Samsung S Band User manual

www.samsung.com
Type E. AXXXXX
05/2013. Rev. 1.0

S Band
User manual

Contents
English ................................................................................................................................1

1
English
• This manual’s images and content may differ from the product and is subject to change
without prior notice.
• This product is only a health assisting device. It cannot be used for medical diagnostic
purposes.
Safety precautions
Do not use the device for anything other than its intended use
Do not disassemble, modify, or repair the device
Any changes or modifications to the device can void your manufacturer’s warranty.
For service, take the device to a Samsung Service Centre.
When using the device, mind the following:
• Humidity and liquids may damage parts or electronic circuits.
• Do not store the device in hot areas. High temperature may cause damage to the device
or shorten battery life.
• Do not drop the device or cause impacts to it.
English

2
Overview
Check the product box for the following items: S Band, Micro USB cable, and user
manual. The supplied items may vary depending on the region.
Indicator light
Micro USB cover
Setting button

3
English
Charging the S Band
The device has a rechargeable internal battery which is non-removable. Make sure
they are fully charged before using it for the first time.
• Use only Samsung-approved chargers.
• The travel adapter is sold separately.

4
1 Connect the travel adapter to the charging socket on the device.
2 Plug the travel adapter into the wall outlet. During charging, the indicator light
will turn red. If the red indicator light flashes, unplug the travel adapter and plug
it in again.
3 When fully charged, the indicator light turns green. Unplug the travel adapter
from the device.
• When the main power turns off by the internal battery discharge, the accumulated
data in the device cannot be restored.
• It is recommended to charge the device and sync with the smartphone before the
battery is discharged.

5
English
Wearing the S Band
Stretch out both sides of the device, and wear it on your wrist.
Do not pull or stretch out the device too hard to avoid damage of the device.

6
Pairing and Connecting with a smartphone
Check physical activities and sleep patterns of daily life by connecting the device to
the smartphone.
To connect with the smartphone, the S Health application must be installed and
launched on the smartphone.
Connecting
1 Press and hold the setting button to enter Pairing mode until the indicator light
flashes red, green, and blue for 30seconds.
2 On the smartphone, launch the S Health application.
3 Tap Health board
→
Walking mate
→ →
S Band.

7
English
4 Tap Scan to search for the device.
5 To pair with the smartphone, select the device from the list of available devices.
• Once pairing is complete, the blue or white indicator light stays for 3seconds,
and then turns off.
• When the device is connected, the green indicator light flashes for 5seconds,
and then turns off.
• When the device is connected, the accumulated data can be managed on the
smartphone.
• At first connection, the device starts counting steps. Press and hold the button for
3seconds to change into other function.
• Physical activities may not be measured accurately when the Wi-Fi and Bluetooth
features are turned on at the same time.
