Samsung AM JXVHGH EU Series Instruction manual

95)
Technical Data Book
'9062XWGRRUXQLW for Europe (/D\HU+]+3+5)
Model : H/P High EER type (AM***JXVHGH*EU, AM*** HXVAGH/EU)
H/P Standard type (AM***JXVAGH*EU, AM*** HXVAGH/EU)
H/R High EER type (AM***JXVHGR*EU)

Version Modification Date Remark
Ver.1.0 Released DVM S(2 Layer) TDB 15.05.22
History
2
Ver.1.1 Modified the size of pipe connections in Specification (for 24HP) 15.06.02
Ver.1.2 Add Note information in Specification regarding EU F-Gas regulation 15.06.16
Ver.1.3 Added ODU combination models (H/P - High EER type)
- Model added : 24HP*, 26HP*, 40HP* 15.09.03
- Combination changed : 60HP
Ver.1.4 Modify the specification of MCA and MFA 16.03.28
Ver.1.5 Modify the specification of ODU(8HP,10HP,12HP) weight 16.04.06
Ver.1.6 16.09.02
Modify 1) Installation Max. Height 110(40) →110(110) (P13~50)
2) AM380JXVHGH1EU MFA 900.00 → 90.0 (P17)
3) AM030JXVHGR/EU MCA 18.5 → 18.0 (P41)
4) AM380JXVHHRG1EU MFA 900.00 → 90.0 (P44)
5) Installation Max. Height & Note (P99,100)
6) MCA & MFA Table (P102~106)
Ver.1.7 16.11.14
Modification for the specification - Net/Shipping weight
: AM140JXVHGH/EU 235kg → 231kg (Net), 254kg → 250kg (Shipping)
AM160JXVHGH/EU 266kg → 262kg (Net), 285kg → 281kg (Shipping)
AM180JXVHGH/EU, AM200JXVHGH/EU, AM220JXVHGH/EU
300kg → 296kg (Net), 319kg → 315kg (Shipping)
AM240HXVAGH/EU, AM260HXVAGH/EU
360kg → 356kg (Net), 375kg → 371kg (Shipping)
AM140JXVHGR/EU 241kg → 237kg (Net), 260kg → 256kg (Shipping)
AM160JXVHGR/EU 272kg → 268kg (Net), 291kg → 287kg (Shipping)
AM180JXVHGR/EU, AM200JXVHGH/EU, AM220JXVHGR/EU
306kg → 302kg (Net), 325kg → 321kg (Shipping)

Nomenclature
Outdoor Units
Model Names
AM
(1)
080
(2)
J
(3)
X
(4)
V
(5)
A
(6)
G
(7)
H
(8)
EU
Buyer
(1) Classification
AM VRF
(2) Capacity
x 1/10 HP (3 digits)
(3) Version
F 2013
H 2014
J 2015
(4) Product Type
X Outdoor Unit
N Indoor Unit
(5) Feature1
V Inverter
M DVM S Eco
(6) Feature2
A Standard
H High EER
(7) Rating Voltage
E 1Ø, 220~240V, 50Hz
G 3Ø, 380~415V, 50Hz
(8) Mode
H Heat Pump
R Heat Recovery
3

Classification Product Image Model Remark
DMS 2.0 MIM-D00AN -
S-NET 3 MST-P3P -
PIM MIM-B16N -
BACnet Gateway MIM-B17N -
LonWorks Gateway MIM-B18N -
On/Off controller MCM-A202DN -
Touch controller MCM-A300N -
Wireless remote
controller MR-EH00 -
MWR-WE10N
(Multi function) A/C+VTL
MWR-WW00N DVM S Hydro Unit
MWR-SH00N -
MWR-VH02 ERV
Operation mode
selection switch MCM-C200 DVM S Series (Except HR Models)
External room sensor MRW-TA Cassette, Wall-mount,
Ceiling, Duct, Console
Compatible interface
module MIM-N01 Nasa-No Nasa
ERV interface module MIM-N10 ERV (Nasa)
External contact
interface module MIM-B14 -
S-Converter MIM-C02N -
MTFC
(Multi tenant function
controller)
MCM-C210N -
Wireless signal
receiver MRK-A10N -
Integrated
Management
System
Building
Management
System
Centralized
Control
System
Individual Control
System
Others
Wired remote
controller
Simplified wired
remote controller
Accessory
4

Product Image Model Remark
MXJ-YA1509M 15.0 kW and below
MXJ-YA2512M Over 15.0 kW~40.0 kW and below
MXJ-YA2812M Over 40.0 kW~45.0 kW and below
MXJ-YA2815M Over 45.0 kW~70.3 kW and below
MXJ-YA3419M Over 70.3 kW~98.4 kW and below
MXJ-YA4119M Over 98.4 kW~135.2 kW and below
MXJ-YA4422M Over 135.2 kW
MXJ-YA1500M 22.4 kW and below
MXJ-YA2500M Over 22.4 kW~70.3 kW and below
MXJ-YA3100M Over 70.3 kW~135.2 kW and below
MXJ-YA3800M Over 135.2 kW
MXJ-TA3419M 135.2 kW and below
MXJ-TA4122M 140.2 kW and Over
MXJ-TA3100M 135.2 kW and below
MXJ-TA3800M 140.2 kW and Over
MXJ-HA2512M 45.0 kW and below (for 4 rooms)
MXJ-HA3115M 70.3 kW and below (for 8 rooms)
MXJ-HA3819M Over 70.3 kW~135.2 kW and
below(for 8 rooms)
MCU-S6NEE1N ~56kW, ~6 indoor units
MCU-S4NEE1N ~56kW, ~4 indoor units
MCU-S4NEE2N 56kW, ~2 indoor units(each indoor unit for 11.2kW~28kW)
MEV-E24SA
MEV-E32SA
MXD-E24K132A
MXD-E24K200A
MXD-E32K200A
MXD-E24K232A
MXD-E24K300A
MXD-E32K224A
MXD-E32K300A
MXD-K025AN 7.0kW~8.75kW
MXD-K050AN 14.0kW~17.5kW
MXD-K075AN 21.0kW~26.25kW
MXD-K100AN 28.0kW~35.0kW
MCM-D201N 28kW~35kW / 56kW~70kW / 84kW~105kW / 112kW~140kW
1 Indoor
2 Indoor
3 Indoor
AHU KIT
EEV KIT
Y-Joint
Y-Joint
Outdoor unit
Distribution
Header
Y-Joint (Only H/R)
Y-Joint (Only H/R)
Outdoor unit
MCU
Accessory
5

Product Image Model Remark
MXD-A38K2A 8~12HP
MXD-A12K2A 14~16HP
MXD-A58K2A 18~26HP
MSD-CAN1 4Way Cassette S
4Way Cassette S(600x600)
MSD-EAN1 ERV-Plus
Motion detect
Sensor
MCR-SMA 4Way Cassette S (600x600)
ERV CO2 Sensor
MOS-C1 ERV, ERV PLUS
MDP-N047SNC0D OAP Duct (14.0 kW)
MDP-N047SNC1D HSP Duct (22.0 / 28.0 kW)
OAP Duct (22.4 / 28.0 kW)
MDP-M075SGU1D MSP Duct (9.0 / 11.2 kW)
MDP-M075SGU2D MSP Duct (12.8 / 14.0 kW)
HSP Duct (11.2 / 12.8 / 14.0 kW)
MDP-M075SGU3D MSP Duct (5.6 / 7.1 kW)
MDP-E075SEE3D Slim Duct (2.0~14.0 kW)
MDP-G075SP Duct S (External, All Capacities)
MDP-G075SQ Duct S (Internal, 3.5 kW~14 kW)
PC1NUSMAN Slim 1Way Cassette
PC1NUPMAN Slim 1Way Cassette (Z-sliding)
PC1MWSKAN 1Way Cassette (1.7 kW, 2.2 kW)
PC2NUSMEN 2Way cassette
PC4SUSMAN 4Way Cassette S(600x600) (Waffle)
PC4SUSMEN 4Way Cassette S(600x600) (Classic)
PC4NUSKAN 4 Way cassette S (Waffle)
PC4NUSKEN 4 Way cassette S (Classic)
PC4NBSKAN 4 Way cassette S (Waffle, Black)
Panel
PDM KIT
S-Plasma Ion KIT
Drain Pump
Accessory
6

Outdoor
1 Line-up
2 Specifications
3 Operation limit
4 Dimensional drawing
5 Electrical wiring diagram
6 Sound pressure level
7 Sound power level
8 Cycle diagram
,QVWDOODWLRQ
7

8HP 10HP 12HP 14HP 16HP 18HP 20HP 22HP 24HP 26HP
AM080JXVH
GH/EU
AM100JXVH
GH/EU
AM120JXVH
GH/EU
AM140JXVH
GH/EU
AM160JXVH
GH/EU
AM180JXVH
GH/EU
AM200JXVH
GH/EU
AM220JXVH
GH/EU
AM240HXV
AGH/EU
AM260HXV
AGH/EU
8HP -11
10HP -11
12HP -11
14HP -11
16HP -1 1
18HP -1 1
20HP -1 1
22HP -1 1
24HP -1 1
26HP -1 1
24HP* AM240JXVHGH1EU* 22
26HP* AM260JXVHGH1EU* 211
28HP AM280JXVHGH1EU 211
30HP AM300JXVHGH1EU 211
32HP AM320JXVHGH1EU 21 1
34HP AM340JXVHGH1EU 21 1
36HP AM360JXVHGH1EU 211
38HP AM380JXVHGH1EU 211
40HP AM400JXVHGH1EU 21 1
40HP* AM400JXVHGH1EU* 2 2
42HP AM420JXVHGH1EU 211
44HP AM440JXVHGH1EU 2 2
46HP AM460JXVHGH1EU 32 1
48HP AM480JXVHGH1EU 311 1
50HP AM500JXVHGH1EU 3111
52HP AM520JXVHGH1EU 3111
54HP AM540JXVHGH1EU 31 11
56HP AM560JXVHGH1EU 31 2
58HP AM580JXVHGH1EU 312
60HP AM600JXVHGH1EU 312
62HP AM620JXVHGH1EU 321
64HP AM640JXVHGH1EU 312
66HP AM660JXVHGH1EU 3 3
68HP AM680JXVHGH1EU 42 2
70HP AM700JXVHGH1EU 411 2
72HP AM720JXVHGH1EU 4112
74HP AM740JXVHGH1EU 4112
76HP AM760JXVHGH1EU 41 12
78HP AM780JXVHGH1EU 41 3
80HP AM800JXVHGH1EU 413
System Model Outdoor Unit Selection
Capacity Number of
Modules
System Model Code
1
L
11
/LQHXS
+HDW3XPSHigh EER type
8
$0a-;9+*+(82XWGRRU8QLWFRPELQDWLRQKDVEHHQDGGHG

8HP 10HP 12HP 14HP 16HP 18HP 20HP 22HP 24HP 26HP
AM080JXVH
GH/EU
AM100JXVH
GH/EU
AM120JXVH
GH/EU
AM140JXVH
GH/EU
AM160JXVH
GH/EU
AM180JXVH
GH/EU
AM200JXVH
GH/EU
AM220JXVH
GH/EU
AM240HXV
AGH/EU
AM260HXV
AGH/EU
36HP AM360JXVHGH2EU 21 1
38HP AM380JXVHGH2EU 21 1
46HP AM460JXVHGH2EU 211
48HP AM480JXVHGH2EU 211
50HP AM500JXVHGH2EU 211
52HP AM520JXVHGH2EU 2 2
58HP AM580JXVHGH2EU 31 11
60HP AM600JXVHGH2EU 31 11
62HP AM620JXVHGH2EU 31 11
64HP AM640JXVHGH2EU 31 2
68HP AM680JXVHGH2EU 321
70HP AM700JXVHGH2EU 321
72HP AM720JXVHGH2EU 3111
74HP AM740JXVHGH2EU 312
76HP AM760JXVHGH2EU 312
78HP AM780JXVHGH2EU 3 3
Capacity System Model Code Number of
Modules
System Model Outdoor Unit Selection
1
L
11
/LQHXS
+HDW3XPSHigh EER type (Compact)
9

8HP 10HP 12HP 14HP 16HP 18HP 20HP 22HP 24HP 26HP
AM080JXVA
GH/EU
AM100JXVA
GH/EU
AM120JXVA
GH/EU
AM140JXVA
GH/EU
AM160JXVA
GH/EU
AM180JXVA
GH/EU
AM200JXVA
GH/EU
AM220JXVA
GH/EU
AM240HXV
AGH/EU
AM260HXV
AGH/EU
8HP -11
10HP -11
12HP -11
14HP -11
16HP -1 1
18HP -1 1
20HP -1 1
22HP -1 1
24HP -1 1
26HP -1 1
28HP AM280JXVAGH1EU 211
30HP AM300JXVAGH1EU 211
32HP AM320JXVAGH1EU 21 1
34HP AM340JXVAGH1EU 21 1
36HP AM360JXVAGH1EU 211
38HP AM380JXVAGH1EU 211
40HP AM400JXVAGH1EU 21 1
42HP AM420JXVAGH1EU 211
44HP AM440JXVAGH1EU 2 2
46HP AM460JXVAGH1EU 32 1
48HP AM480JXVAGH1EU 311 1
50HP AM500JXVAGH1EU 3111
52HP AM520JXVAGH1EU 3111
54HP AM540JXVAGH1EU 31 11
56HP AM560JXVAGH1EU 31 2
58HP AM580JXVAGH1EU 312
60HP AM600JXVAGH1EU 312
62HP AM620JXVAGH1EU 312
64HP AM640JXVAGH1EU 312
66HP AM660JXVAGH1EU 3 3
68HP AM680JXVAGH1EU 42 2
70HP AM700JXVAGH1EU 411 2
72HP AM720JXVAGH1EU 4112
74HP AM740JXVAGH1EU 4112
76HP AM760JXVAGH1EU 41 12
78HP AM780JXVAGH1EU 41 3
80HP AM800JXVAGH1EU 413
Outdoor Unit SelectionSystem Model
Number of
Modules
System Model CodeCapacity
1
L
11
/LQHXS
+HDW3XPSStandard type
10

8HP 10HP 12HP 14HP 16HP 18HP 20HP 22HP 24HP 26HP
AM080JXVA
GH/EU
AM100JXVA
GH/EU
AM120JXVA
GH/EU
AM140JXVA
GH/EU
AM160JXVA
GH/EU
AM180JXVA
GH/EU
AM200JXVA
GH/EU
AM220JXVA
GH/EU
AM240HXV
AGH/EU
AM260HXV
AGH/EU
36HP AM360JXVAGH2EU 21 1
38HP AM380JXVAGH2EU 21 1
46HP AM460JXVAGH2EU 211
48HP AM480JXVAGH2EU 211
50HP AM500JXVAGH2EU 211
52HP AM520JXVAGH2EU 2 2
58HP AM580JXVAGH2EU 31 11
60HP AM600JXVAGH2EU 31 11
62HP AM620JXVAGH2EU 31 11
64HP AM640JXVAGH2EU 31 2
68HP AM680JXVAGH2EU 321
70HP AM700JXVAGH2EU 321
72HP AM720JXVAGH2EU 3111
74HP AM740JXVAGH2EU 312
76HP AM760JXVAGH2EU 312
78HP AM780JXVAGH2EU 3 3
Capacity System Model Code Number of
Modules
System Model Outdoor Unit Selection
1
L
11
/LQHXS
+HDW3XPSStandard type (Compact)
1X

8HP 10HP 12HP 14HP 16HP 18HP 20HP 22HP
AM080JXVH
GR/EU
AM100JXVH
GR/EU
AM120JXVH
GR/EU
AM140JXVH
GR/EU
AM160JXVH
GR/EU
AM180JXVH
GR/EU
AM200JXVH
GR/EU
AM220JXVH
GR/EU
8HP -11
10HP -11
12HP -11
14HP -11
16HP -1 1
18HP -1 1
20HP -1 1
22HP -1 1
24HP AM240JXVHGR1EU 22
26HP AM260JXVHGR1EU 211
28HP AM280JXVHGR1EU 211
30HP AM300JXVHGR1EU 211
32HP AM320JXVHGR1EU 21 1
34HP AM340JXVHGR1EU 21 1
36HP AM360JXVHGR1EU 211
38HP AM380JXVHGR1EU 211
40HP AM400JXVHGR1EU 2 2
42HP AM420JXVHGR1EU 211
44HP AM440JXVHGR1EU 2 2
46HP AM460JXVHGR1EU 32 1
48HP AM480JXVHGR1EU 311 1
50HP AM500JXVHGR1EU 3111
52HP AM520JXVHGR1EU 3111
54HP AM540JXVHGR1EU 31 11
56HP AM560JXVHGR1EU 31 2
58HP AM580JXVHGR1EU 312
60HP AM600JXVHGR1EU 312
62HP AM620JXVHGR1EU 321
64HP AM640JXVHGR1EU 312
66HP AM660JXVHGR1EU 3 3
68HP AM680JXVHGR1EU 42 2
70HP AM700JXVHGR1EU 411 2
72HP AM720JXVHGR1EU 4112
74HP AM740JXVHGR1EU 4112
76HP AM760JXVHGR1EU 41 12
78HP AM780JXVHGR1EU 41 3
80HP AM800JXVHGR1EU 413
System Model Outdoor Unit Selection
Capacity System Model Code Number of
Modules
1
L
11
/LQHXS
+HDWRecoveryHigh EER type
12

Specifications
Outdoor
Type
Model Name
Power Supply Ø, #, V, Hz
Mode -
Performance
HP HP
Capacity
(Nominal)
Cooling kW
Btu/h
Heating kW
Btu/h
Power
Power Input
(Nominal)
Cooling 1) kW
Heating 2) kW
Current
Input
(Nominal)
Cooling 1) A
Heating 2) A
MCA A
MFA A
COP
EER (Nominal Cooling) -
COP (Nominal Heating) -
Energy Grade -
-
Compressor
Type -
Output kW x n
Model Name -
Oil Type -
Fan
Type -
Output x n W
Air Flow Rate
CMM
l/s
External
Static Max. mmAQ
Pa
Piping
Connections
Liquid Pipe Ø, mm
Ø, inch
Gas Pipe Ø, mm
Ø, inch
Discharge Gas Pipe Ø, mm
Ø, inch
Installation
Limitation
Max. Length m
Max. Height m
Field Wiring Power Source Wire mm²
Transmission Cable mm²
Refrigerant Type -
Factory Charging kg
Sound Pressure dBA
Power
External
Dimension
Net Weight kg
Shipping Weight kg
Net Dimensions (WxHxD) mm
Shipping Dimensions
(WxHxD) mm
Operating
Temp.
Cooling ºC
Heating ºC
DVM S(NEW) DVM S(NEW) DVM S(NEW) DVM S(NEW)
AM080JXVHGH/EU AM100JXVHGH/EU AM120JXVHGH/EU AM140JXVHGH/EU
3,4,380-415,50 3,4,380-415,50 3,4,380-415,50 3,4,380-415,50
HP HP HP HP
8.00 10.00 12.00 14.00
22.40 28.00 33.60 40.00
76,400 95,500 114,600 136,500
25.20 31.50 37.80 45.00
86,000 107,500 129,000 153,500
4.59 6.22 7.57 10.55
4.59 5.89 7.56 9.72
7.40 10.00 12.10 16.90
7.40 9.40 12.10 15.60
18.00 21.10 25.00 25.00
25.00 32.00 32.00 32.00
4.88 4.50 4.44 3.79
5.49 5.35 5.00 4.63
ESEER 8.00 ESEER 7.43 ESEER 7.23 ESEER 7.12
----
SSC Scroll x 1 SSC Scroll x 1 SSC Scroll x 1 SSC Scroll x 1
(5.18) (6.39) (6.39) (6.39)
DS-GB052FAVBSGx1 DS-GB066FAVBSGx1 DS-GB066FAVBSGx1 DS-GB066FAVBSGx1
PVE PVE PVE PVE
Propeller Propeller Propeller Propeller
830.0 830.0 830.0 620.0x2
170 170 220 255
2,833.3 2,833.3 3,666.7 4,250.0
8.00 8.00 8.00 8.00
78.40 78.40 78.40 78.40
9.52 9.52 12.70 12.70
3/8" 3/8" 1/2" 1/2"
19.05 22.22 28.58 28.58
3/4" 7/8" 1 1/8" 1 1/8"
----
----
200 (220) 200 (220) 200 (220) 200 (220)
110 (110) 110 (110) 110 (110) 110 (110)
----
0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
R410A R410A R410A R410A
6.50 6.50 6.50 7.70
57.00 58.00 62.00 61.00
77.00 79.00 81.00 81.00
195.5 195.5 195.5 231.0
211.5 211.5 211.5 250.0
880x1,695x765 880x1,695x765 880x1,695x765 1,295x1,695x765
948x1,887x832 948x1,887x832 948x1,887x832 1,363x1,887x832
-5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0
-25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0
* Specifications may be subject to change without prior notice.
1) Nominal cooling capacities are based on;
- Indoor temperature : 27°C DB, 19°C WB
- Outdoor temperature : 35°C DB, 24°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
2) Nominal heating capacities are based on;
- Indoor temperature : 20°C DB, 15°C WB
- Outdoor temperature : 7°C DB, 6°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
3) Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the installation conditions.
4) These products contain R410A which is fluorinated greenhouse gas.
5) If outdoor unit is located in a higher position than indoor unit, level difference is 110m or under.
(If the level difference is higher than 50m, make a decision by PDM kit installation Guide software whether the PDM kit should be installed or not.)
When the outdoor unit is below the indoor unit & the level differences are 40m or more, contact your local dealer for more information.
*PDM kit: Pressure Drop Modulation kit
2
: H/P - High EER type
13

Specifications
Outdoor
Type
Model Name
Power Supply Ø, #, V, Hz
Mode -
Performance
HP HP
Capacity
(Nominal)
Cooling kW
Btu/h
Heating kW
Btu/h
Power
Power Input
(Nominal)
Cooling 1) kW
Heating 2) kW
Current
Input
(Nominal)
Cooling 1) A
Heating 2) A
MCA A
MFA A
COP
EER (Nominal Cooling) -
COP (Nominal Heating) -
Energy Grade -
-
Compressor
Type -
Output kW x n
Model Name -
Oil Type -
Fan
Type -
Output x n W
Air Flow Rate
CMM
l/s
External
Static Max. mmAQ
Pa
Piping
Connections
Liquid Pipe Ø, mm
Ø, inch
Gas Pipe Ø, mm
Ø, inch
Discharge Gas Pipe Ø, mm
Ø, inch
Installation
Limitation
Max. Length m
Max. Height m
Field Wiring Power Source Wire mm²
Transmission Cable mm²
Refrigerant Type -
Factory Charging kg
Sound Pressure dBA
Power
External
Dimension
Net Weight kg
Shipping Weight kg
Net Dimensions (WxHxD) mm
Shipping Dimensions
(WxHxD) mm
Operating
Temp.
Cooling ºC
Heating ºC
DVM S(NEW) DVM S(NEW) DVM S(NEW) DVM S(NEW)
AM160JXVHGH/EU AM180JXVHGH/EU AM200JXVHGH/EU AM220JXVHGH/EU
3,4,380-415,50 3,4,380-415,50 3,4,380-415,50 3,4,380-415,50
HP HP HP HP
16.00 18.00 20.00 22.00
45.00 50.40 56.00 61.60
153,500 172,000 191,100 210,200
50.40 56.70 63.00 69.30
172,000 193,500 215,000 236,500
10.92 11.51 13.05 15.75
10.75 11.62 13.10 15.86
17.50 18.50 20.90 25.30
17.20 18.60 21.00 25.40
32.00 39.1042.5044.50
40.00 50.00 63.00 63.00
4.12 4.38 4.29 3.91
4.69 4.88 4.81 4.37
ESEER 6.82 ESEER 6.71 ESEER 6.66 ESEER 6.32
----
SSC Scroll x 2 SSC Scroll x 2 SSC Scroll x 2 SSC Scroll x 2
(4.39 x 2) (6.39 x 2) (6.39 x 2) (6.39 x 2)
DS-GA046FAVASGx2 DS-GB066FAVBSGx2 DS-GB066FAVBSGx2 DS-GB066FAVBSGx2
PVE PVE PVE PVE
Propeller Propeller Propeller Propeller
620.0x2 620.0x2 620.0x2 620.0x2
255 290 290 290
4,250.0 4,833.3 4,833.3 4,833.3
8.00 8.00 8.00 8.00
78.40 78.40 78.40 78.40
12.70 15.88 15.88 15.88
1/2" 5/8" 5/8" 5/8"
28.58 28.58 28.58 28.58
1 1/8" 1 1/8" 1 1/8" 1 1/8"
----
----
200 (220) 200 (220) 200 (220) 200 (220)
110 (110) 110 (110) 110 (110) 110 (110)
----
0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
R410A R410A R410A R410A
7.70 8.40 8.40 8.40
62.00 63.00 64.00 65.00
82.00 85.00 86.00 88.00
262.0 296.0 296.0 296.0
281.0 315.0 315.0 315.0
1,295x1,695x765 1,295x1,695x765 1,295x1,695x765 1,295x1,695x765
1,363x1,887x832 1,363x1,887x832 1,363x1,887x832 1,363x1,887x832
-5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0
-25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0
* Specifications may be subject to change without prior notice.
Nominal cooling capacities are based on;
2
: H/P - High EER type
14
1)
- Indoor temperature : 27°C DB, 19°C WB
Nominal heating capacities are based on;
- Outdoor temperature : 35°C DB, 24°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
2)
- Indoor temperature : 20°C DB, 15°C WB
Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the installation conditions.
These products contain R410A which is fluorinated greenhouse gas.
- Outdoor temperature : 7°C DB, 6°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
3)
4)
If outdoor unit is located in a higher position than indoor unit, level difference is 110m or under.5)
(If the level difference is higher than 50m, make a decision by PDM kit installation Guide software whether the PDM kit should be installed or not.)
When the outdoor unit is below the indoor unit & the level differences are 40m or more, contact your local dealer for more information.
*PDM kit: Pressure Drop Modulation kit

Specifications
Outdoor
Type
Model Name
Power Supply Ø, #, V, Hz
Mode -
Performance
HP HP
Capacity
(Nominal)
Cooling kW
Btu/h
Heating kW
Btu/h
Power
Power Input
(Nominal)
Cooling 1) kW
Heating 2) kW
Current
Input
(Nominal)
Cooling 1) A
Heating 2) A
MCA A
MFA A
COP
EER (Nominal Cooling) -
COP (Nominal Heating) -
Energy Grade -
-
Compressor
Type -
Output kW x n
Model Name -
Oil Type -
Fan
Type -
Output x n W
Air Flow Rate
CMM
l/s
External
Static Max. mmAQ
Pa
Piping
Connections
Liquid Pipe Ø, mm
Ø, inch
Gas Pipe Ø, mm
Ø, inch
Discharge Gas Pipe Ø, mm
Ø, inch
Installation
Limitation
Max. Length m
Max. Height m
Field Wiring Power Source Wire mm²
Transmission Cable mm²
Refrigerant Type -
Factory Charging kg
Sound Pressure dBA
Power
External
Dimension
Net Weight kg
Shipping Weight kg
Net Dimensions (WxHxD) mm
Shipping Dimensions
(WxHxD) mm
Operating
Temp.
Cooling ºC
Heating ºC
DVM S(NEW) DVM S(NEW) DVM S(NEW) DVM S(NEW)
AM240HXVAGH/EU AM240JXVHGH1EU* AM260HXVAGH/EU AM260JXVHGH1EU*
3,4,380-415,50 3,4,380-415,50 3,4,380-415,50 3,4,380-415,50
HP HP HP HP
24.00 24.00 26.00 26.00
67.20 67.20 72.80 73.60
229,300 229,300 248,400 251,100
75.60 75.60 81.90 82.80
258,000 258,000 279,500 282,500
17.10 15.14 19.30 18.12
19.80 15.12 21.80 17.28
26.83 24.20 30.28 29.00
31.06 24.20 34.20 27.70
55.00 50.00 58.00 50.00
63.00 63.00 63.00 63.00
3.93 4.44 3.77 4.06
3.82 5.00 3.76 4.79
ESEER 6.48 ESEER 7.23 ESEER 6.26 ESEER 7.17
----
SSC Scroll x 2 SSC Scroll x 2 SSC Scroll x 2 SSC Scroll x 2
(6.39 x 2) (6.39)x2 (6.76 x 2) (6.39) + (6.39)
DS-GB066FAVBSGx2 DS-GB066FAVBSGx2 DS-GB070FAVASGx2 DS-GB066FAVBSGx2
PVE PVE PVE PVE
Propeller Propeller Propeller Propeller
620.0x2 (830.0)x2 620.0x2 830.0 + 620.0x2
310 220.0x2 310 220.0 + 255.0
5,166.7 3,666.7x2 5,166.7 3,666.7 + 4,250.0
8.00 8.00 8.00 8.00
78.40 78.40 78.40 78.40
15.88 15.88 19.05 19.05
5/8" 5/8" 3/4" 3/4"
34.92 34.92 34.92 34.92
1 3/8" 1 3/8" 1 3/8" 1 3/8"
----
----
200 (220) 200 (220) 200 (220) 200 (220)
110 (110) 110 (110) 110 (110) 110 (110)
----
0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
R410A R410A R410A R410A
14.30 13.00 14.30 14.20
67.00 65.00 67.00 65.00
91.00 84.00 91.00 84.00
356.0 195.5x2 356.0 195.5 + 231.0
371.0 211.5x2 371.0 211.5 + 250.0
1,295x1,695x765 (880x1,695x765)x2 1,295x1,695x765 880x1,695x765 +
1,295x1,695x765
1,363x1,887x832 (948x1,887x832)x2 1,363x1,887x832 948x1,887x832 +
1,363x1,887x832
-5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0
-25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0
* Specifications may be subject to change without prior notice.
Nominal cooling capacities are based on;
2
: H/P - High EER type
15
1)
- Indoor temperature : 27°C DB, 19°C WB
Nominal heating capacities are based on;
- Outdoor temperature : 35°C DB, 24°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
2)
- Indoor temperature : 20°C DB, 15°C WB
Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the installation conditions.
These products contain R410A which is fluorinated greenhouse gas.
- Outdoor temperature : 7°C DB, 6°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
3)
4)
If outdoor unit is located in a higher position than indoor unit, level difference is 110m or under.5)
(If the level difference is higher than 50m, make a decision by PDM kit installation Guide software whether the PDM kit should be installed or not.)
When the outdoor unit is below the indoor unit & the level differences are 40m or more, contact your local dealer for more information.
*PDM kit: Pressure Drop Modulation kit

Specifications
Outdoor
Type
Model Name
Power Supply Ø, #, V, Hz
Mode -
Performance
HP HP
Capacity
(Nominal)
Cooling kW
Btu/h
Heating kW
Btu/h
Power
Power Input
(Nominal)
Cooling 1) kW
Heating 2) kW
Current
Input
(Nominal)
Cooling 1) A
Heating 2) A
MCA A
MFA A
COP
EER (Nominal Cooling) -
COP (Nominal Heating) -
Energy Grade -
-
Compressor
Type -
Output kW x n
Model Name -
Oil Type -
Fan
Type -
Output x n W
Air Flow Rate
CMM
l/s
External
Static Max. mmAQ
Pa
Piping
Connections
Liquid Pipe Ø, mm
Ø, inch
Gas Pipe Ø, mm
Ø, inch
Discharge Gas Pipe Ø, mm
Ø, inch
Installation
Limitation
Max. Length m
Max. Height m
Field Wiring Power Source Wire mm²
Transmission Cable mm²
Refrigerant Type -
Factory Charging kg
Sound Pressure dBA
Power
External
Dimension
Net Weight kg
Shipping Weight kg
Net Dimensions (WxHxD) mm
Shipping Dimensions
(WxHxD) mm
Operating
Temp.
Cooling ºC
Heating ºC
DVM S(NEW) DVM S(NEW) DVM S(NEW) DVM S(NEW)
AM280JXVHGH1EU AM300JXVHGH1EU AM320JXVHGH1EU AM340JXVHGH1EU
3,4,380-415,50 3,4,380-415,50 3,4,380-415,50 3,4,380-415,50
HP HP HP HP
28.00 30.00 32.00 34.00
78.60 84.00 89.60 95.20
268,200 286,600 305,700 324,800
88.20 94.50 100.80 107.10
301,000 322,400 343,900 365,400
18.49 19.08 20.62 23.32
18.31 19.18 20.66 23.42
29.60 30.60 33.00 37.40
29.30 30.70 33.10 37.50
57.0 64.1 67.5069.5
63.0075.0075.00 80.00
4.25 4.40 4.35 4.08
4.82 4.93 4.88 4.57
ESEER 7.00 ESEER 6.92 ESEER 6.87 ESEER 6.64
----
SSC Scroll x 3 SSC Scroll x 3 SSC Scroll x 3 SSC Scroll x 3
(6.39) + (4.39x2) (6.39) + (6.39x2) (6.39) + (6.39x2) (6.39) + (6.39x2)
DS-GB066FAVBSGx1 +
DS-GA046FAVASGx2 DS-GB066FAVBSGx3 DS-GB066FAVBSGx3 DS-GB066FAVBSGx3
PVE PVE PVE PVE
Propeller Propeller Propeller Propeller
830.0 + 620.0x2 830.0 + 620.0x2 830.0 + 620.0x2 830.0 + 620.0x2
220.0 + 255.0 220.0 + 290.0 220.0 + 290.0 220.0 + 290.0
3,666.7 + 4,250.0 3,666.7 + 4,833.3 3,666.7 + 4,833.3 3,666.7 + 4,833.3
8.00 8.00 8.00 8.00
78.40 78.40 78.40 78.40
19.05 19.05 19.05 19.05
3/4" 3/4" 3/4" 3/4"
34.92 34.92 34.92 34.92
1 3/8" 1 3/8" 1 3/8" 1 3/8"
----
----
200 (220) 200 (220) 200 (220) 200 (220)
110 (110) 110 (110) 110 (110) 110 (110)
----
0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
R410A R410A R410A R410A
14.20 14.90 14.90 14.90
65.00 66.00 66.00 67.00
85.00 86.00 87.00 89.00
195.5 + 262.0 195.5 + 296.0
211.5 + 281.0 211.5 + 315.0
880x1,695x765 +
1,295x1,695x765
880x1,695x765 +
1,295x1,695x765
880x1,695x765 +
1,295x1,695x765
880x1,695x765 +
1,295x1,695x765
948x1,887x832 +
1,363x1,887x832
948x1,887x832 +
1,363x1,887x832
948x1,887x832 +
1,363x1,887x832
948x1,887x832 +
1,363x1,887x832
-5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0
-25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0
* Specifications may be subject to change without prior notice.
Nominal cooling capacities are based on;
2
: H/P - High EER type
16
195.5 + 296.0
211.5 + 315.0
195.5 + 296.0
211.5 + 315.0
1)
- Indoor temperature : 27°C DB, 19°C WB
Nominal heating capacities are based on;
- Outdoor temperature : 35°C DB, 24°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
2)
- Indoor temperature : 20°C DB, 15°C WB
Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the installation conditions.
These products contain R410A which is fluorinated greenhouse gas.
- Outdoor temperature : 7°C DB, 6°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
3)
4)
If outdoor unit is located in a higher position than indoor unit, level difference is 110m or under.5)
(If the level difference is higher than 50m, make a decision by PDM kit installation Guide software whether the PDM kit should be installed or not.)
When the outdoor unit is below the indoor unit & the level differences are 40m or more, contact your local dealer for more information.
*PDM kit: Pressure Drop Modulation kit

Specifications
Outdoor
Type
Model Name
Power Supply Ø, #, V, Hz
Mode -
Performance
HP HP
Capacity
(Nominal)
Cooling kW
Btu/h
Heating kW
Btu/h
Power
Power Input
(Nominal)
Cooling 1) kW
Heating 2) kW
Current
Input
(Nominal)
Cooling 1) A
Heating 2) A
MCA A
MFA A
COP
EER (Nominal Cooling) -
COP (Nominal Heating) -
Energy Grade -
-
Compressor
Type -
Output kW x n
Model Name -
Oil Type -
Fan
Type -
Output x n W
Air Flow Rate
CMM
l/s
External
Static Max. mmAQ
Pa
Piping
Connections
Liquid Pipe Ø, mm
Ø, inch
Gas Pipe Ø, mm
Ø, inch
Discharge Gas Pipe Ø, mm
Ø, inch
Installation
Limitation
Max. Length m
Max. Height m
Field Wiring Power Source Wire mm²
Transmission Cable mm²
Refrigerant Type -
Factory Charging kg
Sound Pressure dBA
Power
External
Dimension
Net Weight kg
Shipping Weight kg
Net Dimensions (WxHxD) mm
Shipping Dimensions
(WxHxD) mm
Operating
Temp.
Cooling ºC
Heating ºC
DVM S(NEW) DVM S(NEW) DVM S(NEW) DVM S(NEW)
AM360JXVHGH1EU AM380JXVHGH1EU AM400JXVHGH1EU AM400JXVHGH1EU*
3,4,380-415,50 3,4,380-415,50 3,4,380-415,50 3,4,380-415,50
HP HP HP HP
36.00 38.00 40.00 40.00
101.60 106.60 112.80 112.00
346,700 363,700 384,900 382,200
114.30 119.70 126.90 126.00
390,000 408,400 433,000 429,900
26.30 26.67 29.85 26.10
25.58 26.61 31.52 26.20
42.20 42.80 47.18 41.80
41.00 42.60 49.80 42.00
69.5076.5083.0085.00
80.00 90.00 100.00 100.00
3.86 4.00 3.78 4.29
4.47 4.50 4.03 4.81
ESEER 6.63 ESEER 6.53 ESEER 6.56 ESEER 6.66
----
SSC Scroll x 3 SSC Scroll x 4 SSC Scroll x 3 SSC Scroll x 4
(6.39) + (6.39x2) (4.39x2) + (6.39x2) (6.39) + (6.76x2) (6.39x2)x2
DS-GB066FAVBSGx3 DS-GA046FAVASGx2 +
DS-GB066FAVBSGx2
DS-GB066FAVBSGx1 +
DS-GB070FAVASGx2 DS-GB066FAVBSGx4
PVE PVE PVE PVE
Propeller Propeller Propeller Propeller
(620.0x2)x2 (620.0x2)x2 (620.0x2)x2 (620.0x2)x2
255.0 + 290.0 255.0 + 290.0 255.0 + 310.0 290.0x2
4,250.0 + 4,833.3 4,250.0 + 4,833.3 4,250.0 + 5,166.7 4,833.3x2
8.00 8.00 8.00 8.00
78.40 78.40 78.40 78.40
19.05 19.05 19.05 19.05
3/4" 3/4" 3/4" 3/4"
41.28 41.28 41.28 41.28
1 5/8" 1 5/8" 1 5/8" 1 5/8"
----
----
200 (220) 200 (220) 200 (220) 200 (220)
110 (110) 110 (110) 110 (110) 110 (110)
----
0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
R410A R410A R410A R410A
16.10 16.10 22.00 16.80
66.00 67.00 68.00 67.00
89.00 89.00 91.00 89.00
231.0 + 296.0 262.0 + 296.0 231.0 + 356.0 296.0x2
250.0 + 315.0 281.0 + 315.0 250.0 + 371.0 315.0x2
(1,295x1,695x765)x2 (1,295x1,695x765)x2 (1,295x1,695x765)x2 (1,295x1,695x765)x2
(1,363x1,887x832)x2 (1,363x1,887x832)x2 (1,363x1,887x832)x2 (1,363x1,887x832)x2
-5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0
-25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0
* Specifications may be subject to change without prior notice.
Nominal cooling capacities are based on;
2
: H/P - High EER type
17
1)
- Indoor temperature : 27°C DB, 19°C WB
Nominal heating capacities are based on;
- Outdoor temperature : 35°C DB, 24°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
2)
- Indoor temperature : 20°C DB, 15°C WB
Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the installation conditions.
These products contain R410A which is fluorinated greenhouse gas.
- Outdoor temperature : 7°C DB, 6°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
3)
4)
If outdoor unit is located in a higher position than indoor unit, level difference is 110m or under.5)
(If the level difference is higher than 50m, make a decision by PDM kit installation Guide software whether the PDM kit should be installed or not.)
When the outdoor unit is below the indoor unit & the level differences are 40m or more, contact your local dealer for more information.
*PDM kit: Pressure Drop Modulation kit

Specifications
Outdoor
Type
Model Name
Power Supply Ø, #, V, Hz
Mode -
Performance
HP HP
Capacity
(Nominal)
Cooling kW
Btu/h
Heating kW
Btu/h
Power
Power Input
(Nominal)
Cooling 1) kW
Heating 2) kW
Current
Input
(Nominal)
Cooling 1) A
Heating 2) A
MCA A
MFA A
COP
EER (Nominal Cooling) -
COP (Nominal Heating) -
Energy Grade -
-
Compressor
Type -
Output kW x n
Model Name -
Oil Type -
Fan
Type -
Output x n W
Air Flow Rate
CMM
l/s
External
Static Max. mmAQ
Pa
Piping
Connections
Liquid Pipe Ø, mm
Ø, inch
Gas Pipe Ø, mm
Ø, inch
Discharge Gas Pipe Ø, mm
Ø, inch
Installation
Limitation
Max. Length m
Max. Height m
Field Wiring Power Source Wire mm²
Transmission Cable mm²
Refrigerant Type -
Factory Charging kg
Sound Pressure dBA
Power
External
Dimension
Net Weight kg
Shipping Weight kg
Net Dimensions (WxHxD) mm
Shipping Dimensions
(WxHxD) mm
Operating
Temp.
Cooling ºC
Heating ºC
DVM S(NEW) DVM S(NEW) DVM S(NEW) DVM S(NEW)
AM420JXVHGH1EU AM440JXVHGH1EU AM460JXVHGH1EU AM480JXVHGH1EU
3,4,380-415,50 3,4,380-415,50 3,4,380-415,50 3,4,380-415,50
HP HP HP HP
42.00 44.00 46.00 48.00
117.60 123.20 128.80 135.20
401,300 420,400 439,500 461,300
132.30 138.60 144.90 152.10
451,400 472,900 494,400 519,000
28.80 31.50 30.89 33.87
28.96 31.72 30.98 33.14
46.20 50.60 49.50 54.30
46.40 50.80 49.60 53.10
87.0 89.0 94.5 94.5
100.00 100.00 125.00 125.00
4.08 3.91 4.17 3.99
4.57 4.37 4.68 4.59
ESEER 6.48 ESEER 6.32 ESEER 6.79 ESEER 6.78
----
SSC Scroll x 4 SSC Scroll x 4 SSC Scroll x 4 SSC Scroll x 4
(6.39x2) + (6.39x2) (6.39x2)x2 (6.39)x2 + (6.39x2) (6.39) + (6.39) + (6.39x2)
DS-GB066FAVBSGx4 DS-GB066FAVBSGx4 DS-GB066FAVBSGx4 DS-GB066FAVBSGx4
PVE PVE PVE PVE
Propeller Propeller Propeller Propeller
(620.0x2)x2 (620.0x2)x2 (830.0)x2 + 620.0x2 830.0 + (620.0x2)x2
290.0x2 290.0x2 220.0x2 + 290.0 220.0 + 255.0 + 290.0
4,833.3x2 4,833.3x2 3,666.7x2 + 4,833.3 3,666.7 + 4,250.0 +
4,833.3
8.00 8.00 8.00 8.00
78.40 78.40 78.40 78.40
19.05 19.05 19.05 19.05
3/4" 3/4" 3/4" 3/4"
41.28 41.28 41.28 41.28
1 5/8" 1 5/8" 1 5/8" 1 5/8"
----
----
200 (220) 200 (220) 200 (220) 200 (220)
110 (110) 110 (110) 110 (110) 110 (110)
----
0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
R410A R410A R410A R410A
16.80 16.80 21.40 22.60
68.00 68.00 68.00 68.00
90.00 91.00 89.00 89.00
296.0x2 296.0x2 195.5x2 + 296.0 195.5 + 231.0 + 296.0
315.0x2 315.0x2 211.5x2 + 315.0 211.5 + 250.0 + 315.0
(1,295x1,695x765)x2 (1,295x1,695x765)x2 (880x1,695x765)x2 +
1,295x1,695x765
880x1,695x765 +
(1,295x1,695x765)x2
(1,363x1,887x832)x2 (1,363x1,887x832)x2 (948x1,887x832)x2 +
1,363x1,887x832
948x1,887x832 +
(1,363x1,887x832)x2
-5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0
-25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0
* Specifications may be subject to change without prior notice.
Nominal cooling capacities are based on;
2
: H/P - High EER type
18
1)
- Indoor temperature : 27°C DB, 19°C WB
Nominal heating capacities are based on;
- Outdoor temperature : 35°C DB, 24°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
2)
- Indoor temperature : 20°C DB, 15°C WB
Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the installation conditions.
These products contain R410A which is fluorinated greenhouse gas.
- Outdoor temperature : 7°C DB, 6°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
3)
4)
If outdoor unit is located in a higher position than indoor unit, level difference is 110m or under.5)
(If the level difference is higher than 50m, make a decision by PDM kit installation Guide software whether the PDM kit should be installed or not.)
When the outdoor unit is below the indoor unit & the level differences are 40m or more, contact your local dealer for more information.
*PDM kit: Pressure Drop Modulation kit

Specifications
Outdoor
Type
Model Name
Power Supply Ø, #, V, Hz
Mode -
Performance
HP HP
Capacity
(Nominal)
Cooling kW
Btu/h
Heating kW
Btu/h
Power
Power Input
(Nominal)
Cooling 1) kW
Heating 2) kW
Current
Input
(Nominal)
Cooling 1) A
Heating 2) A
MCA A
MFA A
COP
EER (Nominal Cooling) -
COP (Nominal Heating) -
Energy Grade -
-
Compressor
Type -
Output kW x n
Model Name -
Oil Type -
Fan
Type -
Output x n W
Air Flow Rate
CMM
l/s
External
Static Max. mmAQ
Pa
Piping
Connections
Liquid Pipe Ø, mm
Ø, inch
Gas Pipe Ø, mm
Ø, inch
Discharge Gas Pipe Ø, mm
Ø, inch
Installation
Limitation
Max. Length m
Max. Height m
Field Wiring Power Source Wire mm²
Transmission Cable mm²
Refrigerant Type -
Factory Charging kg
Sound Pressure dBA
Power
External
Dimension
Net Weight kg
Shipping Weight kg
Net Dimensions (WxHxD) mm
Shipping Dimensions
(WxHxD) mm
Operating
Temp.
Cooling ºC
Heating ºC
DVM S(NEW) DVM S(NEW) DVM S(NEW) DVM S(NEW)
AM500JXVHGH1EU AM520JXVHGH1EU AM540JXVHGH1EU AM560JXVHGH1EU
3,4,380-415,50 3,4,380-415,50 3,4,380-415,50 3,4,380-415,50
HP HP HP HP
50.00 52.00 54.00 56.00
140.20 145.60 151.20 156.80
478,400 496,800 515,900 535,000
157.50 163.80 170.10 176.40
537,400 558,900 580,400 601,900
34.24 34.83 36.37 39.07
34.17 35.04 36.52 39.28
54.90 55.90 58.30 62.70
54.70 56.10 58.50 62.90
101.50 108.60 112.00 114.00
125.00 125.00 125.00 125.00
4.09 4.18 4.16 4.01
4.61 4.67 4.66 4.49
ESEER 6.70 ESEER 6.66 ESEER 6.65 ESEER 6.52
----
SSC Scroll x 5 SSC Scroll x 5 SSC Scroll x 5 SSC Scroll x 5
(6.39) + (4.39x2) +
(6.39x2)
(6.39) + (6.39x2) +
(6.39x2)
(6.39) + (6.39x2) +
(6.39x2) (6.39) + (6.39x2)x2
DS-GB066FAVBSGx3 +
DS-GA046FAVASGx2 DS-GB066FAVBSGx5 DS-GB066FAVBSGx5 DS-GB066FAVBSGx5
PVE PVE PVE PVE
Propeller Propeller Propeller Propeller
830.0 + (620.0x2)x2 830.0 + (620.0x2)x2 830.0 + (620.0x2)x2 830.0 + (620.0x2)x2
220.0 + 255.0 + 290.0 220.0 + 290.0x2 220.0 + 290.0x2 220.0 + 290.0x2
3,666.7 + 4,250.0 +
4,833.3 3,666.7 + 4,833.3x2 3,666.7 + 4,833.3x2 3,666.7 + 4,833.3x2
8.00 8.00 8.00 8.00
78.40 78.40 78.40 78.40
19.05 19.05 19.05 19.05
3/4" 3/4" 3/4" 3/4"
41.28 41.28 41.28 41.28
1 5/8" 1 5/8" 1 5/8" 1 5/8"
----
----
200 (220) 200 (220) 200 (220) 200 (220)
110 (110) 110 (110) 110 (110) 110 (110)
----
0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
R410A R410A R410A R410A
22.60 23.30 23.30 23.30
68.00 68.00 69.00 69.00
90.00 90.00 91.00 91.00
195.5 + 262.0 + 296.0 195.5 + 296.0x2
211.5 + 281.0 + 315.0 211.5 + 315.0x2
880x1,695x765 +
(1,295x1,695x765)x2
880x1,695x765 +
(1,295x1,695x765)x2
880x1,695x765 +
(1,295x1,695x765)x2
880x1,695x765 +
(1,295x1,695x765)x2
948x1,887x832 +
(1,363x1,887x832)x2
948x1,887x832 +
(1,363x1,887x832)x2
948x1,887x832 +
(1,363x1,887x832)x2
948x1,887x832 +
(1,363x1,887x832)x2
-5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0
-25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0
* Specifications may be subject to change without prior notice.
Nominal cooling capacities are based on;
2
: H/P - High EER type
19
195.5 + 296.0x2
211.5 + 315.0x2
195.5 + 296.0x2
211.5 + 315.0x2
1)
- Indoor temperature : 27°C DB, 19°C WB
Nominal heating capacities are based on;
- Outdoor temperature : 35°C DB, 24°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
2)
- Indoor temperature : 20°C DB, 15°C WB
Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the installation conditions.
These products contain R410A which is fluorinated greenhouse gas.
- Outdoor temperature : 7°C DB, 6°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
3)
4)
If outdoor unit is located in a higher position than indoor unit, level difference is 110m or under.5)
(If the level difference is higher than 50m, make a decision by PDM kit installation Guide software whether the PDM kit should be installed or not.)
When the outdoor unit is below the indoor unit & the level differences are 40m or more, contact your local dealer for more information.
*PDM kit: Pressure Drop Modulation kit

Specifications
Outdoor
Type
Model Name
Power Supply Ø, #, V, Hz
Mode -
Performance
HP HP
Capacity
(Nominal)
Cooling kW
Btu/h
Heating kW
Btu/h
Power
Power Input
(Nominal)
Cooling 1) kW
Heating 2) kW
Current
Input
(Nominal)
Cooling 1) A
Heating 2) A
MCA A
MFA A
COP
EER (Nominal Cooling) -
COP (Nominal Heating) -
Energy Grade -
-
Compressor
Type -
Output kW x n
Model Name -
Oil Type -
Fan
Type -
Output x n W
Air Flow Rate
CMM
l/s
External
Static Max. mmAQ
Pa
Piping
Connections
Liquid Pipe Ø, mm
Ø, inch
Gas Pipe Ø, mm
Ø, inch
Discharge Gas Pipe Ø, mm
Ø, inch
Installation
Limitation
Max. Length m
Max. Height m
Field Wiring Power Source Wire mm²
Transmission Cable mm²
Refrigerant Type -
Factory Charging kg
Sound Pressure dBA
Power
External
Dimension
Net Weight kg
Shipping Weight kg
Net Dimensions (WxHxD) mm
Shipping Dimensions
(WxHxD) mm
Operating
Temp.
Cooling ºC
Heating ºC
DVM S(NEW) DVM S(NEW) DVM S(NEW) DVM S(NEW)
AM580JXVHGH1EU AM600JXVHGH1EU AM620JXVHGH1EU AM640JXVHGH1EU
3,4,380-415,50 3,4,380-415,50 3,4,380-415,50 3,4,380-415,50
HP HP HP HP
58.00 60.00 62.00 64.00
163.20 168.20 173.60 179.20
556,900 573,900 592,300 611,500
183.60 189.00 195.30 201.60
626,500 644,900 666,400 687,900
42.05 42.42 41.85 44.55
41.44 42.47 42.06 44.82
67.50 68.10 67.10 71.50
66.40 68.00 67.40 71.80
114.00 121.00 129.50 131.50
125.00 150.00 150.00 150.00
3.88 3.97 4.15 4.02
4.43 4.45 4.64 4.50
ESEER 6.52 ESEER 6.45 ESEER 6.54 ESEER 6.43
----
SSC Scroll x 5 SSC Scroll x 6 SSC Scroll x 6 SSC Scroll x 6
(6.39) + (6.39x2)x2 (4.39x2) + (6.39x2)x2 (6.39x2) + (6.39x2)x2 (6.39x2)x2 + (6.39x2)
DS-GB066FAVBSGx5 DS-GA046FAVASGx2 +
DS-GB066FAVBSGx4 DS-GB066FAVBSGx6 DS-GB066FAVBSGx6
PVE PVE PVE PVE
Propeller Propeller Propeller Propeller
(620.0x2)x3 (620.0x2)x3 (620.0x2)x3 (620.0x2)x3
255.0 + 290.0x2 255.0 + 290.0x2 290.0x3 290.0x3
4,250.0 + 4,833.3x2 4,250.0 + 4,833.3x2 4,833.3x3 4,833.3x3
8.00 8.00 8.00 8.00
78.40 78.40 78.40 78.40
19.05 19.05 22.22 22.22
3/4" 3/4" 7/8" 7/8"
41.28 41.28 53.98 53.98
1 5/8" 1 5/8" 2 1/8" 2 1/8"
----
----
200 (220) 200 (220) 200 (220) 200 (220)
110 (110) 110 (110) 110 (110) 110 (110)
----
0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50 0.75 ~ 1.50
R410A R410A R410A R410A
24.50 24.50 25.20 25.20
69.00 69.00 69.00 69.00
91.00 92.00 92.00 92.00
231.0 + 296.0x2 262.0 + 296.0x2 296.0x3 296.0x3
250.0 + 315.0x2 281.0 + 315.0x2 315.0x3 315.0x3
(1,295x1,695x765)x3 (1,295x1,695x765)x3 (1,295x1,695x765)x3 (1,295x1,695x765)x3
(1,363x1,887x832)x3 (1,363x1,887x832)x3 (1,363x1,887x832)x3 (1,363x1,887x832)x3
-5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0 -5.0 ~ 48.0
-25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0 -25.0 ~ 24.0
* Specifications may be subject to change without prior notice.
Nominal cooling capacities are based on;
2
: H/P - High EER type
20
1)
- Indoor temperature : 27°C DB, 19°C WB
Nominal heating capacities are based on;
- Outdoor temperature : 35°C DB, 24°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
2)
- Indoor temperature : 20°C DB, 15°C WB
Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the installation conditions.
These products contain R410A which is fluorinated greenhouse gas.
- Outdoor temperature : 7°C DB, 6°C WB, Equivalent refrigerant piping : 7.5m, Level differences : 0m
3)
4)
If outdoor unit is located in a higher position than indoor unit, level difference is 110m or under.5)
(If the level difference is higher than 50m, make a decision by PDM kit installation Guide software whether the PDM kit should be installed or not.)
When the outdoor unit is below the indoor unit & the level differences are 40m or more, contact your local dealer for more information.
*PDM kit: Pressure Drop Modulation kit
