1
INTRODUCTION
CONGRATULATIONS ON YOUR PURCHASE OF A
SAMLEX SOLAR RV KIT!
Your new Samlex Solar RV kit provides you with a clean, green, silent and
sustainable way to ensure your batteries are fully charged and you have
a continuous source of electricity while dry camping or in the absence of
a conventional source of electricity. The Samlex Solar RV Kit comes with a
high quality solar panel, which produces DC electricity when illuminated by
sunlight. A state-of-the-art 30 Amp solar charge controller is also provided
in the kit to be connected between the solar panel and the storage
batteries. The solar charge controller will make sure the battery is charged
with the harnessed solar electricity, as per the battery manufacturer’s
recommendations. The solar charge controller comes with eight selectable
charging proles to meet the charging requirements of most standard
lead acid batteries used in RVs and remote off-grid solar applications as
well as Nickel Cadmium (NiCad) batteries. The LCD screen on the charge
controller provides detailed information about the system status including
battery voltage and charging current. The solar charge controller is
ush mountable, which is ideal for mounting within the RV interior. The
Samlex Solar RV kit also incorporates mounting hardware including sturdy
aluminum Z-brackets with the nuts and bolts required to at mount the
solar panel on the roof of the RV or any other at surface. If you wish
to optimize the collection of solar energy by tilting the solar panel to an
optimal inclination, the adjustable tilt-mount may be purchased optionally.
The cable management hardware incorporated in the kit will enable you to
effectively manage any external wiring. To expand your system further and
harness more energy from the sun, you may use one of our expansion kits
which come with a solar panel and all the hardware you need to mount the
extra solar panel and link it to the existing system.
This manual provides instructions on how to put together the various
components of the RV solar charging kit. Please refer to the separate solar
charge controller manual for detailed information about the installation,
operation and programming of the solar charge controller.
Please read the manual carefully before installing or operating the solar
kit to prevent personal injury or damage to the components. If you have
any concerns about the suitability of the kit for your application or doubts
about any of the instructions in the manual contact your authorized Samlex
America Distributor or Samlex America Technical Support at 1-800-561-5885.

4
2
COMPONENTS
No Model SRV-50-KIT SRV-85-KIT SRV-120-KIT SRV-EXP-50-KIT SRV-EXP-85-KIT SRV-EXP-120-KIT
1 Samlex 50 W Solar panel 1 0 0 1 0 0
2 Samlex 85 W Solar panel 0 1 0 0 1 0
3 Samlex 120 W Solar panel 0 0 1 0 0 1
4Samlex 30 Amp Charge Controller
model SCC-30AB 1 1 1 0 0 0
5Pre-wired cable assembly (20 ft)
with MC male Coupler 1 1 1 1 1 1
6Pre-wired cable assembly (20 ft)
with MC female Coupler 1 1 1 1 1 1
7 MC4 Male Connector 0 0 0 1 1 1
8 MC4 Female Connector 0 0 0 1 1 1
9 Positive MC branch connector 0 0 0 1 1 1
10 Negative MC Branch Connector 0 0 0 1 1 1
11 5-hole mounting bracket 4 4 4 4 4 4
12 Stainless Steel Serrated Flange
bolt ¼”-20 x ¾" 4 4 4 4 4 4
13 Stainless Steel Nylon
Insert Locknut, ¼” 4 4 4 4 4 4
14 Stainless Steel Flat washer, ¼”-20 8 8 8 8 8 8
15 Well Nut - Nut Thread: ¼”-20,
Length: 1”, Shank Dia.: ½” 4 4 4 4 4 4
16 Stainless Steel Serrated
Flange Bolt, ¼”-20x1¼” 4 4 4 4 4 4
17 Cable clamp 6 6 6 6 6 6
18 #8 Self Tapping Screws 6 6 6 6 6 6
19 Cable Ties 6 6 6 6 6 6
20 Battery Ring Terminals 2 2 2 2 2 2
21 Insulated Fork Terminals 4 4 4 0 0 0
22 7 x 19, 5/8" Flat Head Tapping
Screws 4 4 4 0 0 0
23 Samlex RV Kit
Installation Manual 1 1 1 1 1 1

5
3
GENERAL SAFETY
3.1. Warnings
Please read the instruction manual carefully before attempting to carry out
any installation and wiring. Contact your RV dealer or Technical support at
Samlex America (1-800-561-5885) for any questions concerning the installation.
Installation and wiring compliance
Installation and wiring must comply with the local and National Electrical Codes and must be done
by a certied electrician.
1. Disconnect all power sources before carrying out the installation.
2. Make sure the correct polarity is observed when making connections between the solar panel,
charge controller and the battery. Damage due to reverse polarity connection is not covered
by warranty.
3. Make sure all wire connections are secure as loose connections may cause sparks.
4. Wear appropriate clothing and safety gear including protective eyewear when performing
any electrical installation.
Preventing re and explosion hazards
Working with electronic/electrical equipment may produce arcs or sparks. Thus, such equipment should not
be used in areas where there are inammable materials or gases requiring ignition protected equipment.
These areas may include spaces containing gasoline powered machinery, fuel tanks, battery compartments.
Precautions when working with batteries
• Batteries contain very corrosive diluted sulphuric acid as electrolyte. Precautions should be taken
to prevent contact with skin, eyes or clothing.
• Batteries generate hydrogen and oxygen during charging resulting in evolution of explosive gas mixture.
Care should be taken to ventilate the battery area and follow the battery manufacturer’s
recommendations.
• Never smoke or allow a spark or ame near the batteries.
• Use caution to reduce the risk of dropping a metal tool on the battery. It could spark or short circuit
the battery or other electrical parts and could cause an explosion.
• Remove metal items like rings, bracelets and watches when working with batteries. The batteries can
produce a short circuit current high enough to weld a ring or the like to metal and thus cause a severe
burn.
• If you need to remove a battery, always remove the ground terminal from the battery rst. Make sure
that all the accessories are off so that you do not cause a spark.
• Use properly insulated tools only when making battery connections.
Precautions when working with solar panels
With the incidence of sunlight or other light sources on all solar panels, a voltage appears at the output
terminals of the solar panel turning it into a source of electricity. To avoid a shock hazard make sure the solar
panel is covered with an opaque (dark) material such as paper/cloth during the installation. Do not make
contact with the terminals when the panel is exposed to sunlight or any other light sources.

6
3
GENERAL SAFETY
Precautions when working with Charge Controller Model no. SCC-30AB
If two or more solar panels are connected in series/parallel make sure that the sum of the short circuit current
ratings of all panel strings does not exceed 80% of the charge controller’s current rating i.e. 24 Amps for the
30 Amp charge controller. The open circuit voltage of the solar array i.e. the maximum voltage across the array
should not exceed 26 V when the 12 V setting on the charge controller is used and not exceed 52 V when the
24 V setting on the charge controller is used.
3.2. Routine Maintenance
• Inspect the solar panels and make sure the surface is free from dust, dirt and other debris,
clean with a wet cloth or glass cleaner, if necessary.
• Check to make sure all structural components, mechanical fasteners and electrical connections are
secure, clean and corrosion-free.
• Check and maintain the battery electrolyte levels at regular intervals as per the battery manufacturer’s
recommendations if ooded wet cell lead acid batteries are used.
• Check and replace damaged components if necessary.
3.3. Installation Overview
1. Read the manual in detail and understand the installation procedure.
2. Open the packaging and check to make sure that all parts have been received as per the parts list
in the manual.
3. Arrange for the required tools to carry out the installation. A sample list of tools (not exhaustive)
is provided in Section 4.
4. Determine the mounting location of the solar panel(s) on the roof of the RV.
5. Mount the charge controller at the desired location (see Section 5).
6. Pass the cable from the solar panels to the interior of the RV (See section 6).
7. Wire the battery to the charge controller and then the solar panel to the charge controller ensuring
the correct polarity is observed (See Section 6).
8. Secure the solar panel to the RV roof (See Section 7).
solar
panel
battery
solar
charge
controller
Fig. 3.3. Installation Block Diagram

7
4
REQUIRED TOOLS & MATERIALS
5
CHARGE CONTROLLER INSTALLATION
1. Philips drive screw driver
2. 7/16” wrench
3. 3/8” wrench
4. Wire stripper
5. Wire crimping tool
6. Hand Drill
7. ½” drill bit
8. Jig-saw or suitable cutting tool
9. Pliers
10.Punch or Awl
4.2. Required Materials
1. Silicone or any suitable roof sealant. Contact your local RV
dealer or RV store for a recommendation on a sealant to
suit your specic RV roof material.
2. Anti-galling lubricant to prevent “thread galling” of
all stainless steel fasteners exposed to the outdoor
environment. This should be available at most hardware or
auto-parts stores. If anti-galling lubricant is not available
any standard lubricant will minimize the occurrence of
“thread galling”.
3. If wiring distances are longer than the lengths of wire
provided with the kit, extra stranded copper wire will
be required. Wires should be 12 AWG or thicker, single
conductor, Type UF (Underground Feeder - marked as
sunlight resistant), Type SE (Service Entrance) or Type USE/
USE-2 (Underground Service Entrance).
4.1. Required Tools
1. The Samlex Solar RV kit comes with a 30 Amp PWM charge controller Model no. SCC-30AB to optimally
charge your batteries from the solar panel.
2. The Solar charge controller comes with its own detailed manual. Read the manual in detail.
The instructions in this section are only a brief summary of information contained in the manual.
3. Make sure the solar panels and batteries are disconnected from the charge controller before
installing the charge controller.
4. The charge controller should ideally be located in an area relatively close to the battery.
5. The charge controller should be mounted indoors in a dry location.
6. The charge controller is designed to be ush mounted on a wall or cabinet so that the wiring
at the back can be accessed. Allow adequate spacing (2-3 inches) behind the unit to accommodate
the charge controller and the wiring.
7. Using the cut-out template provided in the charge controller manual, mark the cut-out on
the installation surface and the location of the mounting holes.
8. Using a hand drill and suitable drill bit, drill the mounting holes.
9. Using a jig saw or suitable cutting tool cut the material out from the installation surface.
10.After wiring the charge controller terminals (see Section 6 on wiring), x the mounting plate
to the installation surface using the screws provided with the charge controller (7 x 19, 5/8" Flat Head
Tapping Screws - Philips Drive).

8
6
WIRING
The battery must be wired to the charge controller before the solar panel is connected to the charge controller.
A pair of 20 foot pre-assembled cables with Multi-Contact (MC) male and female connectors is provided
primarily to connect the solar panel to the charge controller. After making sure that sufcient length is
available to wire the solar panel to the charge controller, any excess wire maybe used to wire the battery to the
charge controller.
6.1. Battery to Charge Controller
• Mark the cables to differentiate between Positive and Negative.
• Make sure the Positive terminal (marked ‘+’) of the battery is connected to the Positive terminal (marked
“BAT +”) of the charge controller and the negative terminal (marked ‘-’) of the battery is connected to
the Negative terminal (marked “BAT -”) of the Charge Controller SCC-30AB. If you are not sure use a DC
voltmeter to determine the polarity of the battery bank. Reverse polarity connection will damage the
Charge Controller and the resulting damage will not be covered by warranty.
• Crimp the insulated fork terminals provided (Fig 6.1.3) to one end of the Positive and Negative battery
leads.
• Insert the fork terminals (g 6.1.3) into the appropriate terminal on the charge controller: Positive lead is
connected to the Positive terminal (marked “BAT+”) of the charge controller Negative lead is connected
to the Negative terminal (marked “BAT -”) of the Charge Controller SCC-30AB.
• Crimp the battery ring terminals (g 6.1.2) provided to the Positive and Negative wire leads to be
connected to the battery terminals.
• Clean the battery post terminals free of corrosion and other impurities.
• Bolt the ring terminals to the battery terminals making sure the correct polarity is observed.
6.2. Solar Panel to Charge Controller
1. Determine the position of the solar panel on the RV roof. While positioning panels, avoid shading of the
solar panel by neighbouring obstacles such as vents, air-conditioners, TV antennas etc. As far as possible,
position the panels to minimize wiring distance between the solar panel and the charge controller. Place
the panel at least 8-10 inches away from the RV roof edges and leave sufcient space to walk around the
panel and access the mounting hardware.
2. Make sure the thickness of the roof at the installation location is at least ½” thick and the material
is strong enough to provide mechanical support to the solar panel and mounting hardware against
possible wind loading. Place the panel length-wise to reduce the effects of wind loading on the RV.
Fig 6.1.1 Rear view
of Solar Charge
Controller showing
terminals
Fig 6.1.2
Battery
Ring
terminal
Fig 6.1.3
Fork
terminal
PV +
PV -
Bat +
Bat -
PV +
PV -
BAT+
BAT -
PV +
PV -
BAT+
BAT -
Warning:
Be careful not to short the battery

9
6
WIRING
3. The solar panels come with a sealed pre-wired junction box with both positive and negative leads
having male and female Multi-contact (MC) connectors respectively. The polarity of the conductors is
marked as ‘+’ for the positive lead and ‘-’ for the negative lead. Do not connect the male and female MC
connectors from the same solar panel together as this will short the solar panel.
4. Connect the MC connector corresponding to the positive lead (marked as ‘+’) on the solar panel to the
suitable mating MC connector from the cable pair provided.It is advisable to identify this extension cable
as the positive lead using a sticker.Similarly connect the MC connector corresponding to the negative
lead (marked as ‘-’) to the suitable mating MC connector from the cable pair provided. As before,
identify this extension cable as the negative lead using a sticker.
5. The cable pair from the solar panel can be routed to the interior of the RV through the roof-top
refrigerator vent. Find where the refrigerator vent is located on the roof of the RV.
6. Select a suitable mounting location for the solar panel, preferably as close to the vent as possible. The
mounting surface should be strong enough to support the mounting hardware, the solar panel and
wind loads.
7. Take off the vent cover to gain access to the duct opening and keep the vent fastening hardware safely
as the vent cover will have to be replaced after the wire has been routed.
8. The wire from the solar panel can be routed by either:
A. Hole in the side of the vent: Drill a suitable hole in the side of the vent and insert a rubber grommet (not provided). Route the
cable pair carefully to the charge controller through the hole. Use appropriate sealant as recommended by your local RV dealer
to ensure the penetration at the side of the vent is watertight.
B. Through the vent screen: Route the cable pair through the vent screen grid holes. Widen the screen grid holes if necessary.
9. Use the cable clamps with #8 self-tapping screws and tie wraps at regular intervals of the wire route
from the solar panel to the charge controller to hold the cables in place for a neat nish. Tuck any excess
wire under the refrigerator vent cover.
10.Replace the refrigerator vent cover and secure with the retained hardware.
11.Crimp the bare end of the cables with the fork terminals provided.
12.Insert the terminals into the appropriate terminal on the charge controller: positive PV lead is connected
to the positive terminal (marked “PV +”) of the charge controller and the negative PV lead is connected
to the negative terminal (marked “PV -”) of the charge controller. Reverse polarity connection will
damage the Charge Controller and the resulting damage will not be covered by warranty.
solar
panel
refrigerator
vent cover
vent
screen method B
method A
Fig. 6.2. Cable entry through RV Vent
Warning:
Avoid sharp, heated or abrasive material on the cable route.

10
7
SOLAR PANEL INSTALLATION
1. Stainless steel can be subject to a process called “thread
galling” in which bolts can twist off and/or the bolt
threads seize to the nut’s thread. Apply Anti-galling
lubricant available at most hardware or auto-parts stores
to all the stainless steel fasteners before installation.
If anti-galling lubricant is not available, any standard
lubricant will minimize the occurrence of “thread
galling”.
2. Fix the mounting brackets to the frame of the previously
positioned solar panel using the slotted opening and the
¼”-20 x ¾"Flange Bolt, Nylon Locknut and at washer.
3. Using a 7/16” wrench, tighten the nuts to secure the
mounting brackets to the PV panel. Recommended
tightening torque is 15 lbs.
4. Position the panel with the attached mounting brackets
at the desired location on the RV roof and mark the
position of the desired mounting hole using a suitable
marker by tracing the hole on the mounting bracket.
Please ensure that the mounting surface on the RV roof is
strong enough to support the mounting hardware, solar
panel and wind loads.
5. The centre and end holes on the mounting brackets are
sized to accept the ¼” hardware supplied with the unit. If
the use of larger sized hardware is desired, holes 2 and 4
can be used.
Well Nut for anchoring Solar Panel to RV Roof
6. A Well-Nut is a bushing of tough neoprene rubber with
a ange at the top end and a captive brass nut mounted
within the bore at the bottom end (g. 7.3). Tightening a
conventional machine bolt or screw engages the captive
nut thereby causing the bushing to expand outwards.
This fastens securely to thinner RV roofs by bulging up
and against the bottom surface of the roof (g. 7.6). If
used in a blind hole in a solid surface material, the rubber
will expand outwards to create a secure fastening (g.
7.7). The neoprene and brass resist most environmental
conditions. Additionally, the Well-Nut seals the drilled
hole effectively against air and liquid leakage.
Typical Installation of a Well-Nut
solar module
1/4” -20x3/4” ange bolt
1/4” at washer
1/4” locknut
mounting bracket
RV roof
1/4” holes
3/8” holes
ange
1/2” diameter
1/4” captive brass nut
Fig. 7.2. 5-Hole Mounting Bracket.
Fig. 7.3. Construction of a Well Nut
ange
1/2” diameter
1/4” captive brass nut
Fig. 7.4. Well-Nut is inserted into
a pre-drilled hole with its ange
against the outter surface. There
is no need for access to the
inner side.
ange
1/2” diameter
1/4” captive brass nut
Fig. 7.5. The 5-hole mounting
bracket is placed against the ange
of the Well-Nut and is secured
by the bolt engaging the captive
brass nut.
ange
1/2” diameter
1/4” captive brass nut
Fig. 7.6 . As the bolt is tightened, the
neoprene body of the Well-Nut is
compressed and expanded, forcing
it tightly into the bolt's threads and
against the inner surface of the thin RV
roof material.
ange
1/2” diameter
1/4” captive brass nut
Fig. 7.7. Installed in a blind
hole in a solid material, the
body of the Well-Nut expands
tightly against the walls of
the hole, effecting a secure,
dependable fastening.
Fig. 7.1. Attaching solar panel to 5-hole mounting bracket.

11
7
SOLAR PANEL INSTALLATION
7. To install the Well-Nuts, drill holes 1¼” deep at the marked positions using a ½” size drill bit. Make sure
that drilling does not interfere with pre-existing wiring installations.
8. Apply silicone or any appropriate sealant recommended by your RV dealer generously to the drilled
holes for water-proong.
9. Insert the ¼” Well-Nut into the drilled holes so that only the ange section remains above the roof
surface.
10.Fasten the mounting brackets to the roof surface by inserting the ¼ x1¼” serrated ange bolt into the
Well-Nut. Tighten using a3/8” wrench to a recommended torque of 15 lbs. When the serrated ange
bolt is screwed into the Well-Nut, the material surrounding the well nut bulges slightly securing the
structure to the RV roof.
11.Make sure all bolts and mounting brackets are covered by good amounts of suitable RV sealant
recommended by your local RV dealer.
Fig. 7.8 Attaching 5-hole
mounting bracket to RV Roof
Rubber bushing material expands
when bolt is tightened to securely
anchor hardware
solar
module
¼”-20 x 1¼” ange bolt
¼” at washer
Well-Nut
mounting bracket
RV roof material
up to approx. 3/8”
thickness

12
8
CONNECTING SOLAR PANELS IN PARALLEL
The Samlex Expansion kits maybe used to
increase the solar energy available to charge
your batteries. Each Samlex Expansion kit
comes with a solar panel, mounting hardware
for the solar panel and a set of MC male and
female branch connectors to parallel the solar
panel to your existing system.
1. If the existing panel is already connected
to the mating connector on the pre-
assembled cables provided in the
original kit, remove this connection
using using a tweezer or any other
suitable tool.
2. Connect the Positive leads (marked as
‘+’) from the two solar panels to the
suitable mating branch connector (as in
g 8.1.).
3. Connect the Negative leads (marked
as ‘-’) from the two solar panels to the
suitable mating branch connector (as in
g 8.1.).
4. Mate the MC branch connectors to the
corresponding mating MC connector on
the pre-assembled cables provided with
your original kit.
Fig. 8.1. Connecting solar modules in parallel.
Additional
Solar Panel
Existing
Solar Panel
Negative MC
branch connector
Positive MC
branch connector
If the additional solar panels
are required to be mounted at a
distance from the existing solar
panel, a pair of cables with a MC4
connector pre-assembled at one
end is provided.
1. Cut the cable pair to the
appropriate length.
2. Strip 0.25" of the insulation
at the blunt ends using a
suitable wire stripper.
3. Crimp the male and female
MC4 connector to the blunt
end of the appropriate cable
with a suitable wire crimping
tool.
4. Complete the connections as
shown in Fig.8.2.
Fig. 8.2. Connection solar modules in parallel with additional module.
Negative MC
branch connector
Positive MC
branch connector
Additional cable pair
Additional
Solar Panel
Existing
Solar Panel

13
9
TYPICAL BATTERY CONNECTIONS
9.1. Series Connection of Batteries
9.2. Parallel Connection of Batteries
Fig. 9.1. Series Connection
When two or more batteries are connected in series, their voltages add up but their AH capacity remains the
same. Fig. 9.1. above shows 2 pieces of 6 V, 200 AH batteries connected in series to form a battery bank of 12
V with a capacity of 200 AH. The Positive terminal of Battery 1 becomes the Positive terminal of the 12 V bank.
The negative terminal of Battery 1 is connected to the Positive terminal of Battery 2. The negative terminal of
Battery 2 becomes the negative terminal of the 12 V battery bank.
Fig. 9.2. Parallel Connection
Solar Charge Controller
SCC30-AB (rear view)
Solar Charge Controller
SCC30-AB (rear view)
Solar Charge Controller
SCC30-AB (rear view)
PV +
PV -
BAT+
BAT - 6V Battery 6V Battery
PV +
PV -
BAT+
BAT - 12V Battery 12V Battery 12V Battery 12V Battery
PV +
PV -
BAT+
BAT - 6V Battery 6V Battery 6V Battery 6V Battery
String 1 String 2
Battery 1 Battery 3Battery 2 Battery 4
Battery 1 Battery 3Battery 2
Battery 1 Battery 2
Battery 4
Cable “A”
Cable “B”
Cable “A”
Cable “B”
Cable “A”
Cable “B”
Solar Charge Controller
SCC30-AB (rear view)
Solar Charge Controller
SCC30-AB (rear view)
Solar Charge Controller
SCC30-AB (rear view)
PV +
PV -
BAT+
BAT - 6V Battery 6V Battery
PV +
PV -
BAT+
BAT - 12V Battery 12V Battery 12V Battery 12V Battery
PV +
PV -
BAT+
BAT - 6V Battery 6V Battery 6V Battery 6V Battery
String 1 String 2
Battery 1 Battery 3Battery 2 Battery 4
Battery 1 Battery 3Battery 2
Battery 1 Battery 2
Battery 4
Cable “A”
Cable “B”
Cable “A”
Cable “B”
Cable “A”
Cable “B”
When two or more batteries are connected in parallel, their voltage remains the same but their AH capacities
add up. Fig. 9.2. shows 4 pieces of 12 V, 100 AH batteries connected in parallel to form a battery bank of
12 V with a capacity of 400 AH. The four Positive terminals of Batteries 1 to 4 are paralleled (connected
together) and this common Positive connection becomes the Positive terminal of the 12 V bank. Similarly, the
four Negative terminals of Batteries 1 to 4 are paralleled (connected together) and this common Negative
connection becomes the Negative terminal of the 12 V battery bank.

14
9
TYPICAL BATTERY CONNECTIONS
Solar Charge Controller
SCC30-AB (rear view)
Solar Charge Controller
SCC30-AB (rear view)
Solar Charge Controller
SCC30-AB (rear view)
PV +
PV -
BAT+
BAT - 6V Battery 6V Battery
PV +
PV -
BAT+
BAT - 12V Battery 12V Battery 12V Battery 12V Battery
PV +
PV -
BAT+
BAT - 6V Battery 6V Battery 6V Battery 6V Battery
String 1 String 2
Battery 1 Battery 3Battery 2 Battery 4
Battery 1 Battery 3Battery 2
Battery 1 Battery 2
Battery 4
Cable “A”
Cable “B”
Cable “A”
Cable “B”
Cable “A”
Cable “B”
CAUTION!
When 2 or more batteries / battery strings are connected in parallel and are then connected to
the Solar Charge Controller SCC30-AB (See Figs. 9.2 and 9.3. given above), attention should be
paid to the manner in which the solar charge controller is connected to the battery bank. Please
ensure that if the positive output cable of the solar charge controller (Cable “A”) is connected
to the positive battery post of the rst battery (Battery 1 in Fig. 9.2.) or to the positive battery
post of the rst battery string (Battery 1 of String 1 in Fig. 9.3.), then the Negative output cable
of the Solar Charge Controller SCC30-AB (Cable “B”) should be connected to the Negative battery post of the last
battery (Battery 2 as in Fig. 9.2) or to the Negative Post of the last battery string (Battery 4 of Battery String 2 as
in Fig. 9.3.). This connection ensures the following:
• The resistances of the interconnecting cables will be balanced.
• All the individual batteries / battery strings will see the same series resistance.
• All the individual batteries will charge at the same charging current and thus,
will be charged to the same state at the same time.
• None of the batteries will see an overcharge condition.
If the positive output cable of the battery charger (Cable “A”) is connected to the positive battery post of the rst
battery (Battery 1 in Fig. 9.2.) or to the positive battery post of the rst battery string (Battery 1 of String 1 in Fig.
9.3.), and the Negative output cable of the battery charger (Cable “B”) is connected to the Negative battery post
of the rst battery (Battery 1 as in Fig. 9.2.) or to the Negative Post of the rst battery string (Battery 1 of Battery
String 1 as in Fig. 9.3.), the following abnormal conditions will result:
• The resistances of the connecting cables will not be balanced.
• The individual batteries will see different series resistances.
• All the individual batteries will be charged at different charging current and thus,
will reach fully charged state at different times.
• The battery with lower series resistance will take shorter time to charge as compared to the battery
which sees higher series resistance and hence, will experience over charging and its life will be reduced.
Figure 9.3. above shows a series – parallel connection consisting of four 6 V, 200 AH batteries to form a 12 V,
400 AH battery bank. Two 6 V, 200 AH batteries, Batteries 1 and 2 are connected in series to form a 12 V, 200
AH battery (String 1). Similarly, two 6 V, 200 AH batteries, Batteries 3 and 4 are connected in series to form a 12
V, 200 AH battery (String 2). These two 12 V, 200 AH Strings 1 and 2 are connected in parallel to form a 12 V,
400 AH bank.
Fig. 9.3. Series-Parallel Connection
9.3. Series – Parallel Connection of Batteries

15
10
WARRANTY
Warranty
The Samlex RV Solar Kit manufactured by Samlex America, Inc. (the “Warrantor“) are warranted to be free
from defects in workmanship and materials under normal use and service. This warranty is in effect from the
date of purchase by the user (the “Purchaser“).
Warranty period for various kit components:
50W/85W/120W Solar Panel: 5 year product workmanship warranty
12 year 90% power output warranty
25 year 80% power output warranty
Samlex 30 Amp Solar Charge Controller
Model SCC-30AB:
5 year product workmanship warranty
Mounting Hardware and Wiring: 5 year product workmanship warranty
For a warranty claim, the Purchaser should contact the place of purchase to obtain a Return Authorization
Number. The defective part or unit should be returned at the Purchaser’s expense to the authorized location.
A written statement describing the nature of the defect, the date of purchase, the place of purchase, and the
Purchaser’s name, address and telephone number should also be included.
If upon the Warrantor’s examination, the defect proves to be the result of defective material or workmanship,
the equipment will be repaired or replaced at the Warrantor’s option without charge, and returned to the
Purchaser at the Warrantor’s expense.
No refund of the purchase price will be granted to the Purchaser, unless the Warrantor is unable to remedy the
defect after having a reasonable number of opportunities to do so.
Warranty service shall be performed only by the Warrantor. Any attempt to remedy the defect by anyone other
than the Warrantor shall render this warranty void.
There shall be no warranty for defects or damages caused by faulty installation or hook-up, abuse or misuse of
the equipment including exposure to excessive heat, salt or fresh water spray, or water immersion.
No other express warranty is hereby given and there are no warranties which extend beyond those described
herein. This warranty is expressly in lieu of any other expressed or implied warranties, including any implied
warranty of merchantability, tness for the ordinary purposes for which such goods are used, or tness for a
particular purpose, or any other obligations on the part of the Warrantor or its employees and representatives.
DISCLAIMER OF LIABILITY
There shall be no responsibility or liability whatsoever on the part of the Warrantor or its employees and
representatives for injury to any persons, or damage to person or persons, or damage to property, or loss
of income or prot, or any other consequential or resulting damage which may be claimed to have been
incurred through the use or sale of the equipment, including any possible failure of malfunction of the
equipment, or part thereof.
The Warrantor assumes no liability for incidental or consequential damages of any kind.
Samlex America Inc. (the “Warrantor”)
110-17 Fawcett Road
Coquitlam BC, V3K 6V2 Canada
[phone]

Owner's
Manual
Please read
this manual
before
operating
your kit
Solar
Charging Kit
SRV-50-KIT
SRV-85-KIT
SRV-120-KIT
SRV-EXP-50-KIT
SRV-EXP-85-KIT
SRV-EXP-120-KIT
110-17 Fawcett Rd
Coquitlam, B.C.
Canada V3K 6V2
T: 604 525 3836
F: 604 525 5221
e-mail: [e-mail]
website: www.samlexsolar.com
092-2009
