Samsung SM-N950U User manual

SM-N950U/W/U1
Common
Mobile Device
CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1 Repair
7. Level 2 Repair
8. Level 3 Repair
9. Reference data
Notice: All functionality, features, specifications,
and other product information provided in this
document, including but not limited to, benefits,
design, pricing, components, performance,
availability, and capabiliti-es of the product are
subject to change without notice. Samsung
reserves the right to alter this doc-ument or the
product described herein at anytime, without
obligation to provide notification of such
changes.
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
Samsung Electronics Co.,Ltd
2017. 08. Rev 1.0
ⓒ
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2.1 CDMA/LTE General Specification
US PCS CDMA CDMA BC10 GPS LTE FDD B1
Tx Freq. range 1850 ~ 1910MHz 824.04 ~ 848.97MHz
817.9 ~
823.1MHz - 1920~1980 MHz
Rx Freq. range 1930 ~ 1990MHz 869.04 ~ 893.97MHz
862.9 ~
868.1MHz 1575.42MHz 2110~2170 MHz
Channel Bandwidth 1.23MHz 1.23MHz 1.23MHz - 5, 10, 15, 20MHz
Channel Spacing 50KHz 30KHz 25KHz Not Used 180KHz
Number of Channel 1200 832 205 1 25, 50, 75, 100
Duplex Separation 80MHz 45MHz 45MHz - 190 MHz
Type of Emission 1M27F9W 1M27F9W 1M27F9W -
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
Tx Local Frequency FTx * 0.7999 FTx * 1.6666 FTx * 1.6666 - -
Rx Local Frequency FRx * 0.8888 FRx * 2 FRx * 2 - -
Frequency Stability (FRX-80MHz)±150Hz (FRX-45MHz)±300Hz (FRX-45MHz)±300Hz - -
Operating
Temperature -30℃~ +60℃-30℃~ +60℃-30℃~ +60℃-30℃~ +60℃-30℃~ +60℃
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
LTE FDD B2 LTE FDD B3LTE FDD B4 LTE FDD B5 LTE FDD B7
Tx Freq. range 1850 ~ 1910 MHz 1710 ~ 1785 MHz 1710~1755 MHz 824 ~ 849 MHz 2500~2570 MHz
Rx Freq. range 1930 ~ 1990 MHz 1805 ~ 1880 MHz 2110~2155 MHz 869 ~ 894 MHz 2620~2690 MHz
Channel Bandwidth 1.4, 3, 5, 10, 15, 20
MHz 1.4, 3, 5, 10, 15, 20 MHz 1.4, 3, 5, 10, 15, 20 MHz 1.4, 3, 5, 10 MHz 5, 10,15, 20 MHz
Channel Spacing 180KHz 180KHz 180KHz 180KHz 180KHz
Number of Channel 6, 15, 25, 50, 75, 100 6, 15, 25, 50, 75, 100 6, 15, 25, 50, 75, 100 6, 15, 25, 50 25, 50, 75, 100
Duplex Separation 80 MHz 95 MHz 400 MHz 45 MHz 45 MHz
Type of Emission
1M11G7D (QPSK)
1M11W7D (16QAM)
1M11W7D (64QAM)
2M71G7D (QPSK)
2M71W7D (16QAM)
2M71W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
1M11G7D (QPSK)
1M11W7D (16QAM)
1M11W7D (64QAM)
2M71G7D (QPSK)
2M71W7D (16QAM)
2M71W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
1M11G7D (QPSK)
1M11W7D (16QAM)
1M11W7D (64QAM)
2M71G7D (QPSK)
2M71W7D (16QAM)
2M71W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
1M11G7D (QPSK)
1M11W7D (16QAM)
1M11W7D (64QAM)
2M71G7D (QPSK)
2M71W7D (16QAM)
2M71W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
Tx Local Frequency - - - - -
Rx Local Frequency - - - - -
Frequency
Stability - - - - -
Operating
Temperature -30℃~ +60℃-30℃~ +60℃-30℃~ +60℃-30℃~ +60℃-30℃~ +60℃
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
LTE FDD B8LTE FDD B12 LTE FDD B13 LTE FDD B17 LTE FDD B18
Tx Freq. range 880 ~ 915 MHz 699 ~ 716 MHz 777~787 MHz 704 ~ 716 MHz 815 ~ 830 MHz
Rx Freq. range 925 ~ 960 MHz 729 ~ 746 MHz 746~756 MHz 734 ~ 746 MHz 860 ~ 875 MHz
Channel Bandwidth 1.4, 3, 5, 10 MHz 1.4, 3, 5, 10 MHz 5, 10 MHz 5, 10 MHz 5, 10, 15 MHz
Channel Spacing 180KHz 180KHz 180KHz 180KHz 180KHz
Number of Channel 6, 15, 25, 50 25, 50, 75, 100 25, 50 25, 50 25, 50, 75
Duplex Separation 45 MHz 30 MHz -31 MHz 30 MHz 45 MHz
Type of Emission
1M11G7D (QPSK)
1M11W7D (16QAM)
1M11W7D (64QAM)
2M71G7D (QPSK)
2M71W7D (16QAM)
2M71W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
1M11G7D (QPSK)
1M11W7D (16QAM)
1M11W7D (64QAM)
2M71G7D (QPSK)
2M71W7D (16QAM)
2M71W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
Tx Local Frequency
Rx Local Frequency
Frequency
Stability
Operating
Temperature -30℃~ +60℃-30℃~ +60℃-30℃~ +60℃-30℃~ +60℃-30℃~ +60℃
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
LTE FDD B19 LTE FDD B20 LTE FDD B25 LTE FDD B26 LTE FDD B28
Tx Freq. range 830 ~ 845 MHz 832 ~ 862 MHz 1850~1915 MHz 814 ~ 849 MHz 703 ~ 748 MHz
Rx Freq. range 875 ~ 890 MHz 791 ~ 821 MHz 1930~1995 MHz 859 ~ 894 MHz 758 ~ 803 MHz
Channel Bandwidth 5, 10, 15 MHz 5, 10, 15, 20 MHz 1.4, 3, 5, 10, 15, 20
MHz 1.4, 3, 5, 10, 15 MHz
3, 5, 10, 15, 20 MHz
Channel Spacing 180KHz 180KHz 180KHz 180KHz 180KHz
Number of Channel 25, 50, 75 25, 50, 75, 100 6, 15, 25, 50, 75, 100 6, 15, 25, 50, 75 15, 25, 50, 75, 100
Duplex Separation 45 MHz -41 MHz 80 MHz 45 MHz 55 MHz
Type of Emission
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
1M11G7D (QPSK)
1M11W7D (16QAM)
1M11W7D (64QAM)
2M71G7D (QPSK)
2M71W7D (16QAM)
2M71W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
1M11G7D (QPSK)
1M11W7D (16QAM)
1M11W7D (64QAM)
2M71G7D (QPSK)
2M71W7D (16QAM)
2M71W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
2M71G7D (QPSK)
2M71W7D (16QAM)
2M71W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
Tx Local Frequency -----
Rx Local Frequency -----
Frequency
Stability -----
Operating
Temperature -30℃~ +60℃-30℃~ +60℃-30℃~ +60℃-30℃~ +60℃-30℃~ +60℃
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
LTE FDD B30 LTE FDD B38 LTE FDD B39 LTE FDD B40 LTE FDD B41
Tx Freq. range 2305 ~ 2315 MHz 2570 ~ 2620 MHz 1880~1920 MHz 2300 ~ 2400 MHz 2496~ 2690 MHz
Rx Freq. range 2350 ~ 2360 MHz 2570 ~ 2620 MHz 1880~1920 MHz 2300 ~ 2400 MHz 2496~ 2690 MHz
Channel Bandwidth 5, 10 MHz 5, 10, 15, 20 MHz 5, 10, 15, 20 MHz 5, 10, 15, 20 MHz 5, 10, 15, 20 MHz
Channel Spacing 180KHz 180KHz 180KHz 180KHz 180KHz
Number of Channel 25, 50 25, 50, 75, 100 25, 50, 75, 100 25, 50, 75, 100 25, 50, 75, 100
Duplex Separation 45 MHz - - - -
Type of Emission
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
Tx Local Frequency -----
Rx Local Frequency -----
Frequency
Stability -----
Operating
Temperature -30℃~ +60℃-30℃~ +60℃-30℃~ +60℃-30℃~ +60℃-30℃~ +60℃
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
LTE FDD B66
Tx Freq. range 1710 ~ 1780 MHz
Rx Freq. range 2110 ~ 2200 MHz
Channel Bandwidth 1.4, 3, 5, 10, 15, 20 MHz
Channel Spacing 180KHz
Number of Channel 6, 15, 25, 50, 75, 100
Duplex Separation 400 MHz
Type of Emission
1M11G7D (QPSK)
1M11W7D (16QAM)
1M11W7D (64QAM)
2M71G7D (QPSK)
2M71W7D (16QAM)
2M71W7D (64QAM)
4M50G7D (QPSK)
4M50W7D (16QAM)
4M50W7D (64QAM)
9M00G7D (QPSK)
9M00W7D (16QAM)
9M00W7D (64QAM)
13M5G7D (QPSK)
13M5W7D (16QAM)
13M5W7D (64QAM)
18M0G7D (QPSK)
18M0W7D (16QAM)
18M0W7D (64QAM)
Tx Local Frequency -
Rx Local Frequency -
Frequency Stability -
Operating Temperature -30℃~ +60℃
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-2. GSM/WCDMA General Specification
GSM850 EGSM
900 DCS1800 PCS1900 WCDMA 2100 WCDMA 1900 WCDMA 1700 WCDMA 900 WCMDA 850
Freq.
Band[MHz
]
Uplink/
Downlink
824~849
869~894 880~915 925~960
1710~178
5
1805~188
0
1850~191
0
1930~199
0
1922~197
7
2112~216
7
1852~190
7
1932~198
7
1710~175
5
2110~215
5
880~915
925~960 824~849 869~894
ARFCN
range 128~251 0~124 &
975~1023
512~885 512~810
UL:
9612~988
8
DL:
10562~10
838
UL:
9262~953
8
DL:
9662~993
8
UL:
1312~151
3
DL:
1537~173
8
UL:
2712~286
3
DL:
2937~308
8
UL:
4132~423
3
DL:
4357~445
8
Tx/Rx
spacing 45MHz 45MHz 95MHz 80MHz 190MHz 80MHz 400MHz 45MHz 45MHz
Mod. Bit
rate/
Bit Period
270.833kb
ps
3.692us
270.833k
bps
3.692us
270.833kb
ps
3.692us
270.833k
bps
3.692us 3.84Mcps
3.84Mcps 3.84Mcps 3.84Mcps 3.84Mcps
Time Slot
Period/
Frame
Period
576.9us
4.615ms 576.9us 4.615ms 576.9us 4.615ms 576.9us 4.615ms
FrameLen
gth:
10ms
Slotlength
:
0.667ms
FrameLen
gth:
10ms
Slotlength
:
0.667ms
FrameLen
gth:
10ms
Slotlength
:
0.667ms
FrameLen
gth:
10ms
Slotlength
:
0.667ms
FrameLen
gth:
10ms
Slotlength
:
0.667ms
Modulatio
n 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK
QPSK
HQPSK QPSK HQPSK QPSK HQPSK QPSK HQPSK QPSK HQPSK
MS Power
33dBm~
5dBm 33dBm~ 5dBm 30dBm~ 0dBm 30dBm~ 0dBm 24dBm~ -50dBm 24dBm~ -50dBm 24dBm~ -50dBm 24dBm~ -50dBm 24dBm~ -50dBm
Power
Class 5pcl ~ 19pcl 5pcl ~ 19pcl
0pcl ~ 15pcl 0pcl ~ 15pcl
3(max+24d
Bm) 3(max+24d Bm) 3(max+24d Bm) 3(max+24d Bm) 3(max+24d Bm)
Sensitivit
y -102dBm -102dBm -100dBm -100dBm - 106.7dBm
-
106.7dBm
-
106.7dBm
-
106.7dBm
-
106.7dBm
TDMA
Mux 8 8 8 8 8 8 8 8 8
Cell
Radius 35Km 35Km 2Km 2Km 2Km 2Km 2Km 2Km 2Km
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
2-3. GSM Tx Power Class
TX Power
control level GSM850
TX Power
control level EGSM900
TX Power
control level DCS1800
TX Power
control level PCS1900
5 33±2 dBm 5 33±2 dBm 0 30±3 dBm 0 30±3 dBm
6 31±2 dBm 6 31±2 dBm 1 28±3 dBm 1 28±3 dBm
7 29±2 dBm 7 29±2 dBm 2 26±3 dBm 2 26±3 dBm
8 27±2 dBm 8 27±2 dBm 3 24±3 dBm 3 24±3 dBm
9 25±2 dBm 9 25±2 dBm 4 22±3 dBm 4 22±3 dBm
10 23±2 dBm 10 23±2 dBm 5 20±3 dBm 5 20±3 dBm
11 21±2 dBm 11 21±2 dBm 6 18±3 dBm 6 18±3 dBm
12 19±2 dBm 12 19±2 dBm 7 16±3 dBm 7 16±3 dBm
13 17±2 dBm 13 17±2 dBm 8 14±3 dBm 8 14±3 dBm
14 15±2 dBm 14 15±2 dBm 9 12±4 dBm 9 12±4 dBm
15 13±2 dBm 15 13±2 dBm 10 10±4 dBm 10 10±4 dBm
16 11±3 dBm 16 11±3 dBm 11 8±4 dBm 11 8±4 dBm
17 9±3 dBm 17 9±3 dBm 12 6±4 dBm 12 6±4 dBm
18 7±3 dBm 18 7±3 dBm 13 4±4 dBm 13 4±4 dBm
19 5±3 dBm 19 5±3 dBm 14 2±5 dBm 14 2±5 dBm
- - - - 15 0±5 dBm 15 0±5 dBm
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
3. Operation Instruction and Installation
Main Function
Item
Description
OS
Android V7.1.1
RF
2G CDMA : BC0 / BC1 / BC10
2G GSM 850(B5) / 900(B8) / 1800(B3) / 1900(B2)
3G WCDMA : B1 / B2 / B4 / B5 / B8
4G(LTE)
- FDD : B1 / B2 / B3 / B4 / B5 / B7 / B8 / B/12/ B13 /B17 / B18 / B19 / B20 / B25 / B26 / B29 / B30 / B66
- TDD : B38 / B39 / B40 / B41
- TD-SCDMA : B34 / B39
Battery
3
,3
00mAh
Base Band
MSM8998 / 2.35GHz, 1.9GHz
Other RF
GPS, Glonass, BT 4.2, USB 3.1, WIFI 802.11 a/b/g/n/ac (2.4G+5GHz), NFC, MST
Camera 12 MP Rear(wide+tele), Dual Pixel, AF
8.0
MP Front
LCD
6.32” Quad HD, 2960 x 1440, dual edge Super AMOLED
RAM
6GB LPDDR4X + 64GB UFS
Sensor Accelerometer, Barometer, Fingerprint Sensor, Gyro Sensor, Geomagnetic Sensor, Hall Sensor,
HR Sensor, Iris Sensor, Proximity Sensor, RGB Light Sensor, Pressure Sensor
Accessory
Charger : 5V/2A or 9 V/1.67 A
Data cable : USB Type-C
Earjack : 3.5pi, 4Pin
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
9. Reference Abbreviate
Reference Abbreviate
― AAC: Advanced Audio Coding.
― AVC : Advanced Video Coding.
― BER : Bit Error Rate
― BPSK: Binary Phase Shift Keying
― CA : Conditional Access
― CDM : Code Division Multiplexing
― C/I : Carrier to Interference
― DMB : Digital Multimedia Broadcasting
― EN : European Standard
― ES : Elementary Stream
― ETSI: European Telecommunications Standards Institute
― MPEG: Moving Picture Experts Group
― PN : Pseudo-random Noise
― PS : Pilot Symbol
― QPSK: Quadrature Phase Shift Keying
― RS : Reed-Solomon
― SI : Service Information
― TDM : Time Division Multiplexing
― TS : Transport Stream
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1. Safety Precautions
1-1. Repair Precaution
Before attempting any repair or detailed tuning, shield the device from RF noise or static
electricity discharges.
Use only demagnetized tools that are specifically designed for small electronic repairs,
as most electronic parts are sensitive to electromagnetic forces.
Use only high quality screwdrivers when servicing products. Low quality screwdrivers can
easily damage the heads of screws.
Use only conductor wire of the properly gauge and insulation for low resistance, because of the low margin
of error of most testing equipment.
We recommend 22-gauge twisted copper wire.
Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily
damaged, even with relatively low heat. Never use a soldering iron with a power rating of
more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).
Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.
Always use the replacement parts that are registered in the SEC system. Third-party replacement parts
may not function properly.
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1. Safety Precautions
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Many semiconductors and ESDs in electronic devices are particularly sensitive to static discharge and can
be easily damaged by it. We recommend protecting these components with conductive anti-static bags
when you store or transport them.
Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate
static electricity from your body before repairing ESDs.
Ensure that soldering irons have AC adapter with ground wires and that the ground wires are properly
connected.
Use only desoldering tools with plastic tips to prevent static discharge.
Properly shield the work environment from accidental electrostatic discharge before opening
packages containing ESDs.
The potential for static electricity discharge may be increased in low humidity environments,
such as air-conditioned rooms. Increase the airflow to the working area to decrease the
chance of accidental static electricity discharges.
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

6.
6-1
6-1
 I
n

M

D

M
※
S
Distribution, tra
Level 1
. S/W D
o
-1. Prep
a
n
stallation
p
M
obile Phon
D
ata Cable
M
obile devic
S
ettings
Confidential
a
a
nsmission, or in
f
Repai
r
o
wnload
a
re for S
p
rogram: D
o
e
c
e specific
S
a
nd proprietar
y
f
ringement of an
y
/W Dow
n
o
wnloader
P
S
/W: Binary
y
-the contents i
y
content or dat
a
n
loading
P
rogram (O
d
files
Data C
a
n this service
g
a
from this docu
m
din3 v3.12
a
ble : GH
3
g
uide subject t
o
m
ent without Sa
m
.
10.exe)
3
9-01949
A
o
change with
o
m
sung’s written
a
A
o
ut prior notic
e
a
uthorization is s
e
t
rictly prohibited.
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

6.
6-1

O
Distribution, tra
Level 1
-2. S/W I
n
O
pen up th
e
Confidential
a
a
nsmission, or in
f
Repai
r
n
stallati
o
e
S/W Insta
a
nd proprietar
y
f
ringement of an
y
o
n Progr
a
llation Pro
g
y
-the contents i
y
content or dat
a
a
m (Dow
n
g
ram by ex
e
n this service
g
a
from this docu
m
n
loader p
r
e
cuting the
"
g
uide subject t
o
m
ent without Sa
m
r
ogram)
"
Odin3 v3.
o
change with
o
m
sung’s written
a
12.10.exe"
o
ut prior notic
e
a
uthorization is s
e
t
rictly prohibited.
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

6.
1.
E
- C
h
- C
h
- C
h
* N
o
Distribution, tra
Level 1
E
nable the
c
h
eck
A
uto
h
eck PIT
h
eck BOO
T
o
te : "Odin
v
Confidential
a
a
nsmission, or in
f
Repai
r
c
heck mark
Reboot, F.
T
LOADER,
P
v
3.12.10 or
a
nd proprietar
y
f
ringement of an
y
by click on
Reset Tim
P
DA, PHO
N
above" ch
e
y
-the contents i
y
content or dat
a
the followi
n
e, Nand Er
a
N
E, CSC a
n
e
cks MD5
c
n this service
g
a
from this docu
m
n
g options,
a
se
n
d USERD
A
c
hecksum j
u
g
uide subject t
o
m
ent without Sa
m
A
T
A
Files
u
st after file
o
change with
o
m
sung’s written
a
selection.
o
ut prior notic
e
a
uthorization is s
e
t
rictly prohibited.
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

6.
2.
E
- E
n
s
i
Distribution, tra
Level 1
E
nter into D
o
n
ter into Do
w
i
multaneou
s
Confidential
a
a
nsmission, or in
f
Repai
r
o
wnload M
o
w
nload Mo
d
s
ly followe
d
a
nd proprietar
y
f
ringement of an
y
o
de
d
e by pres
s
d
by pressi
n
y
-the contents i
y
content or dat
a
s
ing Volum
e
n
g Volume
u
n this service
g
a
from this docu
m
e
Down but
t
u
p button a
s
g
uide subject t
o
m
ent without Sa
m
t
on, Intellig
e
s
a directio
n
o
change with
o
m
sung’s written
a
e
nce butto
n
n
of the ph
o
o
ut prior notic
e
a
uthorization is s
n
and ON/
O
o
ne.
e
t
rictly prohibited.
O
FF Button
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

6.
3.
C
Ma
k
sky
bin
a
Distribution, tra
Level 1
C
onnect the
k
e sure tha
t
blue. The
d
a
ry files in i
t
Confidential
a
a
nsmission, or in
f
Repai
r
device to
P
t
the one of
d
evice is n
o
t
.
a
nd proprietar
y
f
ringement of an
y
P
C via Dat
a
communic
a
o
w connect
e
y
-the contents i
y
content or dat
a
a
Cable.
a
tion ports
e
d with the
n this service
g
a
from this docu
m
[ID:COM]
b
PC and re
a
g
uide subject t
o
m
ent without Sa
m
b
ox is highli
g
a
dy to dow
n
o
change with
o
m
sung’s written
a
g
hted in
load the
o
ut prior notic
e
a
uthorization is s
e
t
rictly prohibited.
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

6.
4.
S
sc
r
bin
5.
D
6.
O
by
p
Yo
u
※
Distribution, tra
Level 1
S
tart downl
o
r
een. The g
r
ary files ha
v
D
isconnect
t
O
nce the d
e
p
ressing th
e
u
can perfo
r
Caution.
Confidential
a
a
nsmission, or in
f
Repai
r
o
ading the
b
r
een colore
v
e been su
c
t
he device
f
e
vice boots
e
following
c
r
m Factory
d
Never di
s
a
nd proprietar
y
f
ringement of an
y
b
inary files
i
d "PASS!"
s
c
cessfully
d
f
rom the D
a
up, you ca
n
c
ode in se
q
d
ata Reset
s
connect
y
-the contents i
y
content or dat
a
nto the de
v
s
ign will ap
p
d
ownloade
d
a
ta cable.
n
check the
uence; *#1
2
by Setting
s
during th
n this service
g
a
from this docu
m
v
ice by clic
k
p
ear on th
e
d
into the d
e
version of
t
234#
s
→Gener
a
e S/W d
o
g
uide subject t
o
m
ent without Sa
m
k
ing Start b
u
e
uppe
r
-left
e
vice.
t
he binary
f
a
l Manage
m
o
wnloadin
o
change with
o
m
sung’s written
a
u
tton on th
e
b
ox if the
ile or name
m
ent →Re
g
.
o
ut prior notic
e
a
uthorization is s
e
e
e
set
e
t
rictly prohibited.
Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
