Samsung Max Heat 2.0 Instruction manual

RAC for North America
(INV, R410A, 60Hz, HP)
RAC
Technical
Data Book
Model : AR**TSF*BWKNCV (Indoor Unit)
AR**TSF**WKXCV (Outdoor Unit)

2
Version Modification Date Remark
Ver.1.0 Released RAC for North America
(Wind-Free 2.0, Quantum 2.0, Max Heat 2.0) 19. 12. 20
Ver.1.1 Updated Model Name including US Code 20. 01. 29
Ver.1.2 Updated the power data (MCA/MOP) in specification pages 20. 02. 14
Ver.1.3 Updated the capacity table pages 20. 03. 26
Ver.1.4 Updated the capacity table pages 20. 04. 08
Ver.1.5 Updated the capacity table pages 20. 05. 14
History

3
(1) Classification
AR RAC
(2) Capacity
x1000 Btu/h
(3) Year
T2020
(4) Product Type
SINVERTER HP R410A
(5) Characteristics
CMotion Detect Sensor +Wi-Fi +
Tri-care Filter
EWi-Fi + Tri-care Filter
FWi-Fi
H-
(6) Design Segment
AWind-Free™ 2.0
YQuantum 2.0
(7) Version
A-Z (1 digit)
(8) Color
WK DA White
(9) Set
NIndoor Unit
XOutdoor Unit
/Set
Nomenclature
Model Name
AR
(1)
09
(2)
T
(3)
S
(4)
F
(5)
A
(6)
B
(7)
WK
(8)
N
(9)
CV
Buyer

4
ࡒƟ˵ʪǮʒࣛθʪʪঊЇϩʒʪЭʪθϑɇɇθʀЇθθʪϩϩ˵ɇϩϑЇʒʪθߢ࢏ߣߧࢩϑи˵ʪǮʒࣛθʪʪঊͱʒʪ࢏θЭʪͱʀϩцϩ˵ɇϩϑ
ɵʪͱиߢ࢏ߣߧࢩϑϑʀͱϑʒʪθʪʒ࢕ϑϩɇθ࢕ɇϑʒʪ˙ʪʒɵцƊ²ŵkߧߧࣛߤߢߣߥ࣑ʪθʀɇƊͱʀʪϩцͱ˙²ʪɇϩ˝ࡥŵʪ˙θ˝ʪθɇϩ˝ࡥ
ɇʒθࣛAͱʒϩͱ˝k˝ʪʪθϑ࣒࢏
Line-up
Indoor Unit
Model Type Design Image
Max Heat 2.0
Wind-Free™ 2.0 Wind-Free
Quantum 2.0 -
Model Type Design
Capacity (kBtu/h)
9121824
Max Heat 2.0
Wind-Free
弍弍弍弍
Wind-Free™ 2.0 弍弍弍弍
Quantum 2.0 - 弍弍弍弍

5
ࡒƟ˵ʪǮʒࣛθʪʪঊЇϩʒʪЭʪθϑɇɇθʀЇθθʪϩϩ˵ɇϩϑЇʒʪθߢ࢏ߣߧࢩϑи˵ʪǮʒࣛθʪʪঊͱʒʪ࢏θЭʪͱʀϩцϩ˵ɇϩϑ
ɵʪͱиߢ࢏ߣߧࢩϑϑʀͱϑʒʪθʪʒ࢕ϑϩɇθ࢕ɇϑʒʪ˙ʪʒɵцƊ²ŵkߧߧࣛߤߢߣߥ࣑ʪθʀɇƊͱʀʪϩцͱ˙²ʪɇϩ˝ࡥŵʪ˙θ˝ʪθɇϩ˝ࡥ
ɇʒθࣛAͱʒϩͱ˝k˝ʪʪθϑ࣒࢏
Model Type Design
Capacity (kW)
91218 24
Max Heat 2.0
Wind-Free
Wind-Free™ 2.0
Quantum 2.0 -
Line-up
Outdoor Unit

6
Contents
1. Specification 7
2. Capacity Table 13
3. Dimensional Drawing 25
4. Center of Gravity 32
5. Electrical Wiring Diagram 35
6. Sound Data 38
7. Temperature and air flow distribution 43
8. Piping Diagram 47
9. Operation Limit 48
10. Capacity Correction 49
11. Installation 51

7
1. Specification
Model Name Indoor Unit
AR09TSFYBWKNCV AR12TSFYBWKNCV AR18TSFYBWKNCV AR24TSFYBWKNCV
Outdoor Unit
AR09TSFYBWKXCV AR12TSFYBWKXCV AR18TSFYBWKXCV AR24TSFYBWKXCV
US Code Indoor Unit
RNS09YBT RNS12YBT RNS18YBT RNS24YBT
Outdoor Unit
RXS09YBT RXS12YBT RXS18YBT RXS24YBT
System
Mode
-
HEAT PUMP HEAT PUMP HEAT PUMP HEAT PUMP
Performance
Capacity
(Min/Std/Max)
Cooling
kW
0.88 / 2.64 / 3.52 0.88 / 3.52 / 4.25 1.61 / 5.28 / 6.45 2.58 / 6.45 / 8.5
Btu/h
3,000 / 9,000 / 12,000 3,000 / 12,000 /14,500 5,500 / 18,000 / 22,000 8,800 / 22,000 / 29,000
US RT
0.25 / 0.75 /1.0 0.25 / 1.0 /1.21 0.46 /1.5 / 1.83 0.73 /1.83 / 2.42
Heating
kW
0.66 / 3.22 / 5.57 0.76 / 3.52 / 5.86 1.17 / 6.15 / 7.18 2.2 / 7.03 /11.72
Btu/h
2,250 / 11,000 /19,000 2,600 / 12,000 / 20,000 4,000 / 21,000 / 24,500 7,500 / 24,000 / 40,000
US RT
0.19 / 0.92 / 1.58 0.22 / 1.0 / 1.67 0.33 /1.75 / 2.04 0.62 / 2 / 3.33
Power
PowerInput
(Min/Std/Max)
Cooling kW
0.18 / 0.65 / 1.15 0.18 /1.0 /1.33 0.3 / 1.63 /1.98 0.52 / 2.1 / 3.0
Heating kW
0.15 / 0.87 / 2.05 0.16 / 0.96 / 2.1 0.27 / 1.85 / 2.0 0.48 / 2.29 / 4.3
Current Input
(Min/Std/Max)
Cooling A
1.2 / 3.1 / 5.4 1.2 / 4.8 / 6.2 2.0 / 7.4 / 9.2 2.7 / 9.8 / 13.5
Heating A
1.0 / 4.2 / 9.1 1.1 / 4.6 / 9.3 2.2 / 8.2 / 9.0 2.6 / 10.5 /18.9
Current
MCA A
12 12.5 16 20
MOP A
20 20 25 30
Efficiency
EER Cooling
(Btu/h)/W
13.95 12.05 11.05 10.50
COP Heating W/W
3.75 3.65 3.35 3.07
SEER (Cooling Energy Grade) (Btu/h)/W
23.5 21.5 20.0 18.0
HSPF (Heating Energy Grade) (Btu/h)/W
12.0 12.0 11.0 9.0
Piping
Connections
Liquid Pipe
Type
Flare connection Flare connection Flare connection Flare connection
ףࡥ࣑ʀ˵࣒
6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4)
Gas Pipe
Type
Flare connection Flare connection Flare connection Flare connection
ףࡥ࣑ʀ˵࣒
9.52 (3/8) 9.52 (3/8) 12.7 (1/2) 15.88 (5/8)
Heat Insulation -
Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Installation
Limitation
Max. Length
(Outdoorto indoor)
m
20 20 30 30
ft
66 66 98 98
Max. Height
(Between ID/OD)
m
15 15 20 20
ft
49 49 66 66
Wiring
connections
Communication Min.
mm²
0.75 0.75 0.75 0.75
Remark -
F1, F2 F1, F2 F1, F2 F1, F2
Power Supply -
Outdoorunit powers indoor unit Outdoorunit powers indoor unit Outdoorunit powers indoor unit Outdoor unit powers indoorunit
Refrigerant
Type
-
R410A R410A R410A R410A
Factory Charging
kg
111.31.8
lbs
2.2 2.2 2.87 3.97
Indoor Unit
Power Supply
ŝࡥ࢈ࡥǤࡥ²і
1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60
Heat
Exchanger
Type
-
F&T F&T F&T F&T
Material Fin
-
Al Al Al Al
Tube -
Cu Cu Cu Cu
Fin Treatment -
Green Hydrophile Green Hydrophile Green Hydrophile Green Hydrophile
Fan
Type
-
Cross Flow Cross Flow Cross Flow Cross Flow
Quantity EA
111 1
Air Flow Rate
Cooling (T/H/M/L)
CMM
10.5 /10 / 9.5 / 8.5 10.9 / 10.5 / 9.5 / 8.5 16.5 / 15.8 /14.4 / 13 18.6 / 17.2 / 15.1 / 13
CFM
370.8 / 353.15 / 335.49 / 300.17 384.93 / 370.8 / 335.49 / 300.17 582.69 / 557.97 / 508.53 / 459.09 656.85 / 607.41 / 533.25 / 459.09
Heating (T/H/M/L)
CMM
11.4 /10.9 / 10.5 / 9.5 11.9 / 11.4 /10.5 / 9.5 16.5 / 15.8 /14.4 / 13 18.6 / 17.2 / 15.1 / 13
CFM
402.59 / 384.93 / 370.8 / 335.49 420.24 / 402.59 / 370.8 / 335.49 582.69 / 557.97 / 508.53 / 459.09 656.85 / 607.41 / 533.25 / 459.09
Fan Motor Type
-
BLDC BLDC BLDC BLDC
Output W x n
27 x 1 27 x 1 27 x 1 27 x 1
Drain Drain Pipe ףࡥ mm
16.3, 550 16.3, 550 16.3, 550 16.3, 550
Sound Sound Pressure
Level H / Silent
dB(A)
37 / 20 38 / 20 41 / 28 45 / 30
External
Dimension
Net Weight
kg
9.1 9.1 11.5 11.5
lbs
20.1 20.1 25.4 25.4
Shipping Weight
kg
10.4 10.4 13.1 13.2
lbs
22.9 22.9 28.9 29.1
Net Dimensions (WxHxD)
mm
820 x 299 x 215 820 x 299 x 215 1,055 x 299 x 215 1,055 x 299 x 215
inch
32.3 x 11.8 x 8.5 32.3 x 11.8 x 8.5 41.5 x11.8 x 8.5 41.5 x 11.8 x 8.5
Shipping Dimensions (WxHxD)
mm
880 x 290 x 375 880 x 290 x 375 1,115 x 290 x 375 1,115 x 290 x 375
inch
34.6 x 11.4 x 14.8 34.6 x 11.4 x 14.8 43.9 x 11.4 x 14.8 43.9 x 11.4 x 14.8
Casing Material -
HIPS HIPS HIPS HIPS
Control System
Infrared remote control -
Included Included Included Included
Wired remote control -
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
Drain Pump Drain Pump
-
--- -
Max. lifting Height / Displacement mm / Liter/h
--- -
Additional
Accessories Drain Pump
External Model
-
--- -
Internal Model -
--- -
Max. lifting Height /
Displacement
mm / Liter/h
--- -
1. Specification
Quantum 2.0

1. Specification
8
Model Name Indoor Unit
AR09TSFYBWKNCV AR12TSFYBWKNCV AR18TSFYBWKNCV AR24TSFYBWKNCV
Outdoor Unit
AR09TSFYBWKXCV AR12TSFYBWKXCV AR18TSFYBWKXCV AR24TSFYBWKXCV
US Code Indoor Unit
RNS09YBT RNS12YBT RNS18YBT RNS24YBT
Outdoor Unit
RXS09YBT RXS12YBT RXS18YBT RXS24YBT
Indoor Unit Additional
Accessories
Easy Filter Plus
-
Removable / Washable Removable / Washable Removable / Washable Removable / Washable
Tri-Care Filter -
--- -
Motion Detect Sensor -
--- -
Wi-Fi -
弋弋弋 弋
Outdoor
Unit
Power Supply
ŝࡥ࢈ࡥǤࡥ²і
1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60
Heat
Exchanger
Type
-
F&T F&T F&T F&T
Material Fin
-
Al Al Al Al
Tube -
Cu Cu Cu Cu
Fin Treatment -
Anti-Corrosion Anti-Corrosion Anti-Corrosion Anti-Corrosion
Compressor
Model Name
KTN130D42UFR KTN130D42UFR UG9TK3150FE4 UG8TH8265FEW
Type -
BLDC ROTARY BLDC ROTARY BLDC ROTARY BLDC ROTARY
Output kW
4.09 4.09 4.57 7.29
Oil Type
-
POE POE POE POE
Initial charge cc
350 350 500 700
Fan
Type
-
Propeller Propeller Propeller Propeller
Discharge direction -
Front Front Front Front
Quantity EA
111 1
Air Flow Rate
CMM
45 45 50 67
CFM
1,589 1,589 1,766 2,365
Fan Motor Type
-
BLDC BLDC BLDC BLDC
Output W x n
40 x 1 40 x 1 40 x 1 125 x 1
Sound Sound Pressure
Level Cooling
dB(A)
45 46 51 56
External
Dimension
Net Weight
kg
31.7 31.7 39.5 55.6
lbs
69.9 69.9 87.1 122.6
Shipping Weight
kg
33.9 33.9 42.6 59.2
lbs
74.7 74.7 93.9 130.5
Net Dimensions (WxHxD)
mm
790 x 548 x 285 790 x 548 x 285 880 x 638 x 310 880 x 798 x 310
inch
31.1 x 21.6 x11.2 31.1 x 21.6 x11.2 34.6 x 25.1 x12.2 34.6 x 31.4 x12.2
Shipping Dimensions (WxHxD)
mm
913 x 622 x 371 913 x 622 x 371 1,023 x 724 x 413 1,023 x 896 x 413
inch
35.9 x 24.5 x 14.6 35.9 x 24.5 x 14.6 40.3 x 28.5 x 16.3 40.3 x 35.3 x 16.3
Casing Material Body -
EGI Steel Plate / PP EGI Steel Plate / PP EGI Steel Plate / PP EGI Steel Plate / PP
Operating
Temp. Range
Cooling ছ
14.0~114.8 14.0~114.8 14.0~114.8 14.0~114.8
Heating ছ
-5.1~ 75.2 -5.1~ 75.2 -5.1~ 75.2 -5.1~ 75.2
NOTE
• Specifications may be subject to change without prior notice.
1) Nominal cooling capacities are based on;
ÃʒͱͱθϩʪΧʪθɇϩЇθʪࡤߤߩঙU9ࡥߣ߫ঙǮ9࣑ߪߢছU9ࢩߨߩছǮ9࣒
ĮЇϩʒͱͱθϩʪΧʪθɇϩЇθʪࡤߥߧঙU9ࡥߤߦঙǮ9࣑߫ߧছU9ࢩߩߧছǮ9࣒ࡥkαЇЭɇʪϩθʪ˙θ˝ʪθɇϩΧΧ˝ࡤߧ࣑ߣߨ࢏ߦ˙ϩ࣒ࡥ
Level differences: 0 m (0ft).
2) Nominal heating capacities are based on;
ÃʒͱͱθϩʪΧʪθɇϩЇθʪࡤߤߢঙU9ࡥߣߧঙǮ9࣑ߨߪছU9ࢩߧ߫ছǮ9࣒
ĮЇϩʒͱͱθϩʪΧʪθɇϩЇθʪࡤߩঙU9ࡥߨঙǮ9࣑ߦߦ࢏ߨছU9ࢩߦߤ࢏ߪছǮ9࣒ࡥkαЇЭɇʪϩθʪ˙θ˝ʪθɇϩΧΧ˝ࡤߧ࣑ߣߨ࢏ߦ˙ϩ࣒ࡥ
Level differences: 0 m (0ft).
3) Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the
installation conditions.
4) These products contain R410A which is fluorinated greenhouse gas.
* The Wind-Free™ unit delivers an air current that is under 0.15 m/s while in Wind-Free™ mode.
Air velocity that is below 0.15 m/s is considered “still air” as defined by ASHRAE 55-2013
(American Society of Heating, Refrigerating, and Air-Conditioning Engineers).
Quantum 2.0

9
1. Specification
Wind-Free™ 2.0
Model Name Indoor Unit
AR09TSFABWKNCV AR12TSFABWKNCV AR18TSFABWKNCV AR24TSFABWKNCV
Outdoor Unit
AR09TSFABWKXCV AR12TSFABWKXCV AR18TSFABWKXCV AR24TSFABWKXCV
US Code Indoor Unit
RNS09ABT RNS12ABT RNS18ABT RNS24ABT
Outdoor Unit
RXS09ABT RXS12ABT RXS18ABT RXS24ABT
System
Mode
-
HEAT PUMP HEAT PUMP HEAT PUMP HEAT PUMP
Performance Capacity
(Min/Std/Max)
Cooling
kW
0.88 / 2.64 / 3.81 0.88 / 3.52 / 4.4 2.2 / 5.28 / 7 2.58 / 6.15 / 9.29
Btu/h
3,000 / 9,000 / 13,000 3,000 / 12,000 /15,000 7,500 / 18,000 / 23,884 8,800 / 21,000 / 31,700
US RT
0.25 / 0.75 /1.08 0.25 /1 /1.25 0.62 /1.5 / 1.99 0.73 /1.75 / 2.64
Heating
kW
0.7 / 3.22 / 6.15 0.76 / 3.52 / 6.3 2.05 / 6.04 /10.84 2.2 / 8.06 /12.02
Btu/h
2,400 / 11,000 / 21,000 2,600 / 12,000 / 21,500 7,000 / 20,600 / 37,000 7,500 / 27,500 / 41,000
US RT
0.2 / 0.92 / 1.75 0.22 / 1.0 /1.79 0.58 / 1.72 / 3.08 0.62 / 2.29 / 3.42
Power
PowerInput
(Min/Std/Max)
Cooling
kW
0.15 / 0.58 /1.1 0.15 / 0.89 / 1.35 0.47 /1.39 / 2.55 0.52 / 1.68 / 3.1
Heating kW
0.15 / 0.73 / 2.2 0.16 / 0.83 / 2.2 0.38 / 1.63 / 3.9 0.5 / 2.4 / 4.3
Current Input
(Min/Std/Max)
Cooling A
1.0 / 2.8 / 5.2 1.0 / 4.2 / 6.3 2.5 / 6.2 / 11.2 2.7 / 7.6 / 13.7
Heating A
1.0 / 3.4 / 9.8 1.1 / 3.8 / 9.8 2.3 / 7.3 / 17.1 2.6 / 10.7 /18.9
Current MCA
A
12 12.5 19 20
MOP A
20 20 30 30
Efficiency
EER Cooling
(Btu/h)/W
15.50 13.50 13.00 12.50
COP Heating W/W
4.40 4.25 3.70 3.36
SEER (Cooling Energy Grade) (Btu/h)/W
24.5 23.0 21.0 20.0
HSPF (Heating Energy Grade) (Btu/h)/W
12.5 12.5 10.0 10.0
Piping
Connections
Liquid Pipe
Type
Flare connection Flare connection Flare connection Flare connection
ףࡥ࣑ʀ˵࣒
6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4)
Gas Pipe
Type
Flare connection Flare connection Flare connection Flare connection
ףࡥ࣑ʀ˵࣒
9.52 (3/8) 9.52 (3/8) 12.7 (1/2) 15.88 (5/8)
Heat Insulation -
Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Installation
Limitation
Max. Length
(Outdoorto indoor)
m
20 20 30 30
ft
66 66 98 98
Max. Height
(Between ID/OD)
m
15 15 20 20
ft
49 49 66 66
Wiring
connections
Communication Min.
mm²
0.75 0.75 0.75 0.75
Remark -
F1, F2 F1, F2 F1, F2 F1, F2
Power Supply -
Outdoor unit powers indoor unit Outdoor unit powers indoor unit Outdoor unit powers indoor unit Outdoor unit powers indoor unit
Refrigerant
Type
-
R410A R410A R410A R410A
Factory Charging
kg
1.15 1.15 1.8 2.5
lbs
2.54 2.54 3.97 5.51
Indoor Unit
Power Supply
ŝࡥ࢈ࡥǤࡥ²і
1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60
Heat
Exchanger
Type
-
F&T F&T F&T F&T
Material Fin
-
Al Al Al Al
Tube -
Cu Cu Cu Cu
Fin Treatment -
Green Hydrophile Green Hydrophile Green Hydrophile Green Hydrophile
Fan
Type
-
Cross Flow Cross Flow Cross Flow Cross Flow
Quantity EA
1111
Air Flow Rate
Cooling (T/H/M/L)
CMM
11.1 /10.1 / 8.6 / 7.1 12.1 / 10.6 / 9.1 / 7.1 16.4 /15.1 /13.2 / 11.3 20.2 / 17.6 / 14.5 / 11.3
CFM
391.99 / 356.68 / 303.71 / 250.73 427.31 / 374.34 / 321.36 / 250.73 579.16 / 533.25 / 466.15 / 399.06 713.36 / 621.54 / 512.06 / 399.06
Heating (T/H/M/L)
CMM
12.1 / 11.1 / 9.6 / 8.1 13.1 / 11.6 /10.1 / 8.1 17 / 15.7 /13.9 /12 20.2 / 17.6 / 14.5 / 11.3
CFM
427.31 / 391.99 / 339.02 / 286.05 462.62 / 409.65 / 356.68 / 286.05 600.35 / 554.44 / 490.87 / 423.78 713.36 / 621.54 / 512.06 / 399.06
Fan Motor Type
-
BLDC BLDC BLDC BLDC
Output W x n
27 x 1 27 x 1 27 x 1 27 x 1
Drain Drain Pipe ףࡥ mm
16.3, 550 16.3, 550 16.3, 550 16.3, 550
Sound Sound Pressure
Level H / Silent
dB(A)
38 / 22 39 / 22 42 / 25 47 / 28
External
Dimension
Net Weight
kg
10.6 10.6 12.5 12.5
lbs
23.4 23.4 27.6 27.6
Shipping Weight
kg
12.0 12.0 14.3 14.3
lbs
26.5 26.5 31.5 31.5
Net Dimensions (WxHxD)
mm
889 x 299 x 215 889 x 299 x 215 1,055 x 299 x 215 1,055 x 299 x 215
inch
35.0 x 11.8 x 8.5 35.0 x11.8 x 8.5 41.5 x11.8 x 8.5 41.5 x 11.8 x 8.5
Shipping Dimensions (WxHxD)
mm
950 x 290 x 375 950 x 290 x 375 1,115 x 290 x 375 1,115 x 290 x 375
inch
37.4 x 11.4 x 14.8 37.4 x 11.4 x 14.8 43.9 x 11.4 x 14.8 43.9 x 11.4 x 14.8
Casing Material -
HIPS HIPS HIPS HIPS
Control System
Infrared remote control -
Included Included Included Included
Wired remote control -
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
Drain Pump Drain Pump
-
----
Max. lifting Height / Displacement mm / Liter/h
----
Additional
Accessories Drain Pump
External Model
-
----
Internal Model -
----
Max. lifting Height /
Displacement
mm / Liter/h
----

1. Specification
10
Wind-Free™ 2.0
Model Name Indoor Unit
AR09TSFABWKNCV AR12TSFABWKNCV AR18TSFABWKNCV AR24TSFABWKNCV
Outdoor Unit
AR09TSFABWKXCV AR12TSFABWKXCV AR18TSFABWKXCV AR24TSFABWKXCV
US Code Indoor Unit
RNS09ABT RNS12ABT RNS18ABT RNS24ABT
Outdoor Unit
RXS09ABT RXS12ABT RXS18ABT RXS24ABT
Indoor Unit Additional
Accessories
Easy Filter Plus
-
Removable / Washable Removable / Washable Removable / Washable Removable / Washable
Tri-Care Filter -
----
Motion Detect Sensor -
----
Wi-Fi -
弋弋弋弋
Outdoor
Unit
Power Supply
ŝࡥ࢈ࡥǤࡥ²і
1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60
Heat
Exchanger
Type
-
F&T F&T F&T F&T
Material Fin
-
Al Al Al Al
Tube -
Cu Cu Cu Cu
Fin Treatment -
Anti-Corrosion Anti-Corrosion Anti-Corrosion Anti-Corrosion
Compressor
Model Name
KTN130D42UFR KTN130D42UFR UG8TH8265FEW UG8TH8265FJW
Type -
BLDC ROTARY BLDC ROTARY BLDC ROTARY BLDC ROTARY
Output kW
4.09 4.09 7.29 7.29
Oil Type
-
POEPOEPOEPOE
Initial charge cc
350 350 700 700
Fan
Type
-
Propeller Propeller Propeller Propeller
Discharge direction -
Front Front Front Front
Quantity EA
1111
Air Flow Rate
CMM
45 45 63 80
CFM
1,589 1,589 2,225 2,825
Fan Motor Type
-
BLDC BLDC BLDC BLDC
Output W x n
40 x 1 40 x 1 125 x 1 125 x 1
Sound Sound Pressure
Level Cooling
dB(A)
45 46 51 56
External
Dimension
Net Weight
kg
32.1 32.1 55.6 68.2
lbs
70.8 70.8 122.6 150.4
Shipping Weight
kg
34.2 34.2 59.2 73.5
lbs
75.4 75.4 130.5 162.0
Net Dimensions (WxHxD)
mm
790 x 548 x 285 790 x 548 x 285 880 x 798 x 310 940 x 998 x 330
inch
31.1 x 21.6 x11.2 31.1 x 21.6 x11.2 34.6 x 31.4 x 12.2 37.0 x 39.3 x 13.0
Shipping Dimensions (WxHxD)
mm
913 x 622 x 371 913 x 622 x 371 1,023 x 896 x 413 995 x1,096 x 426
inch
35.9 x 24.5 x 14.6 35.9 x 24.5 x 14.6 40.3 x 35.3 x 16.3 36.2 x 43.1 x 16.8
Casing Material Body -
EGI Steel Plate / PP EGI Steel Plate / PP EGI Steel Plate / PP EGI Steel Plate / PP
Operating
Temp. Range
Cooling ছ
14.0~114.8 14.0~114.8 14.0~114.8 14.0~114.8
Heating ছ
-5.1~ 75.2 -5.1~ 75.2 -5.1~ 75.2 -5.1~ 75.2
NOTE
• Specifications may be subject to change without prior notice.
1) Nominal cooling capacities are based on;
ÃʒͱͱθϩʪΧʪθɇϩЇθʪࡤߤߩঙU9ࡥߣ߫ঙǮ9࣑ߪߢছU9ࢩߨߩছǮ9࣒
ĮЇϩʒͱͱθϩʪΧʪθɇϩЇθʪࡤߥߧঙU9ࡥߤߦঙǮ9࣑߫ߧছU9ࢩߩߧছǮ9࣒ࡥkαЇЭɇʪϩθʪ˙θ˝ʪθɇϩΧΧ˝ࡤߧ࣑ߣߨ࢏ߦ˙ϩ࣒ࡥ
Level differences: 0 m (0ft).
2) Nominal heating capacities are based on;
ÃʒͱͱθϩʪΧʪθɇϩЇθʪࡤߤߢঙU9ࡥߣߧঙǮ9࣑ߨߪছU9ࢩߧ߫ছǮ9࣒
ĮЇϩʒͱͱθϩʪΧʪθɇϩЇθʪࡤߩঙU9ࡥߨঙǮ9࣑ߦߦ࢏ߨছU9ࢩߦߤ࢏ߪছǮ9࣒ࡥkαЇЭɇʪϩθʪ˙θ˝ʪθɇϩΧΧ˝ࡤߧ࣑ߣߨ࢏ߦ˙ϩ࣒ࡥ
Level differences: 0 m (0ft).
3) Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the
installation conditions.
4) These products contain R410A which is fluorinated greenhouse gas.
* The Wind-Free™ unit delivers an air current that is under 0.15 m/s while in Wind-Free™ mode.
Air velocity that is below 0.15 m/s is considered “still air” as defined by ASHRAE 55-2013
(American Society of Heating, Refrigerating, and Air-Conditioning Engineers).

11
1. Specification
Model Name Indoor Unit
AR09TSFABWKNCV AR12TSFABWKNCV AR18TSFABWKNCV AR24TSFABWKNCV
Outdoor Unit
AR09TSFACWKXCV AR12TSFACWKXCV AR18TSFACWKXCV AR24TSFACWKXCV
US Code Indoor Unit
RNS09ABT RNS12ABT RNS18ABT RNS24ABT
Outdoor Unit
RXS09ACT RXS12ACT RXS18ACT RXS24ACT
System
Mode
-
HEAT PUMP HEAT PUMP HEAT PUMP HEAT PUMP
Performance Capacity
(Min/Std/Max)
Cooling
kW
0.88 / 2.64 / 3.81 0.88 / 3.52 / 4.4 2.2 / 5.28 / 7 2.58 / 6.15 / 9.29
Btu/h
3,000 / 9,000 / 13,000 3,000 / 12,000 /15,000 7,500 / 18,000 / 23,884 8,800 / 21,000 / 31,700
US RT
0.25 / 0.75 /1.08 0.25 / 1.0 /1.25 0.62 /1.5 / 1.99 0.73 /1.75 / 2.64
Heating
kW
0.7 / 3.22 / 6.15 0.76 / 3.52 / 6.3 2.05 / 6.04 /10.84 2.2 / 8.06 /12.02
Btu/h
2,400 / 11,000 / 21,000 2,600 / 12,000 / 21,500 7,000 / 20,600 / 37,000 7,500 / 27,500 / 41,000
US RT
0.2 / 0.92 / 1.75 0.22 / 1.0 /1.79 0.58 / 1.72 / 3.08 0.62 / 2.29 / 3.42
Power
PowerInput
(Min/Std/Max)
Cooling
kW
0.15 / 0.58 /1.1 0.15 / 0.89 / 1.35 0.47 /1.39 / 2.55 0.52 / 1.68 / 3.1
Heating kW
0.15 / 0.73 / 2.2 0.16 / 0.83 / 2.2 0.38 / 1.63 / 3.9 0.5 / 2.4 / 4.3
Current Input
(Min/Std/Max)
Cooling A
1.0 / 2.8 / 5.2 1.0 / 4.2 / 6.3 2.5 / 6.2 / 11.2 2.7 / 7.6 / 13.7
Heating A
1.0 / 3.4 / 9.8 1.1 / 3.8 / 9.8 2.3 / 7.3 / 17.1 2.6 / 10.7 /18.9
Current MCA
A
12 12.5 19 20
MOP A
20 20 30 30
Efficiency
EER Cooling
(Btu/h)/W
15.50 13.50 13.00 12.50
COP Heating W/W
4.40 4.25 3.70 3.36
SEER (Cooling Energy Grade) (Btu/h)/W
24.5 23.0 21.0 20.0
HSPF (Heating Energy Grade) (Btu/h)/W
12.5 12.5 10.0 10.0
Piping
Connections
Liquid Pipe
Type
Flare connection Flare connection Flare connection Flare connection
ףࡥ࣑ʀ˵࣒
6.35 (1/4) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4)
Gas Pipe
Type
Flare connection Flare connection Flare connection Flare connection
ףࡥ࣑ʀ˵࣒
9.52 (3/8) 9.52 (3/8) 12.7 (1/2) 15.88 (5/8)
Heat Insulation -
Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes Both liquid and gas pipes
Installation
Limitation
Max. Length
(Outdoorto indoor)
m
20 20 30 30
ft
66 66 98 98
Max. Height
(Between ID/OD)
m
15 15 20 20
ft
49 49 66 66
Wiring
connections
Communication Min.
mm²
0.75 0.75 0.75 0.75
Remark -
F1, F2 F1, F2 F1, F2 F1, F2
Power Supply -
Outdoor unit powers indoor unit Outdoor unit powers indoor unit Outdoor unit powers indoor unit Outdoor unit powers indoor unit
Refrigerant
Type
-
R410A R410A R410A R410A
Factory Charging
kg
1.15 1.15 1.8 2.5
lbs
2.54 2.54 3.97 5.51
Indoor Unit
Power Supply
ŝࡥ࢈ࡥǤࡥ²і
1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60
Heat
Exchanger
Type
-
F&T F&T F&T F&T
Material Fin
-
Al Al Al Al
Tube -
Cu Cu Cu Cu
Fin Treatment -
Green Hydrophile Green Hydrophile Green Hydrophile Green Hydrophile
Fan
Type
-
Cross Flow Cross Flow Cross Flow Cross Flow
Quantity EA
1111
Air Flow Rate
Cooling (T/H/M/L)
CMM
11.1 /10.1 / 8.6 / 7.1 12.1 / 10.6 / 9.1 / 7.1 16.4 /15.1 /13.2 / 11.3 20.2 / 17.6 / 14.5 / 11.3
CFM
391.99 / 356.68 / 303.71 / 250.73 427.31 / 374.34 / 321.36 / 250.73 579.16 / 533.25 / 466.15 / 399.06 713.36 / 621.54 / 512.06 / 399.06
Heating (T/H/M/L)
CMM
12.1 / 11.1 / 9.6 / 8.1 13.1 / 11.6 /10.1 / 8.1 17 / 15.7 /13.9 / 12 20.2 / 17.6 / 14.5 / 11.3
CFM
427.31 / 391.99 / 339.02 / 286.05 462.62 / 409.65 / 356.68 / 286.05 600.35 / 554.44 / 490.87 / 423.78 713.36 / 621.54 / 512.06 / 399.06
Fan Motor Type
-
BLDC BLDC BLDC BLDC
Output W x n
27 x 1 27 x 1 27 x 1 27 x 1
Drain Drain Pipe ףࡥ mm
16.3, 550 16.3, 550 16.3, 550 16.3, 550
Sound Sound Pressure
Level H / Silent
dB(A)
38 / 22 39 / 22 42 / 25 47 / 28
External
Dimension
Net Weight
kg
10.6 10.6 12.5 12.5
lbs
23.4 23.4 27.6 27.6
Shipping Weight
kg
12.0 12.0 14.3 14.3
lbs
26.5 26.5 31.5 31.5
Net Dimensions (WxHxD)
mm
889 x 299 x 215 889 x 299 x 215 1,055 x 299 x 215 1,055 x 299 x 215
inch
35.0 x 11.8 x 8.5 35.0 x11.8 x 8.5 41.5 x11.8 x 8.5 41.5 x 11.8 x 8.5
Shipping Dimensions (WxHxD)
mm
950 x 290 x 375 950 x 290 x 375 1,115 x 290 x 375 1,115 x 290 x 375
inch
37.4 x 11.4 x 14.8 37.4 x 11.4 x 14.8 43.9 x 11.4 x 14.8 43.9 x 11.4 x 14.8
Casing Material -
HIPS HIPS HIPS HIPS
Control System
Infrared remote control -
Included Included Included Included
Wired remote control -
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
MWR-WE13UN
MWR-WG00UN
MWR-SH11UN
Drain Pump Drain Pump
-
----
Max. lifting Height / Displacement mm / Liter/h
----
Additional
Accessories Drain Pump
External Model
-
----
Internal Model -
----
Max. lifting Height /
Displacement
mm / Liter/h
----
Max Heat 2.0

1. Specification
12
Model Name Indoor Unit
AR09TSFABWKNCV AR12TSFABWKNCV AR18TSFABWKNCV AR24TSFABWKNCV
Outdoor Unit
AR09TSFACWKXCV AR12TSFACWKXCV AR18TSFACWKXCV AR24TSFACWKXCV
US Code Indoor Unit
RNS09ABT RNS12ABT RNS18ABT RNS24ABT
Outdoor Unit
RXS09ACT RXS12ACT RXS18ACT RXS24ACT
Indoor Unit Additional
Accessories
Easy Filter Plus
-
Removable / Washable Removable / Washable Removable / Washable Removable / Washable
Tri-Care Filter -
----
Motion Detect Sensor -
----
Wi-Fi -
弋弋弋弋
Outdoor
Unit
Power Supply
ŝࡥ࢈ࡥǤࡥ²і
1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60 1, 2, 208-230, 60
Heat
Exchanger
Type
-
F&T F&T F&T F&T
Material Fin
-
Al Al Al Al
Tube -
Cu Cu Cu Cu
Fin Treatment -
Anti-Corrosion Anti-Corrosion Anti-Corrosion Anti-Corrosion
Compressor
Model Name
KTN130D42UFR KTN130D42UFR UG8TH8265FEW UG8TH8265FJW
Type -
BLDC ROTARY BLDC ROTARY BLDC ROTARY BLDC ROTARY
Output kW
4.09 4.09 7.29 7.29
Oil Type
-
POE POE POE POE
Initial charge cc
350 350 700 700
Fan
Type
-
Propeller Propeller Propeller Propeller
Discharge direction -
Front Front Front Front
Quantity EA
1111
Air Flow Rate
CMM
45 45 63 80
CFM
1,589 1,589 2,225 2,825
Fan Motor Type
-
BLDC BLDC BLDC BLDC
Output W x n
40 x 1 40 x 1 125 x 1 125 x 1
Sound Sound Pressure
Level Cooling
dB(A)
45 46 51 56
External
Dimension
Net Weight
kg
32.1 32.1 55.6 68.2
lbs
70.8 70.8 122.6 150.4
Shipping Weight
kg
34.2 34.2 59.2 73.5
lbs
75.4 75.4 130.5 162.0
Net Dimensions (WxHxD)
mm
790 x 548 x 285 790 x 548 x 285 880 x 798 x 310 940 x 998 x 330
inch
31.1 x 21.6 x11.2 31.1 x 21.6 x11.2 34.6 x 31.4 x 12.2 37.0 x 39.3 x 13.0
Shipping Dimensions (WxHxD)
mm
913 x 622 x 371 913 x 622 x 371 1,023 x 896 x 413 995 x1,096 x 426
inch
35.9 x 24.5 x 14.6 35.9 x 24.5 x 14.6 40.3 x 35.3 x 16.3 36.2 x 43.1 x 16.8
Casing Material Body -
EGI Steel Plate / PP EGI Steel Plate / PP EGI Steel Plate / PP EGI Steel Plate / PP
Operating
Temp. Range
Cooling ছ
-0.4~114.8 -0.4~114.8 -0.4~114.8 -0.4~114.8
Heating ছ
-13.0~75.2 -13.0~75.2 -13.0~75.2 -13.0~75.2
NOTE
• Specifications may be subject to change without prior notice.
1) Nominal cooling capacities are based on;
ÃʒͱͱθϩʪΧʪθɇϩЇθʪࡤߤߩঙU9ࡥߣ߫ঙǮ9࣑ߪߢছU9ࢩߨߩছǮ9࣒
ĮЇϩʒͱͱθϩʪΧʪθɇϩЇθʪࡤߥߧঙU9ࡥߤߦঙǮ9࣑߫ߧছU9ࢩߩߧছǮ9࣒ࡥkαЇЭɇʪϩθʪ˙θ˝ʪθɇϩΧΧ˝ࡤߧ࣑ߣߨ࢏ߦ˙ϩ࣒ࡥ
Level differences: 0 m (0ft).
2) Nominal heating capacities are based on;
ÃʒͱͱθϩʪΧʪθɇϩЇθʪࡤߤߢঙU9ࡥߣߧঙǮ9࣑ߨߪছU9ࢩߧ߫ছǮ9࣒
ĮЇϩʒͱͱθϩʪΧʪθɇϩЇθʪࡤߩঙU9ࡥߨঙǮ9࣑ߦߦ࢏ߨছU9ࢩߦߤ࢏ߪছǮ9࣒ࡥkαЇЭɇʪϩθʪ˙θ˝ʪθɇϩΧΧ˝ࡤߧ࣑ߣߨ࢏ߦ˙ϩ࣒ࡥ
Level differences: 0 m (0ft).
3) Sound pressure was acquired in an anechoic room. Thus actual noise level may be different depending on the
installation conditions.
4) These products contain R410A which is fluorinated greenhouse gas.
* The Wind-Free™ unit delivers an air current that is under 0.15 m/s while in Wind-Free™ mode.
Air velocity that is below 0.15 m/s is considered “still air” as defined by ASHRAE 55-2013
(American Society of Heating, Refrigerating, and Air-Conditioning Engineers).
Max Heat 2.0

13
2. Capacity Table
RNS09YBT+RXS09YBT (AR09TSFYBWKNCV+AR09TSFYBWKXCV)
Cooling ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥƊ²AࡤƊʪϑɵʪ²ʪɇϩAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
Temperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9ࢩǮ9࣒
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
14 9.6 8.0 0.4 10.1 8.4 0.5 10.6 8.8 0.6 11.3 9.3 0.7 11.8 9.5 0.7 12.2 9.7 0.7 13.1 10.1 0.7 14.2 10.5 0.7
32 9.3 7.8 0.3 9.9 8.3 0.4 10.5 8.7 0.5 11.2 9.2 0.6 11.8 9.5 0.6 12.2 9.7 0.6 13.1 10.1 0.6 14.3 10.6 0.6
50 9.7 8.2 0.3 10.3 8.6 0.4 10.9 9.1 0.5 11.8 9.6 0.6 12.3 9.9 0.6 12.8 10.1 0.6 13.7 10.5 0.6 14.9 11.0 0.6
68 10.2 8.5 0.3 10.8 8.9 0.5 11.3 9.3 0.6 12.1 9.8 0.7 12.7 10.1 0.7 13.1 10.3 0.7 14.1 10.7 0.7 15.1 11.3 0.7
85 10.4 8.6 0.4 11.0 9.1 0.6 11.5 9.5 0.8 12.3 10.0 0.9 12.9 10.3 0.9 13.3 10.5 0.9 14.2 10.9 0.9 15.3 11.4 0.9
95 10.0 8.3 0.5 10.6 8.8 0.7 11.1 9.2 0.9 11.9 9.7 1.0 9.0 7.2 0.6 12.8 10.1 1.0 13.7 10.5 1.1 14.8 11.0 1.0
104 9.4 7.8 0.6 9.9 8.2 0.8 10.4 8.6 1.0 11.1 9.0 1.1 11.6 9.3 1.2 12.0 9.5 1.2 12.8 9.9 1.2 13.9 10.3 1.2
110 8.7 7.2 0.7 9.2 7.7 0.9 9.7 8.0 1.1 10.3 8.4 1.2 10.8 8.7 1.3 11.2 8.9 1.3 12.0 9.2 1.3 13.0 9.7 1.3
115 8.0 6.6 0.7 8.4 7.0 1.0 8.9 7.4 1.1 9.5 7.8 1.3 10.0 8.0 1.3 10.3 8.2 1.4 11.1 8.6 1.4 12.1 9.0 1.4
Heating ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
Temperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9࣒
60 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
-5.08 8.3 1.0 8.0 1.0 8.0 1.0 8.1 1.1 8.3 1.2 8.6 1.4
09.7 1.3 9.4 1.2 9.3 1.3 9.4 1.3 9.5 1.4 9.7 1.6
510.9 1.5 10.6 1.4 10.5 1.5 10.5 1.5 10.5 1.6 10.5 1.8
14 12.5 1.6 12.3 1.6 12.1 1.6 12.0 1.7 11.9 1.8 11.7 2.0
23 13.5 1.6 13.4 1.6 13.2 1.6 13.0 1.7 12.8 1.8 12.4 1.9
32 14.1 1.5 14.1 1.5 13.9 1.5 13.7 1.6 13.4 1.6 12.8 1.8
41 14.3 1.3 14.5 1.3 14.4 1.3 14.1 1.4 13.7 1.5 13.0 1.6
47 14.3 1.1 14.7 1.1 14.5 1.2 11.0 0.9 13.9 1.3 13.0 1.5
55 14.1 1.0 14.7 1.0 14.7 1.1 14.4 1.1 14.0 1.2 13.1 1.3
65 13.8 0.9 14.7 0.9 14.9 1.0 14.7 1.1 14.2 1.1 13.2 1.2
75.2 13.5 1.0 14.8 1.1 15.2 1.1 15.0 1.2 14.6 1.2 13.6 1.4
NOTE
• The performance table shows the average value of each conditions.
Quantum 2.0

2. Capacity Table
14
RNS12YBT+RXS12YBT (AR12TSFYBWKNCV+AR12TSFYBWKXCV)
Cooling ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥƊ²AࡤƊʪϑɵʪ²ʪɇϩAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
Temperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9ࢩǮ9࣒
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
14 10.9 8.7 0.5 11.0 9.1 0.6 11.3 9.5 0.7 12.2 10.0 0.8 12.8 10.3 0.8 13.3 10.5 0.8 14.3 11.0 0.8 15.3 11.4 0.8
32 10.8 8.7 0.3 10.9 9.1 0.4 11.4 9.5 0.5 12.3 10.1 0.6 13.0 10.4 0.6 13.5 10.7 0.7 14.6 11.1 0.7 15.7 11.6 0.6
50 11.3 9.2 0.3 11.5 9.6 0.4 12.0 10.1 0.5 13.0 10.6 0.6 13.7 11.0 0.7 14.2 11.2 0.7 15.3 11.7 0.7 16.5 12.3 0.7
68 12.0 9.7 0.4 12.1 10.1 0.6 12.7 10.6 0.7 13.6 11.1 0.8 14.3 11.4 0.8 14.9 11.8 0.9 16.0 12.3 0.9 17.2 12.8 0.8
85 12.1 9.8 0.6 12.3 10.2 0.8 12.8 10.7 0.9 13.7 11.2 1.0 14.5 11.6 1.1 14.9 11.8 1.1 16.1 12.3 1.1 17.2 12.8 1.1
95 11.8 9.5 0.7 12.0 9.9 0.9 12.4 10.4 1.0 13.3 10.9 1.2 12.0 9.6 1.0 14.5 11.5 1.3 15.6 11.9 1.3 16.7 12.5 1.2
104 11.2 9.0 0.8 11.3 9.4 1.0 11.7 9.8 1.2 12.6 10.3 1.3 13.2 10.6 1.4 13.7 10.9 1.4 14.8 11.3 1.4 15.8 11.8 1.4
110 10.5 8.4 0.8 10.6 8.8 1.1 11.0 9.2 1.2 11.8 9.7 1.4 12.5 10.0 1.5 12.9 10.2 1.5 13.9 10.7 1.5 15.0 11.2 1.5
115 9.8 7.9 0.9 9.9 8.2 1.1 10.2 8.6 1.3 11.0 9.1 1.5 11.7 9.4 1.6 12.1 9.6 1.6 13.1 10.0 1.6 14.1 10.5 1.6
Heating ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
emperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9࣒
60 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
-5.08 10.6 1.1 10.3 1.0 10.3 1.1 10.4 1.1 10.6 1.2 11.0 1.5
011.3 1.4 11.0 1.3 10.9 1.3 10.9 1.4 11.0 1.5 11.3 1.7
512.0 1.6 11.7 1.5 11.5 1.5 11.5 1.6 11.5 1.7 11.6 1.9
14 13.2 1.7 13.0 1.7 12.8 1.7 12.7 1.8 12.5 1.9 12.3 2.1
23 14.4 1.7 14.3 1.7 14.1 1.7 13.9 1.8 13.6 1.9 13.2 2.1
32 15.5 1.6 15.5 1.6 15.3 1.6 15.0 1.7 14.7 1.8 14.0 1.9
41 16.2 1.4 16.5 1.4 16.2 1.4 16.0 1.5 15.6 1.6 14.8 1.7
47 16.5 1.2 16.9 1.2 16.7 1.3 12.0 1.0 16.0 1.4 15.1 1.6
55 16.5 1.1 17.2 1.1 17.1 1.2 16.9 1.2 16.4 1.3 15.4 1.4
65 15.9 1.0 16.9 1.0 17.1 1.1 16.8 1.2 16.4 1.2 15.3 1.3
75.2 14.4 1.1 15.8 1.1 16.2 1.2 16.0 1.3 15.6 1.4 14.5 1.5
NOTE
• The performance table shows the average value of each conditions.
Quantum 2.0

15
2. Capacity Table
Quantum 2.0
RNS18YBT+RXS18YBT (AR18TSFYBWKNCV+AR18TSFYBWKXCV)
Cooling ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥƊ²AࡤƊʪϑɵʪ²ʪɇϩAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
Temperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9ࢩǮ9࣒
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
14 14.0 11.9 0.8 14.8 12.3 0.8 15.6 12.8 0.9 16.6 13.5 0.9 17.4 13.9 0.9 17.9 14.2 0.9 19.2 14.9 0.9 20.8 15.5 0.9
32 14.2 12.1 0.9 15.1 12.6 0.9 16.0 13.2 0.9 17.1 13.9 0.9 18.0 14.4 0.9 18.6 14.7 0.9 20.0 15.4 0.9 21.7 16.1 0.9
50 15.0 12.9 1.0 16.0 13.4 1.0 17.0 14.0 1.1 18.2 14.8 1.1 19.0 15.3 1.1 19.7 15.6 1.1 21.1 16.3 1.1 22.9 17.0 1.1
68 15.9 13.5 1.3 16.9 14.1 1.3 17.8 14.6 1.3 19.1 15.4 1.3 19.9 15.9 1.4 20.5 16.3 1.4 22.0 17.0 1.4 23.8 17.7 1.4
85 16.0 13.6 1.6 16.9 14.1 1.6 17.8 14.6 1.6 19.0 15.4 1.6 19.9 15.9 1.7 20.5 16.3 1.7 21.9 16.9 1.7 23.7 17.6 1.7
95 15.5 13.1 1.8 16.4 13.6 1.8 17.2 14.2 1.8 18.4 14.9 1.8 18.0 14.4 1.6 19.8 15.7 1.9 21.2 16.4 1.9 22.9 17.0 1.9
104 14.5 12.4 1.9 15.4 12.8 2.0 16.2 13.3 2.0 17.3 14.0 2.0 18.1 14.5 2.1 18.6 14.8 2.1 20.0 15.4 2.1 21.6 16.1 2.1
110 13.6 11.6 2.1 14.4 12.0 2.1 15.2 12.5 2.1 16.2 13.2 2.2 17.0 13.6 2.2 17.5 13.9 2.2 18.8 14.5 2.2 20.4 15.2 2.2
115 12.6 10.8 2.2 13.4 11.2 2.2 14.2 11.7 2.2 15.1 12.3 2.3 15.8 12.7 2.3 16.4 13.0 2.3 17.6 13.6 2.3 19.2 14.2 2.3
Heating ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
emperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9࣒
60 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
-5.08 18.2 0.8 12.8 0.7 10.6 0.8 10.7 0.8 11.5 0.9 14.3 1.1
019.0 0.9 14.3 0.8 12.4 0.9 12.4 1.0 13.1 1.1 15.4 1.3
519.8 1.0 15.9 1.0 14.1 1.0 14.1 1.1 14.6 1.2 16.4 1.5
14 20.3 1.9 17.7 1.8 16.4 1.9 16.3 2.0 16.5 2.1 17.4 2.3
23 20.2 2.1 18.9 2.0 18.1 2.1 17.9 2.2 17.8 2.3 17.9 2.5
32 19.5 1.9 19.7 1.9 19.4 1.9 19.1 2.0 18.8 2.1 18.1 2.3
41 18.6 1.6 20.2 1.7 20.5 1.8 20.2 1.9 19.6 1.9 18.2 2.1
47 18.0 1.6 20.6 1.7 21.3 1.8 21.0 1.9 20.2 2.0 18.3 2.2
55 17.2 2.0 21.1 2.1 22.4 2.3 22.1 2.4 21.2 2.5 18.6 2.7
65 16.6 3.4 22.2 3.6 24.3 3.9 24.0 4.0 22.8 4.1 19.4 4.4
75.2 16.5 6.4 23.9 6.8 26.9 7.1 26.6 7.2 25.3 7.4 21.1 7.7
NOTE
• The performance table shows the average value of each conditions.

2. Capacity Table
16
RNS24YBT+RXS24YBT (AR24TSFYBWKNCV+AR24TSFYBWKXCV)
Cooling ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥƊ²AࡤƊʪϑɵʪ²ʪɇϩAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
Temperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9ࢩǮ9࣒
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
14 19.3 11.8 4.2 23.3 19.4 4.4 25.5 22.7 4.7 27.0 23.1 5.0 27.9 22.3 5.1 28.3 22.1 5.1 30.2 22.3 5.2 33.5 25.1 5.1
32 19.7 12.3 1.3 23.8 19.9 1.7 26.1 23.2 1.9 27.7 23.7 2.2 28.7 22.9 2.3 29.1 22.7 2.4 31.1 23.0 2.4 34.5 25.8 2.3
50 20.6 13.0 0.6 24.7 20.7 0.9 27.1 24.0 1.2 28.7 24.4 1.5 29.7 23.7 1.6 30.1 23.5 1.6 32.1 23.7 1.7 35.4 26.5 1.6
68 21.1 13.4 1.0 25.2 21.0 1.3 27.5 24.3 1.6 29.1 24.7 1.9 30.0 23.9 2.1 30.4 23.7 2.1 32.3 23.9 2.1 35.6 26.7 2.1
85 20.4 12.7 1.7 24.4 20.3 2.1 26.6 23.5 2.4 28.1 23.9 2.7 28.9 23.1 2.8 29.3 22.8 2.9 31.0 23.0 2.9 34.2 25.7 2.8
95 19.2 11.7 2.0 23.1 19.2 2.3 25.2 22.4 2.7 26.6 22.7 3.0 22.0 17.6 2.1 27.7 21.5 3.2 29.3 21.7 3.2 32.4 24.3 3.2
104 17.4 10.2 2.0 21.2 17.6 2.4 23.3 20.8 2.7 24.5 21.0 3.1 25.1 20.1 3.2 25.4 19.8 3.3 27.0 19.9 3.3 29.9 22.5 3.2
110 15.8 8.8 1.8 19.5 16.3 2.2 21.5 19.4 2.6 22.6 19.5 2.9 23.2 18.6 3.1 23.5 18.3 3.1 25.0 18.3 3.2 27.9 20.9 3.1
115 14.2 7.5 1.5 17.8 14.9 1.9 19.8 18.0 2.3 20.8 18.1 2.7 21.3 17.1 2.8 21.6 16.8 2.9 23.0 16.8 2.9 25.8 19.3 2.8
Heating ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
emperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9࣒
60 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
-5.08 21.3 2.3 20.0 2.2 20.0 2.2 20.4 2.4 21.1 2.6 22.6 3.0
0 22.4 3.3 21.1 3.1 20.9 3.2 21.2 3.3 21.6 3.5 22.7 3.9
5 23.5 3.9 22.3 3.7 21.9 3.8 22.0 4.0 22.3 4.1 23.0 4.5
14 25.6 4.2 24.6 4.1 24.0 4.2 23.9 4.4 23.8 4.5 23.8 4.9
23 27.6 3.9 26.8 3.8 26.2 3.9 25.8 4.1 25.5 4.3 24.9 4.6
32 29.2 3.1 28.9 3.1 28.3 3.2 27.8 3.4 27.2 3.6 26.1 3.9
41 30.4 2.3 30.6 2.3 27.5 2.4 29.6 2.6 28.8 2.7 27.3 3.1
47 30.9 1.7 31.4 1.8 31.1 1.9 30.5 2.1 29.7 2.2 27.9 2.5
55 30.9 1.3 32.1 1.3 32.0 1.5 31.5 1.6 30.6 1.8 28.5 2.1
65 30.0 1.3 32.0 1.4 32.4 1.6 31.9 1.7 31.0 1.9 28.7 2.2
75.2 27.6 2.5 30.7 2.6 31.7 2.8 31.3 2.9 30.4 3.1 27.9 3.3
NOTE
• The performance table shows the average value of each conditions.
Quantum 2.0

17
2. Capacity Table
RNS09ABT+RXS09ABT (AR09TSFABWKNCV+AR09TSFABWKXCV)
Cooling ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥƊ²AࡤƊʪϑɵʪ²ʪɇϩAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
Temperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9ࢩǮ9࣒
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
14 8.1 8.0 0.4 8.4 8.4 0.5 8.8 8.8 0.6 9.4 9.3 0.7 9.9 9.5 0.7 10.3 9.7 0.7 11.1 10.1 0.7 12.1 10.5 0.7
32 8.5 7.8 0.3 8.7 8.3 0.4 9.2 8.7 0.5 9.9 9.2 0.6 10.5 9.5 0.6 10.9 9.7 0.6 11.8 10.1 0.6 12.7 10.6 0.6
50 9.3 8.2 0.3 9.6 8.6 0.4 10.1 9.1 0.5 10.9 9.6 0.6 11.4 9.9 0.6 11.8 10.1 0.6 12.7 10.5 0.6 13.7 11.0 0.6
68 10.1 8.6 0.3 10.4 9.1 0.5 10.9 9.5 0.6 11.6 10.0 0.7 12.2 10.3 0.7 12.6 10.5 0.7 13.5 11.0 0.7 14.5 11.5 0.7
85 10.2 8.6 0.4 10.5 9.1 0.6 11.0 9.5 0.8 11.7 10.0 0.9 12.3 10.3 0.9 12.7 10.5 0.9 13.6 10.9 0.9 14.6 11.4 0.9
95 9.9 8.3 0.5 10.1 8.8 0.7 10.6 9.2 0.9 11.3 9.7 1.0 9.0 7.2 0.6 12.2 10.1 1.0 13.1 10.5 1.1 14.1 11.0 1.0
104 9.2 7.8 0.6 9.4 8.2 0.8 9.8 8.6 1.0 10.5 9.0 1.1 11.0 9.3 1.2 11.4 9.5 1.2 12.2 9.9 1.2 13.2 10.3 1.2
110 8.5 7.2 0.7 8.7 7.7 0.9 9.0 8.0 1.1 9.7 8.4 1.2 10.2 8.7 1.3 10.6 8.9 1.3 11.4 9.2 1.3 12.3 9.7 1.3
115 7.7 6.6 0.7 7.9 7.0 1.0 8.2 7.4 1.1 8.9 7.8 1.3 9.4 8.0 1.3 9.7 8.2 1.4 10.5 8.6 1.4 11.4 9.0 1.4
Heating ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
emperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9࣒
60 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
-5.08 11.2 1.4 10.1 1.4 9.5 1.4 9.5 1.5 9.5 1.6 9.9 1.8
012.2 1.5 11.2 1.5 10.7 1.5 10.6 1.6 10.6 1.7 10.9 1.9
513.2 1.6 12.3 1.6 11.8 1.6 11.7 1.7 11.7 1.8 11.8 1.9
14 14.3 1.6 13.7 1.6 13.3 1.7 13.1 1.7 13.0 1.8 12.9 2.0
23 14.9 1.6 14.6 1.6 14.3 1.6 14.1 1.7 13.9 1.7 13.6 1.9
32 15.2 1.5 15.1 1.5 14.9 1.5 14.7 1.6 14.4 1.6 14.0 1.8
41 15.1 1.3 15.3 1.3 15.2 1.4 15.0 1.4 14.7 1.5 14.0 1.6
47 14.9 1.2 15.3 1.2 15.3 1.3 11.0 0.7 14.7 1.4 14.0 1.5
55 14.4 1.1 15.2 1.1 15.3 1.1 15.1 1.2 14.7 1.2 13.8 1.4
65 13.8 0.9 14.9 0.9 15.2 1.0 15.0 1.0 14.5 1.1 13.4 1.2
75.2 13.0 0.8 14.6 0.9 15.1 0.9 14.9 1.0 14.4 1.0 13.1 1.1
NOTE
• The performance table shows the average value of each conditions.
Wind-Free™ 2.0

2. Capacity Table
18
RNS12ABT+RXS12ABT (AR12TSFABWKNCV+AR12TSFABWKXCV)
Cooling ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥƊ²AࡤƊʪϑɵʪ²ʪɇϩAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
Temperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9ࢩǮ9࣒
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
14 9.8 8.0 0.5 11.6 9.7 0.6 12.6 10.6 0.8 13.3 11.1 0.9 13.8 11.3 0.9 14.0 11.4 0.9 14.8 11.7 0.9 16.4 12.5 0.9
32 10.4 8.5 0.5 12.2 10.2 0.6 13.3 11.1 0.7 14.0 11.7 0.8 14.5 11.9 0.8 14.7 11.9 0.8 15.6 12.3 0.8 17.2 13.1 0.8
50 10.3 8.5 0.4 12.2 10.2 0.5 13.3 11.1 0.6 14.1 11.7 0.7 14.5 11.9 0.8 14.8 12.0 0.8 15.7 12.4 0.8 17.3 13.2 0.7
68 10.0 8.2 0.3 11.8 9.9 0.5 12.9 10.8 0.6 13.7 11.4 0.7 14.2 11.6 0.7 14.4 11.7 0.8 15.3 12.1 0.8 16.9 12.9 0.7
85 9.5 7.8 0.4 11.4 9.5 0.5 12.4 10.4 0.7 13.2 11.0 0.8 13.6 11.2 0.8 13.8 11.2 0.9 14.7 11.6 0.9 16.3 12.4 0.8
95 9.3 7.6 0.5 11.1 9.3 0.7 12.2 10.2 0.8 12.9 10.7 0.9 12.0 9.6 0.9 13.5 11.0 1.0 14.4 11.3 1.0 15.9 12.1 1.0
104 9.1 7.5 0.6 10.9 9.1 0.8 12.0 10.0 1.0 12.6 10.5 1.1 13.0 10.7 1.2 13.2 10.8 1.2 14.1 11.1 1.2 15.6 11.9 1.2
110 9.1 7.4 0.8 10.9 9.0 1.0 11.9 10.0 1.1 12.5 10.4 1.3 12.9 10.6 1.4 13.1 10.7 1.4 13.9 11.0 1.4 15.4 11.7 1.4
115 9.1 7.4 0.9 10.8 9.0 1.1 11.8 9.9 1.3 12.5 10.4 1.4 12.8 10.5 1.5 13.0 10.6 1.5 13.8 10.9 1.6 15.3 11.7 1.6
Heating ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
emperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9࣒
60 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
-5.08 12.5 1.6 11.2 1.5 10.6 1.6 10.5 1.6 10.6 1.7 11.0 1.9
013.6 1.7 12.5 1.7 11.9 1.7 11.8 1.8 11.8 1.9 12.1 2.1
514.7 1.9 13.7 1.8 13.2 1.9 13.1 1.9 13.0 2.0 13.2 2.2
14 16.2 2.0 15.5 1.9 15.0 2.0 14.8 2.1 14.7 2.2 14.6 2.4
23 17.1 1.9 16.7 1.9 16.4 2.0 16.2 2.1 15.9 2.2 15.6 2.4
32 17.6 1.8 17.6 1.8 17.3 1.9 17.1 2.0 16.8 2.1 16.2 2.3
41 17.7 1.7 18.0 1.7 17.9 1.8 17.6 1.8 17.3 1.9 16.5 2.1
47 17.5 1.5 18.1 1.6 18.1 1.7 12.0 0.8 17.4 1.8 16.5 2.0
55 17.1 1.4 18.0 1.4 18.1 1.5 17.9 1.6 17.4 1.6 16.3 1.8
65 16.3 1.2 17.6 1.2 17.9 1.3 17.6 1.4 17.1 1.5 15.9 1.6
75.2 15.1 1.1 16.9 1.1 17.4 1.2 17.2 1.3 16.6 1.3 15.2 1.5
NOTE
• The performance table shows the average value of each conditions.
Wind-Free™ 2.0

19
2. Capacity Table
RNS18ABT+RXS18ABT (AR18TSFABWKNCV+AR18TSFABWKXCV)
Cooling ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥƊ²AࡤƊʪϑɵʪ²ʪɇϩAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
Temperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9ࢩǮ9࣒
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
14 15.3 12.5 0.6 15.6 13.0 0.8 16.3 13.8 0.9 17.6 14.8 1.1 18.8 15.6 1.1 19.3 15.9 1.2 20.8 16.7 1.2 22.5 17.3 1.1
32 17.1 14.1 0.6 17.6 14.7 0.8 18.4 15.5 1.0 19.9 16.7 1.1 21.2 17.6 1.2 21.8 17.9 1.2 23.5 18.8 1.3 25.3 19.5 1.2
50 19.3 15.9 0.8 19.9 16.6 1.0 20.8 17.5 1.2 22.4 18.7 1.4 23.8 19.7 1.5 24.4 20.0 1.5 26.2 21.0 1.6 28.1 21.7 1.5
68 21.1 17.3 1.1 21.6 18.0 1.4 22.6 18.9 1.6 24.2 20.2 1.8 25.6 21.2 1.9 26.2 21.5 2.0 28.1 22.5 2.0 30.1 23.3 1.9
85 21.5 17.6 1.4 22.0 18.3 1.7 22.9 19.2 2.0 24.5 20.5 2.2 25.9 21.4 2.3 26.5 21.8 2.4 28.4 22.8 2.4 30.4 23.5 2.3
95 20.9 17.1 1.5 21.3 17.8 1.8 22.2 18.7 2.1 23.8 19.9 2.4 18.0 14.4 1.4 25.8 21.2 2.6 27.6 22.1 2.6 29.6 22.9 2.5
104 19.6 16.0 1.5 20.1 16.7 1.9 20.9 17.6 2.2 22.4 18.8 2.5 23.7 19.7 2.7 24.3 20.0 2.7 26.1 20.9 2.7 28.1 21.7 2.7
110 18.4 15.0 1.5 18.8 15.6 1.9 19.5 16.5 2.2 21.0 17.7 2.6 22.3 18.6 2.7 22.9 18.9 2.8 24.7 19.8 2.8 26.6 20.5 2.7
115 17.1 13.9 1.5 17.4 14.5 1.9 18.2 15.3 2.3 19.6 16.5 2.6 20.9 17.4 2.8 21.4 17.7 2.8 23.1 18.5 2.8 25.0 19.2 2.8
Heating ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
emperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9࣒
60 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
-5.08 16.6 2.4 15.5 2.2 15.4 2.3 15.8 2.4 16.3 2.6 17.6 2.9
0 17.7 2.6 16.7 2.4 16.4 2.5 16.6 2.6 17.0 2.8 17.9 3.1
5 18.7 2.7 17.8 2.6 17.4 2.7 17.5 2.8 17.7 2.9 18.3 3.2
14 20.4 2.8 19.6 2.7 19.2 2.8 19.0 2.9 19.0 3.0 19.0 3.3
23 21.8 2.8 21.3 2.7 20.8 2.8 20.6 2.9 20.3 3.0 19.7 3.3
32 23.1 2.6 23.0 2.6 22.5 2.7 22.1 2.8 21.6 2.9 20.6 3.2
41 24.1 2.5 24.5 2.5 27.5 2.4 23.7 2.7 23.0 2.8 21.6 3.1
47 24.7 2.3 25.4 2.4 25.2 2.5 24.7 2.6 24.0 2.7 22.4 3.0
55 25.4 2.2 26.6 2.2 26.6 2.4 26.1 2.5 25.3 2.6 23.5 2.8
65 26.0 2.1 28.0 2.1 28.4 2.3 28.0 2.4 27.1 2.5 25.0 2.8
75.2 26.5 2.1 29.3 2.2 30.2 2.4 29.9 2.5 29.1 2.6 26.8 2.8
NOTE
• The performance table shows the average value of each conditions.
Wind-Free™ 2.0

2. Capacity Table
20
RNS24ABT+RXS24ABT (AR24TSFABWKNCV+AR24TSFABWKXCV)
Cooling ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥƊ²AࡤƊʪϑɵʪ²ʪɇϩAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
Temperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9ࢩǮ9࣒
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
14 21.2 18.1 0.6 22.1 18.5 0.9 23.3 17.5 1.0 25.1 19.2 1.2 26.6 21.3 1.3 27.3 22.1 1.3 29.4 23.7 1.4 32.0 23.4 1.3
32 21.3 18.3 0.7 22.4 18.8 1.0 23.6 17.8 1.2 25.5 19.5 1.4 27.1 21.7 1.5 27.8 22.5 1.5 30.0 24.1 1.6 32.5 23.8 1.5
50 22.5 18.0 1.1 23.6 19.7 1.4 24.9 18.8 1.6 26.7 20.5 1.9 28.3 22.7 2.0 29.0 23.5 2.0 31.2 25.1 2.0 33.8 24.8 2.0
68 23.6 20.0 1.5 24.7 20.5 1.8 25.9 19.5 2.1 27.7 21.3 2.4 29.3 23.4 2.5 30.0 24.2 2.6 32.1 25.8 2.6 34.6 25.5 2.5
85 23.5 20.3 1.8 24.5 20.3 2.2 25.6 19.3 2.5 27.4 21.0 2.8 28.9 23.1 2.9 29.5 23.9 3.0 31.6 25.4 3.0 34.0 25.1 2.9
95 22.5 18.5 1.8 23.5 19.5 2.2 24.6 18.4 2.6 26.2 20.1 2.9 21.0 16.8 1.7 28.3 22.9 3.1 30.3 24.4 3.1 32.6 24.0 3.0
104 20.9 17.5 1.7 21.7 18.1 2.2 22.8 17.0 2.5 24.4 18.6 2.8 25.7 20.6 3.0 26.3 21.3 3.0 28.2 22.8 3.1 30.5 22.4 3.0
110 19.3 15.4 1.6 20.1 16.8 2.0 21.1 15.7 2.4 22.6 17.2 2.7 24.0 19.2 2.9 24.5 19.9 3.0 26.4 21.4 3.0 28.6 21.0 2.9
115 18.7 15.2 1.4 18.5 15.4 1.9 19.4 14.3 2.3 20.8 15.8 2.6 22.1 17.7 2.8 22.7 18.5 2.8 24.5 19.9 2.9 26.6 19.5 2.8
Heating ƟAࡤƟͱϩɇAɇΧɇʀϩцࡥťÃࡤťͱиʪθÃΧЇϩ
Outdoor
emperature
࣑ছࡥU9࣒
ÃʒͱͱθƟʪΧʪθɇϩЇθʪ࣑ছࡥU9࣒
60 64 68 70 72 75
TC PI TC PI TC PI TC PI TC PI TC PI
MBH kW MBH kW MBH kW MBH kW MBH kW MBH kW
-5.08 19.5 2.7 18.2 2.5 18.1 2.6 18.5 2.7 19.2 2.9 20.7 3.3
0 21.4 2.9 20.1 2.8 19.9 2.9 20.1 3.0 20.5 3.2 21.6 3.5
5 23.1 3.1 21.9 3.0 21.5 3.0 21.6 3.2 21.8 3.3 22.5 3.7
14 25.9 3.2 24.9 3.1 24.4 3.2 24.2 3.4 24.1 3.5 24.0 3.9
23 28.2 3.3 27.6 3.2 26.9 3.3 26.6 3.4 26.2 3.6 25.5 3.9
32 30.0 3.2 29.9 3.1 29.3 3.3 28.8 3.4 28.1 3.5 26.9 3.9
41 31.4 3.0 31.8 3.0 27.5 2.4 30.7 3.3 29.9 3.5 28.2 3.8
47 32.0 2.9 32.8 3.0 32.5 3.1 31.9 3.2 31.0 3.4 29.1 3.7
55 32.5 2.8 34.0 2.9 33.9 3.0 33.3 3.2 32.3 3.3 30.1 3.6
65 32.5 2.7 34.9 2.8 35.3 3.0 34.8 3.2 33.8 3.3 31.2 3.7
75.2 31.9 2.8 35.3 3.0 36.4 3.2 36.0 3.3 35.0 3.5 32.2 3.8
NOTE
• The performance table shows the average value of each conditions.
Wind-Free™ 2.0
