

Shenzhen Shuotian Information Technology Co.,LTD
18
In LAN Status, we can check wireless AP’s IP address, Subnet Mask, LAN MAC address and other info showed in
following picture.
P30 LAN Status
Wireless:
For wireless, mainly to configure the wireless SSID, password, encryption, channel, Multi SSID, tag VLAN, RF power
adjust from Basic Setting, Virtual AP, Access control and Advanced Setting:
P31 Basic Setting in Wireless

Shenzhen Shuotian Information Technology Co.,LTD
19
Wireless Status: On mean SSID on, Off mean SSID off.
2G Wireless Analyzer: Mainly to analyze the AP’s signal strength and channel, to make user more easy to choose the
channel with less wireless AP, then to avoid the wifi interface.
Band Width: 20MHz and 40MHz; 20MHz mean bandwidth is 144Mbps, but stronger penetration ability. 40MHz mean
bandwidth is 300Mbps, but some weaker in penetration ability and less stability when wifi interface strong.
P32 Wireless Analyzer
Virtual AP:
There are 3 virtual AP in 2.4G wireless, if need do multi SSID, then users can configure it showed in following picture:
P33 Virtual AP

Shenzhen Shuotian Information Technology Co.,LTD
20
Access Control:
Allow or deny the users access into this wireless AP based on MAC address
P34 MAC Access Control
Advanced Settings:
In this page, will show the regional, mode, RF Power, Max user access...
P35 Advanced Setting
