Samsung AQ12?5(6)MB User manual

SERVICE Manual
CONTENTSAIR CONDITIONER
1. Precautions
2. Product Specifications
3. Operating Instructions and
3. Installation
4. Disassembly and Reassembly
5. Troubleshooting
6. Exploded Views and Parts List
7. Block Diagrams
8. PCB Diagrams
9. Wiring Diagrams
10. Schematic Diagrams
ROOM AIR CONDITIONER
INDOOR UNIT
AQ12✳5(6)MB
AQ12✳5(6)ME
AQ09✳5(6)ME
SH09Z✳5(6)
AQ07✳5(6)ME
SH07Z✳5(6)
AQ09✳7(8)ME
SH09Z✳7(8)
AQ07✳7(8)ME
SH07Z✳7(8)
AQ12✳9(0)ME
SH12Z✳9(0)
AQ12✳A(B)ME
AQ09✳5(6)MED
AQ07✳5(6)MED
SH12Z✳A(B)
SH09Z✳5(6)D
SH07Z✳5(6)D
OUTDOOR UNIT
UQ12✳5(6)MB
UQ12✳5(6)ME
UQ09✳5(6)ME
SH09Z✳5(6)X
UQ07✳5(6)ME
SH07Z✳5(6)X
UQ09✳7(8)ME
SH09Z✳7(8)X
UQ07✳7(8)ME
SH07Z✳7(8)X
UQ12✳9(0)ME
SH12Z✳9(0)X
UQ12✳A(B)ME
UQ09✳5(6)MED
UQ07✳5(6)MED
SH12Z✳A(B)X
SH09Z✳5(6)DX
SH07Z✳5(6)DX
DB81-00181A(4)-cover 3/6/11 3:12 PM Page 3

1-1Samsung Electronics
1. Warning: Prior to repair, disconnect the
power cord from the circuit breaker.
2. Use proper parts: Use only exact replace-
ment parts. (Also, we recommend replacing
parts rather than repairing them.)
3. Use the proper tools: Use the proper tools
and test equipment, and know how to use
them. Using defective tools or test equip-
ment may cause problems later-intermittent
contact, for example.
4. Power Cord: Prior to repair, check the
power cord and replace it if necessary.
5. Avoid using an extension cord, and avoid
tapping into a power cord. This practice
may result in malfunction or fire.
6. After completing repairs and reassembly,
check the insulation resistance.
Procedure: Prior to applying power, mea-
sure the resistance between the power cord
and the ground terminal. The resistance
must be greater than 30 megaohms.
7. Make sure that the grounds are adequate.
8. Make sure that the installation conditions
are satisfactory.
Relocate the unit if necessary.
9. Keep children away from the unit while it is
being repaired.
10. Be sure to clean the unit and its surround-
ing area.
1. Precautions
Fig. 1-1 Avoid Dangerous Contact
Fig. 1-2 No Tapping and No Extension Cords
Fig. 1-3 No Kids Nearby!
O.K
Fig. 1-4 Clean the Unit
DB81-00181A(4)-1 3/6/11 3:23 PM Page 1-1

Samsung Electronics2-1
2. Product Specifications
2-1 Table
Model
Item
Type
Cooling BTU/h(KW)
Heating BTU/h(KW)
Dehumiditying I/h
Air volume Cooling m3/min
Heating
Noise Cooling dB
Heating
Energy efficiency ratio Cooling BTU/h•W
Heating (W/W)
Power V-Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Power factor Cooling %
Heating
Starting current A
Power cord Length m
Number of core wire
Fuse capacity A
Outer Width x Height mm
Dimension x Depth inch
Weight
Refrigerant pipe Liquid mm x L(MT)
GAS mm x L(MT)
Drain hose D x L(mm)
Compressor Type
Motor Type
Rated output
Blower Type
Motor Type
Rated output W
Heat exchanger
Refrigerant control unit
Freezer oil capacity
Refrigerant to change(R-22)
Protection device
Cooling test Condition
Maximum operation Condition
AQ12 ✳ 5(6)MB
Indoor unit Outdoor unit
Wall-mounting
12000
13000
1.9
7.4 19
8.1 19
41 53
41 53
9.375
10.0
1-220 -60
1280
1300
6.0
6.2
97
95.3
30
-
-
250V-10 / 16A
790 x 245 x 165 762 x 532 x 280
31.1 x 9.6 x 6.5 30 x 20.9 x 11
7.7 35
ø6.35 x 5
ø12.7 x 5
ø18 x 2000
Rotary
--
--
Cross-flow Propeller
Resin steel
15 25
2ROW 12STEP 1ROW 20STEP
CAPILLARY TUBE
410
800
MRA 12002-9200/MRA 12002-12008
AQ12 ✳ 5(6)ME
Indoor unit Outdoor unit
Wall-mounting
12000 (3.4)
13000 (3.7)
1.9
7.4 19
8.1 19
41 53
41 53
10.0
10.6
1-220 / 240-50
1200
1230
5.4
5.5
96.6
97.2
30
-
-
250V-10 / 16A
790 x 245 x 165 762 x 532 x 280
31.1 x 9.6 x 6.5 30 x 20.9 x 11
7.7 35
ø6.35 x 5
ø12.7 x 5
ø18 x 2000
Rotary
--
--
Cross-flow Propeller
Resin steel
15 25
2ROW 12STEP 1ROW 20STEP
CAPILLARY TUBE
410
820
MRA 12030-12008/RAC12030-9622
AQ09 ✳ 5(6)ME/SH09Z ✳ 5(6)
Indoor unit Outdoor unit
Wall-mounting
9000 (2.72)
10000 (2.95)
1.4
6.0 18
6.7 18
38 51
38 51
9.375
10.752
1-220 / 240-50
960
930
4.4
4.2
94.9
96.3
30
-
-
250V-10 / 16A
790 x 245 x 165 660 x 497 x 235
31.1 x 9.6 x 6.5 26 x 19.6 x 9.3
7.7 29
ø6.35 x 5
ø9.52 x 5
ø18 x 2000
Rotary
--
--
Cross-flow Propeller
Resin steel
15 25
2ROW 12STEP 1ROW 18STEP
CAPILLARY TUBE
360
670
RAC 12054-9622
Power
Size
Perfor-
mance
INDOOR UNIT : DB27°C WB19°C
INDOOR UNIT : DB32°C WB23°C
OUTDOOR UNIT : DB35°C WB24°C
OUTDOOR UNIT : DB43°C WB26°C
DB81-00181A(4)-1 3/6/11 3:23 PM Page 1-2

2-2Samsung Electronics
AQ07 ✳ 5(6)ME/SH07Z ✳ 5(6)
Indoor unit Outdoor unit
Wall-mounting
7500 (2.3)
8000 (2.38)
0.9
5.6 18
5.5 18
35 50
35 50
10.0
10.959
1-220 / 240-50
750
730
3.3
3.3
98.8
96.7
30
-
-
250V-10 / 16A
790 x 245 x 165 660 x 497 x 235
31.1 x 9.6 x 6.5 26 x 19.6 x 9.3
7.7 29
ø6.35 x 5
ø9.52 x 5
ø18 x 2000
Rotary
--
--
Cross-flow Propeller
Resin steel
15 25
2ROW 12STEP 1ROW 18STEP
CAPILLARY TUBE
360
630
RAC 12086-9622
AQ09 ✳ 7(8)ME/SH09Z ✳ 7(8)
Indoor unit Outdoor unit
Wall-mounting
9000 (2.64)
10000 (2.93)
1.4
6.0 20.5
6.7 20.5
38 51
38 51
9.47
10.75
1-220 / 240-50
950
930
4.2
3.9
98.3
10.37
30
-
-
250V-10 / 16A
790 x 245 x 165 660 x 470 x 242
31.1 x 9.6 x 6.5 26 x 18.5 x 9.5
7.7 2.5
ø6.35 x 5
ø9.52 x 5
ø18 x 2000
Rotary
--
--
Cross-flow Propeller
Resin steel
15 25
2ROW 12STEP 1ROW 18STEP
CAPILLARY TUBE
360
600
MRA 12110-12008/RAC12054-9622
AQ07 ✳ 7(8)ME/SH07Z ✳ 7(8)
Indoor unit Outdoor unit
Wall-mounting
7500 (2.2)
8000 (2.34)
0.9
5.6 20.5
5.5 20.5
35 50
35 50
10.0
10.96
1-220 / 240-50
750
730
3.3
3.2
98.8
99.2
30
-
-
250V-10 / 16A
790 x 245 x 165 660 x 470 x 242
31.1 x 9.6 x 6.5 26 x 18.5 x 9.5
7.7 25
ø6.35 x 5
ø9.52 x 5
ø18 x 2000
Rotary
--
--
Cross-flow Propeller
Resin steel
15 25
2ROW 12STEP 1ROW 18STEP
CAPILLARY TUBE
360
620
MRA 12086-12008/RAC12086-9622
AQ12 ✳ 9(0)ME/SH12Z ✳ 9(0)
Indoor unit Outdoor unit
Wall-mounting
12000 (3.5)
13000 (3.8)
1.9
7.4 19
8.1 19
41 53
41 53
10.3
10.2
1-220 / 240-50
1170
1270
5.0
5.4
101.7
102.3
30
-
-
250V-10 / 16A
790 x 245 x 165 720 x 532 x 245
31.1 x 9.6 x 6.5 28.3 x 20.9 x 9.6
7.7 39
ø6.35 x 5
ø12.7 x 5
ø18 x 2000
Rotary
--
--
Cross-flow Propeller
Resin steel
15 25
2ROW 12STEP 2ROW 20STEP
CAPILLARY TUBE
410
970
MRA 12030-12008/RAC12030-9622
INDOOR UNIT : DB27°C WB19°C
INDOOR UNIT : DB32°C WB23°C
OUTDOOR UNIT : DB35°C WB24°C
OUTDOOR UNIT : DB43°C WB26°C
DB81-00181A(4)-1 3/6/11 3:23 PM Page 1-3

Samsung Electronics2-3
Table (Cont.)
Model
Item
Type
Cooling BTU/h(KW)
Heating BTU/h(KW)
Dehumiditying \ /h
Air volume Cooling m3/min
Heating
Noise Cooling dB
Heating
Energy efficiency ratio Cooling BTU/h•W
Heating (W/W)
Power V-Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Power factor Cooling %
Heating
Starting current A
Power cord Length m
Number of core wire
Fuse capacity A
Outer Width x Height mm
Dimension x Depth inch
Weight
Refrigerant pipe Liquid mm x L(MT)
GAS mm x L(MT)
Drain hose D x L(mm)
Compressor Type
Motor Type
Rated output
Blower Type
Motor Type
Rated output W
Heat exchanger
Refrigerant control unit
Freezer oil capacity
Refrigerant to change(R-22)
Protection device
Cooling test Condition
Maximum operation Condition
AQ12 ✳ A(B)ME / SH12Z ✳ A(B)
Indoor unit Outdoor unit
Wall-mounting
12000 (3.5)
13000 (3.8)
1.9
7.4 23.0
7.9 23.0
41 53
41 53
(2.99)
(2.99)
1-220 / 240-50
1170
1270
5.4
5.5
96.0
96.0
30
-
-
250V-10 / 16A
790 x 245 x 165 740 x 530 x 230
31.1 x 9.6 x 6.5 29.1 x 20.6 x 9.1
7.7 35.0
ø6.35 x 5
ø12.7 x 5
ø18 x 2000
Rotary
--
--
Cross-flow Propeller
Resin steel
15 25
2ROW 12STEP 1ROW 24STEP
CAPILLARY TUBE
410
1000
RAC12030-9622
AQ09 ✳ 5(6)MED/SH09Z ✳ 5(6)D
Indoor unit Outdoor unit
Wall-mounting
9000 (2.64)
10000 (2.85)
1.4
6.0 18
6.7 18
38 51
38 51
8.91
10.87
1-220 / 240-50
1010
920
4.4
4.0
99.8
99.8
30
-
-
250V-10 / 16A
790 x 245 x 165 660 x 497 x 235
31.1 x 9.6 x 6.5 26 x 19.6 x 9.3
7.7 29
ø6.35 x 5
ø9.52 x 5
ø18 x 2000
Rotary
--
--
Cross-flow Propeller
Resin steel
15 25
2ROW 12STEP 1ROW 22STEP
CAPILLARY TUBE
360
610
RAC 12054-9622
AQ07 ✳ 5(6)MED / SH07Z ✳ 5(6)D
Indoor unit Outdoor unit
Wall-mounting
7500 (2.20)
8000 (2.34)
0.9
5.6 18
5.5 18
35 50
35 50
9.74
10.959
1-220 / 240-50
770
730
3.4
3.2
94.4
95.0
30
-
-
250V-10 / 16A
790 x 245 x 165 660 x 497 x 235
31.1 x 9.6 x 6.5 26 x 19.6 x 9.3
7.7 29
ø6.35 x 5
ø9.52 x 5
ø18 x 2000
Rotary
--
--
Cross-flow Propeller
Resin steel
15 25
2ROW 12STEP 1ROW 22STEP
CAPILLARY TUBE
360
520
RAC 12086-9622
Power
Size
Perfor-
mance
INDOOR UNIT : DB27°C WB19°C
INDOOR UNIT : DB32°C WB23°C
OUTDOOR UNIT : DB35°C WB24°C
OUTDOOR UNIT : DB43°C WB26°C
DB81-00181A(4)-1 3/6/11 3:23 PM Page 1-4

2-4Samsung Electronics
2-2 Dimensions
2-2-1 Indoor Unit
790 165
245
Air in
(Front view)
(Remote Control)
(Rear view)
Air out
Installation plate
2245
115
DB81-00181A(4)-1 3/6/11 3:23 PM Page 1-5

Samsung Electronics2-5
2-2-2 Outdoor Unit
249
497
492
660
235
50
11
20
UQ09✳5(6)M✳
UQ07✳5(6)M✳
SH09Z✳5(6)X
SH07Z✳5(6)X
UQ09✳5(6)M✳D
UQ07✳5(6)M✳D
SH09Z✳5(6)DX
SH07Z✳5(6)DX
457 254
242
660
457
11
20
SH07Z✳7(8)X
SH09Z✳7(8)X
UQ07✳7(8)M✳
UQ09✳7(8)M✳
UQ12✳5(6)M✳
280
555
762
532 295
(Front view) (Rear view)
DB81-00181A(4)-1 3/6/11 3:23 PM Page 1-6

Product Specifications
2-6Samsung Electronics
230
506
740 57
20
11
UQ12✳A(B)ME
SH12Z✳A(B)X
UQ12✳9(0)M✳
SH12Z✳9(0)X
532 267
245
496
720 55
11
20
DB81-00181A(4)-1 3/6/11 3:23 PM Page 1-7

Samsung Electronics2-7
2-3 Pressure Graph
20 25 30 35 40 45
32.4/24.0
30.6/22.5
28.8/21.0
27.0/19.0
24.0/17.0
21.5/15.0
6.5
5.5
4.5
3.5
12K BTU
20 25 30 35 40 45
32.4/24.0
30.6/22.5
28.8/21.0
27.0/19.0
24.0/17.0
21.5/15.0
6.5
5.5
4.5
3.5
9K BTU
20 25 30 35 40 45
32.4/24.0
30.6/22.5
28.8/21.0
27.0/19.0
24.0/17.0
21.5/15.0
7
6
5
4
7K BTU
DB81-00181A(4)-1 3/6/11 3:23 PM Page 1-8

3-1Samsung Electronics
3. Operating Instructions and Installation
3-1 Operating Instructions
To select the 5 way function with the remote control, press the 5 way
button one or more times until the desired mode is selected.
Each time you press the 5 way button.
Each 5 way indicator on the indoor unit comes on in order.
Each time you press this button,
FAN SPEED is changed in the following order.
Press until the appearance. the sleep timer can be used when
you are cooling or heating your room to switch the air conditioner off
automatically after a perriod of six hours.
Temp. down button. To decrease the temperature by the pressing
the temperature button.
FUNCTION OF KEY
3-1-1 Name & Function of Key in remote controller
(DOWN)
Power On/Off button to start and stop airconditioner or timer set up.
Press until the appearance. the air condition cools or heats
the room as quickly as possible. after 30minutes, the air,
the airconditioner is reset automatically to the previous mode.
NAMED OF KEY
(UP)
NO
1
2
3
4
5
6
7
8
9
Adjust air flow vertically.
Each time you press this button
Mode is changed in the following order : Auto Mode : Fan Only
: Cool Mode : Heat Mode
: Dry Mode
Temp. up button. To increase the temperature by the pressing
the temperature button.
The ON Timer enables you to switch on the air conditioner automatically
after a given period of time that is from 30 minutes to 24 hours.
To cancel, press the (Set/Cancel) button.
The Off Timer enables you to switch off the air conditioner automatically
after a given period of time that is from 30 minutes to 24 hours.
To cancel, press the (Set/Cancel) button.
DB81-00181A(4)-1 3/6/11 3:23 PM Page 3-1

Samsung Electronics3-2
Operating Instructions and Installation
1. AUTO MODE : In this mode, operation
mode(COOL, HEAT) is selected automati-
cally by the room temperature of initial
operation.
∆T= -1°C, -2°C, 0°C+1°C+2°C
∆T is controlled by setting temperature
up/down key of remote controller
2. COOL MODE : The unit operates according
to the difference between the setting and
room temperature. (18°C~30°C)
3. HEAT MODE : The unit operates according
to the difference between the setting and
room temperature.(16°C~30°C)
*Prevention against cold wind : For about
3~5 minutes after initial operation, thermo
control or “de-ice”, the indoor fan will
either not operate or operate very slowly,
then switch to the selected fan speed. This
period is to allow the indoor unit's heat-
exchanger to prewarm before emitting
warm air.
*High temperature release function : The
outdoor unit for and compressor ON/OFF
control for safety operation, when the over-
heat is heat exchanger of indoor unit.
*De-ice : Deicing operation is controlled by
indoor unit's heat exchanger temperature
and accumulating time of compressor's
operation.
De-ice ends by sensing of the processing
time by de-ice Condition.
4. DRY MODE : Has 3 states, each determined
by room temperature.
The unit operates in DRY mode.
*Compressor ON/OFF Time is controlled
compulsorily(can not set up the fan speed,
always breeze).
*Protective function : Low temperature
release. (Prevention against freeze)
5. TURBO MODE : This mode is available in
AUTO, COOL, HEAT, DRY, FAN MODE.
When this button is pressed at first, the air
conditioner is operated “powerful” state for
30 minutes regardless of the set tempera-
ture, room temperature.
When this button is pressed again, or when
the operating time is 30 minutes, turbo
operation mode is canceled and returned to
the previous mode.
*But, if you press the TURBO button in DRY
or FAN mode that is changed with AUTO
mode automatically.
6. SLEEP MODE : Sleep mode is available
only in COOL or HEAT mode.
The operation will stop after 6 hours.
*In COOL mode : The setting temperature
is automatically raised by 1°C each 1hour
When the temperature has been raised by
total of 2°C, that temperature is main-
tained.
*In HEAT mode : The setting temperature
is automatically droped by 1°C each
1hour.
When the temperature has been droped by
total of 2°C, that temperature is main-
tained.
7. FAN SPEED : Manual (3 step), Auto (4 step)
Fan speed automatically varies depending
on both the difference between setting and
the room temperature.
Room Temp
Tr≥21°C+∆T
21°C +∆T>Tr
Operation Type
Cool Operation (Set Temp:24˚C+∆T)
Heat Operation (Set Temp:22˚C+∆T)
3-1-1 Name & Function of Key in remote controller
DB81-00181A(4)-1 3/6/11 3:23 PM Page 3-2

Operating Instructions and Installation
3-3Samsung Electronics
8. COMPULSORY OPERATION :
For operating the air conditioner without
the remote controller.
*AUTO : The operating is the same func-
tion that AUTO MODE in the remote con-
troller. And each time you press the button
the 5WAY function is changed as follow.
STD ➝ NATURE ➝ POWER ➝ SAVING ➝
SILENCE ➝ POWER OFF
Each time you press This button, 5WAY
function is changed in the following order
STD(standard) ➝ NATURE ➝
POWER(High-speed) ➝ Saving(Power-
Saving) ➝ SILENCE ➝ POWER OFF
❊ STD(standard)( ) : General operation
Mode
❊ NATURE( ) : The unit is operated
according to health
pattern control
❊ POWER( ) : The unit is operated in
powerful state
❊ SAVING( ) : The unit is operated in
power saving state
❊ SILENCE( ) : The unit is operated
quietly
Each mode has Auto, Cool and SLEEP oper-
ation designed in advance.
9. SWING : BLADE-H is rotated vertically by
the stepping motor.
*Swing Set : Press the button under the
remote control is displayed on LCD the
and the blades move up and down. If the
one more time press the button, blades
location is stop.
10. 24-Hour ON/OFF Real Setting Timer. : The
air conditioner is turned ON at a specified
time using .
OFF TIMER : The air Conditioner is turned
OFF at a specified time using .
*ON TIMER : Only timer LED lights on.
*OFF TIMER : Both timer and operation
LED lights on.
11. SELF Diagnosis
12. BUZZER SOUND : Whenever the ON/OFF
button is pressed or whenever change
occurs to the condition which is set up or
select, the compulsory operation mode,
buzzer is sounded "beep".
Indoor unit room temperature sensor
error(open or short)
Check Point
LED DISPLAY
TIMER STD NATURE POWER SAVING SILENCE
LED
:blinking : LED off
Indoor unit heat exchanger temperature
sensor error(open or short)
Indoor fan malfunction
EEPROM error
Option error(option wasn’t set up or
option data error)
DB81-00181A(4)-1 3/6/11 3:23 PM Page 3-3

MEMO
Samsung Electronics3-4
DB81-00181A(4)-1 3/6/11 3:23 PM Page 3-4

4-1Samsung Electronics
4. Disassembly and Reassembly
4-1 Indoor Unit
Stop operation of the air conditioner and remove the power cord before repairing the unit.
No Parts Procedure Remark
1 Front Grille 1) Stop the air conditioner operation and block
the main power.
2) Separate tape of front panel upper.
3) Contract the second finger to the left, and
right handle and pull to open the inlet grille.
4) Take the left and right filter out.
5) Loosen one of the right fixing screw and
separate the terminal cover.
6) Loosen three fixing screws of front grille.
7) Pull the upper left and right of discharge
softly for the outside cover to be pulled out.
8) Pull softly the lower part of discharge and
push it up.
Caution;
Assemble the front panel and fix the
hooks of left and right.
*Taking off the deodorizing filter.
DB81-00181A(4)-1 3/6/11 3:24 PM Page 4-1

Disassembly and Reassembly
Samsung Electronics4-2
No Parts Procedure Remark
2
3
4
Electrical Parts
(Main PCB)
Ass’y Tray Drain.
Heat Exchanger
1) Do “1”above.
2) Take all the connector of PCB upper side out.
(Inclusion Power cord)
3) Separate the outdoor unit connection wire
from the terminal block.
4) If pulling the Main PCB up. it will be taken
out.
1) Do “1”, “2”, above.
Separate the drain hose from the extension
drain hose.
2) Pull tray drain out from the back body.
1) Do “1” and “2”, “3”, above.
2) Loosen two fixing earth screws of right side.
3) Separate the connection pipe.
4) Separate the holder pipe at the rearside.
5) Loosen the three fixing screws of right and
left side.
6) Lifting the heat exchanger up a little to push
the up side for separation from the indoor
unit.
DB81-00181A(4)-1 3/6/11 3:24 PM Page 4-2

Disassembly and Reassembly
4-3Samsung Electronics
No Parts Procedure Remark
5 Fan Motor and
Cross Fan 1) Do “1” “2” ”3” “4”, above.
2) Loosen the fixing two screws and separate
the motor holder.
3) Loosen the fixing screw of fan motor.
(By use of M3 wrench)
4) Separate the fan motor from the fan.
5) Separate the fan from the left holder bearing.
DB81-00181A(4)-1 3/6/11 3:24 PM Page 4-3

Samsung Electronics4-4
4-2 Outdoor Unit
• UQ12✳5(6)M✳
No Parts Procedure Remark
1 Common Work 1) Loosen the fixing screw and separate the
Handle-Cabi RH.
2) Separate the connection wire from the
terminal block.
3) Loosen 6 fixing screws and separate the
upper cabinet.
4) Loosen the fixing screw of Ass'y E-part.
5) Loosen 5 fixing screws and separate the side
cabinet.
DB81-00181A(4)-1 3/6/11 3:24 PM Page 4-4

Disassembly and Reassembly
4-5Samsung Electronics
No Parts Procedure Remark
2 Fan-Motor 1) Loosen 4 fixing screw of the Guard-Fan.
2) Remove the nut flange (Turn to the right to
remove, as it is a left hand screw)
3) Separate the fan.
4) Loosen four fixing screws to separate the
motor.
DB81-00181A(4)-1 3/6/11 3:24 PM Page 4-5

Disassembly and Reassembly
Samsung Electronics4-6
No Parts Procedure Remark
1
2
Common Work
Fan and Motor
1) Loosen the fixing two screws and separate
the cover E-parts.
2) Separate the connection wire from the
terminal block.
3) Loosen five fixing screws and separate the
cabi Upper.
4) Loosen two fixing screws of Ass'y E-part.
5) Loosen nine fixing screws and separate the
cabi side.
1) Do “1”, above.
2) Loosen four screws and seperaate Guard Fan
from front cabinet.
• SH09Z✳5(6)X
• UQ09✳5(6)M✳
• SH07Z✳5(6)X
• UQ07✳5(6)M✳
SH09Z✳5(6)DX
UQ09✳5(6)M✳
SH07Z✳5(6)DX
UQ07✳5(6)M✳
DB81-00181A(4)-1 3/6/11 3:24 PM Page 4-6

Disassembly and Reassembly
4-7Samsung Electronics
No Parts Procedure Remark
3
4
Heat Exchanger
Compressor
2) Remove the nut flange (Turn to the right to
remove, as it is a left hand screw)
3) Separate the fan.
4) Loosen four fixing screws to separate the
motor.
1) Do “1”, 2 above.
2) Loosen two fixing screws of left and right
side.
3) Disassemble the inlet and outlet pipe by
welding.
4) Separate the heat exchanger.
1) Do “1”, above.
2) Loosen the nut on the terminal cover and
open the terminal cover.
3) Disassemble the inlet and outlet pipe of com-
pressor by welding.
4) Disassemble the inlet and outlet pipe of con-
denser by welding.
5) Loosen the three bolts of the lower part.
6) Separate the compressor.
DB81-00181A(4)-1 3/6/11 3:24 PM Page 4-7
