Samsung SH18AP0D User manual

INDOOR UNIT
SH18AP0D
SH24AP6D
OUTDOOR UNIT
SH18AP0DX
SH24AP6DX
SERVICE Manual
CONTENTSAIR CONDITIONER
1. Product Specifications
2. Operating Instructions & Installation
3. Disassembly and Reassembly
4. Refrigerating Cycle Diagram
5. Set Up the Model Option
6. Troubleshooting
7. Exploded Views and Parts List
8. Block Diagram
9. Wiring Diagram
ROOM AIR CONDITIONER
DB98_21605A(1)_co 1/5/05 2:39 PM Page 3

1Samsung Electronics
1. Product Specifications
1-1 Table
Model
Item
Power Source
Capacity kW
Air Circulation (High) m3/min
Moisture Removal (High) |/h
Available Voltage Range V
Running Amperes A
Power Input kW
Power Factor %
Energy Efficiency Ratio W/W
Compressor Locked Rotor Amperes A
Controls / Temperature Control
Control Unit
Timer
Fan Speed (Indoor / Outdoor)
Airflow Direction (Indoor) Horizontal
Vertical
Compressor
Refrigerant / Amount Charged at Rating (R410A)
Refrigerant Control
Operation Sound Indoor Hi/Mi/Low dB-A
Outdoor-Hi dB-A
Refrigerant Tubing Connections
Max. Allowable Tubing Length m
Refrigerant Tube Diameter
Narrow Tube (in.)
Wide Tube (in.)
Refrigerant Tube Kit / Accessories
Height mm
Unit Dimensions Width mm
Depth mm
Height mm
Package Dimensions Width mm
Depth mm
Weight Net kg
Shipping kg
SH18AP0D
Cool Heat
220-240V~,50Hz
5.1 5.8
13.0 13.5
2.5
198~264
8.3 8.1
1.81 1.80
94.8 96.6
2.81 3.22
40
Microprocessor / Thermistor
Wireless remote control
24-Hour ON / OFF
3 Steps and Turbo / 1 Step
Manual
Auto
Rotary(Samsung)
1,250g
Capillary tube
48 / 46 / 44
58
Flare type
15
6.35(1/4")
12.70(1/2")
Optional / Hanger-plate
Indoor unit Outdoor unit
315 620
1,080 787
205 320
286 692
1,151 909
397 444
13 45
16 50
Features
Dimensions
&
Weight
Electrical
Rating
Performance
SH24AP6D
Cool Heat
220-240V~,50Hz
6.8 7.0
14.0 14.5
3.0
198~264
10.8 11.2
2.42 2.49
97.4 96.7
2.81 2.81
58
Microprocessor / Thermistor
Wireless remote control
24-Hour ON / OFF
3 Steps and Turbo / 2 Step
Manual
Auto
Rotary(Samsung)
1,550g
Capillary tube
48 / 46 / 44
61
Flare type
20
6.35(1/4")
15.88(5/8")
Optional / Hanger-plate
Indoor unit Outdoor unit
315 638
1,080 880
205 310
286 704
1,151 1,023
397 413
13 64
16 68
DB98_21605A(1)_1 1/5/05 7:47 PM Page 1

Samsung Electronics2
1-2 Pressure Graph
20
10
32.4/24.0
30.6/22.5
28.8/21.0
27.0/19.0
24.0/17.0
21.5/15.0
9
8
7
6
25 30 35 40 45
■18K BTU
20
10
9
8
7
6
25 30 35 40 45
32.4/24.0
30.6/22.5
28.8/21.0
27.0/19.0
24.0/17.0
21.5/15.0
■24K BTU
Outdoor inlet air D.B. temp.(˚C)
Low pressure(kg/cm2G)
Indoor inlet air D.B. temp.(˚C)
Outdoor inlet air D.B. temp.(˚C)
Low pressure(kg/cm2G)
Indoor inlet air D.B. temp.(˚C)
DB98_21605A(1)_1 1/5/05 7:47 PM Page 2

3Samsung Electronics
2. Operating Instructions & Installation
2-1 The Feature of Key in remote control
Fan speed adjustment button.
Each time you press this button, FAN SPEED is changed in the following order.
Temperature adjustment button(DOWN).
To decrease the temperature by the pressing the temperature button.
FUNCTION
On/Off button.
Press the button to stop or run the air conditioner.
BUTTONNo
1
2
3
4
5
6
7
8
Swing button.
It adjusts the airflow to upward and downward.
Temperature adjustment button(UP).
To increase the temperature by the pressing the temperature button.
(On/Off)
(UP)
(DOWN)
Low Medium High
Automatic(rotated : )
Sleep button.
The sleep timer can be used when you are cooling or heating your room to switch the
air conditioner off automatically after a period of 6 hours.
Turbo button.
The air conditioner cools or heats the room as quickly as possible.
After 30minutes, the air conditioner is reset automatically to the previous mode.
Mode selection button,
Each time you press this button,
Mode is changed in the following order.
: Auto Mode : Fan Mode
: Cool Mode : Heat Mode
: Dry Mode
Energy saving button.
If you wish to save energy when using your air conditioner, select the Energy saving
mode with the button.
DB98_21605A(1)_1 1/5/05 7:47 PM Page 3

Operating Instructions & Installation
Samsung Electronics4
Digital On/Off button.
If you want to turn off the display during operation press the button.
Off Timer button.
The Off Timer enables you to switch off the air conditioner automatically after
a given period of time that is from 30 minutes to 24 hours.
To set the operating time, press the button one or more times until the required
time display.
FUNCTION
Anion button.
Press the button to generate ion from the air conditioner.
BUTTONNo
9
10
11
12
13
On Timer button.
The On Timer enables you to switch on the air conditioner automatically after
a given period of time that is from 30 minutes to 24 hours.
To set the operating time, press the button one or more times until the required
time display.
Timer Set/Cancel button.
After setting On Timer or Off Timer, press the button to set it completely.
And press the button again to cancel On Timer or Off Timer set.
DB98_21605A(1)_1 1/5/05 7:47 PM Page 4

5Samsung Electronics
1. AUTO MODE : In this mode, operation mode(COOL,
HEAT) is selected automatically by the room temperature
of initial operation.
∆T= -1°C, -2°C, 0°C, +1°C, +2°C
∆T is controlled by setting temperature up/down key of
remote control
2. COOL MODE : The unit operates according to the
difference between the setting and room temperature.
(18°C~30°C)
3. HEAT MODE : The unit operates according to the
difference between the setting and room tempera-
ture.(16°C~30°C)
*Prevention against cold wind : In order to prevent the
cool air from flowing out at the heat mode, the indoor fan
does not operate or operates very slowly in the
following cases. At this time, the indoor heat exchanger
will be preheating.
- For 3~5 minutes after the initial operation
- For deicing operation
- The operation of an indoor fan in accordance with
the temperature of an indoor heat exchanger
*High temperature release function : It is a function to
detect an outdoor overload by the sensor of an indoor
heat exchanger and to turn the outdoor fan or the
compressor ON/OFF for safety.
*Deice : Deicing operation is controlled by indoor unit's
heat exchanger temperature and accumulating time of
compressor's operation.
Deice ends by sensing of the processing time by deice
condition.
4. DRY MODE : Has 3 states, each determined by room
temperature.
The unit operates in DRY mode.
*Compressor ON/OFF Time is controlled compulsorily
(can not set up the fan speed, always breeze).
*Protective function : Low temperature release.
(Prevention against freeze)
5. TURBO MODE : This mode is available in AUTO, COOL,
HEAT, DRY, FAN MODE.
When this button is pressed at first, the air conditioner is
operated ''powerful'' state for 30 minutes regardless of the
set temperature, room temperature.
When this button is pressed again, or when the operating
time is 30 minutes, turbo operation mode is canceled and
returned to the previous mode.
*But, if you press the TURBO button in DRY or FAN
mode that is changed with AUTO mode automatically.
6. SLEEP MODE : Sleep mode is available only in COOL or
HEAT mode.
The operation will stop after 6 hours.
*In COOL mode : The setting temperature is
automatically raised by 1°C each 1hour When the
temperature has been raised by total of 2°C, that
temperature is maintained.
*In HEAT mode : The setting temperature is automatically
dropped by 1°C each 1hour.
When the temperature has been dropped by total of 2°C,
that temperature is maintained.
7. FAN SPEED : Manual (3 step), Auto (4 step)
Fan speed automatically varies depending on both the
difference between setting and the room temperature.
8. COMPULSORY OPERATION :
For operating the air conditioner without the remote
control.
*The air conditioner starts up in the most suitable mode
for the room temperature:
Room Temp
Tr≥21°C+∆T
21°C +∆T>Tr
Operation Type
Cool Operation (Set Temp:24˚C+∆T)
Heat Operation (Set Temp:22˚C+∆T)
below 28˚C
28˚C~below 34˚C
34˚C~below 40˚C
above 40˚C
The temperature of
indoor heat exchanger Indoor fan speed
off
LL Speed
L Speed
Setting Speed
Room Temperature
Less than 21˚C
21˚C or above
Operating Mode
Heat
Cool
Temperature Setting
22˚C approx.
24˚C approx.
2-2 Details for Operation Property
DB98_21605A(1)_1 1/5/05 7:47 PM Page 5

Operating Instructions & Installation
Samsung Electronics6
9. SWING : BLADE-H is rotated vertically by the stepping
motor.
*Swing Set : Press the button under the remote
control is displayed on LCD the and the blades
move up and down. If the one more time press the
button, blades location is stop.
10. SETTING THE ON/OFF TIMER. :
*ON TIMER : The On Timer enables you to switch on the
air conditioner automatically after a given period of time.
You can set the period of time from 30 minutes to 24
hours.
*OFF TIMER : The Off Timer enables you to switch off
the air conditioner automatically after a given period of
time. You can set the period of time from 30 minutes to
24 hours.
11. GENERATING ANION :
The air conditioner can generate anion with an ionizer in
the indoor unit.
12. SELF DIAGNOSIS
13. BUZZER SOUND : Whenever the On/Off button is
pressed or whenever change occurs to the condition
which is set up or select, the compulsory operation mode,
buzzer is sounded "beep".
Indoor unit room temperature sensor
error (open or short)
OFF E1
OFF E2
OFF E3
OFF E6
All lamp
blinking
All lamp
blinking
Indoor unit heat exchanger
temperature sensor error(open or short)
Indoor FAN MOTOR error :
Keep the RPM value 450 below for
15 seconds
Error in option
In case of No option set-up
In case of option data error
EEPROM error
Error Mode
Operation Off Operation On
DISPLAY 7-SEGMENT
Remark
DB98_21605A(1)_1 1/5/05 7:47 PM Page 6

7Samsung Electronics
2-3 Installation
2-3-1 Before Installation
Keep the air conditioner drain hose outlet and inlet free from its surroundings.
In case of breakdown, keep the symmetry and fix it to prevent vibration.
The pipe length shall meet the standard as far as possible.
2-3-2 Installation Procedure
■Location
Install the product in an area to guarantee the best cooling effect, convenience of piping and electric work, and inexistence of
vibration or wind in the vicinity.
■Wall Drilling
Drill the wall downward in a diameter of 60 to 65mm.
■Fixing Indoor Unit & Outdoor Unit
Fix the air conditioner hard enough so that it can not fall to the ground. On the roadside, the outdoor unit shall be installed 2m
above ground and kept away from pedestrians to prevent direct exposure to hot wind.
■Pipe Spooling & Connecting
You shall cut the pipe straightly with a pipe cutter and grind all the burrs of the cut surface.
Pipe expansion may continue until the pipe surface becomes uneven or torn apart.
Be sure to use a torque wrench to tighten pipes or flare nuts.
■Leak Test
Put an inert gas like nitrogen in the outdoor unit pipe and put soap bubbles or other test liquids on the pipe surface for the leak test.
■Drain Hose Connecting
Install the drain hose downward to drain water naturally. Be sure to pour water into the hose to check if it drains well.
■Electric & Earth Work
Electric and earth work shall meet the "Electric Facility Technology Standard" and the "Internal Wire Regulation" of the Electric
Business Laws.
■Inspection & Trial Run
Upon completion of the tests, you shall make a trial run while you explain the main functions of the air conditioner to finish the
installation.
Outer Diameter(D)
6.35mm(1/4")
12.70mm(1/2")
15.88mm(5/8")
Torque(kgf.cm)
140~170
380~420
440~480
Depth(A)
1.3mm
2.0mm
2.2mm
D
A
<Torque & Depth>
DB98_21605A(1)_1 1/5/05 7:47 PM Page 7

Samsung Electronics8
2-4 Installation Diagram of Indoor Unit and Outdoor Unit
2-4-1 Air-Purge Procedure
1) Connect each assembly pipe to the appropriate
valve on the outdoor unit and tighten the flare nut.
3) Open the valve of the low pressure side of
manifold gauge counter-clockwise.
4) Purge the air from the system using vacuum
pump for about 30 minutes.
- After that, please recheck that pressure is
stabilization.
- Close the valve of the low pressure side of
manifold gauge clockwise.
- Remove the hose of the low pressure side
of manifold gauge.
7) Check for gas leakage.
- At this time, especially check for gas
leakage from the 3-Way valve’s stem nuts,
and from the service port cap.
2) Connect the charging hose of low pressure side
of manifold gauge to the packed valve having a
service port (3/8" Packed valve) as shown at the
figure.
5) Set valve cork of both liquid side and gas side of
packed valve to the open position.
6) Mount the valve stem nuts to the 2-Way and
3-Way valve. And mount the service port cap to
3-Way valve.
A
B
C
D
Outdoor unit Indoor unit
Gas pipe side
Liquid pipe side
B
(liquid)
A
(gas)
Valve stem
Stem cap
Vacuum Pump
DB98_21605A(1)_1 1/5/05 7:47 PM Page 8

Operating Instructions & Installation
9Samsung Electronics
2-4-2 Refrigerant Refill(R410A)
Refill an air conditioner with refrigerant when refrigerant has been leaked at installing or using.
1) Purge air(for new installation only).
3) Connect the tank to refill with refrigerant.
4) Set the unit to cool operation mode.
7) Stop operation of the air conditioner.
9) Close the cap of each valve.
2) Turn the 3-Way valve clockwise to close,
connect the pressure gauge (low pressure side)
to the service valve, and open the 3-Way valve
again.
5) Check the pressure indicated by the pressure
gauge(low pressure side).
* Standard pressure is should be 9.0~10.0kg/cm2
in a regular, high operation mode.
6) Open the refrigerant tank and fill with refrigerant
until the rated pressure is reached.
* It is recommended not to pour the refrigerant
in too quickly, but gradually while operating a
pressure valve.
8) Close the 3-Way valve, disconnect the
pressure gauge, and open the 3-Way valve
again.
R410A
Suspension hook
High
pressure
gauge
Hand
wheel
Finger tight
fittings
Connected to
high pressure
side
Charging line
For mounting
other and of
hose when
not in use
Compound
gauge
DB98_21605A(1)_1 1/5/05 7:47 PM Page 9

Operating Instructions & Installation
Samsung Electronics10
2-4-3 "Pump down" Procedure
Pump down will be carried out when an evaporator is replaced or when the unit is relocated in another area.
1) Remove the caps from the 2-Way valve and the
3-Way valve.
3) Set the unit to cool operation mode.
(Check if the compressor is operating.)
4) Turn the 2-Way valve clockwise to close.
7) Close the cap of each valve.
2) Turn the 3-Way valve clockwise to close and
connect a pressure gauge (low pressure side)
to the service valve, and open the 3-Way valve
again.
5) When the pressure gauge indicates "0" turn the
3-Way valve clockwise to close.
6) Stop operation of the air conditioner.
Relocation of the air conditioner
•Refer to this procedure when the unit is relocated.
•Carry out the pump down procedure (refer to the details of 'pump down').
•Remove the power cord.
•Disconnect the assembly cable from the indoor and outdoor units.
•Remove the flare nut connecting the indoor unit and the pipe.
•At this time, cover the pipe of the indoor unit and the other pipe using a cap or vinyl plug to avoid foreign
material entering.
•Disconnect the pipe connected to the outdoor unit.
At this time, cover the valve of the outdoor unit and the other pipe using a cap or vinyl plug to avoid foreign
material entering.
•Make sure you do not bend the connection pipes in the middle and store together with the cables.
•Move the indoor and outdoor units to a new location.
•Remove the mounting plate for the indoor unit and move it to a new location.
3-Way Valve
2-Way Valve
DB98_21605A(1)_1 1/5/05 7:47 PM Page 10

11Samsung Electronics
3. Disassembly and Reassembly
3-1 Indoor Unit
Stop operation of the air conditioner and remove the power cord before repairing the unit.
No Parts Procedure Remark
1 Front Panel 1) Stop the air conditioner operation and block
the main power.
2) Detach tape of Front Panel upper.
3) Slide the lower Front Grille down, then
disassemble it by pulling it forwards.
4) Open the upper Front Grille by pulling right
and left sides of the Grille.
5) Take the left and right Filter out.
6) Loosen one of the right screw and detach
the Terminal Cover.
7) Detach the thermistor from the Front Grille.
8) Loosen 6 fixing screws of Front Grille.
9) Pull the lower left and right of discharge
softly for the outside cover to be pulled out.
10) In order to disassemble the Panel Grille,
press, in order, the left, center, and right of
the upper side of the Panel Grille with the
palm of the hand to remove the hook.
And then disassemble the Panel Grille.
DB98_21605A(1)_1 1/5/05 7:47 PM Page 11

Samsung Electronics12
Disassembly and Reassembly
No Parts Procedure Remark
2
3
4
Electrical Parts
(Main PCB)
Tray Drain
Heat Exchanger
1) Take all the connector of PCB upper side
out.(Including Power Cord)
2) Detach the outdoor unit connection wire
from the Terminal Block.
3) If pulling the main PCB up, it will be taken
out.
1) Pull Tray Drain out from the Back Body.
1) Loosen 2 fixing earth screws of right side.
2) Detach the Connection Pipe.
3) Detach the Holder Pipe at the rear side.
4) Loosen 2 fixing screws of right and left
side.
5) Detach the Heat Exchanger from the
indoor unit.
DB98_21605A(1)_1 1/5/05 7:47 PM Page 12

13Samsung Electronics
Disassembly and Reassembly
No Parts Procedure Remark
5 Fan Motor
&
Cross Fan
1) Loosen 4 fixing screws and detach the
Motor Holder.
2) Loosen 1 fixing screw of Fan Motor.
(with a M6 wrench)
3) Detach the Fan Motor from the Fan.
4) Detach the Fan from the left Holder
Bearing.
DB98_21605A(1)_1 1/5/05 7:47 PM Page 13

Samsung Electronics14
3-2 Outdoor Unit
No Parts Procedure Remark
1 Common Work 1) Loosen the fixing screw of the Cover
Control.
2) Loosen the fixing screws of the
Cabinet-Upper.
3) Loosen the fixing screws of the
Cabinet-Side RH.
4) Loosen the fixing screws of the
Cabinet-Side LF.
5) Loosen the fixing screws of the
Ass'y Control Out.
DB98_21605A(1)_1 1/5/05 7:47 PM Page 14

Disassembly and Reassembly
15Samsung Electronics
No Parts Procedure Remark
2
3
4
Fan & Motor
Heat Exchanger
Compressor
1) Remove the Nut Flange (Turn to the
clockwise).
2) Detach the Fan.
3) Loosen 4 fixing screws to detach the
Motor.
1) Loosen 2 fixing screws on both side.
2) Disassemble the pipe in both inlet and
outlet with welding torch.
3) Detach the Heat Exchanger.
1) Loosen the Terminal Cover to open the
Terminal Cover.
2) Disassemble the Cloth Sound Felt.
3) Disassemble the pipe in both inlet and
outlet of the Compressor with welding
torch.
4) Loosen 3 bolts at the bottom.
5) Detach the Compressor.
DB98_21605A(1)_1 1/5/05 7:47 PM Page 15

Samsung Electronics16
4. Refrigerating Cycle Diagram
Indoor Unit Outdoor Unit
T1
T2
2-Way valve
3-Way valve
Gas side
Heat
Exchanger
Heat
Exchanger
Liquid side
Capillary tube
4-Way valve
Cooling
Heating
Gas leak check point
Compressor
Cross fan
Propeller fan
DB98_21605A(1)_1 1/5/05 7:47 PM Page 16

17Samsung Electronics
5. Set Up the Model Option
5-1 Setting Option Setup Method
ex) Option No. :
Step 1 : Enter the Option Setup mode.
1st Take out the batteries of remote control.
2nd Press the temperature button simultaneously and
insert the battery again.
3rd Make sure the remocon display shown as .
Step 2 : Enter the Option Setup mode and select your option according to the following procedure.
3 2
1
4
5 6
1
2
The default value is .
Otherwise, push the button to .
Every time you push the button, the display panel reads or
repeatedly.
✳Setting is not required if you must
a value which has a default.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
3
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
4
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
5
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
6
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
DB98_21605A(1)_1 1/5/05 7:47 PM Page 17

Samsung Electronics18
Set Up the Model Option
Step 3 : Upon completion of the selection, check you made right selections.
Press the Mode Selection key, to set the display part to and check the display part.
The display part shows .
Press the Mode Selection key, to set the display part to and check the display part.
The display part shows .
Step 4 : Pressing the ON/OFF button ( )
When pressing the operation ON/OFF key with the direction of remote control for unit, the sound ''Ding'' or ''Diriring'' is
heard and the OPERATION ICON( ) lamp of the display is flickering at the same time, then the input of option is com-
pleted. (If the diriring sound isn't heard, try again pressing the ON/OFF button.)
Step 5 : Unit operation test-run
First, Remove the battery from the remote control.
Second, Re-insert the battery into the remote control.
Third, Press ON/OFF key with the direction of remote control for set.
7
8
Press button, then the default value is .
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
10
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
11
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
12
Push the button to set the display panel to .
Every time you push the button, the display panel reads
. . . repeatedly.
9 8
7
10
11 12
✳Setting is not required if you must
a value which has a default.
•Error Mode
1st If all lamps of indoor unit are flickering, Plug out, plug in power plug again and press ON/OFF key to retry.
2nd If the unit is not working properly or all lamps are continuously flickering after setting the option code, see if the correct option code is
set up for its model.
9
DB98_21605A(1)_1 1/5/05 7:47 PM Page 18

19Samsung Electronics
Set up the Model Option
■ OPTION ITEMS
REMOCON
MODEL
SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12
SH18AP0D
SH24AP6D
084013170351
0872141d0362
DB98_21605A(1)_1 1/5/05 7:47 PM Page 19
