Salton elite SFH16E Installation guide

INSTRUCTIONS AND WARRANTY
MODEL NO. SFH16E
SALTON ELITE FAN HEATER

2
Congratulations on purchasing our Salton Elite Fan Heater. Each unit is manufactured to
ensure safety and reliability. Before using this appliance for the first time, please read
the instruction manual carefully and keep it for future reference.
FEATURES OF THE SALTON ELITE FAN HEATER
The Salton Elite Fan Heater is ideal for both summer and winter. This unit comes
with a cool-air fan function, perfect for cooling down those hot summer days.
Two heat settings on the heater mean that you can set the heater to WARM or HOT.
The variable thermostat allows you to control the output of the heater, according to
the ambient temperature and size of the room being heated.
The fan heater has a 90˚ oscillating function with a separate on/off switch for the
oscillation.
The over-heat protection switch will automatically switch off the heater in a case of
overheating, and switch it on again when the heater cools down sufficiently.
IMPORTANT SAFEGUARDS
When using any electrical appliance, basic safety precautions should always be followed
including the following:
1. Please read the instructions carefully before using any appliance.
2. Always ensure that the voltage on the rating label corresponds to the mains
voltage in your home.
3. Incorrect operation and improper use can damage the appliance and cause injury
to the user.
4. The appliance is intended for household use only. Commercial use invalids the
warranty and the supplier can not be held responsible for injury or damage
caused when using the appliance for any other purpose than that intended.
5. Avoid any contact with moving parts.
6. Close supervision is required when any appliance is used near or by children or
invalids.
7. Check the power cord and plug regularly for any damage. If the cord or the plug
is damaged, it must be replaced by the manufacturer or a qualified person in
order to avoid an electrical hazard.

3
8. Do not use the appliance if it has been dropped or damaged in any way. In case
of damage, take the unit in for examination and/or repair by an authorised service
agent
9. To reduce the risk of electric shock, do not immerse or expose the motor
assembly, plug or the power cord to water or any other liquid.
10. Never immerse the unit in water or any other liquid for cleaning purposes.
11. Remove the plug from the socket by gripping the plug. Do not pull on the cord to
disconnect the appliance from the mains. Always unplug the unit when not in
use, before cleaning or when adding or removing parts.
12. The use of accessory attachments that are not recommended or supplied by the
manufacturer may result in injuries, fire or electric shock.
13. A short cord is provided to reduce the hazards resulting from becoming
entangled in or tripping over a longer cord.
14. Do not let the cord hang over the edge of a table or counter. Ensure that the cord
is not in a position where it can be pulled on inadvertently.
15. Do not allow the cord to touch hot surfaces and do not place on or near a hot gas
or electric burner or in a heated oven.
16. Do not use the appliance on a gas or electric cooking top or over or near an open
flame.
17. Use of an extension cord with this appliance is not recommended. However, if it
is necessary to use an extension lead, ensure that the lead is suited to the power
consumption of the appliance to avoid overheating of the extension cord,
appliance or plug point. Do not place the extension cord in a position where it can
be pulled on by children or animals or tripped over.
18. This appliance is not suitable for outdoor use. Do not use this appliance for
anything other than its intended use.
19. DO NOT carry the appliance by the power cord.
20. Do not leave this appliance unattended during use. Always unplug the unit when
not in use and before cleaning.
21. Always operate the appliance on a smooth, even, stable surface. Do not place
the unit on a hot surface.
22. Ensure that the switch is in the “Off” position after each use.

4
23. The manufacturer does not accept responsibility for any damage or injury caused
by improper or incorrect use, or for repairs carried out by unauthorised
personnel.
24. In case of technical problems, switch off the machine and do not attempt to repair
it yourself. Return the appliance to an authorised service facility for examination,
adjustment or repair. Always insist on the use of original spare parts. Failure to
comply with the above mentioned pre-cautions and instructions, could affect the
safe operation of this machine.
25. DO NOT COVER THE APPLIANCE.
PLEASE NOTE: When this heater is used for the first time, the heater will emit a smell of
burning and some smoke. This is normal and is caused by the insulation on the
elements and some dust particles on the elements. The smell and smoke will stop after
approximately 5 minutes.
OPERATING INSTRUCTIONS
Place the heater on a stable floor surface, away from curtains, clothes and any other
flammable materials. Make sure the controls knob is in the Off “O” position, and the
temperature control knob is on Min.
Plug the heater into the wall socket and switch on the wall socket.
To switch the unit on, turn the control knob on the right-hand side of the unit in a
clock-wise direction. The first setting is the fan setting. The second setting is the
WARM setting (1000W), and the third and last setting is the HOT setting (2000W).
Select the setting you require.
Next, turn the thermostat control knob (left-hand side of unit) in a clockwise direction
to select your ideal heat setting, based on the room size and the ambient
temperature.
To make the heater oscillate, switch on the oscillation function using the switch on
the front of the base. Turn this switch off to stop the heater from oscillating. The
heater will then point in one direction only.
When you have finished using the heater, turn the control knob to the Off “O” position
and the temperature control knob to the Min position. Switch off the wall socket and
unplug the heater from the wall socket.

5
PLEASE NOTE: The over-heat protection switch will automatically switch off the heater
in a case of overheating, and switch it on again when the heater cools down sufficiently.
CLEANING AND MAINTENANCE
This appliance is for household use only and is not user-serviceable.
Do not open or change any parts by yourself. Please refer to a qualified electrical
service department or return to the supplier if servicing is necessary.
Always remember to unplug the unit from the electrical outlet when not in use
and before cleaning. Ensure that the control knob is set to “0”.
The body of the appliance and the stand should be cleaned with a damp cloth.
Do not use bleach or other abrasive substance or solvents to clean your
appliance as it can be damaging to the finish.
Do not immerse the heater in water or any other liquid, or hold it under a running
tap to clean. Do not let water enter the appliance.
To remove stubborn spots/marks, wipe the surfaces with a cloth slightly
dampened in soapy water or mild non-abrasive cleaner. Rinse and dry a clean,
dry, soft cloth.
STORING THE APPLIANCE
Unplug the unit from the wall outlet and clean all the parts as instructed above.
Ensure that all parts are dry before storing.
Store the appliance in its box or in a clean, dry place.
Never store the appliance while it is still wet or dirty.
Never wrap the power cord around the appliance.
SERVICING THE APPLIANCE
There are no user serviceable parts in this appliance. If the unit is not operating
correctly, please check the following:
You have followed the instructions correctly
That the unit has been wired correctly and that the wall socket is switched on.
That the mains power supply is ON.
That the plug is firmly in the mains socket.

6
If the appliance still does not work after checking the above:
- Consult the retailer for possible repair or replacement. If the retailer fails to resolve the
problem and you need to return the appliance, make sure that:
The unit is packed carefully back into its original packaging.
Proof of purchase is attached.
A reason is provided for why it is being returned.
If the supply cord is damaged, it must be replaced by the manufacturer or an authorised
service agent, in order to avoid any hazard. If service becomes necessary within the
warranty period, the appliance should be returned to an approved Amalgamated
Appliance (Pty) Ltd service centre. Servicing outside the warranty period is still available,
but will, however, be chargeable.
CHANGING THE PLUG
Should the need arise to change the fitted plug, follow the instructions below.
This unit is designed to operate on 230V current only. Connecting to other power
sources may damage the appliance. Connect a three-pin plug as follows:
The wires in this mains lead are coloured in accordance with the following code:
Green/Yellow = Earth
Blue = Neutral
Brown = Live
PLEASE NOTE: THIS IS A CLASS II PRODUCT AND DOES NOT NEED TO BE
EARTHED

7
PLEASE AFFIX YOUR PROOF OF PURCHASE/RECEIPT HERE
IN THE EVENT OF A CLAIM UNDER WARRANTY THIS RECEIPT MUST BE
PRODUCED.
W A R R A N T Y
1. Tedelex Trading (Pty) Limited (“Tedelex”) warrants to the original purchaser of this product
(“the customer”) that this product will be free of defects in quality and workmanship which
under normal personal, family or household use and purpose may manifest within a period of 1
(one) year from the date of purchase (“warranty period”).
2. Where the customer has purchased a product and it breaks, is defective or does not work
properly for the intended purpose, the customer must notify the supplier from whom the
customer bought the product (“the supplier”) thereof within the warranty period. Any claim in
terms of this warranty must be supported by a proof of purchase. If proof of purchase is not
available, then repair, and/or service charges may be payable by the customer to the supplier.
3. The faulty product must be taken to the supplier's service centre to exercise the warranty.
4. The supplier will refund, repair or exchange the product in terms of this warranty subject to
legislative requirements. This warranty shall be valid only where the customer has not broken
the product himself, or used the product for something that it is not supposed to be used for.
The warranty does not include and will not be construed to cover products damaged as a result
of disaster, misuse, tamper, abuse or any unauthorised modification or repair of the product.
5. This warranty will extend only to the product provided at the date of the purchase and not to
any expendables attached or installed by the customer.
6. If the customer requests that the supplier repairs the product and the product breaks or fails to
work properly within 3 (three) months of the repair and not as a result of misuse, tampering or
modification by or on behalf of the customer, then the supplier may replace the product or pay
a refund to the customer.
7. The customer may be responsible for certain costs where products returned are not in the
original packaging, or if the packaging is damaged. This will be deducted from any refund paid
to the customer.
TEDELEX TRADING (PTY) LTD (JOHANNESBURG)
JOHANNESBURG TEL NO. [phone]
CAPE TOWN TEL NO. [phone]
DURBAN TEL NO. [phone]
www.amap.co.za
