Samsung STH-160PI User manual

SPEED DOME CAMERAACCESSORIES
STH-160PO/STH-160PI/STH-128PE
STB-270PW/STB-496PP
USER’S MANUAL
■Beforeattemptingtooperatethisproduct,pleasereadtheinstructionscarefully.
P/No.:6806-0588-01A
SAMSUNGTECHWINCO.,LTD.
145-3,Sangdaewon1-Dong,Jungwon-Gu,
Sungnam,Kyungki-Do,Korea462-703
TEL:[phone]~8141 FAX:[phone]
SAMSUNGOPTO-ELECTRONICSAMERICA,INC.
ELECTORONICIMAGINGDIV.
40SeaviewDrive,SecaucusNJ07094,U.S.A
TEL:[phone] FAX:[phone]
SAMSUNGTECHWINMOSCOWOFFICE
LENNINGRADSDYPR-KT,37A.KORP.14
RUSSIA,125167,MOSCOW
TEL:[phone],9298 FAX:[phone]
SAMSUNGOPTO-ELECTRONICSUKLTD.
SamsungHouse,1000HillswoodDrive
HillswoodBusinessParkChertseySurreyKT16OPS
TEL:[phone] FAX:[phone]
TIANJINSAMSUNGOPTO-ELECTRONICSCO.,LTD.
7PingchangRd,NankaiDist,Tianjin,P.RChina
PostCode:300190
TEL:[phone] FAX:[phone]
SALES NETWORK
http://www.samsungtechwin.com
http://www.samsungcctv.com

3
SPEED DOME CAMERA ACCESSORIES
2
SPEED DOME CAMERA ACCESSORIES
CautionsandWarningsforUse Contents
Thank you for purchasing our products.
These accessories are designed to be mounted and used with Samsung Speed Dome
Camera Series products.
(Except SPD- 1600, SPD- 2500 and SWC-160)
Before application, please read the user’s manual carefully.
▶Note that you need to read carefully all contents related to safety and application methods
before application.
▶All warnings and application methods for using these accessories should be strictly
observed, and it is necessary to follow all operating methods and instructions.
▶The power and cable connection needs to be carried out by installation engineers.
▶Do not connect and use these accessories to products other than the Samsung Dome
Camera Series.
▶The locations for installing the housing should be strong enough to fully secure the
accessories, and all installations need to be carried out by experienced engineers.
▶Do not use these accessories other than for the purposes intended.
Cautions and Warnings for Use .................................................... 2
Product Category .......................................................................... 4
Installation Guide .......................................................................... 6
Component Name.........................................................................11
External Dimensions .....................................................................12
Specification..................................................................................13

5
SPEED DOME CAMERA ACCESSORIES
4
SPEED DOME CAMERA ACCESSORIES
ProductCategory
STH-160PO
Outdoor housing for the Samsung Speed Dome Camera.
STH-160PI
Indoor housing for the Samsung Speed Dome Camera.
STH-128PE
Embedded indoor housing for the Samsung Speed Dome Camera.
STB-270PW
Wall mounted bracket for the Samsung Speed Dome Housing.
STB-496PP
Ceiling mounted bracket for the Samsung Speed Dome camera.
■Model Name
STH-160PO, STH-160PI, STH-128PE
STH => Samsung Techwin Housing
160,128 =>φ(mm), P=>Speed Dome, O=> Outdoor, I=> Indoor,
E=> Embedded
STB-270PW, STB-496PP
STB => Samsung Techwin Bracket
270, 496 => L(mm), P=> Speed Dome, W=> Wall Mounting, P=> Pendant Mounting
Note

4.Fix themountingbracketandhousing using three screws.
5.Fix the housing to the wall mounted bracket using three
screws.
7
SPEED DOME CAMERA ACCESSORIES
6
SPEED DOME CAMERA ACCESSORIES
1.With STB-270PW, the wall mounted bracket, fix the bracket
totheintended location using fourscrews.
STH-160PI is the same as STH-160PO except for the fan and heater.
■STH-160PO (Outdoor Housing), STH-160PI (Indoor Housing)
2.Connect cables to the video cable terminal and controller
cableterminalon the circuit boardofthe mounting bracket.
3.Connect the power cable for the fan heater (Outdoor
Housing).
Video Cable
InstallationGuide
·Pull the connection cable out of the bracket
through the hole in advance.
Cautions
·When using the outdoor or indoor housing,
remove the dome cover of the Speed Dome
Camera for clearer images.
Cautions
·For fixing the circuit board, match the lock screw
part with the direction of the housing sticker.
Cautions
Controller Cable
Mounting Bracket
Power Adapter Cable
Power Cable
7.Connect the circuit board to the connector of the Speed
DomeCameraas shown in thefigure.
6.Fit and turn the Speed Dome Camera into the slot, locating it
in the direction marked on the mounting bracket, and fix it
usingtherotation control screw.
8.Fix the externalcovertothe housing usingfourscrews.

9
SPEED DOME CAMERA ACCESSORIES
8
SPEED DOME CAMERA ACCESSORIES
InstallationGuide
■Ceiling Mounting
1.With the STB- 496PP,theceilingmounted bracket, fix the brackettotheintended location using four screws.Thenfollow
theinstallationguide for the wallmountedbracket.
■STH- 128PE (Concealed Housing)
1.Make a hole of 155mm diameter in the ceiling for
installation.
2.Connect the cables to the video cable terminal and controller
cableterminalon the circuit boardofthe mounting bracket.
Video Cable
·Pull the connection cable to where it is required
through the ceiling.
Cautions
·Check the assembly direction before assembling.
Cautions
3.Fix the mounting bracket to the concealed housing using
threescrews.
Controller Cable
Power Adapter Cable Mounting Bracket

11
SPEED DOME CAMERA ACCESSORIES
10
SPEED DOME CAMERA ACCESSORIES
InstallationGuide ComponentName
4.Fasten the eye bolt on the housing and fix the housingtothe
ceiling,usingthe cable to preventitfrom falling.
5.Fix the housingtotheceiling using three screws.
6.Fit and turn the Speed Dome Camera into the slot, locating it
in the direction marked on the mounting bracket, and fix it
usingtherotation control screw.
7.Connect the mounting bracket to the connector of the
SpeedDomeCamera as shown inthefigure.
8.Fixthe external cover tothehousing using three screws.
■Wall Mounting
■■Ceiling Mounting ■■Embedded Mounting
FAN
BRACKETHEATER
PLATEFIXDOME
RUBBERGASKET
DOMECOVER
RINGDECORATION
WALLBRACKET
HOUSINGOUTDOOR
HOUSINGOUTDOORSHIELD
BRACKETP.C.B
RINGDECORATION
DOMECOVER
PLATEFIXDOME
RUBBERGASKET
FAN
BRACKETHEATER
BRACKETP.C.B
HOUSINGOUTDOORSHIELD
HOUSINGOUTDOOR
CEILINGPIPE
CEILINGFLANGE
CEILINGPLATE
HOUSINGINCEILING
RINGDECORATION
(INCEILINGTYPE)

13
SPEED DOME CAMERA ACCESSORIES
12
SPEED DOME CAMERA ACCESSORIES
ExternalDimensions Specification
■Wall Mounting
■Embedded Indoor Housing ■Ceiling Mounted Housing
88
252
R80
R83
8
217
197
252
88
8
R8
R8
322.58
207
496
761.35
43066
66.00 430.00
175
207
187
270
20
252.3
190
132
180.8
161.5
154
155.7
Unit : mm
※Designand specificationsaresubject tochange without notice.
Cautions
●Samsung Techwin Inc. owns the copyright of this manual.
●This manual may not be reproduced in whole or in part, or transmitted in any form whatsoever, whether
electronic, mechanical or audio, without the written permission of Samsung Techwin.
●The contents of this manual may be revised for functional improvement at any time.
-20℃~50℃
0to90%RH
SCREW(3EA)
FAN
-- - -
HEATER
SCREW(3EA)
SCREW(4EA)
SCREW(3EA)
BHMS
M3xL6
BHMS
M3xL6
HousingOutdoor
RingDecoration
DomeCover
ALDC12
ALDC12
POLYCARBONATE
DC24V0.06A
OperatingTemp.:
morethan45℃
DC24V30W
OperatingTemp.:
lessthan10℃
SelfDrillingScrew
#8xL38(FZY)
PHMSM4xL14
IP67
3,020g
4,100g
ф242x284.5
IP67
3,020g
4,100g
ф242x284.5
-
740g
1,220g
ф190.3x190.3
-
1,130g
1,320g
270x175x140
-
1,750g
1,970g
150x496
-10℃~50℃
0to90%RH
(non-condensing)
-10℃~50℃
0to90%RH
(non-condensing)
-20℃~50℃
0to90%RH
(non-condensing)
-20℃~50℃
0to90%RH
(non-condensing)
Item
Operating
Temperature Range
Humidity
Materials
Accessories
(mm)
Others
Antivibration/Waterproot
Weight (Net)
Weight (Gross)
Dimensions
Model
STH-160PO
(OUTDOORHOUSING)
STH-160PI
(INDOORHOUSING)
STH-128PE
(INDOOREMBEDDEDHOUSING)
STB-270PW
(WALLBRACKET)
STB-496PP
(CEILINGBRACKET)
HousingOutdoor
RingDecoration
DomeCover
BracketWall HousingOutdoor
RingDecoration
CeilingFlange
CeilingPipe
CeilingPlate
ALDC12
SPPS32A/Sch40
SPCC
SAFETYWIRE(1EA)
TurnBuckle(1EA)
WIREJOINT(1EA)
SCREW(3EA)
SUS(ф1.2x2000)
-
-
BHMSM3xL6
EGI(1.2t)
ABS
ALDC12
ALDC12
POLYCARBONATE
ALDC12
SCREW(4EA)
SCREW(3EA)
SelfDrillingScrew
#8xL38(FZY)
PHMSM4xL14

MEMOMEMO
