SAKI Ea Masuta User manual

Please read this user guide carefully and keep it for future reference.
ATTENTION
SPECIFICATIONS
1. To avoid electric shock and fire, do not allow water, liquid or any flammable detergent to get into or to
clean the product.
2. Do not spray insecticide, perfume or other flammable spray around the products.
3. Before connecting the power supply, please check whether the voltage of the product is consistent with
the local power supply voltage.
4. This product can not replace normal ventilation, daily dust collection or oil pumping when cooking.
5. Ensure the product is used in condition of a stable and horizontal level.
6. Leave at least 30 cm of space on the back and sides of the product, and at least 50 cm of space above the
product when using.
7. Ensure that both filter and its cover are properly installed before using.
8. Do not insert finger or other things into air outlet / inlet to prevent physical damage or trouble.
Model Name Ea Masutā
35W
90 m3/h
<11m2
7.68 x 7.68 x 15.87 in 195 x 195 x 403 mm
5 lbs 2.3 kg
AC100-120V 50/60Hz AC220-240V 50/60Hz
Size
Net Weight
Input
Power
CADR
Coverage Area

CONTENT
Product Overview
Control Panel
Filter Installation
Functions
Maintenance & Cleaning
FAQ
01
02
03
04
06
07

PRODUCT OVERVIEW
Night Light
Control Panel
Air Outlet
Body
Air Inlet
Filter
Base
01

CONTROL PANEL
Power Button
Timer Button
Wind Speed Button
Light Control Button
Indicator
02

03
FILTER INSTALLATION
Unplug the power socket of the machine before replacing or installing the filter.
OPEN CLOSE Filter
Packaging
Filter OPEN CLOSE
1. Invert the machine and rotate the base along the direction marked “OPEN”
2. Take out the filter from the machine.
3. Remove the packaging of the filter.
4. Install the filter into the machine.
5. Then install the base, rotate and tighten the base along the direction marked “CLOSE”.

04
FUNCTIONS
When connect to the power socket, the buzzer will ring for 1 second.
The Functions of the Buttons
1. Touch the power button to turn on the machine, the buzzer will ring one time, the power
indicator and the low grade of wind speed indicator light turns white.
2. Touch the button again, the buzzer will ring for one time and the machine will turn offwith all
lights turn off.
NOTICE The machine will record the working modes when turns offwithout
unplugging the power socket.
Power Button
1. In the condition of working, press the timer button to set among the circulation of 2H, 4H and
8H timer with buzzer rings, and the corresponding indicator will be on.
2. Press again, the timer indicator turns offand the machine will work continuously without he
timer.
3. In the status of timing, the machine begins to count down. When the time is up, the fan will
stop working and all lights will be off.
Timer Button
NOTICE
The timer button could not operate in the status of shutdown.

05
When the machine detects the filter is saturated, the power indicator will keep flashing in red.
Please press the power button for 7s to reset aer installing a new filter.
Function of Display Air Quality
1. In the condition of working, press the wind speed button, the buzzer will ring for one time.
2. Press again to adjust the wind speed among the circulation of Low / High / Auto modes with
buzzer rings, the corresponding light will be on.
Wind Speed Button
NOTICE
The wind speed adjustment could not operate in the status of shutdown.
1. In the condition of working, touch the light control button, the light degree can be set
between solight and standard light mode with buzzer rings.
2. Touch again, the LED light turns off.
Light Control Button
NOTICE
The light control button could not operate in the status of shutdown.
Reminder of the Filter Replacement
1. When you turn on the light, it can display the color in gree (very good), yellow (not good) or
red (bad) to show you the present air quality.
2. When you set the wind speed to Auto mode, the wind speed could be auto-changing
according to the air quality among the high mode, middle mode and low mode.

06
MAINTENANCE
CAUTION
- Always make sure the machine is unplugged before maintenance.
- Do not immerse the machine into water or any liquid.
- Do not use abrasive, corrosive or flammable cleansers (such as bleach or alcohol) to clean any part
of the unit.
- Do not use a vacuum cleaner to clean the filter or wash it directly.
- Please sterilize the filter under sunlight regularly.
CLEANING & STORAGE
1. Ensure the machine is power-offand unplugged.
2. Use a socloth with neutral cleanser to clean away any dust or debris from the surface of the unit and air
inlet/outlet.
3. Aer the machine completely dry out, put on the bag and place it in a cool and well ventilated place.
4. If you do not use it for a long time, in the basic of previous steps, please turn on the machine for a few
minutes from time to time to ensure a good performance.
NOTICE Please do not drop any water into the machine when clean the air outlet.

07
TROUBLESHOOTING
SITUATION REASON
The device is not
working
Is it plugged into a power socket? Is there a power outage?
Is the home leakage switch or fuse cut off?
Is the filter replacing indicator keep flashing?
The performance of the
device is poor
Is there any dust in the surface of pre-filter?
Is there any obstacle blocking the air inlet / outlet?
There is significant noise
from the device
Is there anything stuck on the fan in the air outlet?
is the machine tilted?
Please set a lower grade of wind speed if the noise is too loud, or set
low grade of wind when using in bedroom at night.
Nasty smell is coming
out of the device
It is the normal phenomenon that the machine emits the smell of plastic
for the first time.
The machine will emit nasty smell if the filter is dusty, so in this situation,
please clean or replace the filter.
If the burning smell emits from the machine, please unplug the power
socket and contact with buyer or customer service.
The replacing filter
reminder is still flashing
aer the new one has
been replaced.
Please press the power button for 7s to reset the machine and the
life counter of the filter will start.
If the above issues can not solve your problem and still need maintenance, please contact
the supplier or aer sales service center.
Please do not disassemble the machine to maintain by yourself.
