Safety Information
3
English
Before using your new air conditioner, please read this manual thoroughly
to ensure that you know how to safely and efficiently operate the extensive
features and functions of your new appliance.
Because the following operating instructions cover various models, the
characteristics of your air conditioner may differ slightly from those described in
this manual. If you have any questions, call your nearest contact centre or find
help and information online at www.samsung.com.
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property
damage.
Follow directions.
Do NOT attempt.
Make sure the machine is grounded to prevent electric shock.
Cut-off the power supply.
Do NOT disassemble.
FOR INSTALLATION
WARNING
Use the power line with the power specifications of the product or higher
and use the power line for this appliance only. In addition, do not use an
extension line.
• Extending the power line may result in electric shock or fire.
• Do not use an electric transformer. This may result in electric shock or
fire.
• If the voltage/frequency/rated current condition is different, it may cause
fire.
Safety Information
Safety Information
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 3 2016-10-27 오전 10:47:46

Safety Information
Safety Information
4English
The installation of this appliance must be performed by a qualified
technician or service company.
• Failing to do so may result in electric shock, fire, explosion, problems with
the product, or injury.
Install a switch and circuit breaker dedicated to the air conditioner.
• Failing to do so may result in electric shock or fire.
Fix the outdoor unit firmly so that the electric part of the outdoor unit is
not exposed.
• Failing to do so may result in electric shock or fire.
Do not install this appliance near a heater, inflammable material. Do
not install this appliance in a humid, oily or dusty location, in a location
exposed to direct sunlight and water (rain drops). Do not install this
appliance in a location where gas may leak.
• This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high external wall
where it could fall.
• If the outdoor unit falls, it may result in injury, death or property damage.
This appliance must be properly grounded. Do not ground the appliance to
a gas pipe, plastic water pipe, ortelephone line.
• Failure to do so may result in electric shock, fire, an explosion, or other
problems with the product.
• Never plug the power cord into a socket that is not grounded correctly
and make sure that it is in accordance with local and national codes.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 4 2016-10-27 오전 10:47:46

Safety Information
5
English
CAUTION
Install your appliance on a level and hard floor that can support its weight.
• Failing to do so may result in abnormal vibrations, noise, or problems with
the product.
Install the drain hose properly so that water is drained correctly.
• Failing to do so may result in water overflowing and property damage.
Avoid adding drain to waste pipes as odours may arise in the future.
When installing the outdoor unit, make sure to connect the drain hose so
that draining is performed correctly.
• The water generated during the heating operation in the outdoor unit
may overflow and result in property damage.
In particular, in winter, if a block of ice falls, it may result in injury, death
or property damage.
FOR POWER SUPPLY
WARNING
When the circuit breaker is damaged, contact your nearest service centre.
Do not pull or excessively bend the power line. Do not twist ortie the
power line. Do not hook the power line over a metal object, place a heavy
object on the power line, insert the power line between objects, or push
the power line into the space behind the appliance.
• This may result in electric shock or fire.
CAUTION
When not using the air conditioner for a long period of time or during a
thunder/lightning storm, cut the power at the circuit breaker.
• Failing to do so may result in electric shock or fire.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 5 2016-10-27 오전 10:47:47

Safety Information
Safety Information
6English
FOR USING
WARNING
If the appliance is flooded, please contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke,
unplug the power plug immediately and contact your nearest service
centre.
• Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate
immediately without touching the power line. Do not touch the appliance
or power line.
• Do not use a ventilating fan.
• A spark may result in an explosion or fire.
To reinstall the air conditioner, please contact your nearest service centre.
• Failing to do so may result in problems with the product, water leakage,
electric shock, or fire.
• A delivery service for the product is not provided. If you reinstall the
product in another location, additional construction expenses and an
installation fee will be charged.
• Especially, when you wish to install the product in an unusual location
such as in an industrial area or near the seaside where it is exposed to salt
in the air, please contact your nearest service centre.
Do not touch the circuit breakerwith wet hands.
• This may result in electric shock.
Do not turn the air conditioner off with the circuit breakerwhile it is
operating.
• Turning the air conditioner off and then on again with the circuit breaker
may cause a spark and result in electric shock or fire.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 6 2016-10-27 오전 10:47:47

Safety Information
7
English
After unpacking the air conditioner, keep all packaging materials well
out of the reach of children, as packaging materials can be dangerous to
children.
• If a child places a bag over its head, it may result in suffocation.
Do not touch the front panel with your hands or fingers during the heating
operation.
• This may result in electric shock or burns.
Do not insert your fingers or foreign substances into the outlet when the
air conditioner is operating or the front panel is closing.
• Take special care that children do not injure themselves by inserting their
fingers into the product.
Do not insert your fingers or foreign substances into the air inlet/outlet of
the air conditioner.
• Take special care that children do not injure themselves by inserting their
fingers into the product.
Do not strike or pull the air conditionerwith excessive force.
• This may result in fire, injury, or problems with the product.
Do not place an object nearthe outdoor unit that allows children to climb
onto the machine.
• This may result in children seriously injuring themselves.
Do not use this air conditioner for long periods of time in badly ventilated
locations or near infirm people.
• Since this may be dangerous due to a lack of oxygen, open a window at
least once an hour.
If any foreign substance such as water has entered the appliance, cut the
power by unplugging the power plug and turning the circuit breaker off
and then contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance yourself.
• Do not use any fuse (such as copper, steel wire, etc.)other than the
standard fuse.
• Failing to do so may result in electric shock, fire, problems with the
product, or injury.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 7 2016-10-27 오전 10:47:47

Safety Information
Safety Information
8English
CAUTION
Do not place objects or devices underthe indoor unit.
• Water dripping from the indoor unit may result in fire or property damage.
Check that the installation frame of the outdoor unit is not broken at least
once a year.
• Failing to do so may result in injury, death or property damage.
Max current is measured according to IEC standard for safety and current
is measured according to ISO standard for energy efficiency.
Do not stand on top of the appliance or place objects (such as laundry,
lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.)
on the appliance.
• This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
• This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the
appliance.
• As well as being harmful to humans, it may also result in electric shock,
fire or problems with the product.
Do not drink the water from the air conditioner.
• The water may be harmful to humans.
Do not apply a strong impact to the remote controller and do not
disassemble the remote controller.
Do not touch the pipes connected with the product.
• This may result in burns or injury.
Do not use this air conditioner to preserve precision equipment, food,
animals, plants or cosmetics, or for any other unusual purposes.
• This may result in property damage.
Avoid directly exposing humans, animals or plants to the air flow from the
air conditioner for long periods of time.
• This may result in harm to humans, animals or plants.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 8 2016-10-27 오전 10:47:47

Safety Information
9
English
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. Children should
be supervised to ensure that they do not play with the appliance.
For use in Europe: This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children
without supervision.
FOR CLEANING
WARNING
Do not clean the appliance by spraying water directly onto it. Do not use
benzene, thinner, alcohol or acetone to clean the appliance.
• This may result in discoloration, deformation, damage, electric shock or
fire.
Before cleaning or performing maintenance, unplug the air conditioner
from the wall socket and wait until the fan stops.
• Failing to do so may result in electric shock or fire.
CAUTION
Take care when cleaning the surface of the heat exchanger of the outdoor
unit since it has sharp edges.
• To avoid cutting your fingers, wear thick cotton gloves when cleaning it.
• This should be done by a qualified technician please contact your installer
or service centre.
Do not clean the inside of the air conditioner by yourself.
• For cleaning inside the appliance, contact your nearest service centre.
• When cleaning the internal filter, refer to the descriptions in the ‘Cleaning
and Maintaining’ section.
• Failure to do may result in damage, electric shock or fire.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 9 2016-10-27 오전 10:47:47

At a Glance
10 English
Indoor Unit Overview
1WAY (PC1NUSMAN/PC1NUPMAN/PC1NWSMAN)
02
03
04
01
Indoor Unit Overview
At a Glance
01 Display
02 Air flow blade
03 Panel
04 Air intake
Indication Function
Remote control sensor
Operation indicator
Timer indicator
Model not equipped with
S-Plasma ion: Fan indicator
Model equipped with S-Plasma
ion: Purity indicator
Filter reset indicator
NOTE
• Your air conditioner and display may look
slightly different from the illustration shown
above depending on your model.
• When operating an indoor unit (including Fan
mode), the S-Plasma Ion function may not
operate automatically. In this case, turn on
the Purity function with your remote control
to activate the function.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 10 2016-10-27 오전 10:47:48

At a Glance
11
English
4WAY (PC4NUSKAN)
01
04
03
02
01 Display
02 Air flow blade
03 Air intake
04 Air filter (under the grille)
Indication Function
On/Off operation indicator
Removing frost indicator
Timer indicator
Filter reset indicator
Remote control sensor
NOTE
• Your air conditioner and display may look
slightly different from the illustration shown
above depending on your model.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 11 2016-10-27 오전 10:47:48

At a Glance
12 English
Operation Features
Operating temperature and humidity
Mode Outdoor temperature Indoor temperature Indoor humidity
Cool mode -15°C to 50°C 18°C to 32°C 80% or less
Heat mode -20°C to 24°C 30°C or less -
Dry mode -15°C to 50°C 18°C to 32°C 80% or less
CAUTION
• If you use the air conditioner at a relative humidity above 80%, it may cause a formation of
condensation and a leakage of water on the floor.
Operation Features
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 12 2016-10-27 오전 10:47:49

Cleaning and Maintenance
13
English
Cleaning and Maintenance
Cleaning and Maintaining
Cleaning the indoor unit exterior
1WAY Wipe the surface of the unit with a slightly wet
or dry cloth when needed. Wipe off dirt of odd-
shaped areas by using a soft brush.
CAUTION
• Do not use alkaline detergent, sulphuric
acid, hydrochloric acid, or organic solvents
(such as thinner, kerosene, and acetone) to
clean the surfaces.
• Do not attach any stickers on the surfaces
because this may cause damage.
• When you clean the heat exchanger on the
indoor unit, you need to disassemble the
indoor unit. Therefore, you must contact the
local service center for help.
4WAY
Cleaning the outdoor unit heat exchanger
Spray water to clean the dust.
NOTE
• When you clean and inspect the heat
exchanger on the outdoor unit, contact the
local service center for help.
• Make sure to prevent any injury from sharp
edges of the surface when handling the heat
exchanger.
Cleaning and Maintenance
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 13 2016-10-27 오전 10:47:49

Cleaning and Maintenance
14 English
Cleaning and MaintainingCleaning and Maintaining
Cleaning and Maintenance
Cleaning the air filter
CAUTION
• Before cleaning, be sure to turn off the product and remove the power plug.
• Be sure to hold the grille with a hand to prevent dropping from the opening of the front grille.
1 WAY
1 Detaching the air filter
PC1NUSMAN
PUSH
Press the Push signs on the front panel, then
open the grille.
Grab the handle of the air filter and lift it
upward while pushing the handle slightly.
Pull out the air filter from the indoor unit.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 14 2016-10-27 오전 10:47:49

Cleaning and Maintenance
15
English
Cleaning and Maintenance
PC1NUPMAN
Insert a driver at the marked points and open
the front grille.
Press the Push signs on the air filter.
Grab the handle of the air filter and pull it out
from the indoor unit.
PC1NWSMAN
Insert your hand into the front grille and pull
out the front grille to open it.
Press the Push signs on the air filter.
Grab the handle of the air filter and pull it out
from the indoor unit.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 15 2016-10-27 오전 10:47:50

Cleaning and Maintenance
16 English
Cleaning and MaintainingCleaning and Maintaining
Cleaning and Maintenance
2 Cleaning the air filter
Clean the air filter with a vacuum cleaner or soft
brush. If dust is too heavy, then rinse it with
running water and dry it in a ventilated area.
CAUTION
Do not scrub the air filter with a brush or other
cleaning utensil. This may damage the filter.
NOTE
• If the air filter dries in a humid area, it may
produce offensive odours. Clean it again and
dry it in a well-ventilated area.
• The cleaning period may differ depending
on the usage and environmental conditions,
so clean the air filter every week if the air
conditioner is in the dusty area.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 16 2016-10-27 오전 10:47:50

Cleaning and Maintenance
17
English
Cleaning and Maintenance
3 Reassembling the air filter
CAUTION
• If the indoor unit is used without the air filter,
it may be damaged due to dust.
4 Resetting the air filter
After cleaning and reassembling the air filter,
be sure to reset the filter-cleaning reminder as
follows:
• Indoor unit with the wired remote control:
Press the Filter Reset button.
• Indoor unit with the wired remote control:
Press the Setting button → < or > → (Filter
Reset) Blinking → press the Set button.
NOTE
• Be sure to reset the filter-cleaning reminder
every time you clean the air filter although
the filter reset indicator ( ) does not blink.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 17 2016-10-27 오전 10:47:51

Cleaning and Maintenance
18 English
Cleaning and MaintainingCleaning and Maintaining
Cleaning and Maintenance
4 WAY
1 Detaching the air filter
Open the air flow blades on both sides of
the front grille, then open the front grille by
pushing the two push-buttons.
NOTE
• The push-buttons are located on both sides
of the front grill with the Samsung logo.
• You can find the buttons by opening the air
flow blades with your hands.
Pull out the air filter from the indoor unit.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 18 2016-10-27 오전 10:47:51

Cleaning and Maintenance
19
English
Cleaning and Maintenance
2 Cleaning the air filter
Clean the air filter with a vacuum cleaner or soft
brush. If dust is too heavy, then rinse it with
running water and dry it in a ventilated area.
CAUTION
Do not scrub the air filter with a brush or other
cleaning utensil. This may damage the filter.
NOTE
• If the air filter dries in a humid area, it may
produce offensive odours. Clean it again and
dry it in a well-ventilated area.
• The cleaning period may differ depending on
the usage and environmental conditions, so
clean the air filter every week if the indoor
unit is in the dusty area.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 19 2016-10-27 오전 10:47:51

Cleaning and Maintenance
20 English
Cleaning and MaintainingCleaning and Maintaining
Cleaning and Maintenance
3 Reassembling the air filter
CAUTION
• If the indoor unit is used without the air filter,
the indoor unit may be damaged due to dust.
4 Resetting the air filter
After cleaning and reassembling the air filter, be
sure to reset the filter-cleaning reminder as follows:
• Indoor unit with the wired remote control:
Press the Filter Reset button.
• Indoor unit with the wired remote control:
Press the Setting button → < or > → (Filter
Reset) Blinking → press the Set button.
NOTE
• The filter reset indicator blinks when the air
filter should be cleaned.
• If the angle of the air flow blade is changed
by opening the front grille for installation
or maintenance of the indoor unit, be sure
to turn off and then on the auxiliary switch
before operating the indoor unit again. If
not, the angle of the air flow blade may be
changed and the blades may not be closed
after turning off the indoor unit.
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 20 2016-10-27 오전 10:47:52

Cleaning and Maintenance
21
English
Cleaning and Maintenance
Periodical maintenance
Unit Maintenance item Interval Requires qualified
technicians
Indoor
unit
Clean the air filter. At least once a month
Clean the condensate drain pan. Once a year Required
Clean up the heat exchange. Once a year Required
Clean the condensate drain pipe. Once every 4 months Required
Replace the remote control batteries. At least once a year
Outdoor
unit
Clean the heat exchanger on the
outside of the unit. Once every 4 months Required
Clean the heat exchanger on the
inside of the unit. Once a year Required
Clean the electric components with
jets of air. Once a year Required
Verify that all the electric
components are firmly tightened. Once a year Required
Clean the fan. Once a year Required
Verify that the fan assemblies are
firmly tightened. Once a year Required
Clean the condensate drain pan. Once a year Required
CAC_구주Universal 1,4way실내기_IB_DB68-06394A-00_EN-1.indd 21 2016-10-27 오전 10:47:52
