Samsung MH052FUEA User manual

Refer to the service manual in the GSPN(see the rear cover) for the more information.
AIR CONDITIONER CONTENTS
MULTI AIR CONDITIONER
1. Precautions
2. Product Specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Exploded Views and Parts List
6. PCB Diagram and Parts List
7. Wiring Diagram
8. Schematic Diagram
9. Reference Sheet
INDOOR UNIT
MH023/026/035/052FBEA
MH020/026/035/052FVEA
MH020/026/035/052FAEA
MH020/026/035/052FNEA
AQV07/09/12/18/24PSBN
AQV09/12/18YWAN
MH026/035/052FJEA
MH026/035FSEA
MH030/035/052FMEA
NJ026/035LHXEA
MH052FUEA
OUTDOOR UNIT
RJ040F2HXEA
RJ050F2HXEA
RJ060F3HXEA
RJ070F4HXEA
RJ080F4HXEA
RJ100F5HXEA


Contents
11. Precautions ........................................................................................................................................ 1-1
1-1 Installing the air conditioner .......................................................................................................... 1-1
1-2 Power supply and circuit breaker
.................................................................................................. 1-1
1-3 During operation
.............................................................................................................................. 1-2
1-4 Disposing of the unit
....................................................................................................................... 1-2
1-5 Others
................................................................................................................................................. 1-2
12. Product Specifications ............................................................................................................... 2-1
2-1 The Feature of Product .................................................................................................................... 2-1
2-2 Product Specifications
..................................................................................................................... 2-2
2-3 The Comparative Specifications of Product
............................................................................... 2-14
2-4 Accessory and Option Specifications
............................................................................................ 2-22
3. Disassembly and Reassembly .............................................................................................. 3-1
3-1 Outdoor Unit ..................................................................................................................................... 3-2
4. Trouble shooting ........................................................................................................................... 4-1
4-1 Display Error and Check Method ................................................................................................................ 4-1
4-2 Setting Option Setup Method ...................................................................................................................... 4-8
4-3 Items to be checked first ................................................................................................................................. 4-17
4-4 Checking and Testing operation .................................................................................................................. 4-18
4-5 Fault Diagnosis by Symptom ........................................................................................................................ 4-28
4-6 PCB Inspection Method ................................................................................................................................... 4-33
5. Exploded Views and Parts List ............................................................................................. 5-1
5-1 Indoor Unit ......................................................................................................................................... 5-1
5-2 Outdoor Unit
..................................................................................................................................... 5-33
5-3 Assy control out .................................................................................................................................. 5-37
6. PCB Diagram and Parts list ...................................................................................................... 6-1
6-1 Indoor Unit ....................................................................................................................................... 6-1
6-2 Outdoor Unit
.................................................................................................................................... 6-12
7. Wiring Diagram .............................................................................................................................. 7-1
7-1 Indoor Unit ....................................................................................................................................... 7-1
7-2 Outdoor Unit
.................................................................................................................................... 7-11
1
8. Schematic Diagram ...................................................................................................................... 8-1
8-1 Indoor Unit ......................................................................................................................................... 8-1
8-2 Outdoor Unit
.................................................................................................................................... 8-10
9. Reference Sheet ............................................................................................................................. 9-1

Samsung Electronics 1-1
1. Precautions
1-1 Installing the air conditioner
O Users should not install the air conditioner by themselves.
Ask the dealer or authorized company to install the air conditioner except the
window-type air conditioner in U.S.A and Canada.
O If you don’t install the air conditioner properly, it may cause a fire, a water leak-
age or an electric shock.
O You must install the air conditioner according to the national wiring regulations
and safety regulations.
O Install the indoor unit higher than 2.5m from the floor to avoid the injury caused
by the operation of the fan. (except the window-type air conditioner)
O The manufacturer is not responsible for any accidents or injury caused by an
incorrect installation.
When installing the built-in type air conditioner, keep all electric cables such as
the power cable and the connection cord in pipes, ducts, or cable channels to
protect them from the danger of impact or any other incidents.
O More than 2 indoor units should be installed when you use Free Joint Multi air
conditioner.
O RJ060F3HXEA/RJ070F4HXEA
- **024** indoor units cannot be connected.
RJ050F2HXEA
- **024**/MH052FMEA/MH052FUEA indoor units cannot be connected.
RJ040F2HXEA
- **052**/MH***FM*A/NJ***LHXEA/**18**/**24** indoor unites cannot be con-
nected.
1-2 Power supply and circuit breaker
O  If the power cord of the air conditioner is damaged, it must be replaced by the
manufacturer or a qualified person in order to avoid a hazard.
O The air conditioner must be plugged into an independent circuit if applicable or
connect the power cable to the auxiliary circuit breaker.
An all pole disconnection from the power supply must be incorporated in
the fixed wiring with a contact opening of >3mm.
O  Do not extend an electric cord to the air conditioner.
O  The air conditioner must be plugged in after you complete the installation.
suoregnad
Avoid Dangerous Contact
No Tapping and No Extension Cords

1-2 Samsung Electronics
1-4 Disposing of the unit
O Before throwing out the air conditioner, remove the batteries from the remote control.
O When you dispose of the air conditioner, consult your dealer. If pipes are removed incorrectly, refrigerant may blow out and cause
air pollution. When it contacts with your skin, it can cause skin injury.
O The package of the air conditioner should be recycled or disposed of properly for environmental reasons.
1-5 Others
O Never store or load the air conditioner upside down or sideways to prevent the damage to the compressor.
O Young children or infirm persons should be always supervised when they use the air conditioner.
O Max current is measured according to IEC standard for safety.
O Current is measured according to ISO standard for energy efficiency.
O When installing, make sure there is no leakage. When recovering the refrigerant, ground the compressor first before removingthe
connection pipe. If the refrigerant pipe is not properly connected and the compressor works with the service valve open, thepipe
inhales the air and it makes the pressure inside of the refrigerant cycle abnormally high. It may cause explosion and injury.
O Pump Down Procedure (When removing the product)
- Turn on the air conditioner and select Cool mode to run the compressor for 3 minutes.
- Release the valve caps on High and Low pressure side.
- Use Lwrench to close the valve on the high pressure side.
- Approximately 2 minutes after, close the valve on the low pressure side.
- Stop operation of the air conditioner.- Disconnect the pipes.
1-3 During operation
O  Do not repair the air conditioner at your discretion.
It is recommended to contact a service center directly.
O Never spill any kind of liquid on the air conditioner.
If this happens, turn off the air conditioner and contact an authorized service cen-
ter.
O Do not insert anything between the airflow blades to prevent damage of the inner
fan and consequent injury. Keep children away from the air conditioner.
O Do not place any obstacles in front of the air conditioner.
O Do not spray any kind of liquid into the indoor unit. If this happens, turn off the air
conditioner and contact a service center.
O Make sure that the air conditioner is well ventilated at all times:
Do not place a cloth or other materials over it.
O Remove the batteries if you don’t use the remote control for a long time. (If appli-
cable)
O Use the remote control within 7 meters from the indoor unit. (If applicable)
No children Nearby

Samsung Electronics 2-1
2. Product Specifications
2-1 The Feature of Product
■ Multi Inverter(Free Joint Multi) Series delivers comfort to 2~4 rooms with a Single Outdoor Unit.
■ Inverter for High Efficiency Operation.
Thanks to inverter control, efficiency of operation of the outdoor unit is enhanced depending on the number of indoor units
operated and the temperature setting.
When only one indoor unit is used, power is saved, resulting in a smaller electricity bill. When all indoor units are used, high-power
operation achieves comfort quickly in all rooms.
■ Installation of indoor units on different floors is possible.
■ Characteristics
t6TJOHFMFDUSPOJDFYQBOTJPOWBMWFDPOUSPM
t(PPE4MFFQ.PEF.)'/&".)'7&".)'#&".)'"&""2714#/"27:8"/(PPE4MFFQ.PEFDBOIFMQZPV
sleep quickly ,soundly and make up refreshed.
t.1*.PEF.)'/&".)'7&".)'#&".)'"&"5IF.JDSP1MBTNB*PO.PEFDSFBUFETUSPOHQVSJGJFE
zone in your room.
t41*.PEF"27:8"/5IF4VQFS1MBTNB*PO.PEFHFOFSBUFTIZESPHFO)BOEPYZHFO02) to remove a polluted substance and
decomposition of such harmful particles. It makes you breathe better as if you are staying around waterfalls,ocean surf, rivers and
mountains
■ Various Indoor units & combinations
t/FP'PSUF
t.#t7JWBDF
t.JOJXBZDBTTFUUF
t.41EVDU
t4MJNEVDU
t$POTPMF
t4MJNXBZDBTTFUUF
t7JWBMEJ
t.BMEJWFT
t+VOHGSBV
■ Convenient Installation
Auto addressing option : Automated checking of pipe connection.(Refer to the installation manual for detail)
■ Space saving & Environmental Friendly
t$PNQBDUMJHIUPVUEPPSVOJU
t4MJNBOERVJFUJOEPPSVOJUT
t1JQFTJ[FSFEVDUJPO
t0[POFGSJFOEMZ3FGSJHFSBOU3"
t-FBE'SFFDPOUSPMMFS
■ Reliability
t*OTUBMMBUJPOQPTTJCJMJUJFT-FOHUI)FJHIU
t$POWFOJFOUJOTUBMMBUJPOOPOQPMBSJUZBVUPBEESFTTJOH
t*OUFMMJHFOUDPOUSPMOFUXPSL
t&BTZDIFDLJOHTZTUFNDPOEJUJPOCZTFHNFOU
■ Smart & Low Noise outdoor units in any condition
t5#34JOF8BWF$POUSPMMFS/PJTF3FEVDUJPO$POUSPM%VBM'FMUFUD
t'FMU4USVDUVSF/FXGFMUIBTTFMFDUFEUPSFEVDFUIFOPJTFDPNJOHPVUPGUIFDPNQSFTTPS
Double layered felt structure absorbs noise by two times and felt is also covering top of the compressor to
reduce the noise even more.

2-2 Samsung Electronics
2-2 Product Specifications
Model
Item
MH020FNEA MH026FNEA MH035FNEA
INDOOR UNIT
Size
Perfor-
mance
Wall-mounted
2.00
2.20
-
7.73
8.00
32
32
1,220~240,50
30
30
0.18
0.18
825x285x189
32.5x11.2x7.4
7.8
ø6.35x7.5
ø9.52x7.5
ø18, 535
Cross Flow Fan
Resin/steel
-
2ROW 10STEP
EEV
Wall-mounted
2.60
2.90
-
8.31
8.56
32
32
1,220~240,50
30
30
0.18
0.18
825x285x189
32.5x11.2x7.4
7.8
ø6.35x7.5
ø9.52x7.5
ø18, 535
Cross Flow Fan
Resin/steel
-
2ROW 14STEP
EEV
Wall-mounted
3.50
3.80
-
9.54
9.93
36
36
1,220~240,50
35
35
0.19
0.19
825x285x189
32.5x11.2x7.4
7.8
ø6.35x7.5
ø9.52x7.5
ø18, 535
Cross Flow Fan
Resin/steel
-
2ROW 14STEP
EEV
Type
Cooling kW
Heating
Dehumidifying Ɛ/h
Air Volume Cooling m
3
/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Drain Hose ø,mm
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
MH052FNEA
Wall-mounted
5.20
5.60
-
13.21
14.22
40
40
1,220~240,50
50
50
0.30
0.30
1,099x315x217
43.3x12.4x8.5
13
ø6.35x7.5
ø12.7x7.5
ø18, 600
Cross Flow Fan
Resin/steel
2ROW 16STEP
EEV
-

Samsung Electronics 2-3
Model
Item
MH023FBEA
MH026FBEA MH035FBEA MH052FBEA
INDOOR UNIT
Size
Perfor-
mance
Wall-mounted
2.60
2.90
-
8.14
8.23
31
31
1,220~240,50
30
30
0.18
0.18
900x304x185
35.4x12.0x7.3
10.2
ø6.35x7.5
ø9.52x7.5
ø18, 550
Cross Flow Fan
Resin/steel
15
2ROW 14STEP
EEV
Wall-mounted
3.50
3.80
-
9.16
9.46
35
35
1,220~240,50
35
35
0.19
0.19
900x304x185
35.4x12.0x7.3
10.2
ø6.35x7.5
ø9.52x7.5
ø18, 550
Cross Flow Fan
Resin/steel
15
2ROW 14STEP
EEV
Wall-mounted
5.20
5.60
2.5
14.98
14.49
40
40
1,220~240,50
50
50
0.30
0.30
1,100x307x225
43.3x12.1x8.9
13.0
ø6.35x7.5
ø12.7x7.5
ø18, 920
Cross Flow Fan
Resin/steel
15
2ROW 16STEP
EEV
Type
Cooling kW
Heating
Dehumidifying Ɛ/h
Air Volume Cooling m
3
/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Drain Hose ø,mm
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
Product Specifications(cont.)

2-4 Samsung Electronics
Model
Item
MH020FVEA MH026FVEA
INDOOR UNIT
Size
Perfor-
mance
Wall-mounted
2.00
2.20
1.0
7.5
8.1
31
31
1,220~240,50
30
30
0.18
0.18
825x285x189
32.5x11.2x7.4
8.5
ø6.35x7.5
ø9.52x7.5
ø18,550
Cross Flow Fan
Resin/steel
-
2ROW 10STEP
EEV
Wall-mounted
2.60
2.90
1.0
8.5
8.3
31
31
1,220~240,50
30
30
0.18
0.18
825x285x189
32.5x11.2x7.4
8.5
ø6.35x7.5
ø9.52x7.5
ø18,550
Cross Flow Fan
Resin/steel
-
2ROW 10STEP
EEV
Type
Cooling kW
Heating
Dehumidifying Ɛ/h
Air Volume Cooling m
3
/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Drain Hose ø,mm
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
MH035FVEA
Wall-mounted
3.50
3.80
1.3
10.0
10.4
35
35
1,220~240,50
35
35
0.19
0.19
825x285x189
32.5x11.2x7.4
8.5
ø6.35x7.5
ø9.52x7.5
ø18,550
Cross Flow Fan
Resin/steel
-
2ROW 10STEP
EEV
Wall-mounted
5.20
5.60
1.9
14.8
14.8
40
40
1,220~240,50
50
50
0.30
0.30
1,065x298x214
41.9x11.7x8.4
12.0
ø6.35x7.5
ø12.7x7.5
ø18,550
Cross Flow Fan
Resin/steel
-
2ROW 16STEP
EEV
MH052FVEA
Product Specifications(cont.)

Samsung Electronics 2-5
Model
Item
MH020FAEA MH026FAEA MH035FAEA MH052FAEA
INDOOR UNIT
Size
Perfor-
mance
Wall-mounted Wall-mounted Wall-mounted Wall-mounted
2.0 2.6 3.5 5.2
2.2 2.9 3.8 5.6
-- --
7.9 9.1 9.8 14.2
8.2 9.3 10.0 14.6
31 31 35 40
31 31 35 40
1,220~240,50 1,220~240,50 1,220~240,50 1,220~240,50
30 30 35 50
30 30 35 50
0.18 0.18 0.19 0.3
0.18 0.18 0.19 0.3
820 x 286 x 190 820 x 286 x 190 820 x 286 x 190 1,065 x 298 x 222
32.3 x 11.2 x 7.5 32.3 x 11.2 x 7.5 32.3 x 11.2 x 7.5 42.0 x 11.7 x 8.7
99 913
Ø6.35 Ø6.35 Ø6.35 Ø6.35
Ø9.52 Ø9.52 Ø9.52 Ø12.7
Ø18,550 Ø18,550 Ø18,550 Ø18,550
Cross Flow Fan Cross Flow Fan Cross Flow Fan Cross Flow Fan
Resin/steel Resin/steel Resin/steel Resin/steel
-- --
2ROW 14STEP 2ROW 14STEP 2ROW 14STEP 2ROW 16STEP
EEV EEV EEV EEV
Type
Cooling kW
Heating
Dehumidifying Ɛ/h
Air Volume Cooling m
3
/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mm
Gas mm
Drain Hose ø,mm
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
Product Specifications(cont.)

2-6 Samsung Electronics
Model
Item INDOOR UNIT
Size
Perfor-
mance
Type
Cooling kW
Heating
Air Volume Cooling m
3
/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Drain Hose ø,mm
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
Slim 1 way cassette
2.60
2.90
6.2
7.5
30
30
1,220~240,50
45
45
0.23
0.23
970x135x410
38.2x5.3x16.1
10.5
ø6.35x7.5
ø9.52x7.5
VP20(ID20/OD25)
Cross Flow Fan
Feedback SSR
28
2ROW 12STEP
-
Slim 1 way cassette
3.50
3.80
7.6
8.2
32
32
1,220~240,50
50
50
0.25
0.25
970x135x410
38.2x5.3x16.1
10.5
ø6.35x7.5
ø9.52x7.5
VP20(ID20/OD25)
Cross Flow Fan
Feedback SSR
28
2ROW 12STEP
-
MH035FSEAMH026FSEA
Product Specifications(cont.)

Samsung Electronics 2-7
Model
Item
MH026FJEA MH035FJEA MH052FJEA
INDOOR UNIT
Size
Perfor-
mance
Console
2.60
2.90
9.0
10.5
28
28
1,220~240,50
30
30
0.25
0.25
720x620x199
28.3x24.4x7.8
15.0
ø6.35x7.5
ø9.52x7.5
VP20(ID20/OD25)
Turbo Fan
steel
28
2ROW 20STEP
-
Console
3.50
3.80
10.5
11.3
39
39
1,220~240,50
35
35
0.29
0.29
720x620x199
28.3x24.4x7.8
15.0
ø6.35x7.5
ø9.52x7.5
VP20(ID20/OD25)
Turbo Fan
steel
28
2ROW 20STEP
-
Console
5.20
5.60
11.2
12.6
44
44
1,220~240,50
50
50
0.35
0.35
720x620x199
28.3x24.4x7.8
15.0
ø6.35x7.5
ø12.7x7.5
VP20(ID20/OD25)
Turbo Fan
steel
28
2ROW 20STEP
-
Type
Cooling kW
Heating
Air Volume Cooling m
3
/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Drain Hose ø,mm
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
Product Specifications(cont.)

2-8 Samsung Electronics
Model
Item INDOOR UNIT
Size
Perfor-
mance
Slim Duct
2.60
2.90
8.6
9.0
30
30
1,220~240,50
80
80
0.40
0.40
900x199x600
35.4x7.8x23.6
26
ø6.35x7.5
ø9.52x7.5
Sirocco fan
Resin/steel
29
2ROW 12STEP
EEV
Slim Duct
3.50
3.80
9.8
10.3
32
32
1,220~240,50
80
80
0.40
0.40
900x199x600
35.4x7.8x23.6
26
ø6.35x7.5
ø9.52x7.5
Sirocco fan
Resin/steel
29
2ROW 12STEP
EEV
MSP Duct
5.20
5.60
16.3
15.8
37
37
1,220~240,50
170
170
1.04
1.04
900x260x480
35.4x10.2x18.9
29.5
ø6.35x7.5
ø12.7x7.5
Sirocco fan
Resin/steel
50
3ROW 10STEP
EEV
Type
Cooling kW
Heating
Air Volume Cooling m
3
/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
NJ035LHXEA MH052FUEANJ026LHXEA
Product Specifications(cont.)

Samsung Electronics 2-9
Model
Item
MH030FMEA MH035FMEA MH052FMEA
INDOOR UNIT
Size
Perfor-
mance
Mini 4 way cassette
3.50
3.80
10.8
11.7
30
30
1,220~240,50
85
85
0.37
0.37
575x575x260
22.6x22.6x10.2
17
ø6.35x7.5
ø9.52x7.5
Turbo Fan
steel
55
2ROW 10STEP
EEV
Mini 4 way cassette
3.50
3.80
10.8
11.7
34
34
1,220~240,50
85
85
0.37
0.37
575x575x260
22.6x22.6x10.2
17
ø6.35x7.5
ø9.52x7.5
Turbo Fan
steel
55
2ROW 10STEP
EEV
Mini 4 way cassette
5.20
5.60
12.1
13.6
41
41
1,220~240,50
120
120
0.52
0.52
575x575x260
22.6x22.6x10.2
17
ø6.35x7.5
ø12.7x7.5
Turbo Fan
steel
55
2ROW 10STEP
EEV
Type
Cooling kW
Heating
Air Volume Cooling m
3
/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
Product Specifications(cont.)

2-10 Samsung Electronics
Product Specifications(cont.)
Model
Item INDOOR UNIT
Size
Perfor-
mance
Wall-mounted
2.00
2.20
7.9
8.2
36
36
1,220~240,50
30
30
0.18
0.18
820x286x205
32.3x11.3x8.1
9.0
ø6.35x7.5
ø9.52x7.5
Cross Flow Fan
Resin/steel
2ROW 14STEP
_
2.50
3.30
36
36
1,220~240,50
620
800
3.0
3.8
9.0
ø6.35x7.5
ø9.52x7.5
Resin/steel
2ROW 14STEP
Type
Cooling kW
Heating
Air Volume Cooling m3/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
AQV09PSBNAQV07PSBN
_
Cross Flow Fan
_
_
820x286x205
32.3x11.3x8.1
Wall-mounted
3.5
4.0
38
38
1,220~240,50
1060
1080
4.8
4.9
ø6.35x7.5
ø9.52x7.5
Resin/steel
2ROW 14STEP
AQV12PSBN
Wall-mounted
820x286x205
32.3x11.3x8.1
9.0
Cross Flow Fan
_
_
__
__
Model
Item INDOOR UNIT
Size
Perfor-
mance
Type
Cooling kW
Heating
Air Volume Cooling m3/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
6.6
7.8
41
41
1,220~240,50
2120
2160
9.0
10.0
1065x230x298
41.9x9.1x11.7
13.0
ø6.35x7.5
ø15.88x7.5
Resin/steel
2ROW 16STEP
AQV24PSBN
Wall-mounted
Cross Flow Fan
_
_
_
_
5.0
6.0
40
40
1,220~240,50
1470
1660
6.8
7.7
1065x230x298
41.9x9.1x11.7
13.0
ø6.35x7.5
ø12.70x7.5
Resin/steel
2ROW 16STEP
AQV18PSBN
Wall-mounted
Cross Flow Fan
_
_
_
_

Samsung Electronics 2-11
Product Specifications(cont.)
Model
Item INDOOR UNIT
Size
Perfor-
mance
Wall-mounted
2.5
3.2
39
39
1,220~240,50
520
670
2.5
3.1
880x313x237
34.6x12.3x9.3
10.5
ø6.35x7.5
ø9.52x7.5
Cross Flow Fan
Resin/steel
2ROW 16STEP
_
3.5
4.0
41
41
1,220~240,50
850
980
3.9
4.5
ø6.35x7.5
ø9.52x7.5
Resin/steel
2ROW 16STEP
Type
Cooling kW
Heating
Air Volume Cooling m3/min
Heating
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Outer Dimension WxHxD mm
inch
Weight kg
Refrigerant Pipe Liquid mmxL(m)
Gas mmxL(m)
Type
Blower Motor Type
Rated Output W
Heat Exchanger
Refrigerant Control Unit
Power
AQV12YWANAQV09YWAN
_
Cross Flow Fan
_
_
Wall-mounted
5.0
6.0
43
43
1,220~240,50
1558
1662
7.4
7.7
ø6.35x7.5
ø12.7x7.5
Resin/steel
2ROW 16STEP
AQV18YWAN
Wall-mounted
11.5
Cross Flow Fan
_
_
__
__
_
_
880x313x237
34.6x12.3x9.3
10.5
880x313x237
34.6x12.3x9.3

2-12 Samsung Electronics
Product Specifications(cont.)
Model
Item
RJ040F2HXEA RJ050F2HXEA
OUTDOOR UNIT
Power
(Outdoor
Only)
Size
Fan Motor
&
Blower
Com-
pressor
Perfor-
mance
4.0
4.4
30.35
47
47
1110
1020
5.1
4.7
15
790x545x285
35
OLP
Propeller
ø410
-
-
2ROW 24STEP
EEV
1,300
5.0
5.7
33.05
48
48
1425
1360
6.5
6.2
15
39
OLP
Propeller
ø410
-
-
2ROW 28STEP
EEV
1,600
1,220-240V~,50Hz
INVERTER
UG4T150FUDJQSS
BLDC Permanent Magnetic Motor
POE
650
Type
Capacity Cooling kW
Heating
Air Volume m
3
/min
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Fuse Capacity A
Dimension WxHxD mm
Weight kg
Type
Model Name
Motor Type
Lubricant Oil Type
Capacity cc
Protection Device
Blower Type
Size mm
Motor Rated Output W
Capacitor uFxVAC
Heat Exchanger
Refrigerant Control Device
Charging Refrigerant(R410A) gr
Free Joint Multi
790x545x285

Samsung Electronics 2-13
Product Specifications(cont.)
5.9
6.3
41
48
48
1600
1400
7.3
6.4
20
880x798x310
59
Twin Rotary
G8T200FUAEW
700
OLP
Propeller
ø460
50
-
2ROW 36STEP
EEV
2,200
7.0
8.6
44.8
49
49
1900
2000
8.7
9.2
30
880x798x310
65
Twin Rotary
G8T260FUAEW
700
OLP
Propeller
ø460
50
-
2ROW 36STEP
EEV
2,800
8.0
9.3
45.4
50
50
2300
2000
10.5
10.1
30
880x798x310
65
Twin Rotary
G8T260FUEAW
700
OLP
Propeller
ø460
50
-
2ROW 36STEP
EEV
2,800
Free Joint Multi
1,220-240V~,50Hz
BLDC Permanent Magnetic Motor
POE
Model
Item OUTDOOR UNIT
Power
(Outdoor
Only)
Size
Fan Motor
&
Blower
Com-
pressor
Perfor-
mance
Type
Capacity Cooling kW
Heating
Air Volume m
3
/min
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Fuse Capacity A
Dimension WxHxD mm
Weight kg
Type
Model Name
Motor Type
Lubricant Oil Type
Capacity cc
Protection Device
Blower Type
Size mm
Motor Rated Output W
Capacitor uFxVAC
Heat Exchanger
Refrigerant Control Device
Charging Refrigerant(R410A) gr
RJ060F3HXEA RJ070F4HXEA RJ080F4HXEA

2-14 Samsung Electronics
Product Specifications(cont.)
Model
Item
RJ100F5HXEA
OUTDOOR UNIT
Power
(Outdoor
Only)
Size
Fan Motor
&
Blower
Com-
pressor
Perfor-
mance
10
12
70.58
59
63
2900
2930
13.3
13.4
40(EMI)
940X998X330
74.5
OLP
Propeller
ø520
125
-
2ROW 46STEP
EEV
3,300
1,220-240V~,50Hz
Twin Rotary
UG8T300FUBJUSG
BLDC Permanent Magnetic Motor
POE
1200
Type
Capacity Cooling kW
Heating
Air Volume m
3
/min
Noise Cooling dB(A)
Heating
Power ø,V,Hz
Power Consumption Cooling W
Heating
Operating Current Cooling A
Heating
Fuse Capacity A
Dimension WxHxD mm
Weight kg
Type
Model Name
Motor Type
Lubricant Oil Type
Capacity cc
Protection Device
Blower Type
Size mm
Motor Rated Output W
Capacitor uFxVAC
Heat Exchanger
Refrigerant Control Device
Charging Refrigerant(R410A) gr
Free Joint Multi

Samsung Electronics 2-15
2-3 The Comparative Specifications of Product
Outdoor Unit
Design
Net Weight
Indoor Unit
Indoor
Unit
Outdoor
Unit
MH020FVEA
MH026FVEA MH035FVEA
MH020FNEA MH026FNEA MH035FNEA
MH023FBEA MH026FBEA MH035FBEA
MH020FAEA MH026FAEA MH035FAEA
MH026FJEA MH035FJEA
MH040FXEA2C
8.5kg
7.8kg
10.2kg
9.0kg
15.0kg
14.0kg
RJ040F2HXEA
Item
MH026FSEA MH035FSEA 10.5kg
MH020FVEA
MH026FVEA MH035FVEA
MH020FNEA MH026FNEA MH035FNEA
MH023FBEA MH026FBEA MH035FBEA
MH020FAEA MH026FAEA MH035FAEA
MH026FJEA MH035FJEA
8.5kg
7.8kg
10.2kg
9.0kg
15.0kg
MH026FSEA MH035FSEA 10.5kg
AQV07/09/12PSBN 9.0kg
AQV09/12YWAN 10.5kg
MH026FKEA MH035FKEA 15.0kg
RJ040F2HXEA 35.0kg
MH040FXEA2C
%FWFMPQNFOU.PEFM $PNQBSBUJWF.PEFM

2-16 Samsung Electronics
The Comparative Specifications of Product(cont.)
Free Joint Multi(Variable Indoor Unit)
BLDC INVERTER COMPRESSOR
Outer
Dimension
Indoor Unit
Outdoor Unit
The Feature of Product
Item RJ040F2HXEA
Noise
Indoor Unit
Outdoor Unit
RJ040F2HXEA 790X545X285mm MH040FXEA2C
MH040FXEA2C
Free Joint Multi(Variable Indoor Unit)
BLDC INVERTER COMPRESSOR
MH020/026/035FVEA
MH020/026/035FNEA
MH023/026/035FBEA
MH020/026/035FAEA
MH026/035FJEA
MH026/035FSEA
AQV07/09/12PSBN
AQV09/12YWAN
900x304x185mm
825x285x189mm
820x286x190mm
825x285x189mm
820x286x205mm
880x313x237mm
720x620x199mm
970x135x410mm
MH020/026/035FVEA
MH020/026/035FNEA
MH023/026/035FBEA
MH020/026/035FAEA
MH026/035FJEA
MH026/035FSEA
900x304x185mm
825x285x189mm
820x286x190mm
825x285x189mm
720x620x199mm
970x135x410mm
790X545X285mm
MH020/026/035FVEA
MH020/026/035FNEA
MH023/026/035FBEA
MH020/026/035FAEA
MH026/035FJEA
MH026/035FSEA
AQV07/09/12PSBN
AQV09/12YWAN
31/31/35 dB
31/31/35 dB
31/31/35 dB
32/32/36 dB
36/36/38 dB
39/41 dB
28/39 dB
30/32 dB
MH020/026/035FVEA
MH020/026/035FNEA
MH023/026/035FBEA
MH020/026/035FAEA
MH026/035FJEA
MH026/035FSEA
n
n
n
n
n
n
n
n
31/31/35 dB
31/31/35 dB
31/31/35 dB
32/32/36 dB
28/39 dB
30/32 dB
n
n
n
n
n
n
RJ040F2HXEA MH040FXEA2C
47 dB
n
47 dB
n
970x180x390mm
MH026/035FKEA
MH026/035FKEA 36/38 dB
n
