INSTALLATION
MANUAL
Convertible Type Series
Ceiling/Floor : AVXTF 
Air Conditioner
PORTUGUÊS
D
AVXTF_IM_E_27691-1.indd 29 2007-4-20 16:56:51

E-2
Contents
Safety Precautions ............................................................................................................ 3
Accessories ............................................................................................................................ 6
Selecting the Installation Location ....................................................................... 7
Ceiling Installation ............................................................................................................ 9
Floor Installation ................................................................................................................ 10
EEV Kit Installation ............................................................................................................ 11
Purging the Unit ................................................................................................................ 15
Connecting the Refrigerant Pipe ............................................................................ 15
Cutting/Flaring the Pipes ............................................................................................. 16
Performing Leak Test & Insulation ......................................................................... 17
Drain Hose Installation .................................................................................................. 19
Wiring Work ........................................................................................................................... 20
 Indoor Unit Setting .......................................................................................................... 23
Additional Functions ....................................................................................................... 24
Final Checks and User Tips .......................................................................................... 25
Troubleshooting ................................................................................................................ 26
AVXTF_IM_E_27691-1.indd 2 2007-4-20 16:56:35

E-3
ENGLISH
The following safety precautions must be taken when using your air conditioner.
WARNING
• Risk of electric shock can cause injury or death. • Disconnect all remote
electric power supplies before servicing, installing or cleaning.
• Installation must be done by the manufacturer or service agent or a
similar qualified person in order to avoid a hazard.
INSTALLING THE UNIT
 The unit should not be installed by the user. Ask the dealer or
authorized company to install the units.
 If the unit is installed improperly, water leakage, electric shock or fire
may result.
 Mount with the lowest moving parts at least 2.5 m above the floor or
grade level. (If applicable)
 The manufacturer does not assume responsibility for accidents or
injury caused by an incorrectly installed air conditioner. If you are
unsure about installation, contact an installation specialist.
 When installing the built-in type air conditioner, keep all electrical
cables such as the power cable and the connection cord in pipe, ducts,
cable channels e.t.c to protect them against liquids, outside impacts
and so on.
 This appliance is not accessible to the general public. This appliance
should be installed according to the provided installation instruction.
 When installing the air conditioner in a small room, the measure not to
exceed the dangerous density is needed.
- When refrigerant leaks and exceeds the dangerous density,
suffocation may occur.
 If any gas or impurities except R410A refrigerant come into the
refrigerant pipe, serious problem may occur and it may cause injury.
 Use only rated accessories and install the air conditioner with rated
equipments.
- If you dont’t use the rated accessories, the air conditioner may
drop from its place, water may leak or electric shock or fire may occur.
 Ventilate your room when refrigerant gas leaks during installation.
- Toxic gas may generate when refrigerant gas contacts with heat.
Safety Precautions
AVXTF_IM_E_27691-1.indd 3 2007-4-20 16:56:35

E-4
POWER SUPPLY LINE OR CIRCUIT BREAKER
 If the power cable of this air conditioner is damaged, it must be
replaced by service agent or similarly qualified persons in order to
avoid a hazard.
 The unit must be plugged into an independent circuit if applicable or
connect the power cable to the auxiliary circuit breaker. An all pole
disconnection from the power supply must be incorporated in
the fixed wiring with a contact opening of >3mm.
 The air conditioner must be installed in accordance with national
wiring regulations and safety regulations wherever applicable.
 The electric work must be done by service agent or similarly qualified
persons according to national wiring regulations and use only rated
cable.
- If the capacity of the power cable is insufficient or electric work
is not properly completed, electric shock or fire may occur.
 Install the cables with supplied cables firmly. Fix them securely so
that external force is not exerted to the terminal board.
- If the connection or fixing is incomplete, heat generation,
electric shock or fire may occur.
 Connect the power cable between the indoor and outdoor unit
properly so that the electrical component box cover is not get loosen
and attach the cover securely.
- If the the cover is attached incompletely, heat generation,
electric shock or fire of the terminal board may occur.
Safety Precautions (Continued)
AVXTF_IM_E_27691-1.indd 4 2007-4-20 16:56:35

E-5
ENGLISH
 Make sure that you earth the cables.
- Do not connect the earth wire to the gas pipe, water pipe, lighting
rod or telephone wire. If earthing is not complete, electric shock or
fire may occur.
 Install the circuit breaker.
- If the circuit breaker is not installed, electric shock or fire may occur.
 Make sure that the condensed water dripping from the drain hose
runs out properly and safely.
 Install the power cable and communication cable of the indoor and
outdoor unit at least 1m away from the electric appliance.
 Install the indoor unit away from lighting apparatus using the ballast.
- If you use the wireless remote control, reception error may occur
due to the ballast of the lighting apparatus.
 Do not install the air conditioner in following places.
- Place where there is mineral oil or arsenic acid
Resin parts flame and the accessories may drop or water may leak.
The capacity of the heat exchanger may reduce or the air conditioner
may be out of order.
- The place where corrosive gas such as sulfurous acid gas generates
from the vent pipe or air outlet
The copper pipe or connection pipe may corrode and refrigerant
may leak.
- The place where there is a machine that generates electromagnetic
waves
The air conditioner may not operate normally due to control
system.
- The place where there is a danger of existing combustible gas,
carbon fiber or flammable dust
The place where thinner or gasoline is handled
Gas may leak and it may cause fire.
Safety Precautions (Continued)
AVXTF_IM_E_27691-1.indd 5 2007-4-20 16:56:35

E-6
Accessories
The following accessories are supplied with the indoor unit.
The type and quantity may differ depending on the specifications.
Pattern sheet User's manual Installation manual
Plate Hanger Cable-Tie
AVXTF_IM_E_27691-1.indd 6 2007-4-20 16:56:36

E-7
ENGLISH
Selecting the Installation Location
Indoor Unit
 Select a convenient location that permits the air to reach every corner of the
area to be cooled.
 Pre-plan for easy and short routing of the refrigerant tubing and wiring to
the outdoor unit.
 There should be no flammable gas, alkaline, substances present in the air.
 Avoid location where obstacles preventing good air circulation are present.
 Noise prevention should be considered in determining the unit's location.
 The structure, where the unit is to be installed should be strong enough to
support the weight of the unit.
 Rigid wall without vibration.
 Where it is not exposed to direct sunshine.
 Where the air filter can be removed and cleaned easily.
Space Requirements for Indoor Unit
Floor installation
300mm
300mm
Ceiling installation
300mm
50mm
AVXTF_IM_E_27691-1.indd 7 2007-4-20 16:56:36

E-8
Selecting the Installation Location (Continued)
Dimension of the indoor unit

 





Unit : mm
Back side
P ip e o u tle t
(b o tto m s id e )
A ir in ta k e h o le ( 5 0 )
W irin g h o le
D ra in h o s e o u tle t





Pipe outlet-(bottom side)
Drain hose outlet
Wiring hole
Air intake hole (Ø50)
No. Name Description
1 Liquid pipe connection
056ø6.35 (1/4”)
071ø9.52 (3/8”)
2 Gas pipe connection
056ø12.70 (1/2”)
071ø 15.88 (5/8”)
3 Drain pipe connection ID ø 18 Hose
AVXTF_IM_E_27691-1.indd 8 2007-4-20 16:56:37

E-9
ENGLISH
�
Connection pipe
Drain hose
Connection pipe
Drain hose
300mm or more
300mm or more
 





Back side
Unit : mm
It is recommend to install Y-joint before installing the indoor unit.
1Select pipe directions.
When the directions are selected, drill 3-1/8''-(100mm, for pipe and cables)
and 1-3/4''-(40mm, for drain hose) diameter holes on the wall so that it
slants slightly downwards toward the outdoor for smooth water flow.
Note Use the pattern sheet to select pipe directions.
2Drill holes for anchor bolts according to the distance and mount them.
Note Use the pattern sheet.
3Install the unit onto the ceiling. Be sure to arrange the drain hose so that it is
leveled lower than the drain hose connecting port of the indoor unit.
Note For proper drainage of condensate, give a 2° slant to the side of the
unit which will be connected with the drain hose as shown in the
figure.
CAUTION Ensure that the ceiling is strong enough to support the
weight of the indoor unit. Before hanging the unit,
test the strength of each attached suspension bolt
4If installing on dropped ceiling, install threaded rod onto anchor
bolt-(expansion bolt) to long enough to suspend the unit right below the
dropped ceiling and the install the unit suspending on the threaded rod.
Ceiling Installation
AVXTF_IM_E_27691-1.indd 9 2007-4-20 16:56:38

E-10
Floor Installation
1Select pipe directions.
When the directions are selected, drill 3-1/8'' (100mm, for pipe and cables)
and 1-3/4'' (40mm, for drain hose) diameter holes on the wall so that it
slants slightly downwards toward the outdoor for smooth water flow.
Note Use the pattern sheet to select pipe directions.
2Install the hanging plate according to the distance and mount it.
3 Install the unit and be sure to arrange the drain hose so that it is leveled lower
than the drain hose connecting port of the indoor unit.
Drain hose
Drain hose
300mm
or more
300mm
or more






Back side
Unit : mm
AVXTF_IM_E_27691-1.indd 10 2007-4-20 16:56:38

E-11
ENGLISH
EEV Kit Installation
Preparing for Installation
1Check dimension and installation location.
2Check installation place.
By using a pattern sheet, check required installation space.
Concrete
Suspension bolt(3/8" or M10)-field supply
Hole in anchor
Hole in plug
Insert









  




 










 

450mm X 200mm or more
(Maintenance Hole)

Maintenance hole must be located on
the ceiling.
Indoor unit pipe
connection
Outdoor uint pipe
connection
Drain hole
Required maintenance
space
Required
maintenance space
Required maintenance
space
Required
maintenance space
Unit : mm
AVXTF_IM_E_27691-1.indd 11 2007-4-20 16:56:39

E-12
Connection of refrigerant piping & Insulation
1Insert bot anchors, use existing ceiling supports or construct
a suitable support.
CAUTION
Ensure the ceiling is strong enough to support the
weight of the indoor unit. Before hanging the unit,
test the strength of each attached suspension bolt.
2Connect the “IN” refrigerant pipe to the outdoor unit.
3Connect the “OUT” refrigerant pipe to each indoor unit(A, B and C).
The liquid and gas pipes should not be crossed when piping connection.
4Insulate the connection piping. A joint part of pipe needs double
thickness of insulation.
5The EEV kit has to be installed that the user has no access to it. (built-in type)
EEV Kit body
Nylon band
EEV Kit Installation (Continued)
AVXTF_IM_E_27691-1.indd 12 2007-4-20 16:56:40

E-13
ENGLISH
EEV Kit Installation (Continued)
A B C
Wiring & Assigning address
Room A
Room B
Outdoor
unit
Another
EEV Kit
1Connect the AC power cable and communication cable from the outdoor
unit to terminal, then connect the cable to another EEV kit.
2Connect the AC power cable and communication cable to each indoor unit
(A, B and C).
3EEV kit address should be set same with connected indoor units main
address.
For Example When Main address is set as “03” that connected in pipe “A”,
the EEV kit “A” address should be set as “03”.
A
AVXTF_IM_E_27691-1.indd 13 2007-4-20 16:56:41

E-14
If you press a KEY on the PCB, the display will show you a step of appropriate
EEV Kit.
EEV Kit Installation (Continued)
Function of Display
KEY function
KEY No. Meaning Example
K1 Step of EEV Kit A
19 (19 x 10 = 190 STEP) K2 Step of EEV Kit B
K3 Step of EEV Kit C
K4 - -
The numbers which are displayed on left are the status of indoor unit checking
status through communication with same outdoor unit.
(If it indicates 1, 3 and 7, that means the ADDRESS of indoor unit is set to 1, 3 and 7.)
The numbers which are displayed on right indicate the ADDRESS of SW01/SW02,
SW03/SW04 and SW05/SW06 in sequential. (If it indicates 0, 1 and 2, that means the
SW01/SW02 is set to 0, the SW03/SW04 is set to 1, and the SW05/SW06 is set to 2.)
If the communication error occurs in EEV Kit, the ErC0 message will be shown on
the display alternatively.
Each indoor unit runs separately to check pipe connection and address setting.
Test run
 If all units run at the same time, pipe cross connection and address
mismatching cannot be found.
CAUTION
AVXTF_IM_E_27691-1.indd 14 2007-4-20 16:56:41

E-15
ENGLISH
Purging the Unit
On delivery, the indoor unit is loaded with an inert Nitrogen gas.
All this gas must therefore be purged before connecting the assembly piping.
To purge the inert gas, proceed as follows.
1Unscrew the caps at the end of each pipe.
Result: All inert gas escapes from the indoor unit.
Note To prevent dirt or foreign objects from getting into the pipes
during installation, do NOT remove the caps completely until you are
ready to connect the piping.
Connecting the Refrigerant Pipe
There are two refrigerant pipes of differing diameters:
 A smaller one for the liquid refrigerant
 A larger one for the gas refrigerant
 The inside of copper pipe must be clean & has no dust
1
Before connecting the refrigerant pipe, open the cover side.
2
Remove the pinch pipe on the pipes and connect the assembly pipes
to each pipe, tightening the nuts, first manually and then with a torque
wrench, a spanner applying the following torque.
Outer Diameter Torque (kgf•cm)
6.35 mm (1/4") 145~175
9.52 mm (3/8") 333~407
12.70 mm (1/2") 505~615
15.88 mm (5/8") 630~769
Must apply refrigerant oil on the flaring area to prevent
a leak.
Note
3
Be sure that there must be no crack or kink on the bended area.
Refrigerant oil
Torque wrench
Flare nut
Union
Spanner
AVXTF_IM_E_27691-1.indd 15 2007-4-20 16:56:42

E-16
Cutting/Flaring the Pipes
1
Make sure that you prepared the required tools. (pipe cutter, reamer, flaring
tool and pipe holder)
2
If you want to shorten the pipe, cut it using a pipe cutter ensuring that the
cut edge remains at 90° with the side of the pipe. There are some
examples of correctly and incorrectly cut edges below.
3
To prevent a gas leak, remove all burrs at the cut edge of the pipe using a
reamer.
4
Carry out flaring work using flaring tool as shown below.
Outer diameter
(mm)
A(mm)
Flare tool for
R410A clutch type
Conventional flare tool
Clutch type Wing nut type
6.35 0~0.5 1.0~1.5 1.5~2.0
9.52 0~0.5 1.0~1.5 1.5~2.0
12.70 0~0.5 1.0~1.5 1.5~2.0
15.88 0~0.5 1.0~1.5 1.5~2.0
5
Check if you flared the pipe correctly. There are some examples of
incorrectly flared pipes below.
6Outer diameter
(mm)
Connection
Torque (kgf•cm)
Flare dimension
(mm) Flare shape
6.35 145~175 8.70~9.10
9.52 333~407 12.80~13.20
12.70 505~615 16.20~16.60
15.88 630~769 19.30~19.70
O
Oblique
X
Rough
X
Burr
X
Inclined Damaged Surface Cracked Uneven Thickness
X X X X
Flaring tool
Clutch type Wing nut type
A
Die
Copper pipe
York
Die
Copper pipe
Flare nut
R 0.4~0.8
90° ±2°
45° ±2°
 In case of needing brazing, you must work with Nitrogen gas blowing.
CAUTION
AVXTF_IM_E_27691-1.indd 16 2007-4-20 16:56:43

E-17
ENGLISH
Performing Leak Test & Insulation
To check for gas leaks on the indoor unit, check the connection part of
each refrigerant pipe by using Nitrogen gas.
Note See details on the outdoor unit installation manual for leak test.
Leak Test
Leak check
 The designs and shape are subject to
change according to the model.
Insulation
Once you have checked that there are no leaks in the system, you can
insulate the piping and hose.
1 Insulate the refrigerant pipe.
Be sure to run the power supply cable and the communication cable
through electrical conduit as seen in the picture.
- If you insulate the pipes, the condensed water does not fall from the
pipes and the capacity of the air conditioner is improved.
 Check if there are any insulation cracks on the bent pipe.
Insulation
Gas side pipe
Liquid side pipe
Insulation
Clamp
Fix it not to be get wider
Install the insulation
to be overlapped
Indoor unit
Insulation
AVXTF_IM_E_27691-1.indd 17 2007-4-20 16:56:43

E-18
Performing Leak Test & Insulation (Continued)
2 Select the insulator of the refrigerant pipe.
 Insulate the gas side and liquid side pipe referring to the thickness
according to the pipe size.
 The thickness according to the pipe size is a standard of the indoor
temperature of 27°C and humidity of 80%.
If installing in an unfavorable conditions, use thicker one.
 Insulator’s heat-resistance temperature should be more than 120℃.
Pipe size
(mm)
Minimum thickness
of insulator (mm) Remarks
PE foam EPDM foam
Ø6.35~Ø15.88 13 10 If you install the pipe underground,
at the seaside, a spa or on the lake,
use 1 grade thicker one according
to the pipe size.
- 25 19
Refrigerant pipe before EEV kit and MCU or without EEV kit and MCU
 You can contact the gas side and liquid side pipes but the pipes
should not be pressed.
 When contacting the gas side and gas side pipe, use 1 grade thicker
insulator.
Refrigerant pipe after EEV kit and MCU
 Install the gas side and liquid side pipes, leave 10mm of space.
 When contacting the gas side and liquid side pipe, use 1 grade
thicker insulator.
 Install the insulation not to get wider and use the adhesives
on the connection part of it to prevent moisture from entering.
 Wind the refrigerant pipe with insulation tape if it is exposed to
outside sunlight.
 Install the refrigerant pipe respecting that the insulation does not
get thinner on the bent part or hanger of pipe.
 Add the additional insulation if the insulation plate gets thinner.
Additional insulation Hanger
Refrigerant pipe insulation
a×3
a
Gas pipe
10mm
Liquid pipe
Gas pipe
Liquid pipe
Insulation
Insulation
10mm 10mm
AVXTF_IM_E_27691-1.indd 18 2007-4-20 16:56:44

E-19
ENGLISH
Drain Hose Installation
Care must be taken when installing the drain hose for the indoor unit to ensure that any condensation water is
correctly drained outside. When passing the drain hose through the hole drilled in the wall, check that none of
the following situations occur.
The hose must NOT
slope upwards.
The end of the drain
hose must NOT be
placed in water.
Do NOT bend the
hose in different
directions.
Keep a clearance of at
least 5-cm between
the end of the hose
and the ground.
5cm
less
Do NOT place the end
of the drain hose in a
hollow.
Ditch
If draining pipe is not too long.
It may be extended the draining pipe by connecting as following figure.
AVXTF_IM_E_27691-1.indd 19 2007-4-20 16:56:44

E-20
Wiring Work
Silver solder
N L
N L N L N L
Indoor Unit 1
Outdoor Unit
Indoor Unit 2 Indoor Unit 3
Wired Remote
Controller
220-240V~
 ELB : Essential Installation
EEV kit
Indoor Unit 4 Indoor Unit 5 Indoor Unit 6
 Ceiling, wall-mounted indoor unit.
Selecting compressed ring terminal
1Before wiring work, you must turn off all power source.
2Indoor unit power should be supplied through the breaker(MCCB, ELB) separated by the outdoor power.
3The power cable should be used only copper wires.
4Connect the power cable{1(L), 2(N)} among the units within maximum length and communication cable(F1, F2) each.
5Connect V1, V2(for DC12V) and F3, F4(for communication) when installing the wired remote controller.
Power and communication cable connection
Norminal
dimensions for
cable (mm2)
Norminal
dimensions for
screw (mm)
B D d1 E F L d2 t
Standard
dimension
(mm)
Allowance
(mm)
Standard
dimension
(mm)
Allowance
(mm)
Standard
dimension
(mm)
Allowance
(mm)
Min. Min. Max.
Standard
dimension
(mm)
Allowance
(mm)
Min.
1.5 4 6.6 ±0.2 3.4 +0.3
-0.2 1.7 ±0.2 4.1 6 16 4.3 +0.2 00.7
4 8
2.5 4 6.6 ±0.2 4.2 +0.3
-0.2 2.3 ±0.2 6 6 17.5 4.3 +0.2 00.8 4 8.5
4 4 9.5 ±0.2 5.6 +0.3
-0.2 3.4 ±0.2 6 5 20 4.3 +0.2 00.9
AVXTF_IM_E_27691-1.indd 20 2007-4-20 16:56:45
