SERVICEManual
TFT-LCD TV Contents
Refer to the service manual in the GSPN (see the rear cover) for the more information.
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Exploded View & Part List
6. Wiring Diagram
LED-TV
UN46C7000WF/UN55C7000WF
UN46C7000WR(HD-Ready)/UN55C7000WR(HD-Ready)
Chassis : N80A
Model : UN46C7000WF
UN55C7000WF
HD-Ready
UN46C7000WR
UN55C7000WR

Contents
1. Precautions..............................................................................................................1-1
1-1. Safety Precautions .........................................................................................................1-1
1-2. Servicing Precautions.....................................................................................................1-2
1-3. Electrostatically Sensitive Devices (ESD) Precautions ..................................................1-2
1-4. Installation Precautions ..................................................................................................1-3
2. Product specications............................................................................................ 2-1
2-1. Feature & Specications.................................................................................................2-1
2-2. Spec Comparison to the Old Models..............................................................................2-5
2-5. InfoLink...........................................................................................................................2-9
2-6. What is AllShare™ ?..................................................................................................... 2-11
2-7. MediaBridge .................................................................................................................2-18
2-8. Internet@TV.................................................................................................................2-23
2-9. 3D Display....................................................................................................................2-32
2-10. Accessories ................................................................................................................2-35
3. Disassembly and Reassembly............................................................................... 3-1
3-1. Disassembly and Reassembly .......................................................................................3-1
4. Troubleshooting ...................................................................................................... 4-1
4-1. Troubleshooting..............................................................................................................4-1
4-2. Alignments and Adjustments ........................................................................................4-38
4-3. Factory Mode Adjustments...........................................................................................4-39
4-4. White Balance - Calibration..........................................................................................4-55
4-5. Servicing Information....................................................................................................4-57
5. Exploded View & Part List...................................................................................... 5-1
5-1. Exploded View & Part List..............................................................................................5-1
6. Wiring Diagram........................................................................................................6-1
6-1. Wiring Diagram...............................................................................................................6-1
6-2. Connector.......................................................................................................................6-3
6-3. Connector Functions ......................................................................................................6-5
6-4. Cables ............................................................................................................................6-5

GSPN (Global Service Partner Network)
Area Web Site
North America http://service.samsungportal.com
Latin America http://latin.samsungportal.com
CIS http://cis.samsungportal.com
Europe http://europe.samsungportal.com
China http://china.samsungportal.com
Asia http://asia.samsungportal.com
Mideast & Africa http://mea.samsungportal.com
This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2010 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea
P/N: BN82-00750A-00

3-1
3. Disassembly and Reassemble
3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the UN46C7000WF LCD TV.
WARNING: This LCD TV contains electrostatically sensitive devices. Use caution when handling these components.
3-1. Disassembly and Reassembly
Cautions: 1. Disconnect the LCD TV from the power source before disassembly.
2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.
Description Picture Description Screws
1. Place the TV face down on cushioned
table.Remove 4 screws from the Stand.
Remove stand.
6003-000133
(M4, L8, MACHINE)

3-2
3. Disassembly and Reassemble
Description Picture Description Screws
2. Remove the screws of rear-cover.
6003-000133
(M4, L8, MACHINE)
6003-001003
(M4, L12, TAPTYPE)
2-1. Pull out a AC Power Cord
3. Lift up the rear-cover.

3-3
3. Disassembly and Reassemble
Description Picture Description Screws
4. Remove the cables and screws from
SMPS, Main board and Woofer and
Bracket stand link.
46 inch
55 inch
6001-002283
(M3, L5, MACHINE)
6003-000133
(M4, L8, MACHINE)

3-4
3. Disassembly and Reassemble
Description Picture Description Screws
5. Lift up the panel so you can remove front
cover.
Reassembly procedures are in the reverse order of disassembly procedures.※

5-1
5. Exploded View & Part List
5. Exploded View & Part List
5-1. UN46C7000WF Exploded View
T0003
T0175
T0175
M0215
M0014
T0910
M0013
M0524
T0176
BA001
M0027

5-2
5. Exploded View & Part List
5-1-1. UN46C7000WF Parts List
Location No. Code No. Description & Specication Q’ty S.A/S.N.A Remark
T0003 BN96-13119A ASSY COVER P-FRONT;UC7000 46,UO,PMMA+PMM 1 S.A
T0175 BN96-12943B ASSY SPEAKER P;4ohm,4pin,20W,R:630,Enclo 1 S.A
M0215 BN07-00863A LCD-PANEL;LTF460HQ02,SSEZQX,8bit,46,16.7 1 S.A
BA001 BN61-06211A BRACKET-AV;C8K(UO),PCM,T0.45,BKN-P824 1 S.N.A
T0910 BN96-13130B ASSY BRACKET P-STAND LINK;UC7000 46/55,E 1 S.N.A
T0176 BN96-13406B ASSY SPEAKER P;8ohm,4pin,10W,L: 640, R:1 1 S.A
M0014 BN94-02757A ASSY PCB MAIN;UN46C7000WFXZA 1 S.A
M0013 BN96-13126A ASSY COVER P-REAR;46UC7000,PCM,T0.45,BKN 1 S.A
M0524 BN96-13131A ASSY COVER P-GUIDE STAND;UC7000,PC+ABS G 1 S.A
M0027 BN96-13133A ASSY STAND P-BASE;UC7000 46/55,FOUR-LEG, 1 S.A

5-3
5. Exploded View & Part List
5-2. UN46C7000WF Parts List
Service Bom (SA: SERVICEAVAILABLE, SNA: SERVICE NOTAVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UN46C7000WFXZA
0.1 BN90-02588A ASSY COVER FRONT;UC7000 46 1 S.N.A
..2 T0527 AA68-03539A LABEL BAR CODE;65X40mm,ART PAPER 1 S.N.A
..2 T0003 BN96-13119A ASSY COVER P-FRONT;UC7000 46,UO,PMMA+PMM 1 S.A
...3 AB326 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 14 S.N.A
...3 CCM1 BN63-02183H COVER-SHEET;Rhcm,PE Vinyl,T0.04,1300mm,2 0.7 S.N.A
...3 CCM1 BN63-05199B COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL 4 S.N.A
...3 M0112 BN63-06587A COVER-FRONT;UC7000 46,UO,PMMA+PMMA/ABS,H 1 S.N.A
...3 AD070 BN64-01284A DECORATION-BOTTOM;46UC7000,PC,CLEAR,Sn C 1 S.N.A
...3 T0852 BN96-13123A ASSY COVER P-MIDDLE;46UC7000,ABS,HB,BLK 1 S.N.A
....4 BN61-05915B BOSS-TAPE;LB650 65",3M #4711,T1.1,W6.0mm 3.7 S.N.A
....4 BN61-06213A BRACKET-STOPPER BOSS;C8K,SECC+SK5,T1.2 11 S.N.A
....4 CCM1 BN63-02183H COVER-SHEET;Rhcm,PE Vinyl,T0.04,1300mm,2 0.7 S.N.A
....4 BN63-06597A COVER-FRONT MIDDLE;UC7000 46inch,ABS,HB, 1 S.N.A
....4 BN61-06539A BOSS-TAPE;UC8000,PE,T0.16,W5,Transparent 0.15 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.9 S.N.A
...3 BN96-13135A ASSY DECORATION P-WIER;46UC7000,STS304 T 1 S.N.A
....4 BN61-06210A BRACKET-WIRE,A;UC7000 40inch,STAINLESS-S 8 S.N.A
....4 BN61-06283A BRACKET-WIRE,B;UC7000 40inch,STAINLESS-S 2 S.N.A
....4 BN64-01279A DECORATION-WIRE;46UC7000,STS304 T4.0 1 S.N.A
...3 T0176 BN96-13406B ASSY SPEAKER P;8ohm,4pin,10W,L: 640, R:1 1 S.A
...3 M0125 BN96-13847B ASSY BOARD P-TOUCH FUNCTION&POWER IR;UN4 1 S.A
...3 BN60-00162V SPACER-FOAM;FOAM,50000mm,Dark Gray,0.5T, 3.18 S.N.A
...3 CIS1 0203-001598 TAPE-FILAMENT;#8915,0.15,12,55000,CLR 0.06 S.N.A
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
...3 BN61-05915B BOSS-TAPE;LB650 65",3M #4711,T1.1,W6.0mm 0.86 S.N.A
...3 BN61-06539A BOSS-TAPE;UC8000,PE,T0.16,W5,Transparent 0.15 S.N.A
...3 T0382 BP61-00509C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W20.0mm 0.28 S.N.A
0.1 M0002 BN90-02591A ASSY COVER REAR;UC7000 46 1 S.N.A
..2 HC001 BN61-06246A HOLDER-CORD;UC7000 40inch,ABS,BLK 1 S.N.A
..2 M0013 BN96-13126A ASSY COVER P-REAR;46UC7000,PCM,T0.45,BKN 1 S.A
...3 T0069 BN60-00121A SPACER-FELT;UB7000,FELT,L380,BLK,T0.35,W 2 S.N.A
...3 M0006 BN63-06559A COVER-REAR;UC7000 46inch,PCM,T0.45,BKN-P 1 S.N.A
...3 BN96-13128A ASSY MISC P-INSULATOR;UC7000,PC,T0.43 1 S.N.A
....4 BN63-06806A SHEET-INSULATOR SMPS;UC7000 40/46/55inch 1 S.N.A
....4 T0278 BN60-00124A SPACER-SPONGE;UB7000,CR,L310,T2.0,W10 2 S.N.A
...3 BN68-02543F LABEL-TERMINAL BOTTOM;UC7000/8000,UO,PET 1 S.N.A
...3 BN68-02544H LABEL-TERMINAL SIDE;UC7000/8000,UO,PET,T 1 S.N.A
...3 BN60-00162V SPACER-FOAM;FOAM,50000mm,Dark Gray,0.5T, 1.57 S.N.A
0.1 M0216 BN90-02594A ASSY STAND;UC7000 46 1 S.N.A
..2 M0524 BN96-13131A ASSY COVER P-GUIDE STAND;UC7000,PC+ABS G 1 S.A
...3 T0524 6902-001063 BAG PE;LDPE,T0.05,W180,L350,TRP,RECYCLE 1 S.N.A
...3 T0920 BN61-06221A GUIDE-STAND;UC6500 40inch,PC,G/F 20%,V2, 1 S.N.A
...3 BN68-02368C LABEL-ACCESSORY;A/P100G,T0.08,25mmX50mm, 1 S.N.A
...3 BN96-12031N ASSYACCESSORY-SCREW;10 LEDTV(40/46/55), 1 S.N.A
....4 M0081 6003-000133 SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW 9 S.A
....4 BN68-02907A MANUAL FLYER;4 leg base, both side 100x5 1 S.N.A

5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 BN69-04419L PACKING-BAG PE;UC5000,LDPE,70,90,4X8, 9E 1 S.N.A
...3 BN68-02825A MANUAL FLYER-STAND GUIDE;7~9 series,SAMS 1 S.N.A
..2 M0027 BN96-13133A ASSY STAND P-BASE;UC7000 46/55,FOUR-LEG, 1 S.A
...3 BN61-05240A HOLDER-SWIVEL RING TOP;LB700 46,POM HB,A 1 S.N.A
...3 AB323 BN61-06196A BRACKET-STAND;46,55 FOUR-LEG,ALDC12,ALDC 1 S.N.A
...3 BN61-06200A BRACKET-STAND, FRONT;46,55 FOUR-LEG,HGI, 2 S.N.A
...3 BN61-06204A BRACKET-STAND, REAR;46,55 FOUR-LEG,HGI,T 2 S.N.A
...3 BN61-06268A BRACKET-SWIVEL TOP;SPC,T 3.0,Zn-Plating, 1 S.N.A
...3 BN61-06331A HOLDER-SWIVEL RING BOTTOM;UC7K 46/55,POM 1 S.N.A
...3 BN63-06582A COVER-STAND, BASE;46,55 FOUR-LEG,HIPS,HB 1 S.N.A
...3 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 12 S.A
...3 M0081 6003-001238 SCREW-TAPTYPE;FH,+,S,M4,L8,ZPC(BLK),SWRC 5 S.N.A
...3 M0126 BN73-00052E RUBBER-FOOT;4-LEG,CR RUBBER,T1.5 DIA17,R 4 S.N.A
...3 BN74-00031A GREASE;kanto-kasei FL-955,grease,wht 0.6 S.N.A
...3 BN96-13563A ASSY BRACKET P-SWIVEL BOT;4-LEG(55),BRKT 1 S.N.A
....4 BN61-02428Q STUD-PEM;PNA,M3.8,D7,L9.3,ZPC(SIL),SUM24 4 S.N.A
....4 BN61-06269A BRACKET-SWIVEL BOT;SPC,T 3.0,Zn-Plating, 1 S.N.A
...3 BN63-06574A COVER-STAND,TOP;46,55 FOUR-LEG,ABS,HB,GR 1 S.N.A
...3 BN63-06575A COVER-STAND,TOP;46,55 FOUR-LEG,ABS,HB,GR 1 S.N.A
...3 BN63-06946A COVER-STAND FRONT;46/55 FOUR-LEG,ABS,HB, 1 S.N.A
0.1 M0017 BN91-04703A ASSY CHASSIS;UN46C7000WFXZA 1 S.N.A
..2 M0014 BN94-02757A ASSY PCB MAIN;UN46C7000WFXZA 1 S.A
...3 3711-007262 HEADER-BOARD TO CABLE;BOX,18P,2R,2mm,ANG 1 S.N.A
...3 T0756 AA68-01018A LABEL-PQS;50mmX,13,WHITE 1 S.N.A
...3 CIS3 BN40-00164A TUNER;DTVS30CVH071A,NTSC,191CH,45.75MHz, 1 S.A
...3 T0174 BN97-03971A ASSY SMD;UN46C7000WFXZA,BN94-02757A? 1 S.N.A
....4 0401-000116 DIODE-SWITCHING;MMSD914T1,100V,200mA,SOD 7 S.A
....4 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 17 S.A
....4 0402-001098 DIODE-RECTIFIER;SK34,40V,3A,SMC,TP 1 S.A
....4 D0254 0402-001207 DIODE-SCHOTTKY;UPS5819,40V,1000mA,DO-216 1 S.A
....4 0403-001164 DIODE-ZENER;MMSZ5232B,5.32-5.88V,500MW,S 1 S.A
....4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8/6.6V,300mW,SO 11 S.N.A
....4 D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 6 S.A
....4 T0139 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 2 S.A
....4 Q101 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 6 S.A
....4 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 CEQ2 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 6 S.A
....4 Q409 0505-002386 FET-SILICON;AO3415AL,P,-20V,-4A,0.045ohm 4 S.A
....4 IC104 0801-002393 IC-CMOS LOGIC;74VHC244,BUS BUFFER,TSSOP, 1 S.A
....4 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 S.A
....4 IC106 1001-001627 IC-VIDEO SWITCH;SiI9389CTU,TQFP,100P,14x 1 S.A
....4 1006-001480 IC-LINE TRANSCEIVER;MAX3222ECAP+T,SSOP,2 1 S.A
....4 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 1 S.N.A
....4 IC112 1103-001475 IC-EEPROM;M24256-BR,256Kbit,32Kx8,SOP,8P 1 S.A
....4 1105-002049 IC-DDR2 SDRAM;EM68B16CWPA-25H,DDR2 SDRAM 1 S.A
....4 1105-002058 IC-DDR2 SDRAM;K4T1G164QE-HCF8,DDR2,1Gbit 4 S.A
....4 1105-002086 IC-DDR SDRAM;EM6A9320BIA,128MB,LFBGA,144 1 S.A
....4 T0124 1201-002992 IC-POWER AMP;STA369BWS,PSSO,36P,10.3x7.5 2 S.A
....4 T0087 1203-002519 IC-POSI.FIXED REG.;KIA7809AF,DPAK,3P,240 1 S.A
....4 IC703 1203-003121 IC-POSI.FIXED REG.;FAN1112,SOT-223,3P,6. 1 S.A
....4 IC012 1203-003544 IC-POSI.ADJUST REG.;RT9173BPS,SOP-8,8P,5 1 S.A

5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 1203-004363 IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P, 1 S.A
....4 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC012 1203-004937 IC-POSI.ADJUST REG.;MP2000DJ-ADJ-LF-Z,TS 1 S.A
....4 1203-005559 IC-BACKLIGHT DRIVER;MP3302DJ,TSOT23,5P,2 1 S.A
....4 1203-006012 IC-DC/DC CONVERTER;MP8725EL,QFN14,14P,3x 1 S.A
....4 1203-006013 IC-DC/DC CONVERTER;AOZ1031AI,SO-8,8P,4.9 3 S.A
....4 T0087 1203-006109 IC-POSI.FIXED REG.;S-1206B33-M3T1G,SOT-2 1 S.A
....4 T0087 1203-006130 IC-POSI.FIXED REG.;S-1172B25-U5T1G,SOT-8 2 S.A
....4 T0087 1203-006135 IC-POSI.FIXED REG.;AP1117D-33-GZ-13-89,T 2 S.A
....4 IC012 1203-006138 IC-POSI.ADJUST REG.;AP1117DGZ-13-89,TO-2 1 S.A
....4 1204-003100 IC-DECODER;SDP92,FCPBGAH,937P,35x35mm,PL 1 S.A
....4 IC118 1204-003101 IC-VIDEO PROCESS;SDP94,PBGA,345P,19x19mm 1 S.N.A
....4 IC118 1204-003128 IC-VIDEO PROCESS;FRC9459S,FBGA,372P,23x2 1 S.N.A
....4 1205-003733 IC-SWITCH;AP2191MPG-13,MSOP-8L-EP,8P,2.9 3 S.A
....4 1205-003735 IC-SWITCH;AP2151WG-7,SOT25,5P,2.9x1.6mm, 2 S.A
....4 1205-003834 IC-ETHERNET CONTROLLER;RTL8201E-VC-GR,QF 1 S.A
....4 1205-003840 IC-CODEC;WM8595GEFL/RS,QFN,48P,7x7x0.9mm 1 S.A
....4 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 1405-001271 VARISTOR;20Vdc,5A,1.0x0.5x0.6mm,TP 25 S.A
....4 J914 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012 1 S.C
....4 MR604 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 16 S.N.A
....4 HDR7 2007-000139 R-CHIP;220ohm,5%,1/16W,TP,1005 2 S.N.A
....4 MR306 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 7 S.N.A
....4 R319 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 67 S.N.A
....4 R102 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 AR43 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 DR39 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 5 S.N.A
....4 R509 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 3 S.N.A
....4 R111 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 11 S.N.A
....4 HDR17 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 45 S.N.A
....4 R338 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 43 S.N.A
....4 UR23 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 60 S.N.A
....4 2007-000231 R-CHIP;1.3Kohm,1%,1/10W,TP,1608 2 S.A
....4 MR39 2007-000242 R-CHIP;1.5Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 RT01 2007-000483 R-CHIP;1ohm,5%,1/8W,TP,2012 2 S.N.A
....4 2007-000606 R-CHIP;240ohm,1%,1/10W,TP,1608 2 S.A
....4 JR11 2007-000614 R-CHIP;24Kohm,1%,1/10W,TP,1608 2 S.N.A
....4 KAR28 2007-000637 R-CHIP;270Kohm,5%,1/10W,TP,1608 2 S.N.A
....4 PR2 2007-000651 R-CHIP;27Kohm,1%,1/10W,TP,1608 1 S.A
....4 2007-000736 R-CHIP;30Kohm,1%,1/10W,TP,1608 1 S.A
....4 2007-000755 R-CHIP;330Kohm,1%,1/10W,TP,1608 1 S.A
....4 R19 2007-000763 R-CHIP;330ohm,1%,1/10W,TP,1608 1 S.N.A
....4 R124 2007-000775 R-CHIP;33Kohm,5%,1/16W,TP,1005 3 S.N.A
....4 DR37 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 2 S.N.A
....4 2007-000946 R-CHIP;47ohm,1%,1/10W,TP,1608 7 S.A
....4 OTR1 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 29 S.N.A
....4 CER07 2007-001308 R-CHIP;200ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R326 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 3 S.N.A
....4 MR316 2007-002796 R-CHIP;510ohm,5%,1/16W,TP,1005 1 S.A
....4 PR24 2007-002970 R-CHIP;56ohm,5%,1/16W,TP,1005 1 S.A
....4 PR8 2007-007015 R-CHIP;13Kohm,5%,1/16W,TP,1005 2 S.A

5-6
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 R365 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 3 S.N.A
....4 2007-007132 R-CHIP;15Kohm,1%,1/16W,TP,1005 2 S.A
....4 2007-007134 R-CHIP;39Kohm,1%,1/16W,TP,1005 3 S.A
....4 2007-007137 R-CHIP;1.2Kohm,1%,1/16W,TP,1005 1 S.A
....4 2007-007138 R-CHIP;27Kohm,1%,1/16W,TP,1005 2 S.A
....4 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005 15 S.A
....4 DR4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 43 S.N.A
....4 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 3 S.N.A
....4 2007-007197 R-CHIP;3.3ohm,5%,1/16W,TP,1005 2 S.N.A
....4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 60 S.N.A
....4 2007-007309 R-CHIP;12Kohm,1%,1/16W,TP,1005 1 S.A
....4 2007-007313 R-CHIP;6.8Kohm,1%,1/16W,TP,1005 1 S.A
....4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 69 S.N.A
....4 2007-007352 R-CHIP;130Kohm,1%,1/10W,TP,1608 4 S.A
....4 2007-007469 R-CHIP;110ohm,1%,1/16W,TP,1005 1 S.N.A
....4 HDR44 2007-007470 R-CHIP;7.5Kohm,1%,1/16W,TP,1005 2 S.N.A
....4 2007-007538 R-CHIP;56Kohm,1%,1/16W,TP,1005 2 S.A
....4 2007-007617 R-CHIP;2.49Kohm,1%,1/10W,TP,1608 1 S.A
....4 2007-007698 R-CHIP;5.1Kohm,1%,1/16W,TP,1005 1 S.A
....4 2007-007724 R-CHIP;40.2ohm,1%,1/10W,TP,1608 2 S.A
....4 2007-007766 R-CHIP;2Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 2007-007947 R-CHIP;36ohm,1%,1/10W,TP,1608 1 S.A
....4 MR11 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 17 S.N.A
....4 2007-008136 R-CHIP;36Kohm,1%,1/16W,TP,1005 2 S.A
....4 2007-008263 R-CHIP;3Kohm,1%,1/16W,TP,1005 1 S.A
....4 2007-008275 R-CHIP;30Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 2007-008391 R-CHIP;6.34Kohm,1%,1/16W,TP,1005 1 S.A
....4 2007-008811 R-CHIP;1.5ohm,5%,1/16W,TP,1005 1 S.A
....4 2007-009853 R-CHIP;1.6Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 RN22 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 MR38 2011-001093 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 ZRN10 2011-001261 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2. 2 S.A
....4 DAR09 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 21 S.A
....4 DRP29 2011-001396 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, 3 S.N.A
....4 2011-001427 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,2.0 4 S.A
....4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 6 S.A
....4 2011-001497 R-NETWORK;470ohm,5%,1/16W,L,CHIP,4P,TP,1 1 S.N.A
....4 2011-001587 R-NETWORK;100ohm,5%,1/16W,L,CHIP-V,4P,TP 1 S.N.A
....4 2011-001589 R-NETWORK;0ohm,5%,1/16W,L,CHIP-V,4P,TP,1 1 S.N.A
....4 PC43 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 20 S.A
....4 DC54 2203-000278 C-CER,CHIP;.01nF,0.5pF,50V,C0G,TP,1005 3 S.A
....4 DC1 2203-000386 C-CER,CHIP;.015nF,5%,50V,C0G,TP,1005 10 S.A
....4 MC302 2203-000425 C-CER,CHIP;.018nF,5%,50V,C0G,TP,1005 2 S.A
....4 C254 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 16 S.A
....4 C507 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 1 S.A
....4 V1233 2203-000575 C-CER,CHIP;220nF,10%,25V,X7R,TP,2012 9 S.N.A
....4 AD480 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,1005 1 S.A
....4 AD480 2203-000679 C-CER,CHIP;0.027nF,5%,50V,C0G,1005 1 S.A
....4 DC25 2203-000812 C-CER,CHIP;.033nF,5%,50V,C0G,1005 4 S.A
....4 CK40B 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 3 S.N.A
....4 C132 2203-000854 C-CER,CHIP;0.039nF,5%,50V,C0G,1005 1 S.A

5-7
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 AD480 2203-000995 C-CER,CHIP;.047nF,5%,50V,C0G,TP,1005 6 S.A
....4 C101 2203-001124 C-CER,CHIP;0.68NF,10%,50V,X7R,TP,1005 4 S.A
....4 AD480 2203-002180 C-CER,CHIP;1000nF,10%,50V,X7R,3216 2 S.A
....4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 56 S.N.A
....4 AD480 2203-002494 C-CER,CHIP;470nF,10%,16V,X7R,2012 1 S.N.A
....4 C33 2203-002687 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1005 6 S.A
....4 C711 2203-002982 C-CER,CHIP;6.8nF,10%,50V,X7R,1005 2 S.A
....4 C151 2203-003039 C-CER,CHIP;0.008nF,0.25pF,50V,C0G,TP,100 1 S.A
....4 DC18 2203-005138 C-CER,CHIP;1.8nF,10%,50V,X7R,1005 6 S.A
....4 AAC1 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 44 S.N.A
....4 AD480 2203-005344 C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,- 19 S.N.A
....4 AD480 2203-005393 C-CER,CHIP;0.005nF,0.1pF,50V,NP0,TP,1005 1 S.N.A
....4 PC8 2203-005642 C-CER,CHIP;0.22nF,5%,50V,NP0,1005 3 S.N.A
....4 C236 2203-005918 C-CER,CHIP;1000nF,10%,6.3V,X7R,1608 4 S.N.A
....4 AD480 2203-005968 C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005 4 S.N.A
....4 AD480 2203-006039 C-CER,CHIP;1nF,10%,2000V,X7R,3216 2 S.A
....4 AD480 2203-006126 C-CER,CHIP;47nF,10%,16V,X7R,1005 11 S.N.A
....4 PC11 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 3 S.N.A
....4 C102 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 403 S.N.A
....4 C510 2203-006170 C-CER,CHIP;220nF,10%,16V,X7R,1608 3 S.N.A
....4 AD480 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216 9 S.A
....4 C802 2203-006348 C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608 2 S.A
....4 C125 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 61 S.C
....4 HE4 2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,2012 19 S.A
....4 HDC11 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 41 S.N.A
....4 AD480 2203-006636 C-CER,CHIP;220nF,10%,25V,X7R,1608 2 S.A
....4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,1608 8 S.N.A
....4 AD480 2203-006842 C-CER,CHIP;0.47nF,5%,50V,C0G,1005 4 S.N.A
....4 AD480 2203-006992 C-CER,CHIP;0.33nF,5%,50V,C0G,TP,1005 2 S.N.A
....4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 ( 7 S.N.A
....4 AD480 2203-007270 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608 63 S.N.A
....4 2503-001051 C-NETWORK;100nFx4,20%,16V,2012 7 S.A
....4 2601-001056 TRANS-SMD,PULSE;350UH,-,1:1,1:1,12.7X6.7 1 S.A
....4 T0052 2703-000158 INDUCTOR-SMD;1uH,10%,2012 6 S.A
....4 T0052 2703-000222 INDUCTOR-SMD;560nH,10%,2012 2 S.A
....4 VL6 2703-000398 INDUCTOR-SMD;10uH,10%,3225 10 S.A
....4 T0052 2703-001239 INDUCTOR-SMD;3.3uH,10%,1608 1 S.A
....4 T0052 2703-002044 INDUCTOR-SMD;390NH,5%,2012 3 S.A
....4 T0052 2703-002332 INDUCTOR-SMD;330nH,5%,1608 1 S.A
....4 T0052 2703-002557 INDUCTOR-SMD;270NH,5%,1608 2 S.N.A
....4 T0052 2703-003150 INDUCTOR-SMD;4.7uH,20%,5050 4 S.N.A
....4 T0052 2703-003559 INDUCTOR-SMD;4.7uH,20%,8080 3 S.N.A
....4 T0052 2703-003713 INDUCTOR-SMD;1.5uH,20%,7366 3 S.A
....4 X202 2801-004629 CRYSTAL-SMD;27MHz,20ppm,12pF,50ohm,TP 2 S.N.A
....4 X202 2801-004734 CRYSTAL-SMD;25.000000MHz,20ppm,28-AAN,12 1 S.A
....4 2804-001878 OSCILLATOR-CLOCK;49.152MHz,50ppm,10TTL/1 1 S.A
....4 F103 2901-001506 FILTER-EMI SMD;5V,0.13A,0pF,2x1x0.5mm,TP 2 S.A
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608 16 S.N.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 47 S.A
....4 3701-001685 CONNECTOR-HDMI;19P,2ROW,FEMALE,SMD-S,SN 4 S.A
....4 AC510 3708-002777 CONNECTOR-FPC/FFC/PIC;82P,0.5mm/0.75mm,S 1 S.A

5-8
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 3710-002628 SOCKET-INTERFACE;18P,1R,0.5mm,SMD-A,NI 1 S.N.A
....4 3711-005499 HEADER-BOARD TO CABLE;BOX,8P,1R,1.25mm,S 2 S.A
....4 CN906 3711-007317 CONNECTOR-HEADER;BOX,13P,1R,2.0mm,SMD-A, 1 S.A
....4 3711-007319 HEADER-BOARD TO CABLE;SMD,4P,1R,2.50mm,S 2 S.A
....4 3722-003012 JACK-USB;4P,AU+NI,BLK,SMD-A,USB A 2 S.A
....4 IC125 BN13-00031A IC ASIC;LUNA,SDP95,400,3.6,-40to+125C,CA 1 S.A
....4 IC125 BN13-00032A ICASIC;SPD96,PRSS001,144,1.62,-40 to +8 1 S.A
....4 T0077 BN41-01365A PCB MAIN;UC7W,FR-4,4,1.2,200*253,N80A 1 S.N.A
....4 BN68-02775A LABEL-SMD;ALL MODELS,8.5,21,COMMON 2 S.N.A
....4 M0018 BN97-03975A ASSY MICOM;T-VALAUSC-1004.0,2010.02.16 1 S.N.A
.....5 1107-001868 IC-NAND FLASH;KFG8GH6U4M-AIB6,1GByte,512 1 S.A
.....5 BN68-02303A LABEL-IC;9.5MMX8MM,ART PAPER 1 S.N.A
....4 T0010 BP27-00002A COIL CHOKE;SLF6028T-220MR77,22uF,20%,0.1 1 S.A
....4 2007-001285 R-CHIP;5.6ohm,5%,1/16W,TP,1005 32 S.A
....4 AD480 2203-007138 C-CER,CHIP;2200nF,10%,50V,X7R,TP,3216 2 S.A
....4 M0018 BN97-04158A ASSY MICOM;T-VALALD-0003,2010.02.02 1 S.N.A
.....5 IC112 1103-001475 IC-EEPROM;M24256-BR,256Kbit,32Kx8,SOP,8P 1 S.A
....4 M0018 BN97-04159A ASSY MICOM;T-VALCPLD-0008,2010.02.02 1 S.N.A
.....5 1301-001969 IC-CPLD;EPM240T100C4N,TQFP,100P,16x16mm, 1 S.A
....4 M0018 BN97-04160A ASSY MICOM;T-VALAFRCS-20128,2010.02.16 1 S.N.A
.....5 IC112 1103-001406 IC-EEPROM;AT24C512BN-SH25-T,512Kbit,64Kx 1 S.A
....4 0202-001767 SOLDER-CREAM;LST-5710,D20~38,Sn-57Bi-1Ag 1 S.N.A
....4 CN906 3711-007346 CONNECTOR-HEADER;BOX,18P,1R,0.6mm,SMD-A, 1 S.A
....4 1203-005538 IC-DC/DC CONVERTER;AOZ1021HAIL,SOP,8P,4. 2 S.A
....4 1205-003201 IC-BUS SWITCH;TC7WB125FK,SSOP,8P,2x2.3mm 1 S.A
....4 DC2 2203-000330 C-CER,CHIP;.012nF,5%,50V,C0G,TP,1005 4 S.A
....4 T0052 2703-000125 INDUCTOR-SMD;10uH,10%,2012 1 S.A
....4 T0052 2703-003790 INDUCTOR-SMD;4.7uH,20%,8080 2 S.A
....4 X202 2801-003948 CRYSTAL-SMD;12MHz,30ppm,28-AAN,12pF,60oh 1 S.A
....4 X202 2801-004774 CRYSTAL-SMD;24MHz,30ppm,14pF,30ohm,TP 2 S.A
....4 SD3 0407-000114 DIODE-SWITCHING;KDS184,80V,100mA,SOT-23, 1 S.N.A
....4 JA330 3722-002844 JACK-PHONE;1/7P,NI,LAUREL-GREEN,ANGLE 1 S.A
....4 JA330 3722-002845 JACK-PHONE;1/7P,NI,YELLOW,ANGLE 2 S.A
....4 JA330 3722-002846 JACK-PHONE;1/6,NI,BLACK,ANGLE 4 S.N.A
....4 BN97-04404A ASSY MICOM;T-VALAUSS-7003,2010.02.16 1 S.N.A
.....5 IC520 0903-001651 IC-MICROCONTROLLER;61P802-RG480WT,LQFP,4 1 S.A
...3 BA001 BN61-06211A BRACKET-AV;C8K(UO),PCM,T0.45,BKN-P824 1 S.N.A
...3 T0066 BN62-00071A HEAT SINK-ES;22*22*2.6,Ceramic,T2.6,TAPE 4 S.N.A
...3 T0066 BN62-00072A HEAT SINK-ES;40*40*2.6,Ceramic,T2.6,TAPE 1 S.N.A
...3 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 S.N.A
...3 T0010 BN61-06540A HOLDER-AV;UC7000 40,46,55inch UO,HIPS,BL 1 S.N.A
0.1 BN91-04705A ASSY SHIELD;UN46C7000WFXZA 1 S.N.A
..2 T0081 6001-002283 SCREW-MACHINE;BH,+,M3,L5,ZPC(WHT),SWRCH1 12 S.N.A
..2 M0524 BN39-01291A CONNECT WIRE;UE40B7700,Flat Connector As 1 S.A
..2 P001A BN44-00375A SMPS-LED TV PD BD;PD46CF2_ZSM,PSLF172C01 1 S.A
..2 M0230 BN96-12723Q ASSY CABLE P-FPCB LVDS CABLE;LED240Hz-46 1 S.A
..2 T0066 BN96-12845D ASSY POWER CORD;125/7A, UL/CSA,LP-11WL,V 1 S.A
..2 T0175 BN96-12943B ASSY SPEAKER P;4ohm,4pin,20W,R:630,Enclo 1 S.A
..2 CCMM1 BN73-00211B SILICON/RUBBER;UN46B9000XFXZA,SILICON+PO 3 S.N.A
..2 BN73-00271A SILICON/RUBBER-GAPPAD;UE46B7700,SILICON+ 2 S.N.A
..2 T0081 6001-002610 SCREW-MACHINE;BH,+,M4,L6,ZPC(BLK),SWRCH1 12 S.A

5-9
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
..2 SCREW 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 20 S.A
..2 CIS1 0203-001586 TAPE-FILAMENT;#893,0.15,25,55 0.64 S.N.A
..2 T0910 BN96-13130B ASSY BRACKET P-STAND LINK;UC7000 46/55,E 1 S.N.A
...3 BN61-02932G BRACKET-STOPPER NUT;LED TV,M4,D6,L6.5,BR 5 S.N.A
...3 M0115 BN61-06212A BRACKET-STAND LINK;46/55 C8K,HGI,T3.0 1 S.N.A
...3 BN63-07037A SHEET-INSULATOR LINK A;UC 7K 8K 46/55inc 1 S.N.A
...3 BN63-07038A SHEET-INSULATOR LINK B;UC 7K 8K 46/55inc 1 S.N.A
..2 BN68-02884A LABEL-HOLDER SHEET;LED,PET,T0.05 1 S.N.A
0.1 BN91-05220A ASSY LCD-AMLCD;BN07-00863A 1 S.N.A
..2 M0215 BN07-00863A LCD-PANEL;LTF460HQ02,SSEZQX,8bit,46,16.7 1 S.A
...3 M0590 BN81-04356A A/S-T CON LTF460HQ02;LTF460HQ02 1 S.A
0.1 BN92-05542A ASSY LABEL;UN46C7000WFXZA 1 S.N.A
..2 T0527 AA68-03752B LABEL-STICKER;WW,ALL,Art Paper(90g),25,3 1 S.N.A
..2 BN68-02702A LABEL-LED-POP;Highlight Sticker Color(70 1 S.N.A
..2 T0527 BP68-00052B LABEL-00,RATING;CCTV,TETRON PAPER,T0.05, 1 S.N.A
0.1 M0045 BN92-05543A ASSY ACCESSORY;UN46C7000WFXZA 1 S.N.A
..2 BN96-10150A ASSYACCESSORY-MANUAL;UN46,55C7000WFXZA 1 S.A
...3 T0524 6902-000018 BAG PE;LDPE,T0.1,W280,L400,CLEAR,8,2,20. 1 S.N.A
...3 AA68-03242L MANUAL FLYER-07,SAFETY GUIDE;comm,Samsun 1 S.N.A
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 S.N.A
...3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 S.N.A
...3 BN68-02021A MANUAL FLYER-01,WARRANTY CARD;comm,Samsu 1 S.N.A
...3 T0059 BN68-02178A MANUAL FLYER-CARD;COMM,SAMSUNG,eng/spa/c 1 S.N.A
...3 BN68-02186A MANUAL FLYER-TOC GUIDE;COMM,SAMSUNG,10 L 1 S.N.A
...3 T0511 BN68-02627A MANUAL USERS-01;U7000,SAMSUNG,Eng/Spa/Fr 1 S.N.A
...3 BN68-02630A MANUAL FLYER-01,QSG;U7000,SAMSUNG,Eng,N. 1 S.N.A
...3 BN68-02630B MANUAL FLYER-01,QSG;U7000,SAMSUNG,Fra,N. 1 S.N.A
...3 BN96-10788B ASSYACCESSORY-PREVENT;B6000,nylon66 + W 1 S.A
...3 BP68-00263E MANUAL FLYER-WARRANTY CARD;comm,Samsung, 1 S.N.A
...3 BP68-00515B MANUAL FLYER-REGISTRATION CARD;comm,Sams 1 S.N.A
...3 6801-001760 CARD INFORMATION;MEXICO,SEM/ZX,Spanish,W 1 S.N.A
..2 M0045 BN96-10150B ASSYACCESSORY-CABLE;UN40,46,55C7000WFXZ 1 S.A
...3 T0685 4301-000103 BATTERY-ALKALINE;1.5V,750mAH,LR03,10.5x4 2 S.N.A
...3 T0524 6902-001107 BAG PE;LDPE,T0.05,W450,L400,TRP,0,3Separ 1 S.N.A
...3 T0074 BN59-01055A REMOCON;TM1080,SAMSUNG,20PIN SINGLE,49KE 1 S.A
...3 BN61-05596A HOLDER-WIRE CABLE;LED TV,LDPE,T0.8,L150, 1 S.N.A
...3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 S.N.A
...3 M0114 BN39-01154H CBF SIGNAL;UE40B7000WWXXC,RCA 3PIN,30AWG 1 S.A
...3 BN96-10276B ASSY HOLDER P-RING;09 LEDTVALL MODEL,AB 1 S.A
....4 6902-000683 BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,4-PE M 1 S.N.A
....4 AH365 BN61-05280A HOLDER-RING;LB7000 46inch,ABS, HB,gray 4 S.N.A
...3 BN96-10810A ASSY HOLDER P;09 LEDTV MODEL,NYRON 1 S.A
....4 BAG 6902-000031 BAG ZIPPER;LDPE,T0.05,W80,L160,TRP,0,0,4 1 S.N.A
....4 M0114 BN61-05373A HOLDER-WIRE;LB7000 46,NYRON 3 S.N.A
....4 BN61-05491A HOLDER-WIRE STAND;UB7000 46inch,NYRON 1 S.N.A
...3 BN96-12031D ASSY ACCESSORY-SCREW;09 LEDTV(40/46/55), 1 S.N.A
....4 M0081 6003-000133 SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW 1 S.A
....4 6902-000336 BAG ZIPPER;LDPE,T0.05,W70,L80,TRP,0.500g 1 S.N.A
....4 BN68-02215K MANUAL FLYER-COVER-BOTTOM GUIDE;COMM,SAM 1 S.N.A
...3 BN39-01154K CBF SIGNAL-D SUB GENDER;UE40C7700WSXZG,1 1 S.A
...3 BN39-01154L CBF SIGNAL-LAN GENDER;UE40C7700WSXZG,18P 1 S.A

5-10
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...3 BN39-01154M CBF SIGNAL-OPTICAL GENDER;UE40C7700WSXZG 1 S.A
...3 M0114 BN39-01154C CBF SIGNAL;Chelsea Slim, STEREO Plug to 1 S.A
...3 M0114 BN39-01154G CBF SIGNAL;UN40B7000WMXZD,1P/1P*2,30AWG, 1 S.A
...3 BN39-01154P CBF SIGNAL-RF NTSC;UE40C7700,RF NTSC,30A 1 S.A
...3 RB01 BN63-06543B COVER-BOTTOM;UC7000 40,HIPS,V0,BK0020 1 S.A
..2 T0214 0203-001602 TAPE-OPP MASKING;#232,0.14,15,50000,YEL 0.06 S.N.A
..2 AH68-01929E LABEL-SERIAL;MM-X7,XAX,ART PAPER,W20,L10 1 S.N.A
..2 BN68-00797G MANUAL FLYER-01,WARRANTY CARD;comm,Samsu 1 S.N.A
0.1 BN92-05726A ASSY BOX;UC7000 46 1 S.N.A
..2 BH68-00664A LABEL BOX-00;ALL MODEL,A/P 90G,220,90,WH 1 S.N.A
..2 BN69-04704B BOX-SET;46UC7000-FS,CB,A-01,DW3,,W1345,D 1 S.N.A
0.1 BN92-05729A ASSY P/MATERIAL;UC7000 46 1 S.N.A
..2 T0214 0203-001595 TAPE-OPP MASKING;OPP-2,0.075,75,800M,CLR 3 S.N.A
..2 T0524 6902-000959 BAG PE;NITRON,T0.015/T0.5,W1400,L900,TRP 1 S.N.A
..2 M040 6922-000013 BAND PP;PP,W18,L2300m,TRP,21000g 1.14 S.N.A
..2 BH69-00418A BAG WRAPPING;LDPE,762,1828M,SAMEX FACTOR 2.15 S.N.A
..2 BH69-40321C PACKING INNER-00,PAD;COMM,CB-SW4/YEL,203 1 S.N.A
..2 T0246 BN69-04508A CUSHION-SET;46UC7000-FS,EPS,15.4g/l 1 S.N.A
..2 BN68-02422B LABEL-WARNING SHIPPING;ALL MODEL,A/P 100 1 S.N.A

5-1
5. Exploded View & Part List
5. Exploded View & Part List
5-1. UN55C7000WF Exploded View
T0003
M0215
M0014
T0910
M0013
M0524
T0176
BA001
M0027
T0175
T0175

5-2
5. Exploded View & Part List
5-1-1. UN55C7000WF Parts List
Location No. Code No. Description & Specication Q’ty S.A/S.N.A Remark
T0003 BN96-13120A ASSY COVER P-FRONT;UC7000 55,UO,PMMA+PMM 1 S.A
T0175 BN96-12943C ASSY SPEAKER P;4ohm,4pin,25W,R:740,Enclo 1 S.A
M0215 BN07-00864A LCD-PANEL;LTF550HQ02,SSTZQX,8bit,55,16.7 1 S.A
BA001 BN61-06211A BRACKET-AV;C8K(UO),PCM,T0.45,BKN-P824 1 S.N.A
T0910 BN96-13130B ASSY BRACKET P-STAND LINK;UC7000 46/55,E 1 S.N.A
T0176 BN96-13407A ASSY SPEAKER P;8ohm,4pin,15W,L: 700, R:1 1 S.A
M0014 BN94-02757C ASSY PCB MAIN;UN55C7000WFXZA 1 S.A
M0013 BN96-13127A ASSY COVER P-REAR;55UC7000,PCM,T0.45,BKN 1 S.A
M0524 BN96-13131A ASSY COVER P-GUIDE STAND;UC7000,PC+ABS G 1 S.A
M0027 BN96-13133A ASSY STAND P-BASE;UC7000 46/55,FOUR-LEG, 1 S.A

5-3
5. Exploded View & Part List
5-2. UN55C7000WF Parts List
Service Bom (SA: SERVICEAVAILABLE, SNA: SERVICE NOTAVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UN55C7000WFXZA
0.1 BN90-02589A ASSY COVER FRONT;UC7000 55 1 S.N.A
..2 T0527 AA68-03539A LABEL BAR CODE;65X40mm,ART PAPER 1 S.N.A
..2 T0003 BN96-13120A ASSY COVER P-FRONT;UC7000 55,UO,PMMA+PMM 1 S.A
...3 AB326 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 14 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.04,900mm,20 1.4 S.N.A
...3 CCM1 BN63-05199B COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL 4.5 S.N.A
...3 M0112 BN63-06589A COVER-FRONT;UC7000 55,UO,PMMA+PMMA/ABS,H 1 S.N.A
...3 AD070 BN64-01285A DECORATION-BOTTOM;55UC7000,PC,CLEAR,Sn C 1 S.N.A
...3 T0852 BN96-13124A ASSY COVER P-MIDDLE;55UC7000,ABS,HB,BLK 1 S.N.A
....4 BN61-05915B BOSS-TAPE;LB650 65",3M #4711,T1.1,W6.0mm 4.4 S.N.A
....4 BN61-06213A BRACKET-STOPPER BOSS;C8K,SECC+SK5,T1.2 11 S.N.A
....4 BN61-06215A BRACKET-STOPPER PANEL;C8K,SK5,0.5T 2 S.N.A
....4 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.04,900mm,20 1.4 S.N.A
....4 BN63-06598A COVER-FRONT MIDDLE;UC7000 55inch,ABS,HB, 1 S.N.A
....4 BN61-06539A BOSS-TAPE;UC8000,PE,T0.16,W5,Transparent 0.15 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.9 S.N.A
...3 BN96-13136A ASSY DECORATION P-WIER;55UC7000,STS304 T 1 S.N.A
....4 BN61-06210A BRACKET-WIRE,A;UC7000 40inch,STAINLESS-S 8 S.N.A
....4 BN61-06283A BRACKET-WIRE,B;UC7000 40inch,STAINLESS-S 2 S.N.A
....4 BN64-01278A DECORATION-WIRE;55UC7000,STS304 T4.0 1 S.N.A
...3 T0176 BN96-13407A ASSY SPEAKER P;8ohm,4pin,15W,L: 700, R:1 1 S.A
...3 M0125 BN96-13847C ASSY BOARD P-TOUCH FUNCTION&POWER IR;UN5 1 S.A
...3 BN60-00162V SPACER-FOAM;FOAM,50000mm,Dark Gray,0.5T, 3.78 S.N.A
...3 CIS1 0203-001598 TAPE-FILAMENT;#8915,0.15,12,55000,CLR 0.06 S.N.A
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
...3 BN61-05915B BOSS-TAPE;LB650 65",3M #4711,T1.1,W6.0mm 1.1 S.N.A
...3 BN61-06539A BOSS-TAPE;UC8000,PE,T0.16,W5,Transparent 0.15 S.N.A
...3 T0382 BP61-00509C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W20.0mm 0.28 S.N.A
0.1 M0002 BN90-02592A ASSY COVER REAR;UC7000 55 1 S.N.A
..2 HC001 BN61-06246A HOLDER-CORD;UC7000 40inch,ABS,BLK 1 S.N.A
..2 M0013 BN96-13127A ASSY COVER P-REAR;55UC7000,PCM,T0.45,BKN 1 S.A
...3 T0069 BN60-00123A SPACER-FELT;UB7000,FELT,L470,BLK,T0.35,W 2 S.N.A
...3 M0006 BN63-06558A COVER-REAR;UC7000 55inch,PCM,T0.45,BKN-P 1 S.N.A
...3 BN68-02543F LABEL-TERMINAL BOTTOM;UC7000/8000,UO,PET 1 S.N.A
...3 BN68-02544H LABEL-TERMINAL SIDE;UC7000/8000,UO,PET,T 1 S.N.A
...3 BN60-00162V SPACER-FOAM;FOAM,50000mm,Dark Gray,0.5T, 0.41 S.N.A
...3 BN60-00182A SPACER-FOAM;FOAM,30000L,BLK,1.0T,20W 2 S.N.A
...3 BN60-00183A SPACER-FOAM;FOAM,440L,BLK,2.0T,15W 1 S.N.A
...3 BN96-13138A ASSY MISC P-INSULATOR;UC8000 55,PC,T0.43 1 S.N.A
0.1 M0216 BN90-02595A ASSY STAND;UC7000 55 1 S.N.A
..2 M0524 BN96-13131A ASSY COVER P-GUIDE STAND;UC7000,PC+ABS G 1 S.A
...3 T0524 6902-001063 BAG PE;LDPE,T0.05,W180,L350,TRP,RECYCLE 1 S.N.A
...3 T0920 BN61-06221A GUIDE-STAND;UC6500 40inch,PC,G/F 20%,V2, 1 S.N.A
...3 BN68-02368C LABEL-ACCESSORY;A/P100G,T0.08,25mmX50mm, 1 S.N.A
...3 BN96-12031N ASSY ACCESSORY-SCREW;10 LEDTV(40/46/55), 1 S.N.A
....4 M0081 6003-000133 SCREW-TAPTYPE;BH,+,-,S,M4,L8,ZPC(BLK),SW 9 S.A
