Samsung UN F7050AF Series User manual

LED TV
SERVICEManual
LED TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UN**F7050AF
Chassis : U85A
Model : UN46F7050AF
UN55F7050AF
UN60F7050AF
UN65F7050AF

Contents
1. Precautions...................................................................................................................1-1
1-1. Safety Precautions ..............................................................................................................1-1
1-1-1. Warnings...................................................................................................................1-1
1-1-2. Servicing the LED TV ...............................................................................................1-1
1-1-3. Fire and Shock Hazard.............................................................................................1-1
1-1-4. Product Safety Notices .............................................................................................1-2
1-2. Servicing Precautions..........................................................................................................1-3
1-2-1. General Servicing Precautions .................................................................................1-3
1-3. Static Electricity Precautions ...............................................................................................1-4
1-4. Installation Precautions .......................................................................................................1-5
2. Product Specications.................................................................................................2-1
2-1. Product information .............................................................................................................2-1
2-2. Product specications..........................................................................................................2-2
2-2-1. Detailed Specications .............................................................................................2-2
2-2-2. Feature & Specications...........................................................................................2-7
2-3. Accessories ........................................................................................................................2-8
2-4. Viewing the Functions .........................................................................................................2-9
2-4-1. Auto Motion Plus 120 Hz ..........................................................................................2-9
2-4-2. Supported Formats.................................................................................................2-10
2-4-3. Smart Control .........................................................................................................2-13
2-4-4. IR Blaster................................................................................................................2-17
2-4-5. SMART Interaction .................................................................................................2-18
2-4-6. SMART HUB...........................................................................................................2-21
2-4-7. 3D Display ..............................................................................................................2-23
3. Disassembly and Reassembly ....................................................................................3-1
3-1. Disassembly and Reassembly ............................................................................................3-1
4. Troubleshooting ...........................................................................................................4-1
4-1. Troubleshooting...................................................................................................................4-1
4-1-1. Previous Check ........................................................................................................4-1
4-1-2. Simple ow chart of malfunction...............................................................................4-3
4-2. How to Check Fault Symptom.............................................................................................4-4
4-2-1. NO Power .................................................................................................................4-4
4-2-2. No Video (HDMI 1, 2, 3, 4 - Digital Signal) ..............................................................4-7
4-2-3. No Video (Tuner_CVBS) ........................................................................................4-10
4-2-4. No Vido (Tuner DTV) ..............................................................................................4-13
4-2-5. No Video (Video AV) ...............................................................................................4-16
4-2-6. No Video (COMPONENT) ......................................................................................4-19
4-2-7. No Sound (1.Speaker 2.Monitor_out 3.Optical)..................................................4-22

4-3. Factory Mode Adjustments................................................................................................4-26
4-3-1. Detail Factory Option..............................................................................................4-26
4-3-2. Entering Factory Mode ...........................................................................................4-27
4-3-3. Factory Data ...........................................................................................................4-28
4-4. White Balance ...................................................................................................................4-41
4-4-1. Calibration ..............................................................................................................4-41
4-4-2. Service Adjustment.................................................................................................4-41
4-4-3. Adjustment..............................................................................................................4-42
4-5. RS-232C............................................................................................................................4-43
4-6. AV Control Tabe.................................................................................................................4-44
4-7. Software Upgrade..............................................................................................................4-50
4-7-1. How to Check the Software Version .......................................................................4-50
4-7-2. How to Upgade Software........................................................................................4-51
5. Wiring Diagram.............................................................................................................5-1
5-1. Wiring Diagram....................................................................................................................5-1
5-2. Connector............................................................................................................................5-2
5-3. Connector Functions ...........................................................................................................5-5

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2013 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
When servicing the LED TV, Disconnect the AC line cord from the AC outlet.1.
It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this2.
meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the1.
chassis and other metal parts in the monitor.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and2.
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
Leakage Current Hot Check:3.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch rst 4.
in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.)
and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions
1. Precautions
1-1. Safety Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, re and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before1.
attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used.2.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements
to their original position.
After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that3.
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input4.
terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect5.
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greater than 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;6.
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your1.
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent2.
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.3.
Use only a grounded-tip soldering iron to solder or desolder ESDs.4.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate 5.
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs6.
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material7.
to the chassis or circuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or8.
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

For safety reasons, more than a people are required for carrying the product.1.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.2.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature3.
may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed4.
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check5.
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the 6.
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (0.4m) between the product and the wall for ventilation purposes.7.
A rise in temperature within the product may cause re.
If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an8.
explosion (for example, with some lithium batteries), the following applies:
CAUTION
Risk of explosion if battery is replaced by an incorrect type dispose of used batteries according to•
the instructions.
Do not dispose of batteries in a re.•
Do not short circuit, disassemble or overheat the batteries.•
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent•
type.
Do not be exposed to excessive heat such as sunshine, re or the like.•
1-5
1. Precautions
1-4. Installation Precautions

2-1
2. Product specications
2. Product Specications
2-1. Product information
Model UN**F7050AF
Front View
W
D
* W : Width H : High D : Depth
H
Detail View
Front Color Titan Silver
Dimensions
(W x H x D)
46" Set with Stand 1036.6 x 677.1 x 307.2 mm / 40.8 x 26.6 x 12.0 inches
Set without Stand 1036.6 x 591.9 x 30.8 mm / 40.8 x 23.3 x 1.2 inches
55" Set with Stand 1227.9 x 784.9 x 307.2 mm / 48.3 x 30.9 x 12.0 inches
Set without Stand 1227.9 x 699.5 x 30.8 mm / 48.3 x 27.5 x 1.2 inches
60" Set with Stand 1366.0 x 879.8 x 375.6 mm / 53.7 x 34.6 x 14.7 inches
Set without Stand 1366.0 x 786.0 x 31.2 mm / 53.7 x 30.9 x 1.2 inches
65" Set with Stand 1451.4 x 923.2 x 375.6 mm / 57.1 x 36.3 x 14.7 inches
Set without Stand 1451.4 x 840.2 x 32.2 mm / 57.1 x 33.0 x 1.2 inches
Weight
46" Set with Stand 12.8 kg / 28.2 Ibs
Set without Stand 11.2 kg / 24.6 Ibs
55" Set with Stand 16.5 kg / 36.3 Ibs
Set without Stand 14.9 kg / 32.8 Ibs
60" Set with Stand 22.4 kg / 49.3 Ibs
Set without Stand 19.8 kg / 43.6 Ibs
65" Set with Stand 25.7 kg / 56.6 Ibs
Set without Stand 23.1 kg / 50.8 Ibs
Panel Type Black
Internal Memory 4 G
DDR 1 G
Feature 3D / SMART GUIDE / USB HID / DLNA / Full Browsing / Miracast

2-2
2. Product specications
2-2. Product specications
2-2-1. Detailed Specications
NOTE
Design and specications are subject to change without prior notice.
Item UN**F7050AF
General Information Product LED
Series 7
Country UNITED STATES
Display Inch 46" / 55" / 60" / 65"
Resolution 1,920 x 1,080
Ultra Clear Panel Yes
Lvds Format JEIDA
HV Flip ON
Video Picture Engine 3D HyperReal Engine
Clear Motion Rate 720
Dynamic Contrast Ratio Mega Contrast
Micro Dimming Micro Dimming
Precision Black (Local Dimming) No
Wide Color Enhancer (Plus) Yes
Auto Motion Plus 120/240Hz 240Hz
Film Mode Yes
Brightness 300nits
Contrast Ratio 5000:1
Picture 3D-Effect,Film Mode,HDMI Black Level
Detail Resolution 60Hz
Response Time 8ms
Viewing Angle (H/V) 178/178
Natural Mode Support Yes
Audio Dolby Dolby Digital Plus / Dolby Pulse
SRS / DNSe+ DTS Studio Sound
dts 2.0+Digital Out / DTS Premium Audio DTS Premium Audio 5.1
3D Sound Yes
Sound Customizer No
Speaker Type Down Firing + Full Range
Sound Output (RMS) 10W x 2
Woofer No
Sound SRS TheaterSound HD
Sound Amp IC TI | TAS5745

2-3
2. Product specications
Item UN**F7050AF
Audio Speaker Output 10W x 2
Woofer Speaker Output No
Analog 2Ch
Digital Optical
SMART TV Functionality Smart Guide Yes
Family Story Yes
Movie & TV Shows Yes
Fitness Yes
Apps Yes
Kids Yes
Social Yes
Music, Photos & Clip Yes
Samsung SMART View Yes (Clone View only)
Smart Hub Yes
Your Video No
Samsung Sports Experience (SSE) Yes
Smart Scene No
Web Browser Yes
AllShare Control No
Recommendation Bar Yes
VESA Standard Screw Size 400 x 400, M8
Smart Interaction Camera Built-in No
Face Recognition Ready
Hand Gesture Recognition Ready
Voice Recognition (Embedded) Yes (Only Smart Touch Control)
Voice Recognition (Server) Yes (Only Smart Touch Control)
NLU (Natural Language Understanding) Yes (Only Smart Touch Control)
Camera App No
Samsung TV Apps supported Yes
Feature Samsung 3D Yes
3D Converter Yes
History Yes
Multi Tasking No
Smart Phone Remote support Yes
Smart Evolution Support No
Extended PVR No
Time Shift No
Allshare Play Yes
ConnectShare™ (USB2.0) Movie

2-4
2. Product specications
Item UN**F7050AF
Feature AllShare Cast Yes
RUI No
RVU Yes (Direct TV ready)
WiFi Direct Yes
Wireless LAN Built-in Yes
Wireless LAN Adaptor Support No
ISP Bound Service Yes
BT HID Built-in Yes
USB HID Support Yes
OSD Language English, Spanish, French
Samsung IR Blaster Support N/A
User Interface Golden Bridge
Digital Noise Filter Yes
MHL No
Sound Share Yes
InstaPort S (HDMI quick switch) No
HDMI 1.4 3D Auto Setting Yes
HDMI 1.4 A/Return Ch. Support Yes
EPG Yes
Teletext (TTX) No
Miracast No
Anynet+ (HDMI-CEC) Yes
BD Wise Plus Yes
Auto Channel Search Yes
Auto Power Off Yes
Auto Volume Leveler Yes
Caption (Subtitle) Yes
2 Tuner No
Clock&On/Off Timer Yes
Game Mode Yes
Picture-In-Picture Yes
Sleep Timer Yes
V-Chip Yes
Embeded POP Yes
Channel Auto Store,Signal Level,Fine Tune
Plug&Play Yes
Child Lock Yes
Sports Mode No
Paratal Lock Yes

2-5
2. Product specications
Item UN**F7050AF
Feature Media Play(USB & DLNA) Yes
Bluetooth Yes
ACS No
IP Video Closed Caption No
Additional Feature Self Diagnosis Yes
Software Upgrade Yes
HD Connection Guide Yes
Contact Samsung Yes
S/W MCU Name X12
OS Linux
System DTV Tuner ATSC / Clear QAM
Analog Tuner Yes
NTSC 3.58 Yes
Broadcast System ATSC/Clear QAM
ATV Sound System M
DTV Video System ATSC
DTV Sound System Dolby
Tuner Vendor & Model SEM | DTVS20EIL035B
Input & Output HDMI 4
Resolution 1920 x 1080
DVI Supported Port Port1 Type
PC Maximum Supported Resolution 1920 x 1080 | 60 Hz
USB 3
Port 1 Type Host
Port 2 Type Host
Port 3 Type Host
OS Linux
Component In (Y/Pb/Pr) 1
Composite In (AV) 1 (Common Use for Component Y)
Ethernet (LAN) 1
Headphone No
Digital Audio Out (Optical) 1
Audio Out (Mini Jack / LR) 1
PC In (D-sub) No
PC Audio In (Mini Jack) No
DVI Audio In (Mini Jack) No
RF In (Terrestrial/Cable Input) 1
RF In (Satelite Input) No
RS232C (AV CONTROL) 1

2-6
2. Product specications
Item UN**F7050AF
Input & Output Coaxial No
EX-Link Yes
Monitor Output No
IR Out Yes
Design Design Metal
Color Chrome Silver
Bezel Type SNB
Light Effect (Deco) No
Swivel (Left/Right) Yes
Stand Type Quad
Accessory 3D Active Glasses (Included) 4 (SSG-5100GB)
IR Blaster (Included) Yes (Premium)
Wireless LAN Adaptor (Included) No
Network Speaker (Included) No
MOIP Camera (Included) No
Wireless Keyboard (Included) No
Remote Controller Model TM1360B
Battery (for Remote Control) Yes
Mini Wall Mount Support Yes
Ultra Slim Wall Mount Support No
VESA Wall Mount Support Yes
Electric Wall Mount Support No
Slim Gender Cable No
ANT-Cable Yes
Power Cable Yes
User Manual Yes
E-Manual Yes
Floor Stand Support No

2-7
2. Product specications
2-2-2. Feature & Specications
Feature
Digital-TV, RF, 4-HDMI, 1-Component, 1-A/V(Common Use for Component Y), 3-USB2.0(Media Play), LAN, Wi-Fi•
PIP(in HDMI 1, 2, 3, 4 Component and Sub picture is available only in TV mode(DTV/ATV))•
Dolby Digital Plus Pulse, DTS Premium Sound 5.1, DTS Studio Sond•
Specications
Model UN46F7050AF UN55F7050AF UN60F7050AF UN65F7050AF
Item Description
Screen Size (Diagonal) 46˝ Class 55˝ Class 60˝ Class 65˝ Class
LCD Panel FHD 120 Hz
Scanning Frequency Horizontal : 67.5 kHz (TYP)
Vertical : 60 Hz (TYP)
Display Colors Wide Color Enhancer Plus
Display Resolution 1920 x 1080
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock Rate 138 MHz
AC Power Voltage & Frequency AC110-120V 60Hz
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage Temperature : -4˚F ~ 113˚F (-20˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Sound (Output) 10W x 2
Note : AllShare, SMART Guide, Web Browser, USB HID, IR Blaster, Smart Control

2-8
2. Product specications
2-3. Accessories
NOTE
The items’ colors and shapes may vary depending on the model.•
Cables not included in the package contents can be purchased separately.•
The part code for some accessories may differ depending on your region.•
Product Code. No Product Code. No
Smart Touch Control• AA59-00772A Samsung 3D Active Glasses• BN96-30009A
Remote Control• BN59-01162A User Manual• BN68-04930A
Batteries (AAA x 4)• 4301-000103 Regulatory Guide• BN68-04972A
Power Cord• 3903-000853
Image Product Code. No
Holder-Ring• BN61-07295A
Holder-Wire Stand• BN61-08370A
IR Extender Cable• BN96-26652B

2-9
2. Product specications
2-4. Viewing the Functions
2-4-1. Auto Motion Plus 120 Hz
Function Naming
120 Hz FRC + MJC : Auto Motion Plus 120 Hz-
Detail Specications
Function (OSD) 120 Hz FRC Judder reduction
(only 24p source) Blur reduction
Off Off
(repeat) Off Off
Clear ON
(interpolation) Off High
Standard ON
(interpolation) Medium Medium
Smooth ON
(interpolation) High High
Custom Level variable
(0~10)
Demo Demo
(Standard / Off)
120Hz Motion Enhancement
Off Low / Mudium / High Demo

2-10
2. Product specications
2-4-2. Supported Formats
Supported Subtitle Formats
Exterminal
Name File Extension
MPEG-4 Timed text .ttxt
SAMI .smi
SubRip .srt
SubViewer .sub
Micro DVD .sub or .txt
SubStation Alpha .ssa
Advanced SubStation Alpha .ass
Powerdivx .psb
Internal
Name File Extension
Xsub AVI
SubStation Alpha MKV
Advanced SubStation Alpha MKV
SubRip MKV
MPEG-4 Timed text MP4
Supported Music File Formats
File Extension Type Codec Comments
*.mp3 MPEG MPEG1 Audio Layer 3
*.m4a
MPEG4 AAC*.mpa
*.aac
*.ac FLAC FLAC Supports up to 2 channel
*.ogg OGG Vorbis Supports up to 2 channel
*.wma WMA WMA
WMA 10 Pro supports up to 5.1
channel. WMA lossless audio is
not supported. Supports up to M2
prole (except LBR mode)
*.wav wav wav
*.mid
*.midi midi midi type 0, type 1 are supported.
*.ape ape ape

2-11
2. Product specications
Supported Video Formats
File
Extension Container Video Codec Resolution Frame rate (fps)
Bit rate
(Mbps) Audio Codec
*.avi
AVI
MKV
ASF
MP4
3GP
MOV
FLV
VRO
VOB
PS
TS
SVAF
Divx 3.11 / 4 / 5 / 6
1920 x 1080
6~30
30
AC3
LPCM
ADPCM(IMA,
MS)
AAC
HE-AAC
WMA
DD+
MPEG(MP3)
G.711(A-Law,
μ-Law)
*.mkv
*.asf
MPEG4 SP/ASP
*.wmv
*.mp4
H.264 BP/MP/HP
*.3gp
*.vro
Motion JPEG 640 x 480
8
*.mpg
*.mpeg
Microsoft MPEG-4 v3
1280 x 720
*.ts
*.tp Window Media Video
v7,v8
30
*.trp
*.mov
Window Media Video v9
1920x1080
*.v
*.vob
MPEG2
*.svi
*.m2ts
MPEG1
*.mts
*.divx
MVC
640 x 480
24/25/30 60
VP6
6~30
4
*.webm WebM VP8 1920 x1080 20 Vorbis
Other Restrictions
Codecs may not function properly if there is a problem with the content data. Video content does not play or does not
play correctly if there is an error in the content or container. "Sound or video may not work if they have standard bit rates/
frame rates above the TV’s compatibility ratings." If the Index Table is wrong, the Seek (Jump) function does not work.
"When playing video over a network connection, the video may not play smoothly because of data transmission speeds."
Some USB/digital camera devices may not be compatible with the player.
Video Decorders
Supports up to H.264, Level 4.1 (does not support FMO/ASO/RS)•
VC1 AP L4 is not supported.•
All video codecs excluding WMV v7, v8, MSMPEG4 v3, MVC, and VP6:•
Below 1280 x 720: 60 frame max-
Above 1280 x 720: 30 frame max-
GMC is not supported.•
Supports SVAF top/bottom and left/right only.•
Supports Blu-ray/DVD MVC specs only.•
