Samsung AR AY5Y Series User manual

Air conditioner
User manual
AR**AY5Y***
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this user manual carefully and retain it for future
reference.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGX YWYWTXYTXWGGG㝘㤸GXWa[WaXY

2
English
Contents
Safety Information 4
Safety Information 4
At a Glance 11
Indoor Unit Overview 11
Display 12
Remote Control Overview 13
Replacing the remote control batteries 13
Remote Control Operation 14
Selecting an operation mode 14
To set the temperature • To adjust the fan speed • To adjust the airflow direction 15
Smart Features 16
Power Smart Features 16
AI Auto mode 16
Auto mode • Cool mode 17
Dry mode • Fan mode 18
Variety Smart Features 19
Fast function 19
5 Step Cooling function • Quiet function 20
Electricity consumption check • Beep function 21
Auto clean function 22
Display lighting function 23
Wi-Fi function (SmartThings app) 24
Time Scheduling 25
Timed on/ Timed off function 25
good'sleep function 26
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGY YWYWTXYTXWGGG㝘㤸GXWa[WaXY

3
English
Cleaning and Maintenance 27
Schedule 27
Cleaning 28
Appendix 31
Troubleshooting 31
SmartThings app 33
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic
accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste
at the end of their working life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local
government office, for details of where and how they can take these items for environmentally safe
recycling.
Business users should contact their supplier and check the terms and conditions of the purchase
contract. This product and its electronic accessories should not be mixed with other commercial wastes
for disposal.
For more information on safe disposal and recycling, visit our website www.samsung.com/in/support or
contact our Helpline numbers - 1800 40 SAMSUNG (1800 40 7267864)
1800 5 SAMSUNG (1800 5 7267864).
Correct disposal of batteries in this product
This marking on the battery, manual or packaging indicates that the batteries in this product should not
be disposed of with other household waste at the end of theirworking life. Where marked, the chemical
symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference
levels in EC Directive 2006/66.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGZ YWYWTXYTXWGGG㝘㤸GXWa[WaXY

4
Safety Information
English
Safety InformationSafety Information
Safety Information
WARNING: Read This Manual
Read and follow all safety information and instructions before installation, use, or maintenance of this
appliance. Incorrect installation, use, or maintenance of this appliance can result in death, serious injury, or
property damage. Keep these instructions with this appliance. This manual is subject to change. For the latest
version, visit www.samsung.com.
Because the instructions in this manual covervarious models, the characteristics of your air conditioner may
differ slightly from those described. If you have any questions, please contact your service provider or visit
www.samsung.com.
Notices and notes
To make you aware of safety messages and highlighted information, we use the following notices and notes
throughout this manual:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
IMPORTANT
Information of special interest
NOTE
Supplementary information that may be useful
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGG[ YWYWTXYTXWGGG㝘㤸GXWa[WaXY

5
English
Safety InformationSafety Information
WARNING: Low burning velocity material
(This appliance is filled with R-32.)
The user and installer guides should be read carefully.
The user and installer guides should be read carefully.
The service guide should be read carefully.
FOR GENERAL
This appliance is not intended foruse by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible fortheir safety. Children
should be supervised to ensure that they do not play with the appliance.
FOR INSTALLATION
WARNING
Use a power cord with this product's powerspecifications or higher and use the power cord for this
appliance only. In addition, do not use an extension cord.
• Extending the power cord may result in electric shock or fire.
• Do not use an electric transformer. This may result in electric shock or fire.
• If the voltage/frequency/rated current condition is different, it may cause fire.
The installation of this appliance must be performed by a qualified technician orservice company.
• Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury
and may also void warranty on the installed product.
Install an Isolation Switch next to the Air Conditioner (but not on the panels of the AirConditioner)
and circuit breaker dedicated to the air conditioner.
• Failing to do so may result in electric shock or fire.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGG\ YWYWTXYTXWGGG㝘㤸GXWa[WaXZ

6
Safety Information
English
Safety InformationSafety Information
Fix the outdoor unit firmly so that the electric part of the outdoorunit is not exposed.
• Failing to do so may result in electric shock, fire, explosion, or problems with the product.
Do not install this appliance near a heater, or inflammable material. Do not install this appliance in a
humid, oily or dusty location, in a location exposed to direct sunlight and water (or rain). Do not install
this appliance in a location where gas may leak.
• This may result in electric shock or fire.
Never install the outdoor unit in a location such as on a high external wall where it could fall.
• If the outdoor unit falls, it may result in injury, death or property damage.
This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic, water
pipe, or telephone line.
• Failing to do so may result in electric shock, fire, and explosion.
• Make sure to use a socket-outlet with ground.
CAUTION
Install your appliance on a level and hard floor that can support its weight.
• Failing to do so may result in abnormal vibrations, noise, or problems with the product.
Install the drain hose properly so that water drains correctly.
• Failing to do so may result in water overflowing and property damage. Avoid adding drain to
waste pipes as odours may arise in the future.
The product shall be stored in a room with no ignition sources (e.g. open flames, gas appliance,
electric heater, etc.).
• Note that the refrigerant has no odour.
When installing the outdoor unit, make sure to connect the drain hose so that draining is performed
correctly.
• The water generated during heating by the outdoor unit may overflow and result in property
damage.
In particular, in winter, if a block of ice falls, it may result in injury, death or property damage.
Do not install the product in a place where thermo-hygrostat is needed (such as server room,
machinery room, computerroom, etc.)
• Those places do not provide guaranteed operation condition of the product therefore
performance can be poor in these places.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGG] YWYWTXYTXWGGG㝘㤸GXWa[WaXZ

7
English
Safety InformationSafety Information
FOR POWER SUPPLY
WARNING
When the circuit breakeris damaged, contact your nearest service centre.
Do not pull or excessively bend the power line. Do not twist ortie the power line. Do not hook the
power line over a metal object, place a heavy object on the power line, insert the power line between
objects, or push the power line into the space behind the appliance.
• This may result in electric shock or fire.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
CAUTION
When not using the air conditioner for a long period of time or during a thunder/lightning storm, cut
the power at the circuit breaker.
• Failing to do so may result in electric shock or fire.
FOR USING
WARNING
If the appliance is flooded, please contact your nearest service centre.
• Failing to do so may result in electric shock or fire.
If the appliance generates a strange noise, a burning smell or smoke, cut off the power supply
immediately and contact the nearest service centre.
• Failing to do so may result in electric shock or fire.
In case of a malfunction, immediately stop operation of the airconditioner and disconnect the entire
power system. Then consult the authorized service personnel.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediatelywithout touching
the power line. Do not touch the appliance or power line.
• Do not use a ventilating fan.
• A spark may result in an explosion or fire.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGG^ YWYWTXYTXWGGG㝘㤸GXWa[WaXZ

8
Safety Information
English
Safety InformationSafety Information
To reinstall the air conditioner, please contact your nearest service centre.
• Failing to do so may result in problems with the product, water leakage, electric shock, or fire.
• Delivery service for the product is not provided. If you reinstall the product in another location,
additional construction expenses and an installation fee will be charged.
• Especially, when you wish to install the product in an unusual location such as in an industrial
area or near the seaside where it is exposed to salt in the air, please contact your nearest service
centre.
Do not touch the circuit breakerwith wet hands.
• This may result in electric shock.
Do not turn the airconditioner off with the circuit breakerwhile it is operating.
• Turning the air conditioner off and then on again with the circuit breaker may cause a spark and
result in electric shock or fire.
After unpacking the air conditioner, keep all packaging materials well out of the reach of children, as
packaging materials can be dangerous to children.
• If a child places a bag over its head, it may result in suffocation.
Do not touch the airflow blade with your hands or fingers during heating.
• This may result in electric shock or burns.
Do not insert your fingers or foreign substances into the air inlet/outlet of the airconditioner.
• Take special care that children do not injure themselves by inserting their fingers into the
product.
Do not strike orpull the air conditionerwith excessive force.
• This may result in fire, injury, or problems with the product.
Do not place an object nearthe outdoor unit that allows children to climb onto the machine.
• This may result in children seriously injuring themselves.
Do not use this air conditioner for long periods of time in badly ventilated locations or near infirm
people.
• Since this may be dangerous due to a lack of oxygen, open a window at least once an hour.
Do not use means to accelerate the defrost operation or to clean, other than those recommended by
Samsung.
Do not pierce or burn.
Be aware that refrigerants may not contain an odour.
If any foreign substance such as water has entered the appliance, cut off the power supply and
contact the nearest service centre.
• Failing to do so may result in electric shock or fire.
Do not attempt to repair, disassemble, or modify the appliance yourself.
• Do not use any fuse (such as copper, steel wire, etc.) other than the standard fuse.
• Failing to do so may result in electric shock, fire, problems with the product, or injury.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGG_ YWYWTXYTXWGGG㝘㤸GXWa[WaXZ

9
English
Safety InformationSafety Information
CAUTION
Do not place objects or devices underthe indoor unit.
• Water dripping from the indoor unit may result in fire or property damage.
Check that the installation frame of the outdoorunit is not broken at least once a year.
• Failing to do so may result in injury, death or property damage.
To prevent personal injury, make sure that you change the directions of the horizontal airflowblades after
stopping the movements of the vertical airflowblade. (In case of adjusting the horizontal airflow manually)
When the air conditioner does not operate properly for cooling or heating, there is a possibility of
refrigerant leakage. If any leakage, stop operation, ventilate the room, and consult your dealer
immediately for recharging refrigerant.
The refrigerant is not harmful. However, if it comes in contact with fire, it may generate harmful
gases and there is risk of fire.
During transportation of the indoor unit, the pipe lines shall be covered with brackets forprotection.
Do not move the product with holding the pipe lines.
• It may cause gas leakage.
Do not install the product in a ship or a vehicle (such as a campervan).
• Salt, vibration or other environmental factor may cause the product malfunction, electric shock or fire.
Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted
cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
• This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
• This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the appliance.
• As well as being harmful to humans, it may also result in electric shock, fire or problems with the
product.
Do not drink the water from the air conditioner.
• The water may be harmful to humans.
Do not hit, shake, drop, or attempt to disassemble the remote control.
When replacing the remote control batteries, keep them out of the reach of infants.
• If an infant eats batteries, contact a doctor immediately.
When replacing the remote control batteries, be careful not to get the battery fluid on your skin.
• Battery fluid is harmful to humans.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGG` YWYWTXYTXWGGG㝘㤸GXWa[WaXZ

10
Safety Information
English
Safety InformationSafety Information
Do not touch the pipes connected with the product.
• This may result in burns or injury.
Do not cut or burn the refrigerant container or pipings.
Do not point the air direction to the fireplace or heater.
Do not use this air conditioner to preserve precision equipment, food, animals, plants or cosmetics, or
for any other unusual purposes.
• This may result in property damage.
Avoid directly exposing humans, animals or plants to the airflowfrom the air conditioner for long
periods of time.
• This may result in harm to humans, animals or plants.
FOR CLEANING
WARNING
Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner or alcohol
to clean the appliance.
• This may result in discolouration, deformation, damage, electric shock or fire.
Before cleaning or performing maintenance, cut off the power supply and wait until the fan stops.
• Failing to do so may result in electric shock or fire.
CAUTION
Take care when cleaning the surface of the heat exchanger of the outdoor unit since it has sharp
edges.
• This should be done by a qualified technician. Please contact your installer or service centre.
Do not clean the inside of the air conditioner byyourself.
• For cleaning inside the appliance, contact your nearest service centre.
• When cleaning the filter, refer to the descriptions in the 'Cleaning' section.
• Failing to do so may result in damage, electric shock or fire.
• Make sure to prevent any injury from sharp edges of the surface when handling the heat
exchanger.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGXW YWYWTXYTXWGGG㝘㤸GXWa[WaXZ

11
English
At a GlanceAt a Glance
Indoor Unit Overview
The appearance of the actual product may differ slightly from the image below.
01
02
03
04
09
05
06
08
07
01 Air intake
02 Air filter
03 Tri-care filter
04 Front panel
05 Airflow blade (up and down)
06 Airflow blade (left and right)
07 Power button/Remote control receiver
08 Room temperature sensor
09 Display
NOTE
• The product ships with Tri-care filter and the
manual included.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGXX YWYWTXYTXWGGG㝘㤸GXWa[WaXZ

12
Indoor Unit Overview
English
At a GlanceAt a Glance
Display
01
02 03 04
01 Temperature indicator (numeric)
Filter reset indicator ( )
Electricity consumption indicator (numeric)
Auto clean indicator ( )
02 AI Auto indicator
03 Timer indicator
good’sleep indicator
04 Wi-Fi indicator
NOTE
• If the Wi-Fi indicator blinks for10 seconds when operation starts, it means that the air conditioner is not
connected to Wi-Fi. See "SmartThings app" on page 33 and connect the air conditioner to Wi-Fi.
• When connected to Wi-Fi, the air conditioner can gather and learn your user patterns so that it can run in
AI Auto mode.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGXY YWYWTXYTXWGGG㝘㤸GXWa[WaXZ

13
English
At a GlanceAt a Glance
Remote Control Overview
08
09
07
01
05
06
15
16
17
19
20
02
03
04
10
11
12
18
13
14
01 Set temperature indicator
02 Timer option indicator
03 Operation mode indicator
04 Options indicator
05 Low battery indicator
06 Transmit indicator
07 Fan speed indicator
08 Vertical air swing indicator
09 Horizontal air swing indicator
10 Power button
11 Temperature button
12 Timer button
13 Fan speed button
14 Direction button/Selection button
15 Vertical air swing button
16 Mode button
17 Fast/5 Step Cooling button
18 Horizontal air swing button
19 Options/Clean button
20 ƊkƟɵЇϩϩͱࢥƟʪΧʪθɇϩЇθʪϩцΧʪɵЇϩϩͱ࣍ঐ幄ঔ࣎
Replacing the remote control batteries
Two 1.5V AAA batteries
Most operating instructions in this manual require using the remote control.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGXZ YWYWTXYTXWGGG㝘㤸GXWa[WaXZ

14
Remote Control Operation
English
At a GlanceAt a Glance
Selecting an operation mode
To change the current mode between Auto, Cool, Dry, and Fan, press
the (Mode) button.
You can use AI Auto mode after Wi-Fi is connected.
NOTE
You can use the Cool, Dry modes in the following operation range.
Mode Cool Dry
Indoor temperature
16 °C to 32 °C 18 °C to 32 °C
Outdoor
temperature
16 °C to 46 °C 16 °C to 46 °C
Indoor humidity Relative humidity of
ߩߡͱθʪϑϑ1࣑_
࣑ࠞÃ˙ϩ˵ʪɇθʀͱʒϩͱʪθͱΧʪθɇϩʪϑAͱͱͱʒʪɇ˵˝˵ࣗ˵Їʒϩц
environment for an extended period of time, condensation may occur.
You can switch between Celsius and Fahrenheit indications on the
remote control.
Press and hold for 3 or more seconds.
NOTE
• The temperature indications on the indoor unit are not switched.
• This function is canceled when the remote control batteries are
replaced. In this case, run this function again.
You can use the air conditioner easily by selecting a mode and then by controlling the temperature, fan
speed, and air direction.
Remote Control Operation
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGX[ YWYWTXYTXWGGG㝘㤸GXWa[WaX[

15
English
At a GlanceAt a Glance
To set the temperature
To control the temperature in each mode, press the (Temperature)
button:
Mode Temperature control
AI Auto/Auto/Cool ʒЇϑϩɵцߢঐ˙θͱߢߧঐϩͱߤߡঐࢋ
Dry ʒЇϑϩɵцߢঐ˙θͱߢߩঐϩͱߤߡঐࢋ
Fan No temperature control.
To adjust the fan speed
Select from the following fan speeds in each mode:
Mode Available fan speeds
AI Auto/Auto/Dry (Auto)
Cool ࣍Їϩͱ࣎ࡡ ࣍øͱи࣎ࡡ ࣍đʪʒ࣎ࡡ ࣍²˝˵࣎ࡡ
࣍ƟЇθɵͱ࣎
Fan ࣍øͱи࣎ࡡ ࣍đʪʒ࣎ࡡ ࣍²˝˵࣎ࡡ ࣍ƟЇθɵͱ࣎
To adjust the airflow direction
Keep the airflow in a constant direction by stopping the movements
of the vertical and horizontal airflow blades.
In operation or
NOTE
• If you adjust the vertical airflow blade manually, it may not close
completely when you turn off the air conditioner.
• Always use the remote control to adjust the airflow blades. Do
not move the blades by hand. They may not operate normally.
• You cannot control the vertical airflow direction in Cool mode
when the good'sleep function is on.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGX\ YWYWTXYTXWGGG㝘㤸GXWa[WaX[

16
Power Smart Features
English
Smart FeaturesSmart Features
Power Smart Features
AI Auto mode
Use AI Auto mode to automatically operate any of Cool, Dry modes
depending on the learned user patterns gathered from an external
server via Wi-Fi module. The favourite temperature and operation
mode are also set based on the current temperatures (indoor/
outdoor) and the gathered user patterns.
  Select Auto.
NOTE
• You can use this mode afterWi-Fi is connected. Otherwise, Auto
mode is activated.
• In AI Auto mode, the (AI Auto) and (Wi-Fi) indicators
appears on the display of the indoor unit.
• If the gathered user patterns are not sufficient, the set
ϩʪΧʪθɇϩЇθʪϑϑʪϩϩͱߣߥঐࢋ
• Ɵ˵ʪϑʪϩϩʪΧʪθɇϩЇθʪϑʀͱϩθͱʪʒиϩ˵ϩ˵ʪθɇ˝ʪͱ˙ߢߧঐϩͱ
ߤߡঐÃЇϩͱͱʒʪࢋǽͱЇʀɇɇϑͱʀ˵ɇ˝ʪϩɇЇɇцࢋ
•Whenyoupress (Mode) in AI Auto mode, the mode is
cancelled.
• If you change the set temperature in AI Auto mode, it
automatically changes back to the AI comfort temperature after
1 hour.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGX] YWYWTXYTXWGGG㝘㤸GXWa[WaX[

17
English
Smart FeaturesSmart Features
Auto mode
Use Auto mode to perform the powerful cooling function to
automatically reach the desired temperature. When the difference
between the room temperature and the set temperature decreases,
the air conditioner controls the fan speed and airflow direction.
  Select Auto.
NOTE
• If Wi-Fi cannot be connected or the Wi-Fi function is not
supported, this Auto mode is automatically activated instead of
AI Auto mode.
• When the room temperature is higher than the set temperature,
the air conditioner automatically produces cool air.
• When the room temperature is lower than the set temperature,
the air conditioner automatically produces warm air.
Cool mode
Use Cool mode to stay cool in hot weather.
  Select Cool.
NOTE
• For comfort, keep the temperature difference between the indoor
ɇʒͱЇϩʒͱͱθɇθиϩ˵ߦঐࢋ
• After selecting Cool mode, select the desired function,
temperature, and fan speed.
ࣕTo cool more quickly, select a lower temperature and a faster
fan speed.
ࣕTo save energy, select a higher temperature and a slower fan
speed.
ࣕAs the room temperature nears the set temperature, the
compressor motor will slow down to save energy.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGX^ YWYWTXYTXWGGG㝘㤸GXWa[WaX\

18
Power Smart Features
English
Smart FeaturesSmart Features
Dry mode
Use Dry mode in rainy or humid weather.
  Select Dry.
NOTE
• The proper set temperature range for dehumidifying operation is
ߣߥϩͱߣߧঐࢋÃ˙цͱЇ˙ʪʪϩ˵ɇϩϩ˵ʪʀЇθθʪϩ˵Їʒϩцϑʪʪϑ˵˝˵ࡡЇϑʪ
a lower set temperature.
Fan mode
Use Fan mode to run the air conditioner like a floor fan, providing a
breeze without cooling.
  Select Fan.
NOTE
• If the air conditioner will not be used for an extended period
of time, run it in Fan mode for 3 to 4 hours to dry the internal
components.
• The outdoor unit does not operate in Fan mode. This is normal
and not a fault with the air conditioner.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGX_ YWYWTXYTXWGGG㝘㤸GXWa[WaX\

19
English
Smart FeaturesSmart Features
Variety Smart Features
Fast function
Use the Fast function to quickly cool your room. This function is the
most powerful cooling function provided by the air conditioner. You
can select this function in Cool mode.
In Cool mode 
NOTE
• You can change the airflow direction, but you cannot change the
set temperature and the fan speed.
• Selecting the Fast function cancels the 5 Step Cooling,
good'sleep, and Quiet functions.
• You can also start the Fast function from the Options menu:
In Cool mode  
Select Fast. 
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGX` YWYWTXYTXWGGG㝘㤸GXWa[WaX\

20
Variety Smart Features
English
Smart FeaturesSmart Features
5 Step Cooling function
Use the 5 Step Cooling function to adjust the cooling speed by
changing the operation rate of the outdoor unit.
In Cool mode 
NOTE
• Each time you press the button in Cool mode, you can
adjust the operation rate of the outdoor unit in 5 steps.
ࣕ Ãϩϑиϩʀ˵ʪϑϩ˵ʪ˙ͱͱи˝ͱθʒʪθࡠߩߡߧߡߥߡߢߣߡ
Aͱͱͱʒʪࢋ
• In the entry to the 5 Step Cooling function, the outdoor unit
ͱΧʪθɇϩʪϑɇϩߩߡͱ˙ͱΧʪθɇϩͱθɇϩʪɇʒϩ˵ʪЭʪθϩʀɇɇθϑи˝ͱ˙
the indoor unit starts.
• You can adjust the desired temperature, fan speed, and airflow
direction.
• Ǯ˵ʪϩ˵ʪͱΧʪθɇϩͱθɇϩʪͱ˙ϩ˵ʪͱЇϩʒͱͱθЇϩϑϑʪϩϩͱɇцͱ˙ߩߡࡡ
ߧߡࡡɇʒߥߡࡡцͱЇʀɇϑɇЭʪʪʪθ˝цʀͱͱ˝ࢋ
• When there are many people at the room in hot weather, select
ߢߣߡͱ˙ͱΧʪθɇϩͱθɇϩʪ˙ͱθϑϩθͱ˝ʀͱͱ˝ࢋ
• When using the 5 Step Cooling function, the operating rate
displayed on the remote controller and the actual power
consumption ratio of the product maybe different depending on
the indoor/outdoor temperature environment.
Quiet function
Use the Quiet function to reduce the unit’s operating noise. You can
select this function in Cool mode.
In Cool mode  
Select Quiet. 
NOTE
• You can change the set temperature and the airflow direction,
but you cannot change the fan speed.
• Selecting the Quiet function cancels the 5 Step Cooling,
good'sleep, and Fast functions.
yhjW]\TWWpihy`\WW{G㡔䗁nlv{sluT~liUGGGYW YWYWTXYTXWGGG㝘㤸GXWa[WaX\
