Instruction Booklet
Model: CG1770
smart coffee
grinder

2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed including the following:
1.Read all instructions carefully before use.
2.Never leave the appliance unattended while plugged into the wall
outlet.
3.To protect against electrical hazards, do not immerse cord, plug or
appliance in water or any other liquid or place in the dishwasher.
4.Close supervision is necessary when any appliance is used by or near
children.
5.Unplug from outlet when not in use, when removing or putting on parts
and before cleaning.
6.DO NOT operate any appliance with a damaged cord or plug or after
the appliance has been damaged in any manner. Return appliance to
manufacturer for examination.
7.The use of accessories or attachments not recommended by
manufacturer may cause hazards.
8.DO NOT use outdoors.
9.DO NOT let cord hang over edge of table or counter, or touch hot
surfaces.
10.DO NOT use appliance for other than intended use.
11.DO NOT place on or near a hot gas or electric burner or in a heated
oven.
12.Always attach plug to appliance rst, then plug cord into the wall
outlet. To disconnect, turn any control to ‘OFF’, then remove plug
from the wall outlet.
13.To avoid overheating the motor, do not use the Grinder continuously
for more than 30 seconds.
14.To avoid injury to persons and damage, always unplug the appliance
and wait for the motor to stop completely, immediately after use and
before assembling/disassembling or cleaning.
15.Never put your hands, wooden spoons or other foreign substances
into the Grinding Bowl when the Grinding Bowl is assembled or the
appliance is connected to the wall outlet.

16. Before using, ensure there are no foreign objects in the Grinder.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
POLARIZED PLUG
This appliance has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug will t in a polarized outlet
only one way. If the plug does not t fully in the outlet, reverse the plug.
If it still does not t, contact a qualied electrician. Do not modify the
plug in any way.
DESCRIPTION OF PARTS
1. Cover Assembly
a. Inner Cover
b. Outer Cover
2. Grinding Bowl
3. Cleaning System ((inside grinding bowl)
4. Start Button
5. Cup Selector Button
6. Grind Selector Button
7. Base
8. Cleaning Brush (not shown)
BEFORE FIRST USE
1.Remove all packaging.
2.Turn the Cover Assembly counterclockwise and remove.
3.Separate the Inner and Outer Cover.
4.Turn the Grinding Bowl counterclockwise and remove.
5.Wash the Cover and Bowl in warm soapy water. Rinse and dry
thoroughly. NOTE: DO NOT place any parts of the appliance in the
dishwasher. IMPORTANT: Be careful when wiping out the Grinding
Bowl, the blade is very sharp.
6.Follow the instructions in the Care and Cleaning section to reassemble
the appliance.
3
1a
1b
2
3
5
6
7
4

4
HOW TO USE
1. Place the Grinding Bowl and the Cover Assembly on the Grinder. See
the assembly instructions in the Care and Cleaning section.
NOTE: The Coffee Grinder will only operate with the Cover and
Grinding Bowl in the locked position.
2. Remove the Inner Cover by grabbing it by the nger tabs and lifting it
straight up.
3. Ensure that the Grinding Bowl is empty and clean then pour whole
coffee beans into the Grinding Bowl and ll to the desired amount.
The minimum capacity is ¼ cup (60 ml) of coffee beans and maximum
capacity ¾ cup (180 ml).
NOTE: NEVER ll above the MAX level.
4. Place the Inner Cover back onto the Grinder.
5. Plug the Grinder into the wall outlet.
6. Press the Selection Buttons to choose the desired number of cups and
desired grind.
7. Press and HOLD the Start Button to begin grinding. The Grinder will
stop automatically when the grinding cycle is complete.
NOTE: To stop the grinding cycle at any time, release the Start
Button. If the Start
Button is pressed again, the Grinder will start from the beginning of the
timed cycle.
IMPORTANT: NEVER remove the Cover until the blades have
stopped moving.
8. Remove the Grinding Bowl and Cover Assembly together by turning
the Grinding Bowl counterclockwise and lifting it straight up.
9. Use the Cleaning System by gently twisting the Cover back and forth
to remove the coffee grounds from the sides and bottom of the
Grinding Bowl.
10.Remove the Inner Cover and shake out the coffee grounds.
11.Use the ground coffee immediately or place in an airtight container
for storage.
GRIND SELECTOR CONTROL
The Grind Selector Control has 3 settings, ne medium and coarse.
The setting that you choose will inuence the strength of coffee.
• Fine: Use for turkish coffee, espresso, latte, macchiato and
cappuccino
• Medium: Use for french press coffee makers and lter coffee
makers
• Coarse: Use for percolators

5
Coffee Beans
Experimenting with the Grinder will enable you to get exactly the grind
you prefer for your coffee. A ne grind exposes more surface to the
water and therefore a more rapid rate of extraction of avour. A coarser
grind, which exposes little surface, is appropriate for the longer brewing
cycle of percolators. Check your coffee maker instructions for the type of
grind that is best.
For the freshest, most robut cup of coffee, grind only enough coffee for
the pot you are making. If you are making a large pot, you may need
to grind in two batches. Coffee beans will keep up to 2 months in the
freezer (in an airtight container) and can be ground while still frozen.
Fresh beans will yield the best avour and aroma.
Tips for making espresso:
a) The coffee must be nely ground but not too ne. The correct grind
should look gritty like salt or sand.
b) If the grind is too ne, the water will not ow through the coffee when
brewing.
c) If the grind is too coarse, the water will ow through too fast.
Use the chart below as a guide to the amount of coffee beans required
for coffee.
Cups of Coffee
(5 oz./150 ml)
Bean Quantity
Tablespoons
Bean Quantity ML
4 4 60
6 4.5 67.5
8 6 90
10 7.5 112.5
12 9 135
Herbs and Spices
Herbs and spices take on a fresh, more avourful taste when freshly
ground. Dried herbs can be combined and ground for a few seconds
giving them move avour. Peppercorns, when freshly ground, taste
totally different from canned pre-ground pepper. Spices such as allspice,
cardamom, celery seed, mustard seed & coriander seed grind very well.
