Samsung PL70 Manual

Technical Information
Samsung camera samsung PL70
SAMSUNG

Contents
Part 1. Firmware
Part 2. Adjustment
Part 3. Disassembly

1. Firmware
Product Name
Product
Name
Product Name Mondrian 125W VE
Korean VLUU PL70
Abroad SAMSUNG PL70
For USA SAMSUNG SL720
Barrel
Barrel Name E2
Applied Product _

1. Firmware
Checking Firmware
Initialization
1. Turn on the Camera

1. Firmware
2. Press and hold the WIDE + Down and then press the Power OFF.

1. Firmware
3. Turn on the camera and check whether the camera is reset or not.

1. Firmware
Checking Firmware
Checking version
1. Power source should be full-charged battery.
2. Remove the memory card from the camera & turn off the camera.
3. Press the Shutter + Down and then press the Power ON.

1. Firmware
4.After checking Firmware version, turn off the camera.

1. Firmware
Upgrading Firmware
General Firmware
How To Upgrade Firmware
Firmware File Construction :
- Code Area : Being Included Operation codes for camera driving.
- Partition[1:3] : Being Included all kind of resources for camera driving.
=> Defective Pixel & Lens shading adjustment data goes to save in Partition3.
- UserArea : Being saved all setting data while customer played their camera function,
and other adjustment data, also.
▷[Reference] General F/W
- Upgrading the general firmware means that real action is occurred on "Code" area + "Partition[1:2]" .
- Do not change what saved on "UserArea" & "Partition3"

1. Firmware
1. Insert the memory card included F/W file & Upgrading script file.
* Being asked 2 files for FW Upgrading, those are F/W data file & Upgarding Script file.
* Recommendation: When do the upgrading process, whole data should be back-up before.
(Otherwise, whole data saved in Flash Memory will be deleted.)
2. Use theAC adapter or a fully charged battery.
* To upgrade the firmware, the battery level indicator on the LCD monitor must be full (level three).
3. Turn on the camera.

1. Firmware
4. F/W ver which will be upgraded is shown on LCD, automatically.
To start the upgrading process, press the Shutter button.

1. Firmware
5. Upgrading process is doing while displayed the F/W ver on LCD.
6.After completing the upgrade, the camera is turned off automatically.

1. Firmware
Upgrading Firmware
Full Firmware
How to do Full Ver F/W upgrading
Firmware File Construction :
- CodeArea : Being Included Operation codes for camera driving.
- Partition[1:3] : Being Included all kind of resources for camera driving.
=> Defective Pixel & Lens shading adjustment data goes to save in Partition3.
- UserArea : Being saved all setting data while customer played their camera function,
and other adjustment data, also.
▷[Reference] Full F/W
- Upgrading the general firmware means that real action is occurred on "Code" area + "Partition[1:2]" .
- Do not change what saved on "UserArea" & "Partition3"

1. Firmware
▷[Reference] Full F/W
- Upgrading Full Firmware means that real action is occurred on "Code" area + "Partition[1:3]"
- Some adjustment data saved on "UserArea" will not be changed.
- Defective Pixel & Lens Shading adjustment data have to be reset,
cause those files are saved on Partition3. Do not forget to re-adjust or do the back-up process for
adjustments so that previous adjustment files are restored.
- While done the FULL F/W upgrading, adjustment files will be saved into the external memory card,
automatically. Then, do uploading those adjustment files according to below steps. (No.1 ~ No.7)
-Automatically saved files into the external memory card
: LSCLUT0.BIN, DefectivePixel0.bin, DefectivePixel1.bin (3 types)

1. Firmware
1. Insert the memory card included F/W file & Upgrading script file.
* Being asked 2 files for FW Upgrading, those are F/W data file & Upgarding Script file.
* Recommendation: When do the upgrading process, whole data should be back-up before.
(Otherwise, whole data saved in Flash Memory will be deleted.)
2. Use theAC adapter or a fully charged battery.
* To upgrade the firmware, the battery level indicator on the LCD monitor must be full (level three).
3. Turn on the camera.

1. Firmware
4. F/W ver which will be upgraded is shown on LCD, automatically.

1. Firmware
5. To start the upgrading process, press the Shutter button.
Then, process will be done, automatically.
5-1. Before done the Full F/W upgrading,
being done some adjustment files are back-up to the external memory card, automatically.

1. Firmware
5-2. Then, Full F/W upgrading also will be progressed. (Blinking the Green LED)
5-3.After completing the full ver. upgrading, the camera is turned off automatically.
6. Re-boot the camera body in order to re-write files which are BACK-UP previously.

1. Firmware
7. Press the SHUTTER (S1) Button then back up process will be done.

1. Firmware
8.After completed the Back-up process, comes out to Power Off status.
