Sam QUICK HITCH Technical reference manual

P1
QUICK HITCH
All models
SAM QUICK HITCH
BACK VIEW - (SMALL & LARGE PIN)
INSTR UCTI ON AND
PARTS MANUAL
www.sammachinery.co.nzPh 07 847 8492 or 0508 726 726
Strong. Simple. Smart.

P2
INSTRUCTION MANUAL
THANKS FOR CHOOSING A SAM
This Instruction and Parts Manual covers all SAM Quick hitches manufactured since 2019.
For all other SAM Machinery Instruction Manuals please visit www.sammachinery.co.nz
SERIAL NUMBER
All SAM Machinery products are identified with a unique serial number located on the back of the Quick Hitch
(e.g. ‘18 AH 1234’). Please include this number with all parts and servicing enquiries so we can provide you with fast
and accurate assistance.
G’DAY
Coombridge & Alexander have created SAM Quick Hitches from over 70 years’ experience making agricultural
machinery in New Zealand. Strong, simple and smart, each product is handcraed from the very best materials and
componentry we can find. They are known for their practical design and easy to use operation.
A family-owned and operated company located in the heart of the Waikato, Coombridge & Alexander control
the complete manufacturing process of the iconic SAM range: Fertiliser Spreaders, Combo Spreaders, Orchard
Spreaders, Feed Wagons, Hydraulic Trailers and Quick Hitches.
We stand by the quality of all of our products - our team have put the hard work in so you can expect a long working
life out of your gear. All the best with your new SAM. We trust you will love it.
For all parts, servicing or support enquiries please contact us on 07 847 8492.
For international parts and servicing please contact 0064 7 847 8492.
www.sammachinery.co.nz
MODEL DETAILS
MODEL
SERIAL NUMBER
18 QH 1234
Proudly NZ-made since 1946
Serial Number:
Call + 64 7 847 8492 | 0508 726 726
Visit www.sammachinery.co.nz
Email [e-mail]
HQ Maeroa Road, Hamilton, New Zealand

P3
BASIC SAFETY
Many agricultural machines have potentially dangerous moving parts, which can cause serious or fatal
injuries. Remember;
1. Read ALL warning labels on the machine or accessory and ensure you understand operating instructions.
2. Do not use the Quick Hitch in steep areas where there is a high-risk of undue stress occurring on componentry
or roll-over.
3. Loads are not to exceed the recommended rating.
Large 40mm pin (15,000kg) This is suitable for a 50mm towing eye.
Small 32mm pin (12,000kg) This is suitable for a 40mm towing eye.
OPERATIONAL CHECK
1. Attach tractor li arms to the hitch using the provided pins.
2. Attach the top link and adjust so the towing pin is in a vertical position at towing height.
3. Undo rope so you can access it from the tractor seat.
4. Back the tractor to the implement and li towing pin through the implement towing eye.
5. Ensure the safety latch clicks into place to hold the towing eye down.
6. Li to a suitable towing height to ensure the implement drawbar clears the ground for all terrain.
BASIC SAFETY
BASIC MAINTENANCE
To keep your SAM Quick Hitch in excellent working condition, please follow these basic maintenance procedures
as you go.
1. Check for any wear or damage to the pin and locking latch.
2. Check for any cracking on the frame.
3. If you notice any of the above - do not use.
Please keep these checks up for the lifetime of your SAM.
HOW TO USE

P4
HEALTH & SAFETY
TROUBLESHOOTING
If you need spare parts or need help contact Coombridge & Alexander (SAM Machinery) directly
or see your local dealership.
HEALTH & SAFETY RISK ASSESSMENT
A hazard identification, assessment and control procedure has been conducted on a representative SAM Hydraulic Quick
Hitch and where necessary appropriate risk control measures have been outlined below;
HAZARD HARM CONTROLS
Heavy frame 1. Liing injury
2. Crushing injury
You can use the tractor to li the
quick hitch into position ready for
coupling to the tractor.
Use proper liing technique when
moving manually. Li using strength
from your feet and legs to protect
your back.
Make sure the Quick Hitch is sitting
on fairly flat ground.
Coming loose from the hitch
or pin breaking 3. Crushing injury
Regulary check the hitch is in a
sound condition.
Do not exceed recommended load
ratings.
Roll-over potential 4. Crushing injury or fatality
Do not operate Quick Hitch in areas
that are too steep for; 1. safe opera-
tion, 2. adequate weight on hitch

P5
HEALTH & SAFETY
2
7
6
5
3
4
PARTS MANUAL
HYDRAULIC TRAILER SIDE-VIEW
REFERENCE PART NO. DESCRIPTION QTY.
13661 D shackle 1
2 6335 Label - SAM - yellow/white small 1
33592 Linch pin 1
4 6317 Pin - top link 1
56318 Pin - li arm 2
6 3664 Rope 1
7 3645 Spring 1
8 P4847 Tow pin - large 40mm 1
Tow pin - small 32mm 1
*Please include the serial number with all parts and servicing enquiries.
PARTS
1
8

P6
QUALITY GUARANTEE
SAM Machinery products are guaranteed against any defects in either material or manufacture for a period of
24 months from delivery date, provided that the equipment has not been subject to abuse or misuse, operated
incorrectly, over-loaded or used for purposes other than for which the equipment is designed. Or is not
maintained correctly or if fitted with other than genuine parts.
Claims are only valid when approved by the manufacturer. No person or agent is authorised to assume
any liability.
As the use of the equipment is outside our control we can only guarantee quality. No liability for loss, direct
expenses incurred from the use of this equipment or from any other cause of in respect of performance etc.
can be accepted.
Defective parts must be returned freight paid to the manufacturer or available to be inspected as directed.
Should such parts prove to the manufacturers satisfaction to be faulty - repair of - replacement of defective parts
shall constitute fulfillment of guarantee obligations. Parts destroyed, lost or tampered with nullify guarantee.
WARRANTY
SAM Machinery products as designed and supplied by Coombridge & Alexander Ltd, are warranted against faulty
workmanship and defective materials for a period of 24 months from date of purchase. Such warranty is subject to
the following conditions:
1. This warranty covers the repair or replacement of parts or machinery sold by Coombridge &
Alexander Ltd and damaged as a result of faulty workmanship of materials in such part of machinery.
It does not extend to any other loss or damage including consequential loss or damage to other
property or persons.
2. No responsibility will be accepted for repairs made other than by Coombridge & Alexander Ltd or its
accredited agent and without prior authorisation by Coombridge & Alexander Ltd.
a. Without limiting the generality of paragraph 1. above, this warranty does not cover the following;
b. Losses sustained through delay in delivery
c. Travel expenses
d. Damage caused by accident, misuse or abuse
3. Damage to any goods which have been altered or modified by someone other than Coombridge &
Alexander Ltd or its authorised dealers.
4. Procedure for recovery under warranty;
1. No loss or damage will be covered under warranty unless the following procedure is followed by
the purchaser.
1. If the purchaser is an authorised dealer -
a. Coombridge & Alexander Ltd must first be advised of details of the goods
concerned, the loss or damage sustained and the circumstances in which the loss
or damage arose.
b. Coombridge & Alexander Ltd will then decide if such loss or damage is within the
terms of warranty and shall advise the dealer as to how the loss or damage is to be
repaired.
2. If the purchase is not an authorised dealer -
a. The loss or damage should be reported directly to Coombridge & Alexander Ltd
who will advise whether it is covered by the warranty and direct the purchaser
accordingly as to what action is to be taken.
QUALITY GUARANTEE AND WARRANTY
