Samsung AM18A1(B1)E09 User manual

SERVICE Manual
CONTENTSAIR CONDITIONER
1. Precautions
2.ProductSpecifications
3. OperatingInstructions and
Installation
4.Disassembly and Reassembly
5. Troubleshooting
6. Exploded Views andParts List
7. BlockDiagrams
8. PCBDiagrams
9. Wiring Diagrams
10. Schematic Diagrams
ROOM AIR CONDITIONER
INDOOR UNIT
AM18A1(B1)E09
AM18A1(B1)B09
AM19A1(B1)E07
AM19A1(B1)B12
OUTDOOR UNIT
UM18A1(B1)E2
UM18A1(B1)B2
UM19A1(B1)E2

© Samsung Electronics Co., Ltd. DEC. 1998.
Printed in Korea.
Code No. DB81-10176A(2)

1. Warning: Prior to repair, disconnect the
power cord from the circuit breaker.
2. Use proper parts: Use only exact replacement
parts. (Also, we recommend replacing parts
rather than repairing them.)
3. Use the proper tools: Use the proper tools
and test equipment, and know how to use
them. Using defective tools or test equipment
may cause problems later-intermittent contact,
for example.
4. Power Cord: Prior to repair, check the power
cord and replace it if necessary.
5. Avoid using an extension cord, and avoid tap-
ping into a power cord. This practice may
result in malfunction or fire.
6. After completing repairs and reassembly,
check the insulation resistance. Procedure:
Prior to applying power, measure the resis-
tance between the power cord and the ground
terminal. The resistance must be greater than
30 megohms.
7. Make sure that the grounds are adequate.
8. Make sure that the installation conditions are
satisfactory. Relocate the unit if necessary.
9. Keep children away from the unit while it is
being repaired.
10. Be sure to clean the unit and its surrounding
area.
Samsung Electronics 1-1
1. Precautions
Fig. 1-1 Avoid Dangerous Contact
Fig. 1-2 No Tapping and No Extension Cords
Fig. 1-3 No Kids Nearby!
Fig. 1-4 Clean the Unit

1-2 Samsung Electronics
MEMO

Samsung Electronics 2-1
2. Product Specifications
2-1 Table
Model AM18A1(B1)E2 AM18A1(B1)B2 AM19A1(B1)E2
INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT
Item AM18A1(B1)E09 UM18A1(B1)E2 AM18A1(B1)B09 UM18A1(B1)B2 AM19A1(B1)E07 AM19A1(B1)E12 UM19A1(B1)E2
Type - Wall-Mounting Multi Split Wall-Mounting Multi Split
Cooling BTU/h 9,000 18,000(9,000x2) 9,000 18,000(9,000x2) 7,000 12,000 19,000 (7,000+12,000)
Dehumiditying I/h 1.6 - 1.6 - 1.2 1.9 -
Air volume Cooling m3/min 7.0 - 7.0 - 6.0 8.3 -
Noise Cooling dB 35 54 35 54 33 38 54
Power V-Hz 1-220-240V~, 50Hz 1-220V~, 60Hz 1-220V~, 50Hz
Power consumption Cooling W 870 1,740(870x2) 860x2 1,720(860x2) 720 1,230 1,820
Operating current Cooling A 3.7 7.4(3.7x2) 4.0 8.0(4.0x2) 3.1 5.3 8.0
Power factor Cooling % 97.9 97.7 96.0 96.0 94.0
Starting current A 30 30
Power cord(Option) - HO7RNF 2.5 - H07RNF2.5 - - H07RNF2.5
HO5RNF (5G 1mm2) HO5RNF (5G 1mm2) H05RNF (5G 1mm2)
Fuse capacity A 3.15 - 3.15 - 3.15 3.15 3.15 / 5
Outer W x H x D mm 815x298x182 787x620x320 815x298x182 787x620x320 815x298x182 815x298x182 787x620x320
dimension inch
32.08x11.73x7.17 30.98x24.41x12.6 32.08x11.73x7.17 30.98x24.41x12.6 32.08x11.73x7.17 32.08x11.73x7.17 30.98x24.41x12.6
Weight kg 9.6 53 9.6 53 9.6 9.6 53
Refrigerant pipe Liquid OD(mm)xL(m) ø6.35 x 5 ø6.35 x 5 ø6.35x5 ø6.35x5 -
GAS ø9.52x5 ø9.52 x 5 ø9.52x5 ø12.7x5 -
Drain hose ID(mm) x L(m) ø17 x 2,000 ø17x2,000
Type - Rotary - Rotary Rotary Rotary Rotary
Comp- Model name - 44B092JW1E6 - 44B092IW1E5 44A070JW1E1 48A124JV1E5 44A070JW1E1 + 48A124JV1E5
Capacitor - 30µF x 420VAC - 20µF x 450VAC 25µF x 450VAC 30µF x 420VAC 20µF x 450VAC + 30µF x 420VAC
ressor
Motor Tape(model) - - - - - - -
Rated output W - 675 - 675 675 1,210 -
Type Cross-fan Propeller Cross-fan Propeller Cross-fan Cross-fan Propeller
Blower Motor Type Resin Still Resin Still Resin Resin Still
Rated output W 35 35 35 35 35 35 35
Heat exchanger 2Row 12Step 2Row 24Step 2Row 12Step 2Row 24Step 2Row 12Step 2Row 12Step 2Row 24Step
Refrigerant control unit A,B-UNIT ; Capillary Tube A,B-UNIT ; Capillary Tube.
Freezer oil capacity cc - 280 - 280 280 360 -
Refrigerant to change (R-22) g - 800x2 - 790x2 700 850 700 + 850
Protection device - MRA12037-12007 - MRA12032-12008 MST24AMN-12008 MRA12030-12008 -
Standard Conditions ISO R5151 Standard ARI Standard ISO R5151 Standard
•The basic performance test is based on the piping of 5MT. (Be sure to check the installing conditions as extension of the piping
may lead to performance degradetion.)
Perfor-
mance
Power
Size

2-2 Samsung Electronics
2-2 Dimensions
2-2-1 Indoor Unit
2-2-1 Outdoor Unit
(Front view) (Rear view)
Air
in
(Front view) (Remote control)
(Rear view)
815 182
Air out
Installation plate
58
22

Samsung Electronics 2-3
2-3 Refrigerating Cycle Block Diagram
Refrigerating cycle temperature and pressure
STD Pressure Piping Temp.(°C) Temp. Condition (°C)
Operating Condition (kg/cm2G) T1 T2 Indoor Outdoor
3-way valve DB WB DB WB
Standard 5.0~5.2 11 11 27 19 35 24
A or B Max over load 6.0~6.3 16 15 32 23 43 26
Cooling Low temp. 3.4~3.6 3 2 21 15 21 15
Standard 5.0~5.2 12 10 27 19 35 24
A + B Max over load 6.0~6.3 16 15 32 23 43 26
Low temp. 3.4~3.6 3 2 21 15 21 15
INDOOR UNIT
T1
T2 Gas side
Cooling
Compressor-A Gas leak
check point
Liquid side
Capillary tube
2-way valve
3-way valve
Heat
exchanger
(Evaporator)
Heat
exchanger
(Condenser)
(A) (B)
OUTDOOR UNIT

2-4 Samsung Electronics
MEMO

Samsung Electronics 3-1
3. Operating Instructions and Installation
3-1 Operating Instructions
3-1-1 Name & Function of Key in remote controller
NO
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
NAMED OF KEY
MODE
(UP)
(DOWN)
TURBO
OFF
ON TIMER
OFF TIMER
SET
CANCEL
(UP)
Without regard to ON/OFF condition in remote controller,
use this button to set current time.
Adjust the current time using button.
(Data can be transmitted after setting up the time)
If the button is pressed once, the time decrease by one minute
during the time set mode, and ten minutes during the timer set mode.
If the button is pressed once, the time increase by one minute
during the time set mode, and ten minutes during the timer set mode.
Use this button to reserve or cancel the timer on and timer off.
Use this button to reserve the timer on.
Set up the time that operation stop.
Set up the time that operation start.
Each time you press this button,
FAN SPEED is changed in the following order.
Adjusts air flow vertically.
Each time you press this button,
Use this button for sleep operation.
(The SLEEP mode can be selected at COOL and HEAT mode.)
Set up the reserve or cancel the timer on and timer off quickly
Use this button to provide heavy duty cooling & Heating for 30 minutes.
Each time you press this button,
MODE is changed in the following order.
Temp. down button. If the button is pressed once,
the setting temperature is decreased by 1°C
Temp. up button. If the button is pressed once,
the setting temperature is increased by 1°C
On/Off Button. Use this button to start and stop air conditioner.
FUNCTION OF KEY
(DOWN)
TIME
C
O
V
E
RT
I
M
E
R

3-2 Samsung Electronics
Operating Instructions and Installation
1. AUTO MODE : In this mode, operation
COOL mode is selected automatically by the
room temperature of initial operation.
∆T= -1°, -2°C, 0°C+1°C+2°C
∆T is controlled by setting temperature
up/down key of remote controller
* FAN SPEED : AUTO
2. COOL MODE : The unit operates according
to the difference between the setting and
room temperature. (18°C~30°C)
3. DRY MODE : Has 3 states, each determined
by room temperature.
The unit operates in DRY mode.
*Compressor ON/OFF Time is controlled
compulsorily(can not set up the fan speed,
always breeze).
*Protective function : Low temperature
release. (Prevention against freeze)
4. TURBO MODE : This mode is available in
AUTO, COOL, DRY, FAN MODE.
When this button is pressed at first, the air
conditioner is operated “powerful” state for
30 minutes regardless of the set tempera-
ture, room temperature.
When this button is pressed again, or when
the operating time is 30 minutes, turbo
operation mode is canceled and returned to
the previous mode.
*But, if you press the TURBO button in DRY
or FAN mode that is changed with AUTO
mode automatically.
5. SLEEP MODE : Sleep mode is available
only in COOL mode.
The operation will stop after 6 hours.
*In COOL mode : The setting temperature
is automatically raised by 1°C each 1hour
When the temperature has been raised by
total of 2°C, that temperature is main-
tained.
6. FAN SPEED : Manual (3 step), Auto (4 step)
Fan speed automatically varies depending
on both the difference between setting and
the room temperature.
Operation Type
Cool Operation
Room Temp
Tr≥24.5°C+∆T Compressor ON
Tr≤24°C+∆T Compressor OFF
3-1-2 Name & Function of Key in remote controller
